PRIME Series ASUS Prime is the next evolution of the ASUS motherboard, born of a pedigree that stretches back to 1989. Our team of world-class engineers are passionate about empowering everyone to enjoy the benefits of customization & tuning, & the driving force behind the development of Prime is to make advanced enthusiast controls easily accessible — maximizing performance, stability & compatibility for the very best DIY PC experiences. Simply stated: it’s time for Prime. PRIME X370-PRO supports 5 Way Optimization & NVIDIA SLI to present you the huge performance experience. Lighting fast storage speed is elevated by NVME 32 Gb/s M.2, 10 Gb/s USB (Universal Serial Bus) 3.1. ASUS Safe Slot for enhanced PCIe retention & shearing resistance. While AURA RGB lighting & synchronization brighten up your PC built! superb performance &8231;5-Way Optimization: One click overclock & cooling, done! &8231;FAN Xpert 4: Advanced fan & liquid controls for ultimate cooling & quietness. &8231; Ultra-fast transfer speed: M.2 onboard speed up to 32 Gbps. &8231; Ultimate-Speed 10 Gbps With USB (Universal Serial Bus) 3.1 Onboard: Enjoy the 10 Gbit/s speed! Seamless Entertainment &8231;AURA SYNC: Full for onboard RGB LED illumination & perfect synchronization with Aura gear. &8231; Refined Audio: Realtek S1220A codec provides pristine & powerful audio quality. &8231; Turbo LAN: More throughput, less CPU usage & great gaming experiences! Proven Quality ASUS Safe Slot: Enhance PCIe retention & shearing resistance. 5X Protection III &8231; Safe Slot Core: Fortified PCIe Slot prevents damage &8231;LANGuard: Protects against LAN surges, lightning strikes & static-electricity discharges! &8231; Overvoltage Protection: World-class circuit-protecting power design &8231;DIGI+ VRM: Precision control for stable power! &8231; Stainless-Steel Back I/O: 3X corrosion-resistance for greater durability!

