Features ASRock Super Alloy Supports 7th & 6th Generation Intel Core™ i 7/i 5/i 3/ Pentium/ Celeron Processors (Socket 1151) Supports DDR4 2400 1 PCIe 3.0 x 16, 2 PCIe 2.0 x 1 Graphics Output Options: HDMI, D-Sub, DVI-D 7.1 CH HD Audio (Realtek ALC887 Audio Codec), ELNA Audio Caps 4 SATA3, 1 M.2 (PCIe Gen 2 x 4 & SATA3) 4 USB (Universal Serial Bus) 3.1 Gen 1 (2 Front, 2 Rear) Intel Gigabit LAN Overview PCIe Gen 2 x 4 M.2 The PCIe Gen 2 x 4 interface pushes data transfer speeds up to 20 Gb/s. In addition, it also supports SATA 3 6 Gb/s M.2 modules, & is compatible with ASRock’s U.2 Kit for installing some U.2 SSDs. Intel LAN Intel LAN provides the best throughput performance, lower CPU utilization, enhanced stability & is able to deliver ultimate network experience to users! User friendly UEFI & EZ Mode ASRock UEFI is the smoothest, slickest mouse-controlled BIOS has been enhanced to make it even more friendly. Advanced mode provides a more comprehensive environment that is designed for overclockers & power users who want maximum control over their PC’s hardware. EZ mode is a dashboard which contains multiple readings of the system’s current status. You can check the most crucial information of your system, such as CPU speed, DRAM frequency, SATA information, fan speed, etc. Digi Power Unlike traditional motherboards that use analog power, this motherboard uses a next generation digital PWM (Pulse-Width Modulation) design, which provides CPU Vcore voltage more efficiently & smoothly, so that the stability & lifespan of the motherboard is greatly enhanced. 4K x 2K Composed by a minimum of 3840 x 2160 pixels, which is twice the horizontal & vertical resolution of the 1080p format.

Specification Unique Feature ASRock Super Alloy
- Premium 50A Power Choke
- Sapphire Black PCB
- High Density Glass Fabric PCB ASRock Full Spike Protection (for all USB (Universal Serial Bus), Audio, LAN Ports) ASRock Live Update & APP Shop CPU
- Supports 7th & 6th Generation Intel Core™ i 7/i 5/i 3/ Pentium/ Celeron Processors (Socket 1151)
- Supports CPU up to 91W
- Digi Power design
- 5 Power Phase design
- Supports Intel Turbo Boost 2.0 Technology Chipset
- Intel H110 Memory
- Dual Channel DDR4 Memory Technology
- 2 x DDR4 DIMM Slots
- Supports DDR4 2400/2133 non-ECC, un-buffered memory*
- Supports ECC UDIMM memory modules (operate in non-ECC mode)
- Max. capacity of system memory: 32GB**
- Supports Intel Extreme Memory Profile (XMP) 2.0
- 15μ Gold Contact in DIMM Slots *7th Gen Intel CPU supports DDR4 up to 2400; 6th Gen Intel CPU supports DDR4 up to 2133. ** Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows 32-bit OS. For Windows 64-bit OS with 64-bit CPU, there is no such limitation. BIOS
- 64 Mb AMI UEFI Legal BIOS with multilingual GUI support
- ACPI 5.0 Compliant wake up events
- SMBIOS 2.7 Support
- CPU, DRAM, PCH 1.0V Voltage Multi-adjustment Graphics
- Supports Intel HD Graphics Built-in Visuals: Intel Quick Sync Video with AVC, MVC (S3D) & MPEG-2 Full HW Encode 1, Intel In Tru™ 3D, Intel Clear Video HD Technology, Intel Insider™, Intel HD Graphics
- Gen 9 LP, DX11.3, DX12
- HWAEncode/ Decode: VP8, HEVC 8b, VP9, HEVC 10b (For 7th Gen Intel CPU)
- HWA Encode/ Decode: VP8, HEVC 8b; GPU/SWEncode/ Decode: VP9, HEVC 10b (For 6th Gen Intel CPU)
- Max. shared memory 1024MB**
- Three graphics output options: D-Sub, DVI-D & HDMI***
- Supports HDMI with max. resolution up to 4K x 2K (4096x 2160) @ 24 Hz / (3840x 2160) @ 30 Hz
- Supports DVI-D with max. resolution up to 1920x 1200 @ 60 Hz
- Supports D-Sub with max. resolution up to 1920x 1200 @ 60 Hz
- Supports Auto Lip Sync, Deep Color (12bpc), xv YCC & HBR (High Bit Rate Audio) with HDMI Port (Compliant HDMI monitor is required)
- Supports Accelerated Media Codecs: HEVC, VP8, VP9
- Supports HDCP with DVI-D & HDMI Ports
- Supports Full HD 1080p Blu-ray (BD) playback with DVI-D & HDMI Ports * Intel HD Graphics Built-in Visuals & the VGA outputs can be supported only with processors which are GPU integrated. ** The size of maximum shared memory may vary from different operating systems. *** Supports up to 2 displays simultaneously **** Due to chipset limitation, the Blu-ray playback of Intel HD Graphics is only supported under Windows 8 / 8 64-bit / 7 / 7 64-bit. ***** Intel In Tru™ 3D is only supported under Windows 8 / 8 64-bit / 7 / 7 64-bit. Audio
- 7.1 CH HD Audio (Realtek ALC887 Audio Codec)*
- Supports Surge Protection
- ELNA Audio Caps * To configure 7.1 CH HD Audio, it is required to use an HD front panel audio module & enable the multi-channel audio feature through the audio driver. LAN
- Gigabit LAN 10/100/1000 Mb/s
- Giga PHY Intel I219V
- Supports Wake-On-LAN
- Supports Lightning/ESD Protection (ASRock Full Spike Protection)
- Supports Energy Efficient Ethernet 802.3az
- Supports PXE Slots
- 1 x PCI Express 3.0 x 16 Slot (PCIE1: x 16 mode)*
- 2 x PCI Express 2.0 x 1 Slots * Supports NVMe SSD as boot disks Storage
- 4 x SATA3 6.0 Gb/s Connectors, support NCQ, AHCI & Hot Plug*
- 1 x M.2 Socket, supports M Key type 2230/2242/2260/2280 M.2 SATA3 6.0 Gb/s module & M.2 PCI Express module up to Gen 2 x 4 (20 Gb/s)** * If M2_1 is occupied by a SATA-type M.2 device, SATA3_3 will be disabled. ** Supports ASRock U.2 Kit Supports NVMe SSD as boot disks Connector
- 1 x Print Port Header
- 1 x COM Port Header
- 1 x TPM Header
- 1 x Chassis Intrusion Header
- 1 x CPU Fan Connector (4-pin)*
- 2 x Chassis Fan Connectors (4-pin)
- 1 x 24 pin ATX Power Connector
- 1 x 4 pin 12V Power Connector
- 1 x Front Panel Audio Connector
- 2 x USB (Universal Serial Bus) 2.0 Headers (Support 4 USB (Universal Serial Bus) 2.0 ports) (Supports ESD Protection)
- 1 x USB (Universal Serial Bus) 3.1 Gen 1 Header (Supports 2 USB (Universal Serial Bus) 3.1 Gen 1 ports) (Supports ESD Protection)** * The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power. **USB3_3_4 is shared with USB_7_8. Rear Panel I/O
- 1 x PS/2 Mouse/ Keyboard Port
- 1 x D-Sub Port
- 1 x DVI-D Port
- 1 x HDMI Port
- 4 x USB (Universal Serial Bus) 2.0 Ports (Supports ESD Protection)
- 2 x USB (Universal Serial Bus) 3.1 Gen 1 Ports (Supports ESD Protection)
- 1 x RJ-45 LAN Port with LED (ACT/LINK LED & SPEED LED)
- HD Audio Jacks: Line in / Front Speaker / Microphone Software & UEFI Software
- ASRock APP Charger
- ASRock XFast LAN* UEFI
- ASRock EZ Mode
- ASRock Full HD UEFI
- ASRock My Favorites in UEFI
- ASRock Instant Flash
- ASRock Internet Flash
- ASRock Crashless BIOS
- ASRock UEFI Tech Service * These utilities can be downloaded from ASRock Live Update & APP Shop. Support CD
- Drivers, Utilities, Anti Virus Software (Trial Version), Google Chrome Browser & Toolbar Accessories
- Quick Installation Guide, Support CD, I/O Shield
- 2 x SATA Data Cables
- 1 x Screw for M.2 Socket Hardware Monitor
- CPU/ Chassis temperature sensing
- CPU/ Chassis Fan Tachometer
- CPU/ Chassis Quiet Fan
- CPU/ Chassis Fan multi-speed control
- CASE OPEN detection
- Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore, DRAM, PCH 1.0V Form Factor
- Micro ATX Form Factor: 8.9-in x 7.2-in, 22.6 cm x 18.3 cm
- Solid Capacitor design OS
- Microsoft Windows 10 64-bit (For 7th Gen Intel CPU)
- Microsoft Windows 10 64-bit / 8.1 64-bit / 7 32-bit / 7 64-bit (For 6th Gen Intel CPU)* * To install Windows 7 OS, a modified installation disk with x HCI drivers packed into the ISO file is required. Please check our User Manual for more detailed instructions. For the updated Windows 10 driver, please visit ASRocks website for details. Certifications
- FCC, CE The

Specification is subject to change without notice in advance. The brand & product names are trademarks of their respective companies. Any configuration other than original product

Specification is not guaranteed. The above user interface picture is a sample for reference. The actual user interface may vary with the updated software version.






























































































...

