This MST hub lets you connect four monitors to your Display Port™ (DP) 1.2 equipped Windows laptop or desktop. Increase productivity with multiple screens The newest generations of computers are more portable than ever, which often means that you’re left with fewer video outputs & smaller integrated screens. This MST hub solves both of these problems by letting you connect four additional displays to your computer, which makes multitasking much easier. Connect to any display With the MST hub, you can use Display Port video adapters & cable adapters that enable you to connect HDMI, VGA or DVI displays. This ensures your MST hub will be compatible with virtually any television, monitor or projector. This MST hub is VESA & Display Port certified to support DP 1.2 enabled systems, for seamless integration with your existing video equipment. Configure your displays for any environment Using the MST hub, you can extend your desktop onto additional monitors & stream independent content to each display giving you the freedom to multitask & increase your productivity. You can also mirror the same image onto multiple displays for remote viewing applications such as digital signage. Enjoy amazing video quality, without draining system resources MST technology uses your existing video card to minimize the use of system resources while delivering Ultra HD 4K resolutions. This unprecedented performance makes MST perfect for high-resolution applications such as graphic design, gaming & medical imaging. Note: When using a Display Port 1.1 video card the MST hub will act as a splitter, automatically mirroring your video source across all displays. Resolution limitations apply. The MSTDP124DP supports plug-&-play installation for a hassle-free setup, & is backed by a Star Tech.com 2-year warranty & free lifetime technical support. Features Maximize your productivity by connecting four independent displays to your computer using the MST Hub Connect to almost any television, monitor or projector with the support of low-cost adapters Increase external video performance with support for resolutions up to 4K VESA & Display Port certified Compatible with DP1.2 graphics cards such as AMD Eyefinity Technology & AMD Radeon Plug-&-play installation Newly engineered chipset for increased compatibility

Specification Warranty 2 Years Hardware Audio Yes Chipset ID STDP4320 Converter Type MST Hub Output Signal Display Port Ports 4 Performance Maximum Digital Resolutions 3840 x 2160 @30hz Supported Resolutions 1024x 768 1280x 720 (High-definition 720p) 1920x 1080 (High-definition 1080p) 1920x 1200 2560x 1440 2560x 1600 3840 x 2160 (Ultra HD 4K) @30hz Wide Screen Supported Yes Connector (s) Connector A 1
- Display Port (20 pin) Male Input Connector B 4
- Display Port (20 pin) Female Output Physical Characteristics Color Black Enclosure Type Plastic Product Height 15 mm [0.6 in] Product Length 105 mm [4.1 in] Product Weight 127 g [4.5 oz] Product Width 65 mm [2.6 in] Power Center Tip Polarity Positive Input Current 0.5 A Input Voltage 110 ~ 240 AC Output Current 3A Output Voltage 5 DC Plug Type N Power Source AC Adapter Included Environmental Operating Temperature 0°C to 45°C (32°F to 113°F) Storage Temperature -20°C to 70°C (-4°F to 158°F)



...