Specification CPU AM4 socket for AMD Ryzen™/7th Generation A-series/ Athlon™ Processors Supports CPU up to 8 cores* * Due to CPU limitation, CPU cores supported varies by processor. ** Refer to www.asus.com for the AMD CPU support list. Chipset AMD X370 Chipset Memory AMD Ryzen™ Processors 4 x DIMM, max. 64GB, DDR4 2666/2400/2133 MHz, ECC & non-ECC, un-buffered memory AMD 7th Generation A-series/ Athlon™ Processors 4 x DIMM, max. 64GB, DDR4 2400/2133 MHz, non-ECC, un-buffered memory Dual channel memory architecture * Hyper DIMM support is subject to the physical characteristics of individual CPUs. ** Refer to www.asus.com for the Memory QVL (Qualified Vendors List). Expansion Slots AMD Ryzen™ Processors 2 x PCI Express 3.0/2.0 x 16 slots (single at x 16 or dual at x 8/x 8 mode) AMD 7th Generation A-series/ Athlon™ Processors 1 x PCI Express 3.0/2.0 x 16 slots (single at x 8 ) AMD X370 chipset 1 x PCI Express 2.0 x 16 slot (max. at x 4 mode)* 3 x PCI Express 2.0 x 1 slots *PCIe X16_3 slot shares bandwidth with PCIe X1_1 & PCIe X1_3. VGA Integrated AMD Radeon™ R Series Graphics in the 7th Generation A-Series APU Multi-VGA output support: Display Port/HDMI ports Supports Display Port 1.2 with max. resolution 4096 x 2160@60 Hz Supports HDMI 1.4b with max. resolution 4096 x 2160 @24 Hz / 2560 x 1600 @60 Hz Maximum shared memory of 2048MB Multi-GPU support AMD Ryzen™ Processors Supports NVIDIA 2-Way/ Quad-GPU SLI™ Technology Supports AMD 3-Way/ Quad-GPU Cross Fire X™ Technology AMD 7th Generation A-series/ Athlon™ Processors Supports AMD 2-Way/ Quad-GPU Cross Fire X™ Technology Storage AMD Ryzen™ Processors
- 1 x M.2 Socket 3 with M Key, type 2242/2260/2280/22110 (PCIE 3.0 x 4 & SATA modes) storage devices support AMD 7th Generation A-series/ Athlon™ Processors
- 1 x M.2 Socket 3 with M Key, type 2242/2260/2280/22110 (PCIE 3.0 x 2 & SATA modes) storage devices support AMD X370 chipset with RAID 0, 1, 10 support
- 8 x SATA 6.0 Gb/s ports (gray) LAN Intel I211AT Gigabit LAN Audio Realtek S1220A 8-channel high definition audio CODEC
- Audio Shielding: Ensures precision analog/digital separation & greatly reduces multi-lateral interference
- Dedicated audio PCB layers: Separate layers for left & right channels to guard the quality of the sensitive audio signals
- Premium Japanese audio capacitors: Provide warm, natural & immersive sound with exceptional clarity & fidelity.
- Supports jack-detection, multi-streaming, front panel jack-retasking
- High quality 120d B SNR stereo playback output (Line-out@back) & 113d B SNR input (Line-in) support
- Optical S/PDIF out port at back I/O USB (Universal Serial Bus) AMD Ryzen™/7th Generation A-series/ Athlon™ Processors
- 4 x USB (Universal Serial Bus) 3.0/2.0 ports (4 ports at back panel[blue]) AMD X370 Chipset
- 1 x USB (Universal Serial Bus) 3.1/3.0/2.0 front panel connector
- 4 x USB (Universal Serial Bus) 3.0/2.0 ports (2 ports at mid-board; 2 ports at back panel, Type-A[blue] & Type-C)
- 4 x USB (Universal Serial Bus) 2.0/1.1 ports at mid-board ASMedia USB (Universal Serial Bus) 3.1 controllers
- 2 x USB (Universal Serial Bus) 3.1/3.0/2.0 ports (2 ports at back panel[teal blue]) ASUS Exclusive Features Performance Optimization 5-Way Optimization - Whole system optimization with a single click! Perfectly consolidates TPU, EPU, DIGI+ VRM, Fan Xpert 4, & Turbo App DIGI+ VRM - 6+4 Phase digital power design TPU - Auto Tuning EPU - EPU Fan Xpert 4 featuring Fan Auto Tuning function & multiple thermistors selection for optimized system cooling control Turbo App featuring system performance tuning, network priority, & audio scene configuration for selected applications. Gaming Scenario AURA
- Bright up your Build Audio Features
- Audio that roars on the battlefield EZ DIY UEFI BIOS EZ Mode
- featuring friendly graphics user interface
- ASUS Crash Free BIOS 3
- ASUS EZ Flash 3 Q-Design
- ASUS Q-Shield
- ASUS Q-Slot
- ASUS Q-DIMM
- ASUS Q-Connector ASUS Special Features Special

