Protect your home, business or loved ones with this state of the art CCTV kit. Consisting of two super high resolution 420TVL outdoor cameras & two high resolution 420TVL dome cameras this system really does cover all aspects of personal security, with more connectivity with PTZ cameras, POS, ATM, Alarm & Audio devices. With the push notification it supports, SECURIX users can have real-time alerts for motions occurs in their premises via their iPhone, iPad & i Touch (using the SECURIX iPhone App. available for download from the app store). A simple user interface & wizard based set up ensures that even the novice user gets the most out of their home security setup with the minimum of fuss. The bullet cameras are even resistant to tampering with their anti-cut cable system. This SECURIX CCTV system is the home security system that homes & business have been waiting for. Pre Installed 500GB SATA Hard disk storage built-in. Professional H.264 Network DVR with real-time display (100ips), recording (100ips) & playback (100ips) 500GB SATA Hard disk storage built-in All Cameras with 20 meters night vision & Auto white balance POS & ATM interface via built-in RS232 port for recording & playback together with Text-in data PTZ (Pan Tilt Zoom) camera interface via RS485 port & support more than 60 different PTZ protocols D1 resolution support for clear recording & playback images Recording setup programmable for each cameras independently User-friendly Graphical User Interface (GUI) Menu System Wizard setup for easy & convenient menu configuration Event recording/playback/log footage available for Motion detection, Video-loss, Video-blind Support up to 1 x 2TB SATA HDD Support Disk Overwrite Mode for continuous recording Constant recording while transmitting to remote site & during playback Real-time system management for Disk temperature, Disk bad & Disk S.M.A.R.T 64 Group & 256 Users can access to DVR with programmable access-right per each group ISM Technology, a professional storage management solution for security DVR, applied for stability USB (Universal Serial Bus) Mouse & Infrared Remote Control included Support data backup to USB (Universal Serial Bus) Flash memory & Upgrade through USB (Universal Serial Bus) Flash memory Support VGA output for LCD monitor display
Specification
- Camera Type
- Analogue Day & Night
- Yes Effective Pixel Resolution
- NTSC: 352 x 240 • PAL: 352 x 288 Pixels Resolution
- 420 TV Lines Scan Frequency
- (Horizontal) x (Vertical) IR Illuminatiuon
- Yes Brightness Control
- Automatic Video Resolution
- 720x 480 (N), 720x 576 (P) Frame Rates
- 30/25 Per Second Storage
- 500 GB Network Interface
- 1 x RJ-45 Audio Output
- 1 x RCA Video Out
- Yes USB (Universal Serial Bus) Ports
- 2 x USB (Universal Serial Bus) 2.0 Input Ports
- 4 x RCA Network Protocol
- Manual, ADSL, DHCP, DVRNS Network Speeds Supported
- 10/100 MBps Operating System
- Linux (Embedded) Environmental
- Operating Temperature 5 to 40 °C
- Humidity 0 to 90 % DC Input Voltage
- 12 V DC Internal/ External Use
- Internal & External Weatherproof
- Yes
Dimensions
- 26.5 cm (W) x 5.2 cm (D) x 18.8 cm (H)
- Weight