ASRock H170M-ITX/ac Socket 1151 DVI-D HDMI 7.1 CH HD Audio Mini-ITX Motherboard General Unique Feature ASRock Super Alloy Premium 45A Power Choke Dual-Stack MOSFET (DSM) High Density Glass Fabric PCB ASRock 802.11ac Wi Fi ASRock Full Spike Protection ASRock Live Update & APP Shop CPU Supports 6th Generation Intel Core i 7/i 5/i 3/ Pentium/ Celeron Processors (Socket 1151) Digi Power design 6 Power Phase design Supports Intel Turbo Boost 2.0 Technology Chipset Intel H170 Supports Intel Small Business Advantage 4.0 Memory Dual Channel DDR4 Memory Technology 2 x DDR4 DIMM Slots Supports DDR4 2133 non-ECC, un-buffered memory Supports ECC UDIMM memory modules (operate in non-ECC mode) Max. capacity of system memory: 32GB* Supports Intel Extreme Memory Profile (XMP) 2.0 * Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows 32-bit OS. For Windows 64-bit OS with 64-bit CPU, there is no such limitation. BIOS 128 Mb AMI UEFI Legal BIOS with multilingual GUI support ACPI 5.0 Compliant wake up events SMBIOS 2.7 Support CPU, GT_CPU, DRAM, PCH 1.0V, VCCIO, VPPM, VCCSA Voltage Multi-adjustment Audio, Video & Networking Graphics Supports Intel HD Graphics Built-in Visuals: Intel Quick Sync Video with AVC, MVC (S3D) & MPEG-2 Full HW Encode 1, Intel In Tru 3D, Intel Clear Video HD Technology, Intel Insider, Intel HD Graphics 510/530 Pixel Shader 5.0, Direct X 12 Max. shared memory 1792MB Dual graphics output: Support DVI-D & HDMI ports by independent display controllers Supports HDMI with max. resolution up to 4K x 2K (4096x 2160) @ 24 Hz / (3840x 2160) @ 30 Hz Supports DVI-D with max. resolution up to 1920x 1200 @ 60 Hz Supports Auto Lip Sync, Deep Color (12bpc), xv YCC & HBR (High Bit Rate Audio) with HDMI Port (Compliant HDMI monitor is required) Supports Accelerated Media Codecs: HEVC, VP8, VP9 Supports HDCP with DVI-D & HDMI Ports Supports Full HD 1080p Blu-ray (BD) playback with DVI-D & HDMI Ports * Intel HD Graphics Built-in Visuals & the VGA outputs can be supported only with processors which are GPU integrated. ** Due to chipset limitation, the Blu-ray playback of Intel HD Graphics is only supported under Windows 8 / 8 64-bit / 7 / 7 64-bit. *** Intel In Tru 3D is only supported under Windows 8 / 8 64-bit / 7 / 7 64-bit. Audio 7.1 CH HD Audio with Content Protection (Realtek ALC892 Audio Codec)* Premium Blu-ray Audio support Supports Surge Protection (ASRock Full Spike Protection) ELNA Audio Caps * To configure 7.1 CH HD Audio, it is required to use an HD front panel audio module & enable the multi-channel audio feature through the audio driver. LAN 1 x Intel I219V (Gigabit LAN PHY 10/100/1000 Mb/s) 1 x Realtek RTL8111H (PCIE x 1 Gigabit LAN 10/100/1000 Mb/s) Supports Wake-On-WAN (on Realtek RTL8111H) Supports Wake-On-LAN Supports Lightning/ESD Protection (ASRock Full Spike Protection) Supports LAN Cable Detection (on Realtek RTL8111H) Supports Energy Efficient Ethernet 802.3az Supports PXE Wireless LAN Supports IEEE 802.11a/b/g/n/ac Supports Dual-Band (2.4/5 GHz) Supports high speed wireless connections up to 433 Mbps Supports Bluetooth 4.0 / 3.0 + High speed class II Expansion / Connectivity Slots 1 x PCI Express 3.0 x 16 Slot (PCIE1: x 16 mode)* 1 x Vertical Half-size Mini-PCI Express Slot: For Wi Fi + BT Module** * Supports NVMe SSD as boot disks ** This Mini-PCI Express Slot supports Wi Fi & m SATA devices. Storage 4 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1, RAID 5, RAID 10, Intel Rapid Storage Technology 14 & Intel Smart Response Technology), NCQ, AHCI & Hot Plug 1 x m SATA Connector (shared with Mini-PCI Express Slot), support RAID (RAID 0, RAID 1, RAID 5, RAID 10, Intel Rapid Storage Technology 14 & Intel Smart Response Technology), NCQ, AHCI & Hot Plug Connector 1 x TPM Header 1 x Chassis Intrusion Header 1 x CPU Fan Connector (4-pin) (Smart Fan Speed Control) 1 x Chassis Fan Connector (4-pin) (Smart Fan Speed Control)* 1 x 20 pin ATX Power Connector 1 x 4 pin 12V Power Connector 1 x Front Panel Audio Connector 1 x USB (Universal Serial Bus) 2.0 Header (Supports 2 USB (Universal Serial Bus) 2.0 ports) (Supports ESD Protection (ASRock Full Spike Protection)) 1 x USB (Universal Serial Bus) 3.0 Header (Supports 2 USB (Universal Serial Bus) 3.0 ports) (Supports ESD Protection (ASRock Full Spike Protection)) * All CPU/ Chassis Fan Connectors can auto detect if 3-pin or 4-pin fan is in use. The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power. Rear Panel I/O
- 1 x PS/2 Mouse/ Keyboard Port 1 x DVI-D Port 1 x HDMI Port 2 x USB (Universal Serial Bus) 2.0 Ports (Supports ESD Protection (ASRock Full Spike Protection)) 6 x USB (Universal Serial Bus) 3.0 Ports (Supports ESD Protection (ASRock Full Spike Protection)) 2 x RJ-45 LAN Ports with LED (ACT/LINK LED & SPEED LED) HD Audio Jacks: Line in / Front Speaker / Microphone Other Features / Miscellaneous Software & BIOS Software ASRock A-Tuning ASRock Disk Health Report ASRock USB (Universal Serial Bus) Key ASRock APP Charger ASRock XFast LAN ASRock XFast RAM ASRock Fast Boot (Fast Boot, Restart to UEFI)* UEFI ASRock EZ Mode ASRock Full HD UEFI ASRock My Favorites in UEFI ASRock Instant Flash ASRock Internet Flash ASRock Crashless BIOS ASRock OMG (Online Management Guard) ASRock UEFI System Browser ASRock UEFI Tech Service ASRock Easy RAID Installer ASRock Easy Driver Installer * These utilities can be downloaded from ASRock Live Update & APP Shop. Support CD
- Drivers, Utilities, Anti Virus Software (Trial Version), Google Chrome Browser & Toolbar Hardware Monitor CPU/ Chassis temperature sensing CPU/ Chassis Fan Tachometer CPU/ Chassis Quiet Fan (Auto adjust chassis fan speed by CPU temperature) CPU/ Chassis Fan multi-speed control CASE OPEN detection Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore Form Factor Mini-ITX Form Factor Solid Capacitor design OS Microsoft Windows 10 64-bit / 8.1 64-bit / 7 32-bit / 7 64-bit* * To install Windows 7 OS, a modified installation disk with x HCI drivers packed into the ISO file is required. Please check our User Manual for more detailed instructions. For the updated Windows 10 driver, please visit ASRock's website for details. Certifications FCC, CE, WHQL Er P/ Eu P ready (Er P/ Eu P ready power supply is required)

...