Features: ASUS Safe Slot
- Protect your graphics card Investment ASUS 5X Protection III
- ASUS Safe Slot Core
- Fortified PCIe with solid soldering
- ASUS LANGuard
- Protects against LAN surges, lightning strikes & static-electricity discharges!
- ASUS Overvoltage Protection
- World-class circuit-protecting power design
- ASUS DIGI+ VRM
- 6+4 Phase digital power design
- ASUS DRAM Overcurrent Protection: Enhanced DRAM overcurrent protection
- ASUS Stainless-Steel Back I/O: 3X corrosion-resistance for greater durability!
- ASUS ESD Guards
- Enhanced ESD protection
- AI Suite 3
- Ai Charger ASUS Quiet Thermal Solution Quiet Thermal Design:
- ASUS Fan Xpert 4
- Stylish Fanless Design: Chipset Heat-sink & MOS Heat-sink solution ASUS Exclusive Overclocking Features Precision Tweaker 2:
- v VDDCR CPU: Adjustable CPU voltage at 0.00625V increment
- v VDDCR SOC: Adjustable CPU/NB voltage at 0.00625V increment
- v DRAM Bus: Adjustable DRAM voltage at 0.005V increment Overclocking Protection:
- ASUS C.P.R. (CPU Parameter Recall) Back Panel I/O Ports 1 x PS/2 Keyboard/ Mouse Combo port 1 x Display Port 1 x HDMI port 1 x Intel LAN (RJ45) port 2 x USB (Universal Serial Bus) 3.1/3.0/2.0 ports (teal blue, Type-A) 1 x USB (Universal Serial Bus) 3.0/2.0 ports (Type-C) 5 x USB (Universal Serial Bus) 3.0/2.0 ports (blue, Type-A) 1 x Optical S/PDIF out 5 x Audio Jacks (Line in, Front Speaker Out, Mic in, Center/ Subwoofer, Rear Speaker Out) Internal I/O Connectors 1 x USB (Universal Serial Bus) 3.1/3.0/2.0 front panel connector 1 x USB (Universal Serial Bus) 3.0/2.0 connector support additional 2 USB (Universal Serial Bus) ports 2 x USB (Universal Serial Bus) 2.0/1/1 connectors support additional 4 USB (Universal Serial Bus) ports 1 x M.2 Socket 3 for M Key, type 2242/2260/2280/22110 devices support, (both SATA & PCIE mode) 8 x SATA 6.0 Gb/s connectors (gray) 1 x CPU Fan header (4-pin) for both 3-pin (DC mode) & 4-pin (PWM mode) CPU coolers control with auto detection support 1 x CPU OPT Fan header (4-pin) 1 x AIO Pump header (4-pin) 1 x W_PUMP+ header (4-pin) 2 x Chassis Fan connectors (4-pin) for both 3-pin (DC mode) & 4-pin (PWM mode) coolers control with auto detection support 1 x Aura RGB header 1 x Front panel audio connector (AAFP) 1 x TPM connector 1 x COM connector 1 x 24-pin EATX Power connector 1 x 8-pin EATX 12V Power connector 1 x System Panel 1 x Clear CMOS header BIOS 128 Mb Flash ROM, UEFI AMI BIOS, Pn P, DMI3.0, Wf M2.0, SM BIOS 3.0, ACPI 6.1, Multi-language BIOS, ASUS EZ Flash 3, Crash Free BIOS 3, F11 EZ Tuning Wizard, F6 Qfan Control, F3 My Favorites, Last Modified log, F12 Print Screen, and ASUS DRAM SPD (Serial Presence Detect) memory information Manageability Wf M 2.0, DMI 3.0, WOL by PME, PXE Accessories 4 x Serial ATA 6.0 Gb/s cables 1 x SLI HB BRIDGE (2-WAY-M) 1 x ASUS Q-Shield 1 x Q-connector 1 x Support DVD 1 x M.2 screw package 1 x users manual Support DVD Drivers ASUS Utilities EZ Update Anti-virus software (OEM version) Operating System Support Windows 10 64-bit Form Factor ATX Form Factor, 12”x 9.6” (30.5cm x 24.4cm)















































...

Asus AMD Radeon R7 250 1GB GDDR5 VGA DVI HDMI PCI-E Graphics Card Graphics Engine AMD Radeon R7 250 Bus Standard PCI Express 3.0 Video Memory GDDR5 1024MB Engine Clock GPU Boost Clock: 1050 MHz GPU Base Clock: 1000 MHz Memory Clock 1150 MHz (4600 MHz GDDR5 ) Memory Interface 128-bit Resolution DVI Max Resolution: 1920x 1200 Digital Max Resolution:2560x 1600 Interface D-Sub Output: Yes x 1 DVI Output: Yes x 1 (DVI-D) HDMI Output: Yes x 1 HDCP Support: Yes Power Consumption up to 75 Wno additional PCIe power required Software ASUS GPU Tweak & Driver ASUS Features Super Alloy Power

Dimensions 16 x 11.1 x 3.4 Centimeter

...

