Sapphire R9 270X 4GB GDDR5 WITH BOOST & OC Dual DVI HDMI Display Port Graphics Card The R9 270X supports Direct X 11.2 & all the latest game enhancements. It has 1280 stream processors & 4GB of GDDR5 memory delivering excellent performance in all but the most extreme settings, & is considerably faster than competing solutions in this price range. Specification: Display Support 3 x Maximum Display Monitor (s) support Output 1 x HDMI (with 3D) 1 x Display Port 1.2 1 x Dual-Link DVI-D 1 x Dual-Link DVI-I GPU Up to 1020/ Boost: Up to 1070 MHz Core Clock 28 nm Chip up to 1280 x Stream Processors Video Memory 4096 MB Size 256 -bit GDDR5 5600 MHz Effective Dimension 228 (L)X109 (W)X35 (H) mm Size. 2 x slot Software Driver CD SAPPHIRE Tri XX Utility Accessory Cross Fire Bridge Interconnect Cable DVI to VGA Adapter 6 PIN to 4 PIN Power Cable x 2 HDMI 1.4a high speed 1.8 meter cable (Full Retail SKU only) System Requirements: PCI Express based PC is required with one X16 lane graphics slot available on the motherboard. 4X75 Watt 6-pin PCI Express power connector is required for Cross Fire X system. 2X75 Watt 6-pin PCI Express power connector is required. 4096MBMinimum of system memory. Installation software requires CD-ROM drive. DVD playback requires DVD drive. Blu-ray / HD DVD playback requires Blu-ray / HD DVD drive. 500 Watt Power Supply is required. 600 Watt Power Supply is recommended for Cross Fire X System. 64-bit operating system highly recommended ...

SAPPHIRE DUAL-X R9 270X 2GB GDDR5 OC Dual DVI HDMI Display Port PCI-E Graphics Card Aimed at the slightly more budget conscious gamer, the R9 270X series is the perfect match for gameplay at 1080p with maximum settings. The SAPPHIRE R9 270X Dual-X model again features the proven SAPPHIRE Dual-X technology & delivers the best cost:performance ratio in its class. Specification: Display Support 3 x Maximum Display Monitor (s) support Output: 1 x HDMI (with 3D) 1 x Display Port 1 x Dual-Link DVI-D 1 x Dual-Link DVI-I GPU: 1020 MHz Core Clock 28 nm Chip 1280 x Stream Processors Video Memory: 2048 MB Size 256 -bit GDDR5 5600 MHz Effective Dimension: 228 (L)X109 (W)X35 (H) mm Size. 2 x slot Software: Driver CD SAPPHIRE Tri XX Utility System Requirements: PCI Express based PC is required with one X16 lane graphics slot available on the motherboard. 4X75 Watt 6-pin PCI Express power connector is required for Cross Fire X system. 2X75 Watt 6-pin PCI Express power connector is required. 4096MBMinimum of system memory. Installation software requires CD-ROM drive. DVD playback requires DVD drive. Blu-ray / HD DVD playback requires Blu-ray / HD DVD drive. 500 Watt Power Supply is required. 600 Watt Power Supply is recommended for Cross Fire X System. 64-bit operating system highly recommended ...

SAPPHIRE TOXIC R9 270X 2GB GDDR5 Dual DVI HDMI Display Port PCI-E Graphics Card Aimed at the slightly more budget conscious gamer, the R9 270X series is the perfect match for gameplay at 1080p with maximum settings, yet has models starting from as low as $199. Extreme factory overclocks again make this the fastest product available in this family. This model allows the gamer with a more limited budget to take advantage of the high quality & enhanced performance of the flagship TOXIC series.

Specification Display Support: supports up to 4 display monitor (s) without Display Port 4 x Maximum Display Monitor (s) support Output: 1 x HDMI (with 3D) 1 x Display Port 1 x Dual-Link DVI-D 1 x Dual-Link DVI-I GPU: 1100/ Boost:1150 MHz Core Clock 28 nm Chip 1280 x Stream Processors Video Memory: 2048 MB Size 256 -bit GDDR5 6000 MHz Effective Dimension: 308 (L)X113 (W)X41 (H) mm Size. 2.2 x slot Software: Driver CD SAPPHIRE Tri XX Utility System Requirements: PCI Express based PC is required with one X16 lane graphics slot available on the motherboard. 4X75 Watt 6-pin PCI Express power connector is required for Cross Fire X system. 2X75 Watt 6-pin PCI Express power connector is required. 4096MBMinimum of system memory. Installation software requires CD-ROM drive. DVD playback requires DVD drive. Blu-ray / HD DVD playback requires Blu-ray / HD DVD drive. 500 Watt Power Supply is required. 600 Watt Power Supply is recommended for Cross Fire X System. 64-bit operating system highly recommended

...