This MST hub lets you connect two monitors to your Mini Display Port™ (m DP) 1.2 equipped Windows tablet, laptop or desktop. It’s USB (Universal Serial Bus) powered, so the only thing you'll need to operate the hub is your computer. The hub features a newly engineered chipset that was specifically designed & rigorously tested to resolve compatibility issues with the Microsoft Surface™ Pro 3. Increase productivity with multiple screens The newest generations of computers are more portable than ever, which often means that you’re left with fewer video outputs & smaller integrated screens. This MST hub solves both of these problems by letting you connect two additional displays to your computer, which makes multitasking much easier. Connect to any display With the MST hub, you can use Mini Display Port video adapters & cable adapters that enable you to connect HDMI, VGA or DVI displays. This ensures your MST hub will be compatible with virtually any television, monitor or projector. The hub is VESA & Display Port certified to support m DP 1.2 enabled systems, for seamless integration with your existing video equipment. Configure your displays for any environment Using the MST hub, you can extend your desktop onto additional monitors & stream independent content to each display giving you the freedom to multitask & increase your productivity. You can also mirror the same image onto multiple displays for remote viewing applications such as digital signage. Enjoy amazing video quality, without draining system resources MST technology uses your existing video card to minimize the use of system resources while delivering Ultra HD 4K resolutions. This unprecedented performance makes MST perfect for high-resolution applications such as graphic design, gaming & medical imaging. Note: When using a Display Port 1.1 video card the MST hub will act as a splitter, automatically mirroring your video source across all displays. Resolution limitations apply. The MSTMDP122DP supports plug-&-play installation for a hassle-free setup, & is backed by a Star Tech.com 2-year warranty & free lifetime technical support. Features Maximize your productivity by connecting two independent displays to your computer using the MST hub Connect to almost any television, monitor or projector with the support of low-cost adapters Newly engineered chipset for increased compatibility with Microsoft Surface Pro 3 Support for resolutions up to 4K VESA & Display Port certified Compatible with DP1.2 graphics cards such as AMD Eyefinity technology & AMD Radeon Plug-&-play installation Specifications Warranty 2 Years Hardware Audio Yes Chipset ID STDP4320 Converter Type MST Hub Output Signal Display Port Ports 2 Performance Maximum Digital Resolutions 3840x 2160 @ 30hz Supported Resolutions 1024x 768 1280x 720 (High-definition 720p) 1920x 1080 (High-definition 1080p) 1920x 1200 2560x 1440 2560x 1600 3840 x 2160 (Ultra HD 4K) @30hz Wide Screen Supported Yes Connector (s) Connector A 1
- Mini-Display Port (20 pin) Male Input Connector B 2
- Display Port (20 pin) Female Output Physical Characteristics Color Black Enclosure Type Plastic Product Height 14 mm [0.6 in] Product Length 62 mm [2.4 in] Product Weight 51 g [1.8 oz] Product Width 58 mm [2.3 in] Power Power Source USB (Universal Serial Bus)-Powered Environmental Humidity 50-90% Operating Temperature 0°C to 40°C (32°F to 104°F) Storage Temperature -20°C to 60°C (-4°F to 140°F)

...

The MSTDP123DP Display Port 1.2 MST Hub lets you connect up to three Display Port monitors/projectors to a single Display Port (1.2) output on your laptop, or desktop computer. Extend Your Display The hub splits a Display Port 1.2 output into three separate Display Port signals -- enabling your computer for high quality multi-monitor applications such as a video wall, extending your desktop, or mirroring your primary display to additional monitors or projectors. Extend Your Performance With separate image outputs & resolution support up to 2560x 1600 for two displays, & 1920x 1200 for a third display, the Display Port MST hub allows monitors connected through the hub to operate individually with the exact same performance as the Display Port 1.2 graphics card on your computer. Extend Your Compatibility The MST hub is compatible with Display Port video adapters, enabling you to output the additional video signals to HDMI, DVI, or VGA displays. Warranty Information Warranty 2 Years Hardware Converter Type MST Hub Ports 3 Audio Yes Chipset ID VMM2300BKG/SYNAPTICS Output Signal Display Port Connector (s) Connector A 1
- Display Port (20 pin) Latching Male Connector B 3
- Display Port (20 pin) Latching Female Performance Maximum Digital Resolutions 2560x 1600 Wide Screen Supported Yes Software OS Compatibility Windows 8 (32/64) Windows 7 (32/64) Special Notes / Requirements Note Display Port 1.2 with MST+HBR2 support from the GPU is required for independent display output Physical Characteristics Color Black Enclosure Type Plastic Product Length 200 mm [7.9 in] Product Width 78 mm [3.1 in] Product Height 20 mm [0.8 in] Product Weight 95 g [3.4 oz] Power Input Voltage 110 ~ 240 AC Input Current 0.5 A Output Voltage 5 DC Output Current 3A Center Tip Polarity Positive Environmental Operating Temperature 0°C to 45°C (32°F to 113°F) Storage Temperature -20°C to 70°C (-4°F to 158°F) Packaging Information Shipping (Package) Weight 0.6kg [1.3 lb] What's in the Box Included in Package 1
- 3-Port Multi Monitor Display Port MST Hub 1
- Power Adapter (NA/EU/UK/AUS) 1
- Instruction Manual




...

The CMHOOKMW Multi-Directional Vertical Cable Management D-ring lets you add an internal or external facing cable hook to your server rack or cabinet, to provide an organized channel for cables. Constructed of high-quality steel, the cable management ring measures 2.4 x 3.9in (6 x 10cm). For flexible mounting options, the cable ring features a right-angled mounting bracket with 2 sets of mounting holes, enabling you to face the D-ring in the direction that best fits your application. Providing strain relief for attached cables, multiple cable rings can be attached to your rack where you need them for a versatile cable management solution. Backed by a Star Tech.com 2-year warranty. Route cables neatly through your rack with an easy-to-install cable management ring Face the D-ring internally or externally to the rack, with a right-angled mounting bracket Increase the longevity of your server & networking equipment interfaces by providing cable strain relief • Color Black • Enclosure Thickness 2 mm [0.1 in] • Enclosure Type Steel • External Height 64 mm [2.5 in] • External Width 102 mm [4 in] • Product Weight 173 g [6.1 oz] • Warranty 2 years ...