Asus AMD Radeon R9 NANO 4GB HDMI Display Port PCI-E Graphics Card Specifications Graphics Engine AMD Radeon R9 NANO Bus Standard PCI Express 3.0 Open GL Open GL 4.5 Video Memory 4GB High Bandwidth Memory (HBM) Engine Clock 1000 MHz Memory Clock 500 MHz Memory Interface 4096-bit Resolution Digital Max Resolution:4096x 2160 Interface HDMI Output: Yes x 1 (Native) Display Port: Yes x 3 (Native) (Regular DP) HDCP Support: Yes Software ASUS GPU Tweak II & Driver

Dimensions 6 " x 4.5 " x 1.5 " Inch 15.24 x 11.5 x 3.9 Centimeter

...

Asus AMD Radeon R9270X-DC2-2GD5 2GB GDDR5 VGA DVI HDMI Display Port PCI-E Graphics Card Graphics Engine AMD Radeon R9 270X Bus Standard PCI Express 3.0 Video Memory GDDR5 2GB Engine Clock GPU Boost Clock: 1050 MHz GPU Base Clock: 1000 MHz Memory Clock 5600 MHz (1400 MHz GDDR5 ) Memory Interface 256-bit Resolution D-Sub Max Resolution: 2048x 1536 DVI Max Resolution: 2560x 1600 Interface D-Sub Output: Yes x 1 (via DVI to D-Sub adaptor x 1) DVI Output: Yes x 1 (DVI-D), Yes x 1 (DVI-I) HDMI Output: Yes x 1 Display Port: Yes x 1 (Regular DP) HDCP Support: Yes Software ASUS Utilities & Driver ASUS Features Direct CU Series Super Alloy Power

Dimensions 10.7 " x 5.24 " x 1.578 " Inch

...

Asus AMD Radeon RX 460 4GB GDDR5 DVI-D HDMI Display Port PCI-E Graphics card OUTSHINE THE COMPETITION ROG Strix RX 460 gaming graphics cards are packed with exclusive ASUS technologies, including Direct CU II Technology with Patented Wing-Blade Fans for up to 30% cooler & 3X quieter performance, & Industry-only Auto-Extreme Technology for premium quality & the best reliability. Aura RGB Lighting enables a gaming system personalization. ROG Strix RX 460 also has GPU Tweak II with XSplit Gamecaster that provides intuitive performance tweaking & instant gameplay streaming. Specifications Graphics Engine AMD Radeon RX 460 Bus Standard PCI Express 3.0 Open GL Open GL4.5 Video Memory GDDR5 4GB Engine Clock 1256 MHz (OC Mode) 1236 MHz (Gaming Mode) * Retail goods are with default Gaming Mode, OC Mode can be adjusted with one click on GPU Tweak II Memory Clock 7000 MHz Memory Interface 128-bit Resolution Digital Max Resolution:5120x 2880 Interface DVI Output: Yes x 1 (Native) (DVI-D) HDMI Output: Yes x 1 (Native) (HDMI 2.0) Display Port: Yes x 1 (Native) (Regular DP) HDCP Support: Yes Power Connectors 1 x 6-pin Software ASUS GPU Tweak II & Drive Aura (Graphics Card) Utility

Dimensions 7.6 " x 4.7 " x 1.4 " Inch 19.4 x 12 x 3.5 Centimeter

...

