The MDP2DVIMM3B Mini Display Port to DVI Adapter Cable lets you directly connect your Mini DP video source (Desktop PC, Laptop, Ultrabook™, etc.) to a DVI monitor or projector, eliminating the expense of having to upgrade to a Mini Display Port-capable monitor. The adapter cable is 3 feet (1 m) in length, & features male-to-male connectors, allowing you to connect your Mini Display Port source directly to a DVI display device with no additional cabling required. Compatible with Intel Thunderbolt™, when connected directly to a supporting Display Port over Thunderbolt I/O port, the adapter supports resolutions up to 1920x 1200 (WUXGA). MDP2DVIMM3B is a passive adapter that requires a dual-mode Display Port port (Display Port++), meaning that DVI & HDMI signals can also be passed through the port.
Specification Audio: No Chipset ID: NXP 3361 Converter Type: Passive Output Signal: DVI-D (DVI Digital) Warranty: 2 Year Manufacturer warranty Connector (s) Connector A: 1
- Mini-Display Port (20 pin) Male Connector B: 1
- DVI-D (25 pin) Male Performance Maximum Cable Length: 0.9 m [3 ft] Wide Screen Supported: Yes Maximum Digital Resolutions: 1920x 1200 / 1080p Physical Characteristics Cable Length: 0.9 m [3 ft]
Colour: Black
Height: 15 mm [0.6 in]
Width: 38 mm [1.5 in] Length: 920 mm [36.2 in] Weight: 75 g [2.6 oz]