The FIBSTSC3 3-meter (10ft) Multimode 62.5/125 Duplex Fiber Patch Cable is terminated with one ST (male) connector & one SC (male) connector, to provide the necessary connection between fiber networking devices for high-speed, long distance networks. To ensure optimum performance, our multimode fiber duplex cable is individually tested & certified to be within acceptable optical insertion loss limits for guaranteed compatibility & 100% reliability. Backed by Lifetime Warranty, our ST-SC Multimode Fiber Patch cable is guaranteed to provide long-lasting dependability, & finest top quality performance. The Star Tech.com Advantage Can maximize wiring conduit usage while minimizing installation problems Fiber optic cables provide a higher quality signal over a greater distance Fiber optic cables are an ultimate solution for high- speed data transmission Backed by Star Tech.com lifetime warranty ...

The NM25MF Null Modem Adapter features one male & one female DB25 connector, enabling you to convert a straight through cable into a null modem cable for connecting two serial devices. The DB25M to DB25F cable adapter is backed by Star Tech.com’s lifetime warranty. The Star Tech.com Advantage Guaranteed reliability ...

The ET91000LCOAM Managed Fiber Media Converter lets you extend a Gigabit Ethernet connection over Multimode LC fiber, with the added benefit of remote management capabilities. Compliant with 802.3ah OAM (Operations, Administration & Management), this managed media converter incorporates an easy-to-use web interface for operation, administration & maintenance, enabling you to quickly determine the location of failing links & the fault conditions without sending service personnel to the physical location of the device. An effective solution for connecting a Gigabit Ethernet (1000 Base-T) network to remote network segments over a (1000 Base-LX/SX) fiber backbone, the Ethernet to fiber converter supports full Gigabit speeds at distances of up to 550m (1804ft) through the installed Multi-Mode LC SFP. The converter also features an all-steel chassis, for durability in harsh environments. The Star Tech.com Advantage Adjust settings & monitor the link remotely with OAM management capabilities Operates as standalone device or can be installed into the ETCHS2U 20 slot chassis for added versatility Rugged steel casing for durability in harsh environments ...

It’s all about selection. Choose the colors you want, the lengths you want, the styles you want Select from a wide variety of colors, lengths, & styles to complete your network solutions. That way, you can organize your cable runs & identify network connections faster, easily find the cables that best suit your network connection requirements, & pick the styles, either snagless – perfect for concealed cable runs – or molded – perfect for strengthening the connector to prevent damage. 100% copper for outstanding value Get the highest value for your cable investment with our Cat 6 cables, each one manufactured using high-quality copper conductors. 24-gauge wire for high-performance network connections Ensure high-performance capability for your demanding Ethernet applications, such as Power-over-Ethernet, using cables that include 24 AWG copper. 50-micron gold connectors provide peak conductivity Rely on our RJ45 connectors to deliver optimum conductivity while eliminating signal loss due to oxidation or corrosion. Lifetime Warranty We back all our cables with a lifetime warranty. ...

The USBPNLBFBM3 3ft Panel Mount USB (Universal Serial Bus) Cable features one USB (Universal Serial Bus)-B male connector on one end & a USB (Universal Serial Bus)-B panel mount female port on the other, providing a convenient solution for custom enclosures (e.g. internally mounted hard drives). Offering 3ft in cable length, the adapter means that you can extend the connection as needed within the system case. 1x USB (Universal Serial Bus)-B male connector 1x USB (Universal Serial Bus)-B panel mount female port Offers 3' in cable length ...

This 1ft USB (Universal Serial Bus) to Panel mount USB (Universal Serial Bus) cable features a 5-pin motherboard header connection on one end & a panel mount USB (Universal Serial Bus) A (female) port on the other, providing a simple & easy to access USB (Universal Serial Bus) 2.0 port on a panel mount receptacle. The USB (Universal Serial Bus) panel mount cable offers a convenient solution for connecting bootable thumb drives or authentication fobs etc. to the motherboard USB (Universal Serial Bus) connection. ...
