Aerocool launched brand new Integrator power supply series aim to mainstream computing systems. Numbers of SATA connectors for RAID storage, up to 85% efficiency for power saving, & single +12V rail for extreme CPU/GPU power consumption. Good DC quality with lower ripple & noise, & fully protect functions to guard your components in system. No more headache to install by long 20+4P & 4+4P up to 550mm. KEY FEATURES Black Outlook
- Elegant black PSU casing with fully black mesh cables. ATX12V ver.2.31
- Compliant with ATX12V Ver.2.3. High Efficiency
- High efficiency PSU
- up to 85% efficiency. Single 12V Rail
- Single 12V rail for high compatibility & extreme high current output. Long Cabling
- Main cable length up to 550mm is easy for high-end tower chassis installation. One PCIe
- One PCIe 6+2pin connector for mid-range graphic card. 6 SATA
- Up to 6 SATA connectors supports for numbers of hard drives. 12cm Silent Fan
- 12cm silent black fan with smart thermal fan speed control circuit. Fully Protection
- Fully protection functions with OVP/UVP/OPP/SCP/SIP. Fully Safety
- Safety & EMC certified by CE & TUV. ECO friendly
- ECO friendly by Ro HS & Erp 2013 directives.











...

Aerocool launched brand new Integrator power supply series aim to mainstream computing systems. Numbers of SATA connectors for RAID storage, up to 85% efficiency for power saving, & single +12V rail for extreme CPU/GPU power consumption. Good DC quality with lower ripple & noise, & fully protect functions to guard your components in system. No more headache to install by long 20+4P & 4+4P up to 550mm. Features Black Outlook
- Elegant black PSU casing with fully black mesh cables ATX12V ver.2.31
- Compliant with ATX12V Ver.2.3; Noise: < 29 d BA High Efficiency
- High efficiency PSU
- up to 85% in efficiency Single 12V Rail
- Single 12V rail for high compatibility & extreme high current output Long Cabling
- Main cable length up to 550mm is easy for high-end tower chassis installation One PCIe
- One PCIe 6+2pin connector for mid-range graphic card 6 SATA
- Up to 6 SATA connectors supports for numbers of hard drives 12cm Silent Fan
- 12cm silent black fan with smart thermal fan speed control circuit *DOES NOT CONTAIN MAINS SUPLY LEAD*








...

Aerocool Integrator 600W 80+ Certified PSU 12cm Black Fan Active PFC TW Caps UK Cable Connectors 20+4 Pin Main Connectors: 1 4+4 Pin 12V Connectors: 1 SATA Connectors: 7 4-Pin Molex Connectors: 4 6+2 Pin PCI-e Connectors: 2 Floppy Drive Connectors: 1 Detailed Specifications Dimensions: 150mm x 85mm x 140mm (W x H x D) Input Voltage: 230 VAC Input Current: 4.5A Input Frequency Range: 47-53 Hz PFC: Active PFC (>.99) Power Good Signal: 100-500 ms Hold Up Time: >17ms Efficiency: > 81% (85% max) MTBF: > 100, 000 Hours Protection: OVP / UVP / OPP / OTP / SCP / SIP Power: 600W Operation Temperature: 0-40°C Safety: CE/FCC/TUV/CB Cooling: 12cm Fan Noise: < 26 d BA 80 Plus Certified: Yes
- 80 Plus
...

Aerocool Integrator 700W 80+ Certified PSU 12cm Black Fan Active PFC TW Caps UK Cable 20+4 Pin Main Connectors: 1 4+4 Pin 12V Connectors: 1 SATA Connectors: 7 4-Pin Molex Connectors: 4 6+2 Pin PCI-e Connectors: 2 Floppy Drive Connectors: 1 ...