Features • HDR Ready. • 3rd Gen Fin FET 14. • Radeon Free Sync 2 Technology. • Re Live Capture & Stream. • Direct X 12 Optimized. • 4th Generation GCN. • AMD Liquid VR Technology. • AMD Virtual Super Resolution (VSR). • AMD Cross Fire Technology. • Open CL Support. Product Overview IP5X-Certified Dust Resistance ASUS fan design is certified under the International Protection Marking (IP Code) as IP5X dust resistant for enhanced reliability & optimal fan performance, even under severe conditions. AUTO-EXTREME Technology Industry-only 100% automated production process ensures premium quality. Super Alloy Power II Premium alloys in power delivery components reduce heat allowing cards to run 15% & last 2.5 times longer than reference. GPU Tweak II with XSplit Gamecaster Intuitive performance tweaking & instant gameplay streaming. Radeon RX 500 Series Everyone fights for something & our global community is no different. Equip yourself with the latest Radeon RX 500 series graphics card & get the gaming experience & performance you deserve. Prepare yourself for the future of gaming. Built on the incredible Polaris architecture. • High performance gaming & total hardware control, through an elegant Radeon software interface. • Share your memorable moments & clutch victories with Radeon Re Live. • Use Radeon Chill for higher clock speeds with less power. • Free Sync™ 2 & Direct X 12 support for the smoothest gaming experiences. • Built to last with HDMI 2.0 & Display Port 1.4 HBR3/1.4 HDR connections. Specifications Graphics Engine AMD Radeon RX 550 Open GL Open GL4.5 Video Memory GDDR5 4GB Engine Clock 1183 MHz Stream Processors 512 Memory Clock 7000 MHz Memory Interface 128-bit Resolution Digital Max Resolution:5120x 2880 Interface DVI Output: Yes x 1 (Native) (DVI-D) HDMI Output: Yes x 1 (Native) (HDMI 2.0) Display Port: Yes x 1 (Native) (Regular DP) HDCP Support: Yes Software ASUS GPU Tweak II & Driver

Dimensions 7.2 " x 4.4 " x 1.7 " Inch 18.2 x 11.2 x 4.3 Centimeter Note &65294; To have the best cooling performance, ASUS RX550-4G extends the fansink to 2 slots. Please double check you Chassis & Motherboard dimension prior to purchase to make sure it fits in your system!

...

Game codes will be emailed out within 5 working days of invoice date Redemption/ Terms & conditions available ‘here’ One application per customer Features 1380 MHz Boost Clock in OC mode for outstanding performance & gaming experience. Patented Wing-Blade 0d B Fans for max air flow with 105% more air pressure. Play in silence with 0d B fans. IP5X-Certified Fans are dust resistant for longer fan lifespan. Industry Only Auto-Extreme Technology with Super Alloy Power II delivers premium quality & best reliability. VR-friendly HDMI Ports for immersive virtual reality experiences. GPU Tweak II with Xsplit Gamecaster provides intuitive performance tweaking & instant gameplay streaming. Product Overview The Sweet Spot Performance ASUS Dual series RX 580 comes equipped with Patented Wing-Blade Fans for max air flow with 105% more air pressure. The fans are IP5X dust-resistant for enhanced reliability & a longer lifespan. While exclusive Auto-Extreme Technology with Super Alloy Power II components for superior stability. GPU Tweak II with XSplit Gamecaster that provides intuitive performance tweaking & instant gameplay streaming. 0d B Technology Game in Complete Silence Innovative 0d B technology stops the fan completely when the GPU temperature remains below 55°C, letting you enjoy light gaming in complete silence. IP5X-Certified Dust Resistance Longer Fan Lifespan The fans in ASUS Dual series of RX 580 graphics cards are certified under the International Protection Marking (IP code) as IP5X dust resistant for enhanced reliability & a longer lifespan. This stringent certification process ensures ASUS Dual series of RX 580 graphics cards provide optimal fan performance, even under severe conditions. Patented Wing-Blade Design Max Air Flow with 105% More Air Pressure Patented wing-blade fans delivers maximum air flow & 105% greater static pressure over the heat sink, while operating at an up to 3X quieter volume than reference cards. Auto-Extreme Technology with Super Alloy Power II Premium quality & best reliability ASUS graphics cards are produced using Auto-Extreme technology, an industry-first 100% automated production process, & feature premium Super Alloy Power II components that enhance efficiency, reduce power loss, decrease component buzzing under load, & lower thermal temperatures for unsurpassed quality & reliability. VR-Friendly HDMI Ports Enjoy immersive virtual reality experience ASUS Dual series of RX 580 graphics cards have two HDMI ports for connecting a VR device & display at the same time, so you can enjoy immersive virtual reality experiences anytime without having to swap cables. GPU Tweak II with XSplit Gamecaster GPU Tweak II: Intuitive performance tweaking Adjust clock speeds, voltages & fan speeds to tune your graphics card (s) exactly how you want to. Select between GPU Tweak’s Standard or Advanced modes depending on your level of experience. Choose Standard Mode to access Intuitive options for easy tweaking. This is great for those learning how to tune graphics cards. Alternatively try out the Advanced Mode for sophisticated & extensive tuning options that enable complete control for experienced overclockers. Specifications Graphics Engine AMD Radeon RX 580 Open GL Open GL4.5 Video Memory GDDR5 4GB Engine Clock 1380 MHz (OC Mode) 1360 MHz (Gaming Mode) Stream Processors 2304 Memory Clock 7000 MHz Memory Interface 256-bit Resolution Digital Max Resolution:7680x 4320 Interface DVI Output: Yes x 1 (Native) (DVI-D) HDMI Output: Yes x 2 (Native) (HDMI 2.0) Display Port: Yes x 2 (Native) (Regular DP) HDCP Support: Yes Power Connectors 1 x 8-pin Software ASUS GPU Tweak II & Driver