Features ASRock Super Alloy Supports 7th & 6th Generation Intel Core™ i 7/i 5/i 3/ Pentium/ Celeron Processors (Socket 1151) Supports DDR4 2400 (Intel 7th Gen CPUs) / 2133 (Intel 6th Gen CPUs) 2 PCIe 3.0 x 16, 4 PCIe 3.0 x 1, 1 M.2 (Key E) AMD Quad Cross Fire X™ Graphics Output Options: HDMI, DVI-D, D-Sub 7.1 CH HD Audio (Realtek ALC1220 Audio Codec), Supports Creative Sound Blaster Cinema 3 6 SATA3, 2 Ultra M.2 (PCIe Gen 3 x 4 & SATA3) 8 USB (Universal Serial Bus) 3.0 (1 Type-C, 4 Front, 3 Rear) Intel Gigabit LAN ASRock AURA RGB LED CPU
- Supports 7th & 6th Generation Intel Core™ i 7/i 5/i 3/ Pentium/ Celeron Processors (Socket 1151)
- Digi Power design
- 8 Power Phase design
- Supports Intel Turbo Boost 2.0 Technology Chipset
- Intel H270 Memory
- Dual Channel DDR4 Memory Technology
- 4 x DDR4 DIMM Slots
- Supports DDR4 2400/2133 non-ECC, un-buffered memory*
- Supports ECC UDIMM memory modules (operate in non-ECC mode)
- Max. capacity of system memory: 64GB**
- Supports Intel Extreme Memory Profile (XMP) 2.0
- 15μ Gold Contact in DIMM Slots *7th Gen Intel CPU supports DDR4 up to 2400; 6th Gen Intel CPU supports DDR4 up to 2133. ** Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows 32-bit OS. For Windows 64-bit OS with 64-bit CPU, there is no such limitation. BIOS
- 128 Mb AMI UEFI Legal BIOS with multilingual GUI support
- ACPI 6.0 Compliant wake up events
- SMBIOS 2.7 Support
- CPU, GT_CPU, DRAM, VPPM, PCH 1.0V, VCCIO, VCCST, VCCSA, VCCPLL Voltage Multi-adjustment Graphics
- Supports Intel HD Graphics Built-in Visuals: Intel Quick Sync Video with AVC, MVC (S3D) & MPEG-2 Full HW Encode 1, Intel In Tru™ 3D, Intel Clear Video HD Technology, Intel Insider™, Intel HD Graphics
- Gen 9 LP, DX11.3, DX12
- HWAEncode/ Decode: VP8, HEVC 8b, VP9, HEVC 10b (For 7th Gen Intel CPU)
- HWA Encode/ Decode: VP8, HEVC 8b; GPU/SWEncode/ Decode: VP9, HEVC 10b (For 6th Gen Intel CPU)
- Max. shared memory 1024MB**
- Three graphics output options: D-Sub, DVI-D & HDMI
- Supports Triple Monitor
- Supports HDMI with max. resolution up to 4K x 2K (4096x 2160) @ 24 Hz / (3840x 2160) @ 30 Hz
- Supports DVI-D with max. resolution up to 1920x 1200 @ 60 Hz
- Supports D-Sub with max. resolution up to 1920x 1200 @ 60 Hz
- Supports Auto Lip Sync, Deep Color (12bpc), xv YCC & HBR (High Bit Rate Audio) with HDMI Port (Compliant HDMI monitor is required)
- Supports HDCP with DVI-D & HDMI Ports
- Supports Full HD 1080p Blu-ray (BD) playback with DVI-D & HDMI Ports * Intel HD Graphics Built-in Visuals & the VGA outputs can be supported only with processors which are GPU integrated. ** The size of maximum shared memory may vary from different operating systems. *** Due to chipset limitation, the Blu-ray playback of Intel HD Graphics is only supported under Windows 8 / 8 64-bit / 7 / 7 64-bit. **** Intel In Tru™ 3D is only supported under Windows 8 / 8 64-bit / 7 / 7 64-bit. Audio
- 7.1 CH HD Audio with Content Protection (Realtek ALC1220 Audio Codec)
- Premium Blu-ray Audio support
- Supports Surge Protection (ASRock Full Spike Protection)
- Nichicon Fine Gold Series Audio Caps
- 120d B SNR DAC with Differential Amplifier
- TI NE5532 Premium Headset Amplifier for Front Panel Audio Connector (Supports up to 600 Ohm headsets)
- Pure Power-In
- Direct Drive Technology
- PCB Isolate Shielding
- Impedance Sensing on Front Out port
- Individual PCB Layers for R/L Audio Channel
- AURA RGB LED
- Gold Audio Jacks
- 15μ Gold Audio Connector
- Supports Creative Sound Blaster™ Cinema 3 LAN
- Gigabit LAN 10/100/1000 Mb/s
- Giga PHY Intel I219V
- Supports Wake-On-LAN
- Supports Lightning/ESD Protection (ASRock Full Spike Protection)
- Supports Energy Efficient Ethernet 802.3az
- Supports PXE Slots
- 2 x PCI Express 3.0 x 16 Slots (PCIE2: x 16 mode; PCIE4: x 4 mode)*
- 4 x PCI Express 3.0 x 1 Slots (Flexible PCIe)**
- Supports AMD Quad Cross Fire X™ & Cross Fire X™
- 1 x M.2 Socket (Key E), supports type 2230 Wi Fi/BT module***
- 15μ Gold Contact in VGA PCIe Slot (PCIE2) * Supports NVMe SSD as boot disks ** If PCIE5 or PCIE6 is occupied, PCIE4 will run at x 2 mode. *** If M2_3 is occupied, PCIE3 will be disabled. Storage
- 6 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1, RAID 5, RAID 10, Intel Rapid Storage Technology 15 & Intel Smart Response Technology), NCQ, AHCI & Hot Plug*
- 2 x Ultra M.2 Sockets, support type 2230/2242/2260/2280 M.2 SATA3 6.0 Gb/s module & M.2 PCI Express module up to Gen 3 x 4 (32 Gb/s)** * If M2_1 is occupied by a SATA-type M.2 device, SATA_5 will be disabled. If M2_2 is occupied by a SATA-type M.2 device, SATA_0 will be disabled. ** Supports Intel Optane™ Technology Supports NVMe SSD as boot disks Supports ASRock U.2 Kit Connector
- 1 x COM Port Header
- 1 x TPM Header
- 1 x Chassis Intrusion Header
- 1 x Power LED & Speaker Header
- 1 x AURA RGB LED Header*
- 1 x CPU Fan Connector (4-pin)**
- 2 x Chassis Fan Connectors (4-pin) (Smart Fan Speed Control)
- 1 x Chassis Optional/ Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)***
- 1 x 24 pin ATX Power Connector (Hi-Density Power Connector)
- 1 x 8 pin 12V Power Connector (Hi-Density Power Connector)
- 1 x Front Panel Audio Connector (15μ Gold Audio Connector)
- 1 x Thunderbolt™ AIC Connector (5-pin)
- 1 x Thunderbolt™ AIC Connector (10-pin)****
- 3 x USB (Universal Serial Bus) 2.0 Headers (Support 5 USB (Universal Serial Bus) 2.0 ports) (Supports ESD Protection (ASRock Full Spike Protection))
- 2 x USB (Universal Serial Bus) 3.0 Headers (Support 4 USB (Universal Serial Bus) 3.0 ports) (Supports ESD Protection (ASRock Full Spike Protection)) * Supports up to 12V/3A, 36W LED Strip. ** The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power. *** The Chassis Optional/ Water Pump Fan supports the water cooler fan of maximum 1.5A (18W) fan power. CHA_FAN2 can auto detect if 3-pin or 4-pin fan is in use. **** Only one Thunderbolt™ AIC Card is supported. Rear Panel I/O
- 2 x Antenna Ports
- 1 x PS/2 Mouse/ Keyboard Port
- 1 x D-Sub Port
- 1 x DVI-D Port
- 1 x HDMI Port
- 1 x Optical SPDIF Out Port
- 1 x USB (Universal Serial Bus) 2.0 Port (Supports ESD Protection (ASRock Full Spike Protection))
- 1 x Fatal 1ty Mouse Port (USB 2.0) (Supports ESD Protection (ASRock Full Spike Protection))
- 3 x USB (Universal Serial Bus) 3.0 Type-A Ports (Supports ESD Protection (ASRock Full Spike Protection))
- 1 x USB (Universal Serial Bus) 3.0 Type-C Port (Supports ESD Protection (ASRock Full Spike Protection))
- 1 x RJ-45 LAN Port with LED (ACT/LINK LED & SPEED LED)
- HD Audio Jacks: Rear Speaker / Central / Bass / Line in / Front Speaker / Microphone (Gold Audio Jacks) Accessories
- Quick Installation Guide, Support CD, I/O Shield
- 2 x SATA Data Cables
- 3 x Screws for M.2 Sockets Hardware Monitor
- Temperature Sensing: CPU, Chassis, Chassis Optional/ Water Pump Fans
- Fan Tachometer: CPU, Chassis, Chassis Optional/ Water Pump Fans
- Quiet Fan (Auto adjust chassis fan speed by CPU temperature): CPU, Chassis, Chassis Optional/ Water Pump Fans
- Fan Multi-Speed Control: CPU, Chassis, Chassis Optional/ Water Pump Fans
- CASE OPEN detection
- Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore, DRAM, VPPM, PCH 1.0V, VCCSA, VCCST Form Factor
- ATX Form Factor: 12.0-in x 9.6-in, 30.5 cm x 24.4 cm OS
- Microsoft Windows 10 64-bit (For 7th Gen Intel CPU)
- Microsoft Windows 10 64-bit / 8.1 64-bit / 7 32-bit / 7 64-bit (For 6th Gen Intel CPU)** * To install Windows 7 OS, a modified installation disk with x HCI drivers packed into the ISO file is required. Please check our User Manual for more detailed instructions. For the updated Windows 10 driver, please visit ASRock's website for details. Certifications
- FCC, CE, WHQL
- Er P/ Eu P ready (Er P/ Eu P ready power supply is required)

































































































...

Features ASRock Super Alloy Supports 7th & 6th Generation Intel Core™ i 7/i 5/i 3/ Pentium/ Celeron Processors (Socket 1151) Supports DDR4 2400 (Intel 7th Gen CPUs) / 2133 (Intel 6th Gen CPUs) 2 PCIe 3.0 x 16, 2 PCIe 3.0 x 1 AMD Quad Cross Fire X™ Graphics Output Options: HDMI, DVI-D, D-Sub Supports Triple Monitor 7.1 CH HD Audio (Realtek ALC892 Audio Codec), Supports Creative Sound Blaster Cinema 3 6 SATA3, 2 Ultra M.2 (One supports PCIe Gen 3 x 4 & SATA3, the other one supports PCIe Gen 3 x 4 only) 8 USB (Universal Serial Bus) 3.0 (1 Type-C, 4 Front, 3 Rear) ASRock AURA RGB LED

Specification Gaming Armor Memory
- 15μ Gold Contact in DIMM Slots VGA Card
- 15μ Gold Contact in VGA PCIe Slot (PCIE1) Internet
- Intel LAN Audio
- Creative Sound Blaster™ Cinema 3 Unique Feature ASRock Super Alloy
- Premium 50A Power Choke
- Nichicon 12K Black Caps (100% Japan made high quality conductive polymer capacitors)
- I/O Armor
- Matte Black PCB
- High Density Glass Fabric PCB ASRock Intel 4-Layer Memory POOL (Planes on Outer Layers) Technology ASRock Steel Slots ASRock Ultra M.2 (PCIe Gen 3 x 4 & SATA3) ASRock Full Spike Protection ASRock Live Update & APP Shop CPU
- Supports 7th & 6th Generation Intel Core™ i 7/i 5/i 3/ Pentium/ Celeron Processors (Socket 1151)
- Digi Power design
- 6 Power Phase design
- Supports Intel Turbo Boost 2.0 Technology Chipset
- Intel H270 Memory
- Dual Channel DDR4 Memory Technology
- 4 x DDR4 DIMM Slots
- Supports DDR4 2400/2133 non-ECC, un-buffered memory*
- Supports ECC UDIMM memory modules (operate in non-ECC mode)
- Max. capacity of system memory: 64GB**
- Supports Intel Extreme Memory Profile (XMP) 2.0
- 15μ Gold Contact in DIMM Slots *7th Gen Intel CPU supports DDR4 up to 2400; 6th Gen Intel CPU supports DDR4 up to 2133. ** Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows 32-bit OS. For Windows 64-bit OS with 64-bit CPU, there is no such limitation. BIOS
- 128 Mb AMI UEFI Legal BIOS with multilingual GUI support
- ACPI 6.0 Compliant wake up events
- SMBIOS 2.7 Support
- CPU, GT_CPU, DRAM, PCH 1.0V, VCCIO, VCCSA, VCCST Voltage Multi-adjustment Graphics
- Supports Intel HD Graphics Built-in Visuals: Intel Quick Sync Video with AVC, MVC (S3D) & MPEG-2 Full HW Encode 1, Intel In Tru™ 3D, Intel Clear Video HD Technology, Intel Insider™, Intel HD Graphics
- Gen 9 LP, DX11.3, DX12
- HWAEncode/ Decode: VP8, HEVC 8b, VP9, HEVC 10b (For 7th Gen Intel CPU)
- HWA Encode/ Decode: VP8, HEVC 8b; GPU/SWEncode/ Decode: VP9, HEVC 10b (For 6th Gen Intel CPU)
- Max. shared memory 1024MB**
- Three graphics output options: D-Sub, DVI-D & HDMI
- Supports Triple Monitor
- Supports HDMI with max. resolution up to 4K x 2K (4096x 2160) @ 24 Hz / (3840x 2160) @ 30 Hz
- Supports DVI-D with max. resolution up to 1920x 1200 @ 60 Hz
- Supports D-Sub with max. resolution up to 1920x 1200 @ 60 Hz
- Supports Auto Lip Sync, Deep Color (12bpc), xv YCC & HBR (High Bit Rate Audio) with HDMI Port (Compliant HDMI monitor is required)
- Supports HDCP with DVI-D & HDMI Ports
- Supports Full HD 1080p Blu-ray (BD) playback with DVI-D & HDMI Ports * Intel HD Graphics Built-in Visuals & the VGA outputs can be supported only with processors which are GPU integrated. ** The size of maximum shared memory may vary from different operating systems. *** Due to chipset limitation, the Blu-ray playback of Intel HD Graphics is only supported under Windows 8 / 8 64-bit / 7 / 7 64-bit. **** Intel In Tru™ 3D is only supported under Windows 8 / 8 64-bit / 7 / 7 64-bit. Audio
- 7.1 CH HD Audio with Content Protection (Realtek ALC892 Audio Codec)*
- Premium Blu-ray Audio support
- Supports Surge Protection (ASRock Full Spike Protection)
- Nichicon Fine Gold Series Audio Caps
- Supports Creative Sound Blaster™ Cinema 3 * To configure 7.1 CH HD Audio, it is required to use an HD front panel audio module & enable the multi-channel audio feature through the audio driver. LAN
- Gigabit LAN 10/100/1000 Mb/s
- Giga PHY Intel I219V
- Supports Wake-On-LAN
- Supports Lightning/ESD Protection (ASRock Full Spike Protection)
- Supports Energy Efficient Ethernet 802.3az
- Supports PXE Slots
- 2 x PCI Express 3.0 x 16 Slots (PCIE1: x 16 mode; PCIE4: x 4 mode)*
- 2 x PCI Express 3.0 x 1 Slots (Flexible PCIe)
- Supports AMD Quad Cross Fire X™ & Cross Fire X™
- 15μ Gold Contact in VGA PCIe Slot (PCIE1) * Supports NVMe SSD as boot disks Storage
- 6 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1, RAID 5, RAID 10, Intel Rapid Storage Technology 15 & Intel Smart Response Technology), NCQ, AHCI & Hot Plug*
- 1 x Ultra M.2 Socket (M2_1), supports type 2230/2242/2260/2280 M.2 SATA3 6.0 Gb/s module & M.2 PCI Express module up to Gen 3 x 4 (32 Gb/s)**
- 1 x Ultra M.2 Socket (M2_2), supports type 2230/2242/2260/2280 M.2 PCI Express module up to Gen 3 x 4 (32 Gb/s)** * If M2_1 is occupied by a SATA-type M.2 device, SATA3_0 will be disabled. ** Supports Intel Optane™ Technology Supports NVMe SSD as boot disks Supports ASRock U.2 Kit Connector
- 1 x Print Port Header
- 1 x COM Port Header
- 1 x TPM Header
- 1 x Chassis Intrusion & Speaker Header
- 1 x AURA RGB LED Header*
- 2 x CPU Fan Connectors (1 x 4-pin, 1 x 3-pin)**
- 2 x Chassis Fan Connectors (4-pin) (Smart Fan Speed Control)***
- 1 x 24 pin ATX Power Connector
- 1 x 8 pin 12V Power Connector
- 1 x Front Panel Audio Connector
- 2 x USB (Universal Serial Bus) 2.0 Headers (Support 4 USB (Universal Serial Bus) 2.0 ports) (Supports ESD Protection (ASRock Full Spike Protection))
- 2 x USB (Universal Serial Bus) 3.0 Headers (Support 4 USB (Universal Serial Bus) 3.0 ports) (Supports ESD Protection (ASRock Full Spike Protection)) * Supports up to 12V/3A, 36W LED Strip. ** The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power. ***CHA_FAN1 & CHA_FAN2 can auto detect if 3-pin or 4-pin fan is in use. Rear Panel I/O
- 1 x PS/2 Mouse Port
- 1 x PS/2 Keyboard Port
- 1 x D-Sub Port
- 1 x DVI-D Port
- 1 x HDMI Port
- 1 x USB (Universal Serial Bus) 2.0 Port (Supports ESD Protection (ASRock Full Spike Protection))
- 1 x Fatal 1ty Mouse Port (USB 2.0) (Supports ESD Protection (ASRock Full Spike Protection))
- 3 x USB (Universal Serial Bus) 3.0 Type-A Ports (Supports ESD Protection (ASRock Full Spike Protection))
- 1 x USB (Universal Serial Bus) 3.0 Type-C Port (Supports ESD Protection (ASRock Full Spike Protection))
- 1 x RJ-45 LAN Port with LED (ACT/LINK LED & SPEED LED)
- HD Audio Jacks: Line in / Front Speaker / Microphone Software & UEFI Software
- ASRock F-Stream
- ASRock AURA RGB LED
- ASRock Key Master
- ASRock APP Charger
- ASRock XFast LAN* UEFI
- ASRock EZ Mode
- ASRock Full HD UEFI
- ASRock My Favorites in UEFI
- ASRock Instant Flash
- ASRock Internet Flash
- ASRock Crashless BIOS
- ASRock UEFI System Browser
- ASRock UEFI Tech Service
- ASRock Easy RAID Installer * These utilities can be downloaded from ASRock Live Update & APP Shop. Support CD
- Drivers, Utilities, Anti Virus Software (Trial Version), Google Chrome Browser & Toolbar Accessories
- Quick Installation Guide, Support CD, I/O Shield
- 2 x SATA Data Cables
- 2 x Screws for M.2 Sockets Hardware Monitor
- CPU/ Chassis temperature sensing
- CPU/ Chassis Fan Tachometer
- CPU/ Chassis Quiet Fan (Auto adjust chassis fan speed by CPU temperature)
- CPU/ Chassis Fan multi-speed control
- CASE OPEN detection
- Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore, DRAM, PCH 1.0V Form Factor
- Micro ATX Form Factor: 9.6-in x 9.6-in, 24.4 cm x 24.4 cm OS
- Microsoft Windows 10 64-bit (For 7th Gen Intel CPU)
- Microsoft Windows 10 64-bit / 8.1 64-bit / 7 32-bit / 7 64-bit (For 6th Gen Intel CPU)* * To install Windows 7 OS, a modified installation disk with x HCI drivers packed into the ISO file is required. Please check our User Manual for more detailed instructions. For the updated Windows 10 driver, please visit ASRock's website for details. Certifications
- FCC, CE, WHQL
- Er P/ Eu P ready (Er P/ Eu P ready power supply is required)













































































