Aerocool Integrator 850W PSU 12cm Black Fan Active PFC TW Caps UK Cable Integrator 850W The most powerful 850W PSU of Integrator series by Aerocool is the 80 Plus Bronze certified power supply. The most valuable & suitable PC energy component for gamers & system integrators is featuring a 12cm thermal control silent fan, clean DC quality with low ripple noise, & a number of connectors with cable mesh. Key Features ATX12V Ver.2.4
- Compliant with latest INTEL ATX12V Ver.2.4 design guide. 80 Plus Bronze
- Up to 85%+ efficiency with official 80 Plus Bronze certificate. Cable mesh sleeving
- All direct DC cables with mesh sleeving for reduce airflow interference. Support INTEL C6/C7 power saving mode
- Support latest INTEL 4th generation HASWELL CPU with C6/C7 power saving mode. Single 12V rail
- Single 12V rail for high compatibility & extreme high current output. Clean & stable DC output quality
- Clear & pure DC output quality with low ripple noise. 550mm main cable length
- 20+4P & CPU 4+4P cable length up to 550mm
- easy reach to all components. 2 PCIe 6+2pin
- 2 PCIe 6+2pin connectors for high-end graphic card. 7 SATA for huge storage
- Up to 7 SATA connectors supports multiple of hard drives. 12cm silent cooling fan
- 12cm silent cooling fan with smart thermal fan speed control circuit. OVP/UVP/OPP/SCP/SIP
- Complete protections with OVP/UVP/OPP/SCP/SIP. CE, CB & TUV
- Safety & EMC certified by CE, CB & TUV. Ro HS & Er P 2013
- ECO friendly with Active PFC, Ro HS & Er P 2013. 2 Years Warranty PSU Specifications AC INPUT: 230 VAC 5A 50 Hz DC +3.3V +5V +12V1 -12V +5VSB Output 24A 20A 65A 0.3A 3A Max 850W Connectors 20+4 Pin Main Connectors: 1 4+4 Pin 12V Connectors: 1 SATA Connectors: 7 4-Pin Molex Connectors: 4 6+2 Pin PCI-e Connectors: 2 Floppy Drive Connectors: 1 Specifications Dimensions: 150mm x 86mm x 140mm (W x H x D) Input Voltage: 230 VAC Input Current: 5A Input Frequency Range: 50 Hz PFC: Active PFC (>.99) Power Good Signal: 100-500 ms Hold Up Time: >17ms Efficiency: >82% MTBF: > 100, 000 Hours Protection: OVP/UVP/OPP/SCP/SIP Power: 850W Operation Temperature: 0-40°C Safety: CE / CB / TUV Cooling: 120mm silent fan with therrnal fan speed control Noise: < 23 d BA 80 Plus Certified: Yes
- 80 Plus Bronze














...

Aerocool’s Integrator MX series is the latest high-efficient Semi-Modular power supply. The most valuable & suitable PC energy component for gamers & system integrators & it features a 12cm thermal control silent fan hich gives the user clean DC quality with low ripple noise & a number of connectors with cable mesh. Key Features Semi-modular cable management by user’s system configuration. Elegant Black PSU casing with Fully Black Mesh cables. Compliant with ATX12V Ver.2.4. Fully compatible with the latest generation Intel Core series processors starting from the 4th Generation CPU Intel ‘ Haswell’ platform’s C6/C7 power saving mode. Up to 88%+ efficiency with official 80 Plus 230V EU Bronze certificate. Single 12V rail for high compatibility & extreme high current output. 20 + 4 Pin & CPU 4 + 4 Pin cable length up to 550mm
- easy reach to all components. Two PCIe 6 + 2 Pin connectors for mid-range graphic cards. Up to 7 SATA connectors supports multiple hard drives. Complete protections with OVP / UVP / OPP / SCP / SIP. Safety & EMC certified by CE & TUV. ECO friendly with Ro HS & Erp 2014 directives.
...

Aerocool Lightning Series Transparent 12cm Blue LED Fan Key

Features: Transparent black frame & transparent

...

Aerocool Lightning Series Transparent 12cm Red LED Fan Key Features Transparent black frame & transparent red blades with quad red LEDs. 7 fan blade design generates a sturdy high air pressure & air flow. Anti-vibration screws included to assorb vibration caused by spinning action. 3-pin to 4-pin adaptor included. Specifications

Dimensions: 120 X 120 X 25mm Rated Voltage: DC 12V Starting Voltage: 6V Power Consumption: 3W Rated Current: 0.25±0.05A Speed: 1200±10% RPM Air Flow: 41.40CFM Air Pressure: 1.32mm-H2O Noise: 22.5d B (A) MTBF: 20, 000 Hours

...

Aerocool Lightning Series Transparent 14cm Blue LED Fan Key Features Transparent black frame & transparent blue blades with quad blue LEDs. 11 fan blade design generates a sturdy high air pressure & air flow. Anti-vibration screws included to assorb vibration caused by spinning action. 3-pin to 4-pin adaptor included. Specifications

Dimensions: 140 X 140 X 25mm Rated Voltage: DC 12V Starting Voltage: 7V Power Consumption: 3W Rated Current: 0.25±0.05A Speed: 1200±10% RPM Air Flow: 48CFM Air Pressure: 1.52mm-H2O Noise: 22d B (A) MTBF: 20, 000 Hours

...

Aerocool Lightning Series Transparent 14cm Red LED Fan Key Features Transparent black frame & transparent red blades with quad red LEDs 11 fan blade design generates a sturdy high air pressure & air flow. Anti-vibration screws included to assorb vibration caused by spinning action. 3-pin to 4-pin adaptor included. Specifications

Dimensions: 140 X 140 X 25mm Rated Voltage: DC 12V Starting Voltage: 7V Power Consumption: 3W Rated Current: 0.25±0.05A Speed: 1200±10% RPM Air Flow: 48CFM Air Pressure: 1.52mm-H2O Noise: 22d B (A) MTBF: 20, 000 Hours

...