Dimensions 9.53 " x 5.07 " x 1.49 " Inch 24.2 x 12.89 x 3.8 Centimeter

...

Features Max Contact Technology that is 2X more contact with GPU for enhanced thermal transfer. Patented Wing-Blade IP5X-Certified Fans for maximum airflow & longer fan lifespan. ASUS Fan Connect II equips with hybrid controlled fan headers for optimal system cooling. Industry Only Auto-Extreme Technology with Super Alloy Power II delivers premium quality & best reliability. ASUS Aura Sync RGB LED synchronisation enables a gaming system personalisation. VR-friendly HDMI ports let you enjoy VR experiences anytime without having to swap cables. GPU Tweak II with XSplit Gamecaster provides intuitive performance tweaking & real-time streaming. OUTSHINE THE COMPETITION ROG Strix Radeon RX 580 gaming graphics cards are packed with exclusive ASUS technologies, including all-new Max Contact Technology that is 2X more contact with GPU for enhanced thermal transfer, & Patented Wing-Blade IP5X-Certified Fans for maximum airflow & longer fan lifespan. While ASUS Fan Connect II features 4-pin, hybrid-controlled headers connected to system fans for optimal system cooling. ASUS Aura Sync RGB LED synchronization enables a gaming system personalization & VR-friendly HDMI ports let gamers easily enjoy immersive virtual reality experiences. ROG Strix Radeon RX 580 also has GPU Tweak II with XSplit Gamecaster that provides intuitive performance tweaking & instant gameplay streaming. Auto-Extreme Technology Industry-only 100% Automated Production Process All ASUS graphics cards are now produced using Auto-Extreme Technology, an industry-exclusive, 100% automated production process that incorporates premium materials to set a new standard of quality. Auto-Extreme Technology ensures consistent graphics card quality as well as enhanced performance & longevity. Since the introduction of Auto-Extreme technology, reliability has enhanced by 30%. This new manufacturing process is also environmentally friendly, eliminating harsh chemicals & reducing power consumption by 50%. 7+1 Phase Super Alloy Power II Enhanced Durability & Efficiency ASUS engineers have integrated premium alloy components into their graphics card designs to reinforce overall reliability. Super Alloy Power II components greatly enhance efficiency, reduce power loss & achieve thermal levels that are Approx. 50% cooler than previous designs. ...