...

Features ASRock Super Alloy Supports 7th & 6th Generation Intel Core™ i 7/i 5/i 3/ Pentium/ Celeron Processors (Socket 1151) Supports DDR4 2400 (Intel 7th Gen CPUs) / 2133 (Intel 6th Gen CPUs) 2 PCIe 3.0 x 16, 2 PCIe 3.0 x 1 AMD Quad Cross Fire X™ Graphics Output Options: HDMI, DVI-D, D-Sub Supports Triple Monitor 7.1 CH HD Audio (Realtek ALC892 Audio Codec), ELNA Audio Caps 6 SATA3, 2 Ultra M.2 (One supports PCIe Gen 3 x 4 & SATA3, the other one supports PCIe Gen 3 x 4 only) 8 USB (Universal Serial Bus) 3.0 (1 Type-C, 4 Front, 3 Rear)

Specification Unique Feature ASRock Super Alloy
- Premium 50A Power Choke
- Sapphire Black PCB
- High Density Glass Fabric PCB ASRock Intel 4-Layer Memory POOL (Planes on Outer Layers) Technology ASRock Ultra M.2 (PCIe Gen 3 x 4 & SATA3) ASRock Full Spike Protection ASRock Live Update & APP Shop CPU
- Supports 7th & 6th Generation Intel Core™ i 7/i 5/i 3/ Pentium/ Celeron Processors (Socket 1151)
- Digi Power design
- 6 Power Phase design
- Supports Intel Turbo Boost 2.0 Technology Chipset
- Intel H270 Memory
- Dual Channel DDR4 Memory Technology
- 4 x DDR4 DIMM Slots
- Supports DDR4 2400/2133 non-ECC, un-buffered memory*
- Supports ECC UDIMM memory modules (operate in non-ECC mode)
- Max. capacity of system memory: 64GB**
- Supports Intel Extreme Memory Profile (XMP) 2.0
- 15μ Gold Contact in DIMM Slots *7th Gen Intel CPU supports DDR4 up to 2400; 6th Gen Intel CPU supports DDR4 up to 2133. ** Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows 32-bit OS. For Windows 64-bit OS with 64-bit CPU, there is no such limitation. BIOS
- 128 Mb AMI UEFI Legal BIOS with multilingual GUI support
- ACPI 6.0 Compliant wake up events
- SMBIOS 2.7 Support
- CPU, GT_CPU, DRAM, PCH 1.0V, VCCIO, VCCSA, VCCST Voltage Multi-adjustment Graphics
- Supports Intel HD Graphics Built-in Visuals: Intel Quick Sync Video with AVC, MVC (S3D) & MPEG-2 Full HW Encode 1, Intel In Tru™ 3D, Intel Clear Video HD Technology, Intel Insider™, Intel HD Graphics
- Gen 9 LP, DX11.3, DX12
- HWAEncode/ Decode: VP8, HEVC 8b, VP9, HEVC 10b (For 7th Gen Intel CPU)
- HWA Encode/ Decode: VP8, HEVC 8b; GPU/SWEncode/ Decode: VP9, HEVC 10b (For 6th Gen Intel CPU)
- Max. shared memory 1024MB**
- Three graphics output options: D-Sub, DVI-D & HDMI
- Supports Triple Monitor
- Supports HDMI with max. resolution up to 4K x 2K (4096x 2160) @ 24 Hz / (3840x 2160) @ 30 Hz
- Supports DVI-D with max. resolution up to 1920x 1200 @ 60 Hz
- Supports D-Sub with max. resolution up to 1920x 1200 @ 60 Hz
- Supports Auto Lip Sync, Deep Color (12bpc), xv YCC & HBR (High Bit Rate Audio) with HDMI Port (Compliant HDMI monitor is required)
- Supports HDCP with DVI-D & HDMI Ports
- Supports Full HD 1080p Blu-ray (BD) playback with DVI-D & HDMI Ports * Intel HD Graphics Built-in Visuals & the VGA outputs can be supported only with processors which are GPU integrated. ** The size of maximum shared memory may vary from different operating systems. *** Due to chipset limitation, the Blu-ray playback of Intel HD Graphics is only supported under Windows 8 / 8 64-bit / 7 / 7 64-bit. **** Intel In Tru™ 3D is only supported under Windows 8 / 8 64-bit / 7 / 7 64-bit. Audio
- 7.1 CH HD Audio with Content Protection (Realtek ALC892 Audio Codec)*
- Premium Blu-ray Audio support
- Supports Surge Protection (ASRock Full Spike Protection)
- ELNA Audio Caps * To configure 7.1 CH HD Audio, it is required to use an HD front panel audio module & enable the multi-channel audio feature through the audio driver. LAN
- Gigabit LAN 10/100/1000 Mb/s
- Giga PHY Intel I219V
- Supports Wake-On-LAN
- Supports Lightning/ESD Protection (ASRock Full Spike Protection)
- Supports Energy Efficient Ethernet 802.3az
- Supports PXE Slots
- 2 x PCI Express 3.0 x 16 Slots (PCIE1: x 16 mode; PCIE4: x 4 mode)*
- 2 x PCI Express 3.0 x 1 Slots (Flexible PCIe)
- Supports AMD Quad Cross Fire X™ & Cross Fire X™ * Supports NVMe SSD as boot disks Storage
- 6 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1, RAID 5, RAID 10, Intel Rapid Storage Technology 15 & Intel Smart Response Technology), NCQ, AHCI & Hot Plug*
- 1 x Ultra M.2 Socket (M2_1), supports type 2230/2242/2260/2280 M.2 SATA3 6.0 Gb/s module & M.2 PCI Express module up to Gen 3 x 4 (32 Gb/s)**
- 1 x Ultra M.2 Socket (M2_2), supports type 2230/2242/2260/2280 M.2 PCI Express module up to Gen 3 x 4 (32 Gb/s)** * If M2_1 is occupied by a SATA-type M.2 device, SATA3_0 will be disabled. ** Supports Intel Optane™ Technology Supports NVMe SSD as boot disks Supports ASRock U.2 Kit Connector
- 1 x Print Port Header
- 1 x COM Port Header
- 1 x TPM Header
- 1 x Chassis Intrusion & Speaker Header
- 2 x CPU Fan Connectors (1 x 4-pin, 1 x 3-pin)*
- 2 x Chassis Fan Connectors (4-pin) (Smart Fan Speed Control)**
- 1 x 24 pin ATX Power Connector
- 1 x 8 pin 12V Power Connector
- 1 x Front Panel Audio Connector
- 2 x USB (Universal Serial Bus) 2.0 Headers (Support 4 USB (Universal Serial Bus) 2.0 ports) (Supports ESD Protection (ASRock Full Spike Protection))
- 2 x USB (Universal Serial Bus) 3.0 Headers (Support 4 USB (Universal Serial Bus) 3.0 ports) (Supports ESD Protection (ASRock Full Spike Protection)) * The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power. **CHA_FAN1 & CHA_FAN2 can auto detect if 3-pin or 4-pin fan is in use. Rear Panel I/O
- 1 x PS/2 Mouse Port
- 1 x PS/2 Keyboard Port
- 1 x D-Sub Port
- 1 x DVI-D Port
- 1 x HDMI Port
- 2 x USB (Universal Serial Bus) 2.0 Ports (Supports ESD Protection (ASRock Full Spike Protection))
- 3 x USB (Universal Serial Bus) 3.0 Type-A Ports (Supports ESD Protection (ASRock Full Spike Protection))
- 1 x USB (Universal Serial Bus) 3.0 Type-C Port (Supports ESD Protection (ASRock Full Spike Protection))
- 1 x RJ-45 LAN Port with LED (ACT/LINK LED & SPEED LED)
- HD Audio Jacks: Line in / Front Speaker / Microphone Software & UEFI Software
- ASRock A-Tuning
- ASRock APP Charger
- ASRock XFast LAN* UEFI
- ASRock EZ Mode
- ASRock Full HD UEFI
- ASRock My Favorites in UEFI
- ASRock Instant Flash
- ASRock Internet Flash
- ASRock Crashless BIOS
- ASRock UEFI System Browser
- ASRock UEFI Tech Service
- ASRock Easy RAID Installer * These utilities can be downloaded from ASRock Live Update & APP Shop. Support CD
- Drivers, Utilities, Anti Virus Software (Trial Version), Google Chrome Browser & Toolbar Accessories
- Quick Installation Guide, Support CD, I/O Shield
- 2 x SATA Data Cables
- 2 x Screws for M.2 Sockets Hardware Monitor
- CPU/ Chassis temperature sensing
- CPU/ Chassis Fan Tachometer
- CPU/ Chassis Quiet Fan (Auto adjust chassis fan speed by CPU temperature)
- CPU/ Chassis Fan multi-speed control
- CASE OPEN detection
- Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore, DRAM, PCH 1.0V Form Factor
- Micro ATX Form Factor: 9.6-in x 9.6-in, 24.4 cm x 24.4 cm
- Solid Capacitor design OS
- Microsoft Windows 10 64-bit (For 7th Gen Intel CPU)
- Microsoft Windows 10 64-bit / 8.1 64-bit / 7 32-bit / 7 64-bit (For 6th Gen Intel CPU)* * To install Windows 7 OS, a modified installation disk with x HCI drivers packed into the ISO file is required. Please check our User Manual for more detailed instructions. For the updated Windows 10 driver, please visit ASRock's website for details. Certifications
- FCC, CE, WHQL
- Er P/ Eu P ready (Er P/ Eu P ready power supply is required)


































































































...

Features Supports 8th Generation Intel Core™ Processors (Socket 1151) Supports DDR4 2666 1 PCIe 3.0 x 16, 1 PCIe 2.0 x 1 Graphics Output Options: DVI-D, D-Sub 7.1 CH HD Audio (Realtek ALC887 Audio Codec), ELNA Audio Caps 4 SATA3 4 USB (Universal Serial Bus) 3.1 Gen 1 (2 Front, 2 Rear) Supports Full Spike Protection, ASRock Live Update & APP Shop Overview HEVC 10-bit Decoding/ Encoding Supports HEVC 10-bit Decoding/ Encoding to provide substantially enhanced video quality & higher bit depth video experience. Solid Capacitor Design ASRock applied solid capacitors on this motherboard. With these solid caps, this motherboard is allowed to perform more stably & ensure longer lifetime. ELNA Audio Caps Who says high quality audio is only available on high-end motherboards? ASRock applied ELNA audio capacitors on mainstream & entry-level motherboards! Compared with traditional solid caps, the leakage current of ELNA audio caps is merely 3u A. This is the key to reduce noise level significantly & satisfy even the pickiest audiophiles. Water Pump Header This is not only a standard CPU fan header, but also supports water pumps! This header provides a maximum of 1.5A power for supporting the most popular water pumps. User also can adjust the voltage of water pump to get higher cooling performance with lower noise. Full Spike Protection Some sensitive digital components on the motherboard are vulnerable to power surges, the excessive current may cause your system to malfunction immediately. ASRock Full Spike Protection

Includes:: various technologies to prevent your motherboard’s components from being damaged by these unexpected voltage spikes.

Specification Unique Feature ASRock Super Alloy
- Sapphire Black PCB
- High Density Glass Fabric PCB ASRock Full Spike Protection (for all USB (Universal Serial Bus), Audio, LAN Ports) ASRock Live Update & APP Shop CPU
- Supports 8th Generation Intel Core™ Processors (Socket 1151)
- Supports CPU up to 95W
- 4 Power Phase design
- Supports Intel Turbo Boost 2.0 Technology Chipset
- Intel H310 Memory
- Dual Channel DDR4 Memory Technology
- 2 x DDR4 DIMM Slots
- Supports DDR4 2666 / 2400 / 2133 non-ECC, un-buffered memory
- Max. capacity of system memory: 32GB*
- Supports Intel Extreme Memory Profile (XMP) 2.0
- 15μ Gold Contact in DIMM Slots * Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows 32-bit OS. For Windows 64-bit OS with 64-bit CPU, there is no such limitation. BIOS
- 128 Mb AMI UEFI Legal BIOS with multilingual GUI support
- ACPI 6.0 Compliant wake up events
- SMBIOS 2.7 Support
- DRAM, PCH 1.05V Voltage Multi-adjustment Graphics
- Supports Intel UHD Graphics Built-in Visuals: Intel Quick Sync Video with AVC, MVC (S3D) & MPEG-2 Full HW Encode 1, Intel In Tru™ 3D, Intel Clear Video HD Technology, Intel Insider™, Intel UHD Graphics
- Direct X 12
- HWA Encode/ Decode: AVC/H.264, HEVC/H.265 8-bit, HEVC/H.265 10-bit, VP8, VP9 8-bit, VP9 10-bit (Decode only), MPEG2, MJPEG, VC-1 (Decode only)
- Dual graphics output: Support DVI-D & D-Sub ports by independent display controllers
- Supports DVI-D with max. resolution up to 1920x 1200 @ 60 Hz
- Supports D-Sub with max. resolution up to 1920x 1200 @ 60 Hz
- Supports HDCP with DVI-D Port * Intel UHD Graphics Built-in Visuals & the VGA outputs can be supported only with processors which are GPU integrated. Audio
- 7.1 CH HD Audio (Realtek ALC887 Audio Codec)*
- Supports Surge Protection
- ELNA Audio Caps * To configure 7.1 CH HD Audio, it is required to use an HD front panel audio module & enable the multi-channel audio feature through the audio driver. LAN
- PCIE x 1 Gigabit LAN 10/100/1000 Mb/s
- 1 x Realtek RTL8111H
- Supports Wake-On-LAN
- Supports Lightning/ESD Protection
- Supports Energy Efficient Ethernet 802.3az
- Supports PXE Slots
- 1 x PCI Express 3.0 x 16 Slot (PCIE2: x 16 mode)
- 1 x PCI Express 2.0 x 1 Slot * Supports NVMe SSD as boot disks Storage
- 4 x SATA3 6.0 Gb/s Connectors, support NCQ, AHCI & Hot Plug Connector
- 1 x TPM Header
- 1 x Chassis Intrusion & Speaker Header
- 1 x CPU Fan Connector (4-pin)*
- 1 x Chassis/ Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)**
- 1 x 24 pin ATX Power Connector
- 1 x 8 pin 12V Power Connector
- 1 x Front Panel Audio Connector
- 1 x USB (Universal Serial Bus) 2.0 Header (Supports 2 USB (Universal Serial Bus) 2.0 ports) (Supports ESD Protection)
- 1 x USB (Universal Serial Bus) 3.1 Gen 1 Header (Supports 2 USB (Universal Serial Bus) 3.1 Gen 1 ports) (Supports ESD Protection) * The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power. ** The Chassis/ Water Pump Fan supports the water cooler fan of maximum 2A (24W) fan power. CHA_FAN1/WP can auto detect if 3-pin or 4-pin fan is in use. Rear Panel I/O
- 1 x PS/2 Mouse/ Keyboard Port
- 1 x D-Sub Port
- 1 x DVI-D Port
- 4 x USB (Universal Serial Bus) 2.0 Ports (Supports ESD Protection)
- 2 x USB (Universal Serial Bus) 3.1 Gen 1 Ports (Supports ESD Protection)
- 1 x RJ-45 LAN Port with LED (ACT/LINK LED & SPEED LED)
- HD Audio Jacks: Line in / Front Speaker / Microphone Software & UEFI Software
- ASRock A-Tuning
- ASRock XFast LAN UEFI
- ASRock EZ Mode
- ASRock Full HD UEFI
- ASRock My Favorites in UEFI
- ASRock Instant Flash
- ASRock Internet Flash * These utilities can be downloaded from ASRock Live Update & APP Shop. Support CD
- Drivers, Utilities, Anti Virus Software (Trial Version), Google Chrome Browser & Toolbar Accessories
- Quick Installation Guide, Support CD, I/O Shield
- 2 x SATA Data Cables Hardware Monitor
- Temperature Sensing: CPU, Chassis/ Water Pump Fans
- Fan Tachometer: CPU, Chassis/ Water Pump Fans
- Quiet Fan (Auto adjust chassis fan speed by CPU temperature): CPU, Chassis/ Water Pump Fans
- Fan Multi-Speed Control: CPU, Chassis/ Water Pump Fans
- CASE OPEN detection
- Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore Form Factor
- Micro ATX Form Factor: 7.5-in x 7.4-in, 19.1 cm x 18.8 cm
- Solid Capacitor design OS
- Microsoft Windows 10 64-bit Certifications
- FCC, CE
- Er P/ Eu P ready (Er P/ Eu P ready power supply is required)












































































...