Asus AMD Radeon RX 470 Gaming 4GB GDDR5 DVI-D HDMi Display Port PCI-E Graphics Card OUTSHINE THE COMPETITION ROG Strix RX 470 gaming graphics cards are packed with exclusive ASUS technologies, including Direct CU II Technology with Patented Wing-Blade Fans for up to 30% cooler & 3X quieter performance, & Industry-only Auto-Extreme Technology for premium quality & the best reliability. Aura RGB Lighting enables a gaming system personalisation. ROG Strix RX 470 also has GPU Tweak II with XSplit Gamecaster that provides intuitive performance tweaking & instant gameplay streaming. Specifications Graphics Engine AMD Radeon RX 470 Bus Standard PCI Express 3.0 Open GL Open GL 4.5 Video Memory GDDR5 4GB Engine Clock 1270 MHz (OC Mode) 1250 MHz (Gaming Mode) Memory Clock 6600 MHz Memory Interface 256-bit Resolution Digital Max Resolution:5120x 2880 Interface DVI Output: Yes x 2 (Native) (DVI-D) HDMI Output: Yes x 1 (Native) (HDMI 2.0) Display Port: Yes x 1 (Native) (Regular DP) HDCP Support: Yes Software ASUS GPU Tweak II & Driver Aura (Graphics Card) Software

Dimensions 9.5 " x 5.1 " x 1.6 " Inch 24.2 x 12.9 x 4.2 Centimeter

...

ASUS Strix RX480 is an all-new gaming graphics card packed with exclusive ASUS technologies, including Direct CU III with Triple Patented Wing-Blade 0d B Fan Design delivers max air flow with 30% cooler & 3X quieter performance. ASUS STRIX-RX480-O8G-GAMING with factory-overclocked provides better gaming experience. The cards with exclusive 8 phase AUTO-EXTREME Technology with Super Alloy Power II which is an industry-only, 100% automated production process that incorporates Super Alloy Power II components for premium quality & best reliability. ASUS STRIX-RX480- (O)8G-GAMING armored with Aura RGB Lighting, it displays millions of color & six lighting effects to express your own unique style. VR-FRIENDLY HDMI PORTS can connect a VR device & display at the same time & enjoy immersive virtual reality experiences without having to swap cables. ASUS FANCONNECT featuring two 4-pin GPU-controlled headers that can be connected to system fans for targeted supplemental cooling & optimal thermal performance. ASUS graphics cards bundled with GPU Tweak II with Xsplit Gamecaster provides intuitive performance tweaking & lets you stream your gameplay instantly. What's more, streaming or recording your gameplay with Free 1-year premium XSplit Gamecaster (USD 99.95 /yr) lets users share gameplay live.

Features:
- Factory-overclocked provides faster gaming experience.
- Exclusive Direct CU III design with Triple Patented Wing-blade Fan
- 30% cooler & 3X quieter.
- 8 phase AUTO-EXTREME Technology with Super Alloy Power II which is premium quality & reliability.
- Aura RGB Lighting to express your own unique style.
- VR-FRIENDLY HDMI Ports can connect a VR device & display at the same time.
- ASUS Fan Connect featuring two 4-pin GPU-controlled headers that can be connected to system fans for targeted supplemental cooling & optimal thermal performance.
- GPU Tweak II with Xsplit Gamecaster provides intuitive performance tweaking & lets you stream your gameplay instantly.
- Free 1-year premium XSplit Gamecaster (USD 99.95 /yr) lets users share gameplay live. Specification:-
- GPU: Polaris
- Stream Processors: 2304
- Core Speed: TBAMHz
- Boost Speed: 1330 M Hz
- Memory Speed: 8000 Mhz
- Memory interface: 256-Bit
- Memory capacity: 8192MB GDDR5
- PCI-Express X16 lane required
- 350W or greater PSU required
- 175W TDP
- Power Connectors: 1x 8-pin required
- Display Outputs: 1x DVI, 1x HDMI, 3x Display Port






















...