Features Supports 9th & 8th Gen Intel Core™ Processors (Socket 1151) Supports DDR4 2666 1 PCIe 3.0 x 16, 1 PCIe 2.0 x 1 Graphics Output Options: DVI-D, D-Sub, HDMI 7.1 CH HD Audio (Realtek ALC887 Audio Codec), ELNA Audio Caps 4 SATA3 4 USB (Universal Serial Bus) 3.1 Gen 1 (2 Front, 2 Rear) Supports Full Spike Protection, ASRock Live Update & APP Shop Overview HEVC 10-bit Decoding/ Encoding Supports HEVC 10-bit Decoding/ Encoding to provide substantially enhanced video quality & higher bit depth video experience. 4K x 2K Composed by a minimum of 3840 x 2160 pixels, which is twice the horizontal & vertical resolution of the 1080p format. 3 Graphics Outputs Complete with all three types of most used connectors! Packed with a D-Sub + DVI-D + HDMI combo. Plus the HDMI port supports 4K resolution. Water Pump Header This is not only a standard CPU fan header, but also supports water pumps! This header provides a maximum of 1.5A power for supporting the most popular water pumps. User also can adjust the voltage of water pump to get higher cooling performance with lower noise. ELNA Audio Caps Who says high quality audio is only available on high-end motherboards? ASRock applied ELNA audio capacitors on mainstream & entry-level motherboards! Compared with traditional solid caps, the leakage current of ELNA audio caps is merely 3u A. This is the key to reduce noise level significantly & satisfy even the pickiest audiophiles. Solid Capacitor Design ASRock applied solid capacitors on this motherboard. With these solid caps, this motherboard is allowed to perform more stably & ensure longer lifetime. A-Tuning A-Tuning is ASRocks multi purpose software suite with a new interface, more new features & enhanced utilities. Full Spike Protection Some sensitive digital components on the motherboard are vulnerable to power surges, the excessive current may cause your system to malfunction immediately. ASRock Full Spike Protection

Includes:: various technologies to prevent your motherboard’s components from being damaged by these unexpected voltage spikes. Live Update & APP Shop ASRock Live Update & APP Shop is designed for your convenience. We provide various apps & support software for users to download. You can also easily optimize your system & keep your motherboard up to date with ASRock Live Update & APP Shop.

Specification Unique Feature ASRock Super Alloy
- Sapphire Black PCB
- High Density Glass Fabric PCB ASRock Full Spike Protection (for all USB (Universal Serial Bus), Audio, LAN Ports) ASRock Live Update & APP Shop CPU
- Supports 9th & 8th Gen Intel Core™ Processors (Socket 1151)
- Supports CPU up to 95W
- 4 Power Phase design
- Supports Intel Turbo Boost 2.0 Technology Chipset
- Intel H310 Memory
- Dual Channel DDR4 Memory Technology
- 2 x DDR4 DIMM Slots
- Supports DDR4 2666 / 2400 / 2133 non-ECC, un-buffered memory
- Max. capacity of system memory: 64GB*
- Supports Intel Extreme Memory Profile (XMP) 2.0
- 15μ Gold Contact in DIMM Slots * Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows 32-bit OS. For Windows 64-bit OS with 64-bit CPU, there is no such limitation. BIOS
- 128 Mb AMI UEFI Legal BIOS with multilingual GUI support
- ACPI 6.0 Compliant wake up events
- SMBIOS 2.7 Support
- DRAM, PCH 1.05V Voltage Multi-adjustment Graphics
- Supports Intel UHD Graphics Built-in Visuals: Intel Quick Sync Video with AVC, MVC (S3D) & MPEG-2 Full HW Encode 1, Intel In Tru™ 3D, Intel Clear Video HD Technology, Intel Insider™, Intel UHD Graphics
- Direct X 12
- HWA Encode/ Decode: AVC/H.264, HEVC/H.265 8-bit, HEVC/H.265 10-bit, VP8, VP9 8-bit, VP9 10-bit (Decode only), MPEG2, MJPEG, VC-1
- Three graphics output options: D-Sub, DVI-D & HDMI**
- Supports HDMI 1.4 with max. resolution up to 4K x 2K (4096x 2160) @ 30 Hz
- Supports DVI-D with max. resolution up to 1920x 1200 @ 60 Hz
- Supports D-Sub with max. resolution up to 1920x 1200 @ 60 Hz
- Supports Auto Lip Sync, Deep Color (12bpc), xv YCC & HBR (High Bit Rate Audio) with HDMI 1.4 Port (Compliant HDMI monitor is required)
- Supports HDCP 2.2 with DVI-D & HDMI 1.4 Ports
- Supports 4K Ultra HD (UHD) playback with HDMI 1.4 Port * Intel UHD Graphics Built-in Visuals & the VGA outputs can be supported only with processors which are GPU integrated. ** Supports up to 2 displays simultaneously Audio
- 7.1 CH HD Audio (Realtek ALC887 Audio Codec)*
- Supports Surge Protection
- ELNA Audio Caps * To configure 7.1 CH HD Audio, it is required to use an HD front panel audio module & enable the multi-channel audio feature through the audio driver. LAN
- PCIE x 1 Gigabit LAN 10/100/1000 Mb/s
- 1 x Realtek RTL8111H
- Supports Wake-On-LAN
- Supports Lightning/ESD Protection
- Supports Energy Efficient Ethernet 802.3az
- Supports PXE Slots
- 1 x PCI Express 3.0 x 16 Slot (PCIE2: x 16 mode)*
- 1 x PCI Express 2.0 x 1 Slot * Supports NVMe SSD as boot disks Storage
- 4 x SATA3 6.0 Gb/s Connectors, support NCQ, AHCI & Hot Plug Connector
- 1 x TPM Header
- 1 x Chassis Intrusion & Speaker Header
- 1 x CPU Fan Connector (4-pin)*
- 1 x Chassis/ Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)**
- 1 x 24 pin ATX Power Connector
- 1 x 8 pin 12V Power Connector
- 1 x Front Panel Audio Connector
- 1 x USB (Universal Serial Bus) 2.0 Header (Supports 2 USB (Universal Serial Bus) 2.0 ports) (Supports ESD Protection)
- 1 x USB (Universal Serial Bus) 3.1 Gen 1 Header (Supports 2 USB (Universal Serial Bus) 3.1 Gen 1 ports) (Supports ESD Protection) * The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power. ** The Chassis/ Water Pump Fan supports the water cooler fan of maximum 2A (24W) fan power. CHA_FAN1/WP can auto detect if 3-pin or 4-pin fan is in use. Rear Panel I/O
- 1 x PS/2 Mouse/ Keyboard Port
- 1 x D-Sub Port
- 1 x DVI-D Port
- 1 x HDMI Port
- 4 x USB (Universal Serial Bus) 2.0 Ports (Supports ESD Protection)
- 2 x USB (Universal Serial Bus) 3.1 Gen 1 Ports (Supports ESD Protection)
- 1 x RJ-45 LAN Port with LED (ACT/LINK LED & SPEED LED)
- HD Audio Jacks: Line in / Front Speaker / Microphone Software & UEFI Software
- ASRock A-Tuning
- ASRock XFast LAN UEFI
- ASRock EZ Mode
- ASRock Full HD UEFI
- ASRock My Favorites in UEFI
- ASRock Instant Flash
- ASRock Internet Flash * These utilities can be downloaded from ASRock Live Update & APP Shop. Support CD
- Drivers, Utilities, Anti Virus Software (Trial Version), Google Chrome Browser & Toolbar Accessories
- Quick Installation Guide, Support CD, I/O Shield
- 2 x SATA Data Cables Hardware Monitor
- Temperature Sensing: CPU, Chassis/ Water Pump Fans
- Fan Tachometer: CPU, Chassis/ Water Pump Fans
- Quiet Fan (Auto adjust chassis fan speed by CPU temperature): CPU, Chassis/ Water Pump Fans
- Fan Multi-Speed Control: CPU, Chassis/ Water Pump Fans
- CASE OPEN detection
- Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore Form Factor
- Micro ATX Form Factor: 7.5-in x 7.4-in, 19.1 cm x 18.8 cm
- Solid Capacitor design OS
- Microsoft Windows 10 64-bit Certifications
- FCC, CE















































































...

Features Supports 9th & 8th Gen Intel Core™ Processors (Socket 1151) Supports DDR4 2666 1 PCIe 3.0 x 16, 2 PCIe 2.0 x 1 AMD Quad Cross Fire X™ Graphics Output Options: HDMI, DVI-D, D-Sub 7.1 CH HD Audio (Realtek ALC887 Audio Codec), ELNA Audio Caps 4 SATA3, 1 M.2 (PCIe Gen 2 x 4 & SATA3) 4 USB (Universal Serial Bus) 3.1 Gen 1 (2 Front, 2 Rear) Intel Gigabit LAN PCIe Gen 2 x 4 M.2 The PCIe Gen 2 x 4 interface pushes data transfer speeds up to 20 Gb/s. In addition, it also supports SATA 3 6 Gb/s M.2 modules, & is compatible with ASRock’s U.2 Kit for installing some U.2 SSDs. Intel LAN Intel LAN provides the best throughput performance, lower CPU utilization, enhanced stability & is able to deliver ultimate network experience to users! 3 Graphics Outputs Complete with all three types of most used connectors! Packed with a D-Sub + DVI-D + HDMI combo. Plus the HDMI port supports 4K resolution. 4K x 2K Composed by a minimum of 3840 x 2160 pixels, which is twice the horizontal & vertical resolution of the 1080p format. ELNA Audio Caps Who says high quality audio is only available on high-end motherboards? ASRock applied ELNA audio capacitors on mainstream & entry-level motherboards! Compared with traditional solid caps, the leakage current of ELNA audio caps is merely 3u A. This is the key to reduce noise level significantly & satisfy even the pickiest audiophiles. A-Tuning A-Tuning is ASRocks multi purpose software suite with a new interface, more new features & enhanced utilities. Full Spike Protection Some sensitive digital components on the motherboard are vulnerable to power surges, the excessive current may cause your system to malfunction immediately. ASRock Full Spike Protection

Includes:: various technologies to prevent your motherboard’s components from being damaged by these unexpected voltage spikes. Live Update & APP Shop ASRock Live Update & APP Shop is designed for your convenience. We provide various apps & support software for users to download. You can also easily optimize your system & keep your motherboard up to date with ASRock Live Update & APP Shop. Specifications Unique Feature ASRock Super Alloy
- Sapphire Black PCB
- High Density Glass Fabric PCB ASRock Full Spike Protection (for all USB (Universal Serial Bus), Audio, LAN Ports) ASRock Live Update & APP Shop CPU
- Supports 9th & 8th Gen Intel Core™ Processors (Socket 1151)
- Supports CPU up to 95W
- 4 Power Phase design
- Supports Intel Turbo Boost 2.0 Technology Chipset
- Intel H310 Memory
- Dual Channel DDR4 Memory Technology
- 2 x DDR4 DIMM Slots
- Supports DDR4 2666 / 2400 / 2133 non-ECC, un-buffered memory
- Max. capacity of system memory: 32GB*
- Supports Intel Extreme Memory Profile (XMP) 2.0
- 15μ Gold Contact in DIMM Slots * Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows 32-bit OS. For Windows 64-bit OS with 64-bit CPU, there is no such limitation. BIOS
- 128 Mb AMI UEFI Legal BIOS with multilingual GUI support
- ACPI 6.0 Compliant wake up events
- SMBIOS 2.7 Support
- CPU, GT_CPU, DRAM, PCH 1.05V Voltage Multi-adjustment Graphics
- Supports Intel UHD Graphics Built-in Visuals: Intel Quick Sync Video with AVC, MVC (S3D) & MPEG-2 Full HW Encode 1, Intel In Tru™ 3D, Intel Clear Video HD Technology, Intel Insider™, Intel UHD Graphics
- Direct X 12
- HWA Encode/ Decode: AVC/H.264, HEVC/H.265 8-bit, HEVC/H.265 10-bit, VP8, VP9 8-bit, VP9 10-bit (Decode only), MPEG2, MJPEG, VC-1
- Three graphics output options: D-Sub, DVI-D & HDMI**
- Supports HDMI 1.4 with max. resolution up to 4K x 2K (4096x 2160) @ 30 Hz
- Supports DVI-D with max. resolution up to 1920x 1200 @ 60 Hz
- Supports D-Sub with max. resolution up to 1920x 1200 @ 60 Hz
- Supports Auto Lip Sync, Deep Color (12bpc), xv YCC & HBR (High Bit Rate Audio) with HDMI 1.4 Port (Compliant HDMI monitor is required)
- Supports HDCP 2.2 with DVI-D & HDMI 1.4 Ports
- Supports 4K Ultra HD (UHD) playback with HDMI 1.4 Port * Intel UHD Graphics Built-in Visuals & the VGA outputs can be supported only with processors which are GPU integrated. ** Supports up to 2 displays simultaneously Audio
- 7.1 CH HD Audio (Realtek ALC887 Audio Codec)*
- Supports Surge Protection
- ELNA Audio Caps * To configure 7.1 CH HD Audio, it is required to use an HD front panel audio module & enable the multi-channel audio feature through the audio driver. LAN
- Gigabit LAN 10/100/1000 Mb/s
- Giga PHY Intel I219V
- Supports Wake-On-LAN
- Supports Lightning/ESD Protection
- Supports Energy Efficient Ethernet 802.3az
- Supports PXE Slots
- 1 x PCI Express 3.0 x 16 Slot (PCIE1: x 16 mode)*
- 2 x PCI Express 2.0 x 1 Slots * Supports NVMe SSD as boot disks Storage
- 4 x SATA3 6.0 Gb/s Connectors, support NCQ, AHCI & Hot Plug*
- 1 x M.2 Socket (M2_1), supports M Key type 2230/2242/2260/2280 M.2 SATA3 6.0 Gb/s module & M.2 PCI Express module up to Gen 2 x 4 (20 Gb/s)** * If M2_1 is occupied by a SATA-type M.2 device, SATA3_3 will be disabled. ** Supports NVMe SSD as boot disks Supports ASRock U.2 Kit Connector
- 1 x Print Port Header
- 1 x COM Port Header
- 1 x TPM Header
- 1 x Chassis Intrusion & Speaker Header
- 1 x CPU Fan Connector (4-pin)*
- 2 x Chassis/ Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)**
- 1 x 24 pin ATX Power Connector
- 1 x 8 pin 12V Power Connector
- 1 x Front Panel Audio Connector
- 2 x USB (Universal Serial Bus) 2.0 Headers (Support 4 USB (Universal Serial Bus) 2.0 ports) (Supports ESD Protection)
- 1 x USB (Universal Serial Bus) 3.1 Gen 1 Header (Supports 2 USB (Universal Serial Bus) 3.1 Gen 1 ports) (Supports ESD Protection)*** * The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power. ** The Chassis/ Water Pump Fan supports the water cooler fan of maximum 2A (24W) fan power. CHA_FAN1/WP & CHA_FAN2/WP can auto detect if 3-pin or 4-pin fan is in use. ***USB_11_12 is shared with USB_9_10. Rear Panel I/O
- 1 x PS/2 Mouse/ Keyboard Port
- 1 x D-Sub Port
- 1 x DVI-D Port
- 1 x HDMI Port
- 4 x USB (Universal Serial Bus) 2.0 Ports (Supports ESD Protection)
- 2 x USB (Universal Serial Bus) 3.1 Gen 1 Ports (Supports ESD Protection)
- 1 x RJ-45 LAN Port with LED (ACT/LINK LED & SPEED LED)
- HD Audio Jacks: Line in / Front Speaker / Microphone Software & UEFI Software
- ASRock A-Tuning
- ASRock XFast LAN UEFI
- ASRock EZ Mode
- ASRock Full HD UEFI
- ASRock My Favorites in UEFI
- ASRock Instant Flash
- ASRock Internet Flash * These utilities can be downloaded from ASRock Live Update & APP Shop. Support CD
- Drivers, Utilities, Anti Virus Software (Trial Version), Google Chrome Browser & Toolbar Accessories
- Quick Installation Guide, Support CD, I/O Shield
- 2 x SATA Data Cables
- 1 x Screw for M.2 Socket Hardware Monitor
- Temperature Sensing: CPU, Chassis/ Water Pump Fans
- Fan Tachometer: CPU, Chassis/ Water Pump Fans
- Quiet Fan (Auto adjust chassis fan speed by CPU temperature): CPU, Chassis/ Water Pump Fans
- Fan Multi-Speed Control: CPU, Chassis/ Water Pump Fans
- CASE OPEN detection
- Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore, DRAM, PCH 1.0V Form Factor
- Micro ATX Form Factor: 8.9-in x 7.4-in, 22.6 cm x 18.8 cm
- Solid Capacitor design OS
- Microsoft Windows 10 64-bit Certifications
- FCC, CE
- Er P/ Eu P ready (Er P/ Eu P ready power supply is required)


















































































...

Features Supports 8th Generation Intel Core™ Processors (Socket 1151) Supports DDR4 2666 1 PCIe 3.0 x 16, 1 PCIe 2.0 x 1 Graphics Output Options: DVI-D, D-Sub, HDMI 7.1 CH HD Audio (Realtek ALC887 Audio Codec), ELNA Audio Caps 4 SATA3 4 USB (Universal Serial Bus) 3.1 Gen 1 (2 Front, 2 Rear) Supports Full Spike Protection, ASRock Live Update & APP Shop Overview 3 Graphics Outputs Complete with all three types of most used connectors! Packed with a D-Sub + DVI-D + HDMI combo. Plus the HDMI port supports 4K resolution. ELNA Audio Caps Who says high quality audio is only available on high-end motherboards? ASRock applied ELNA audio capacitors on mainstream & entry-level motherboards! Compared with traditional solid caps, the leakage current of ELNA audio caps is merely 3u A. This is the key to reduce noise level significantly & satisfy even the pickiest audiophiles. Solid Capacitor Design ASRock applied solid capacitors on this motherboard. With these solid caps, this motherboard is allowed to perform more stably & ensure longer lifetime. Water Pump Header This is not only a standard CPU fan header, but also supports water pumps! This header provides a maximum of 1.5A power for supporting the most popular water pumps. User also can adjust the voltage of water pump to get higher cooling performance with lower noise. Full Spike Protection Some sensitive digital components on the motherboard are vulnerable to power surges, the excessive current may cause your system to malfunction immediately. ASRock Full Spike Protection

Includes:: various technologies to prevent your motherboard’s components from being damaged by these unexpected voltage spikes. A-Tuning A-Tuning is ASRocks multi purpose software suite with a new interface, more new features & enhanced utilities. Live Update & APP Shop ASRock Live Update & APP Shop is designed for your convenience. We provide various apps & support software for users to download. You can also easily optimize your system & keep your motherboard up to date with ASRock Live Update & APP Shop.

Specification nique Feature ASRock Super Alloy
- Sapphire Black PCB
- High Density Glass Fabric PCB ASRock Full Spike Protection (for all USB (Universal Serial Bus), Audio, LAN Ports) ASRock Live Update & APP Shop CPU
- Supports 8th Generation Intel Core™ Processors (Socket 1151)
- Supports CPU up to 95W
- 5 Power Phase design
- Supports Intel Turbo Boost 2.0 Technology Chipset
- Intel H310 Memory
- Dual Channel DDR4 Memory Technology
- 2 x DDR4 DIMM Slots
- Supports DDR4 2666 / 2400 / 2133 non-ECC, un-buffered memory
- Max. capacity of system memory: 32GB*
- Supports Intel Extreme Memory Profile (XMP) 2.0
- 15μ Gold Contact in DIMM Slots * Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows 32-bit OS. For Windows 64-bit OS with 64-bit CPU, there is no such limitation. BIOS
- 128 Mb AMI UEFI Legal BIOS with multilingual GUI support
- ACPI 6.0 Compliant wake up events
- SMBIOS 2.7 Support
- DRAM, PCH 1.05V Voltage Multi-adjustment Graphics
- Supports Intel UHD Graphics Built-in Visuals: Intel Quick Sync Video with AVC, MVC (S3D) & MPEG-2 Full HW Encode 1, Intel In Tru™ 3D, Intel Clear Video HD Technology, Intel Insider™, Intel UHD Graphics
- Direct X 12
- HWAEncode/ Decode: AVC/H.264, HEVC/H.265 8-bit, HEVC/H.265 10-bit, VP8, VP9 8-bit, VP9 10-bit (Decode only), MPEG2, MJPEG, VC-1 (Decode only)
- Three graphics output options: D-Sub, DVI-D & HDMI**
- Supports HDMI with max. resolution up to 4K x 2K (4096x 2160) @ 30 Hz
- Supports DVI-D with max. resolution up to 1920x 1200 @ 60 Hz
- Supports D-Sub with max. resolution up to 1920x 1200 @ 60 Hz
- Supports Auto Lip Sync, Deep Color (12bpc), xv YCC & HBR (High Bit Rate Audio) with HDMI Port (Compliant HDMI monitor is required)
- Supports HDCP with DVI-D & HDMI Ports
- Supports 4K Ultra HD (UHD) playback with HDMI Port * Intel UHD Graphics Built-in Visuals & the VGA outputs can be supported only with processors which are GPU integrated. ** Supports up to 2 displays simultaneously Audio
- 7.1 CH HD Audio (Realtek ALC887 Audio Codec)*
- Supports Surge Protection
- ELNA Audio Caps * To configure 7.1 CH HD Audio, it is required to use an HD front panel audio module & enable the multi-channel audio feature through the audio driver. LAN
- PCIE x 1 Gigabit LAN 10/100/1000 Mb/s
- 1 x Realtek RTL8111H
- Supports Wake-On-LAN
- Supports Lightning/ESD Protection
- Supports Energy Efficient Ethernet 802.3az
- Supports PXE Slots
- 1 x PCI Express 3.0 x 16 Slot (PCIE2: x 16 mode)*
- 1 x PCI Express 2.0 x 1 Slot * Supports NVMe SSD as boot disks Storage
- 4 x SATA3 6.0 Gb/s Connectors, support NCQ, AHCI & Hot Plug Connector
- 1 x TPM Header
- 1 x Chassis Intrusion & Speaker Header
- 1 x CPU Fan Connector (4-pin)
- 1 x Chassis/ Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)**
- 1 x 24 pin ATX Power Connector
- 1 x 8 pin 12V Power Connector
- 1 x Front Panel Audio Connector
- 1 x USB (Universal Serial Bus) 2.0 Header (Supports 2 USB (Universal Serial Bus) 2.0 ports) (Supports ESD Protection)
- 1 x USB (Universal Serial Bus) 3.1 Gen 1 Header (Supports 2 USB (Universal Serial Bus) 3.1 Gen 1 ports) (Supports ESD Protection) * The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power. ** The Chassis/ Water Pump Fan supports the water cooler fan of maximum 2A (24W) fan power. CHA_FAN1/WP can auto detect if 3-pin or 4-pin fan is in use. Rear Panel I/O
- 1 x PS/2 Mouse/ Keyboard Port
- 1 x D-Sub Port
- 1 x DVI-D Port
- 1 x HDMI Port
- 4 x USB (Universal Serial Bus) 2.0 Ports (Supports ESD Protection)
- 2 x USB (Universal Serial Bus) 3.1 Gen 1 Ports (Supports ESD Protection)
- 1 x RJ-45 LAN Port with LED (ACT/LINK LED & SPEED LED)
- HD Audio Jacks: Line in / Front Speaker / Microphone Software & UEFI Software
- ASRock A-Tuning
- ASRock XFast LAN UEFI
- ASRock EZ Mode
- ASRock Full HD UEFI
- ASRock My Favorites in UEFI
- ASRock Instant Flash
- ASRock Internet Flash * These utilities can be downloaded from ASRock Live Update & APP Shop. Support CD
- Drivers, Utilities, Anti Virus Software (Trial Version), Google Chrome Browser & Toolbar Accessories
- Quick Installation Guide, Support CD, I/O Shield
- 2 x SATA Data Cables Hardware Monitor
- Temperature Sensing: CPU, Chassis/ Water Pump Fans
- Fan Tachometer: CPU, Chassis/ Water Pump Fans
- Quiet Fan (Auto adjust chassis fan speed by CPU temperature): CPU, Chassis/ Water Pump Fans
- Fan Multi-Speed Control: CPU, Chassis/ Water Pump Fans
- CASE OPEN detection
- Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore Form Factor
- Micro ATX Form Factor: 7.5-in x 7.4-in, 19.1 cm x 18.8 cm
- Solid Capacitor design OS
- Microsoft Windows 10 64-bit Certifications
- FCC, CE
- Er P/ Eu P ready (Er P/ Eu P ready power supply is required)
















































































...

Features Supports 8th Generation Intel Core™ Processors (Socket 1151) Supports DDR4 2666 1 PCIe 3.0 x 16, 2 PCIe 2.0 x 1 AMD Quad Cross Fire X™ Graphics Output Options: HDMI, DVI-D, D-Sub 7.1 CH HD Audio (Realtek ALC887 Audio Codec), ELNA Audio Caps 4 SATA3, 1 M.2 (PCIe Gen 2 x 4 & SATA3) 4 USB (Universal Serial Bus) 3.1 Gen 1 (2 Front, 2 Rear) Intel Gigabit LAN Overview PCIe Gen 2 x 4 M.2 The PCIe Gen 2 x 4 interface pushes data transfer speeds up to 20 Gb/s. In addition, it also supports SATA 3 6 Gb/s M.2 modules, & is compatible with ASRock’s U.2 Kit for installing some U.2 SSDs. 4K x 2K Composed by a minimum of 3840 x 2160 pixels, which is twice the horizontal & vertical resolution of the 1080p format. 3 Graphics Outputs Complete with all three types of most used connectors! Packed with a D-Sub + DVI-D + HDMI combo. Plus the HDMI port supports 4K resolution. ELNA Audio Caps Who says high quality audio is only available on high-end motherboards? ASRock applied ELNA audio capacitors on mainstream & entry-level motherboards! Compared with traditional solid caps, the leakage current of ELNA audio caps is merely 3u A. This is the key to reduce noise level significantly & satisfy even the pickiest audiophiles. A-Tuning A-Tuning is ASRocks multi purpose software suite with a new interface, more new features & enhanced utilities. Full Spike Protection Some sensitive digital components on the motherboard are vulnerable to power surges, the excessive current may cause your system to malfunction immediately. ASRock Full Spike Protection

Includes:: various technologies to prevent your motherboard’s components from being damaged by these unexpected voltage spikes. Live Update & APP Shop ASRock Live Update & APP Shop is designed for your convenience. We provide various apps & support software for users to download. You can also easily optimize your system & keep your motherboard up to date with ASRock Live Update & APP Shop.

Specification Unique Feature ASRock Super Alloy
- Sapphire Black PCB
- High Density Glass Fabric PCB ASRock Full Spike Protection (for all USB (Universal Serial Bus), Audio, LAN Ports) ASRock Live Update & APP Shop CPU
- Supports 8th Generation Intel Core™ Processors (Socket 1151)
- Supports CPU up to 95W
- 5 Power Phase design
- Supports Intel Turbo Boost 2.0 Technology Chipset
- Intel H310 Memory
- Dual Channel DDR4 Memory Technology
- 2 x DDR4 DIMM Slots
- Supports DDR4 2666 / 2400 / 2133 non-ECC, un-buffered memory
- Max. capacity of system memory: 32GB*
- Supports Intel Extreme Memory Profile (XMP) 2.0
- 15μ Gold Contact in DIMM Slots * Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows 32-bit OS. For Windows 64-bit OS with 64-bit CPU, there is no such limitation. BIOS
- 128 Mb AMI UEFI Legal BIOS with multilingual GUI support
- ACPI 6.0 Compliant wake up events
- SMBIOS 2.7 Support
- CPU, GT_CPU, DRAM, PCH 1.05V Voltage Multi-adjustment Graphics
- Supports Intel UHD Graphics Built-in Visuals: Intel Quick Sync Video with AVC, MVC (S3D) & MPEG-2 Full HW Encode 1, Intel In Tru™ 3D, Intel Clear Video HD Technology, Intel Insider™, Intel UHD Graphics
- Direct X 12
- HWA Encode/ Decode: AVC/H.264, HEVC/H.265 8-bit, HEVC/H.265 10-bit, VP8, VP9 8-bit, VP9 10-bit (Decode only), MPEG2, MJPEG, VC-1 (Decode only)
- Three graphics output options: D-Sub, DVI-D & HDMI**
- Supports HDMI with max. resolution up to 4K x 2K (4096x 2160) @ 30 Hz
- Supports DVI-D with max. resolution up to 1920x 1200 @ 60 Hz
- Supports D-Sub with max. resolution up to 1920x 1200 @ 60 Hz
- Supports Auto Lip Sync, Deep Color (12bpc), xv YCC & HBR (High Bit Rate Audio) with HDMI Port (Compliant HDMI monitor is required)
- Supports HDCP with DVI-D & HDMI Ports
- Supports 4K Ultra HD (UHD) playback with HDMI Port * Intel UHD Graphics Built-in Visuals & the VGA outputs can be supported only with processors which are GPU integrated. ** Supports up to 2 displays simultaneously Audio
- 7.1 CH HD Audio (Realtek ALC887 Audio Codec)*
- Supports Surge Protection
- ELNA Audio Caps * To configure 7.1 CH HD Audio, it is required to use an HD front panel audio module & enable the multi-channel audio feature through the audio driver. LAN
- Gigabit LAN 10/100/1000 Mb/s
- Giga PHY Intel I219V
- Supports Wake-On-LAN
- Supports Lightning/ESD Protection
- Supports Energy Efficient Ethernet 802.3az
- Supports PXE Slots
- 1 x PCI Express 3.0 x 16 Slot (PCIE1: x 16 mode)*
- 2 x PCI Express 2.0 x 1 Slots * Supports NVMe SSD as boot disks Storage
- 4 x SATA3 6.0 Gb/s Connectors, support NCQ, AHCI & Hot Plug*
- 1 x M.2 Socket (M2_1), supports M Key type 2230/2242/2260/2280 M.2 SATA3 6.0 Gb/s module & M.2 PCI Express module up to Gen 2 x 4 (20 Gb/s)** * If M2_1 is occupied by a SATA-type M.2 device, SATA3_3 will be disabled. ** Supports NVMe SSD as boot disks Supports ASRock U.2 Kit Connector
- 1 x Print Port Header
- 1 x COM Port Header
- 1 x TPM Header
- 1 x Chassis Intrusion & Speaker Header
- 1 x CPU Fan Connector (4-pin)*
- 2 x Chassis/ Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)**
- 1 x 24 pin ATX Power Connector
- 1 x 8 pin 12V Power Connector
- 1 x Front Panel Audio Connector
- 2 x USB (Universal Serial Bus) 2.0 Headers (Support 4 USB (Universal Serial Bus) 2.0 ports) (Supports ESD Protection)
- 1 x USB (Universal Serial Bus) 3.1 Gen 1 Header (Supports 2 USB (Universal Serial Bus) 3.1 Gen 1 ports) (Supports ESD Protection)*** * The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power. ** The Chassis/ Water Pump Fan supports the water cooler fan of maximum 2A (24W) fan power. CHA_FAN1/WP & CHA_FAN2/WP can auto detect if 3-pin or 4-pin fan is in use. ***USB_11_12 is shared with USB_9_10. Rear Panel I/O
- 1 x PS/2 Mouse/ Keyboard Port
- 1 x D-Sub Port
- 1 x DVI-D Port
- 1 x HDMI Port
- 4 x USB (Universal Serial Bus) 2.0 Ports (Supports ESD Protection)
- 2 x USB (Universal Serial Bus) 3.1 Gen 1 Ports (Supports ESD Protection)
- 1 x RJ-45 LAN Port with LED (ACT/LINK LED & SPEED LED)
- HD Audio Jacks: Line in / Front Speaker / Microphone Software & UEFI Software
- ASRock A-Tuning
- ASRock XFast LAN UEFI
- ASRock EZ Mode
- ASRock Full HD UEFI
- ASRock My Favorites in UEFI
- ASRock Instant Flash
- ASRock Internet Flash * These utilities can be downloaded from ASRock Live Update & APP Shop. Support CD
- Drivers, Utilities, Anti Virus Software (Trial Version), Google Chrome Browser & Toolbar Accessories
- Quick Installation Guide, Support CD, I/O Shield
- 2 x SATA Data Cables
- 1 x Screw for M.2 Socket Hardware Monitor
- Temperature Sensing: CPU, Chassis/ Water Pump Fans
- Fan Tachometer: CPU, Chassis/ Water Pump Fans
- Quiet Fan (Auto adjust chassis fan speed by CPU temperature): CPU, Chassis/ Water Pump Fans
- Fan Multi-Speed Control: CPU, Chassis/ Water Pump Fans
- CASE OPEN detection
- Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore, DRAM, PCH 1.05V Form Factor
- Micro ATX Form Factor: 8.9-in x 7.4-in, 22.6 cm x 18.8 cm
- Solid Capacitor design OS
- Microsoft Windows 10 64-bit Certifications
- FCC, CE
- Er P/ Eu P ready (Er P/ Eu P ready power supply is required)




















































































...