Sapphire Vapor-X R9 270X 2GB GDDR5 OC Dual DVI HDMI Displayort PCI-E Graphics Card Aimed at the slightly more budget conscious gamer, the R9 270X series is the perfect match for gameplay at 1080p with maximum settings. The SAPPHIRE R9 270X Vapor-X model features a second generation Vapor-X cooler design, lighter in weight but delivering the industry acclaimed quiet & efficient cooling associated with this br&. Specification: Display Support 4 x Maximum Display Monitor (s) support Output 1 x HDMI (with 3D) 1 x Display Port 1.2 1 x Dual-Link DVI-D 1 x Dual-Link DVI-I GPU: 1050/ Boost:1100 MHz Core Clock 28 nm Chip 1280 x Stream Processors Video Memory: 2048 MB Size 256 -bit GDDR5 5800 MHz Effective Dimension: 264 (L)X103 (W)X35 (H) mm Size. 2 x slot Software: Driver CD SAPPHIRE Tri XX Utility System Requirements: PCI Express based PC is required with one X16 lane graphics slot available on the motherboard. 4X75 Watt 6-pin PCI Express power connector is required for Cross Fire X system. 2X75 Watt 6-pin PCI Express power connector is required. Installation software requires CD-ROM drive. DVD playback requires DVD drive. Blu-ray/HD DVD playback requires Blu-ray / HD DVD drive. 500 Watt Power Supply is required. 600 Watt Power Supply is recommended for Cross Fire X System. 64-bit operating system highly recommended ...

The SAPPHIRE R9 270X Vapor-X model features a second generation Vapor-X cooler design, lighter in weight but delivering the industry acclaimed quiet & efficient cooling associated with this br&.

Specification Display Support 4 x Maximum Display Monitor (s) support Output 1 x HDMI (with 3D) 1 x Display Port 1.2 1 x Dual-Link DVI-D 1 x Dual-Link DVI-I GPU 1050/ Boost:1100 MHz Core Clock 28 nm Chip 1280 x Stream Processors Video Memory 2048 MB Size 256 -bit GDDR5 5800 MHz Effective

Dimensions 264 (L)X103 (W)X35 (H) mm Size. 2 x slot



...

Always looking to deliver the best solutions to the user, even the base model in this family features SAPPHIRE’s highly acclaimed Dual-X cooler. Dual-X, with its two aerofoil fans, & graduated heatpipes, is a design which received industry acclaim in the previous generation of products. The SAPPHIRE R9 280X Dual-X model is the most cost effective member of the family & yet is still overclocked compared with the reference design to give users the best possible value for your money in this performance class. Specifications Display Support 3 x Maximum Display Monitor (s) support Output 1 x HDMI (with 3D) 1 x Display Port 1.2 1 x Dual-Link DVI-D 1 x Dual-Link DVI-I GPU 870/ Boost:1020 MHz Core Clock 28 nm Chip 2048 x Stream Processors Video Memory 3072 MB Size 384 -bit GDDR5 6000 MHz Effective Dimension 262 (L)X112 (W)X34 (H) mm Size 2 x slot Accessory Cross Fire Bridge Interconnect Cable 8 PIN to 4 PIN Power Cable 6 PIN to 4 PIN Power Cable ...

“ Free AMD Radeon Rewards download coupon GOLD from 30th April 2014 whilst stocks last with selected cards. Offer on selected cards only, not available on ex-display cards.” The SAPPHIRE R9 280X TOXIC Edition features the exciting new Tri-X cooler design which uses three sophisticated aerofoil section fans together with industry leading 10mm heatpipes to give unrivalled cooling efficiency. The stylish shroud is designed not only to look cool, but to manage the airflow over the card for maximum cooling effect. This new cooler, together with a high performance 10-phase power management system & high quality components such as the SAPPHIRE exclusive double sided Black Diamond chokes & long-life solid capacitors, has enabled SAPPHIRE to deliver stable higher power levels whilst keeping temperatures low. As a result the TOXIC edition features extreme factory programmed overclocks, delivering the best performance in the industry for this product family. & at the touch of a switch, the user can choose between UEFI & non-UEFI platforms. Display Support
- 5 x Maximum Display Monitor (s) support Output 1 x HDMI (with 3D) 2 x Mini-Display Port 1 x Single-Link DVI-D 1 x Dual-Link DVI-I GPU 1100/ Boost:1150 MHz Core Clock 28 nm Chip 2048 x Stream Processors Video Memory 3072 MB Size 384 -bit GDDR5 6400 MHz Effective Dimension 308 (L)X113 (W)X41 (H) mm Size. 2.2 x slot System Requirements PCI Express based PC is required with one X16 lane graphics slot available on the motherboard. 4096MBMinimum of system memory. Installation software requires CD-ROM drive. DVD playback requires DVD drive. Blu-ray / HD DVD playback requires Blu-ray / HD DVD drive. 750 Watt Power Supply is required. 1000 Watt Power Supply is recommended for Cross Fire X System. 2X150 Watt 8-pin PCI Express power connector is required. 4X150 Watt 8-pin PCI Express power connector is required for Cross Fire X system.
...

Sapphire VAPOR-X R9 280X 3GB GDDR5 OC Dual DVI HDMI Display Port PCI-E Graphics card User looking for a slightly less extreme solution can choose the SAPPHIRE R9 280X Vapor-X model. SAPPHIRE was the first company to use vapor-chamber cooling in its graphics cards & has now implemented its award winning Vapor-X cooler on the R9 280X, delivering highly efficient & quiet cooling. Factory overclocked to deliver increased performance over the standard model, the SAPPHIRE R9 280X Vapor-X model is a great choice for professional users as well as gamers. Display Support 3 x Maximum Display Monitor (s) support Output: 1 x HDMI (with 3D) 1 x Display Port 1 x Dual-Link DVI-D 1 x Dual-Link DVI-I GPU: 950/ Boost:1070 MHz Core Clock 28 nm Chip 2048 x Stream Processors Video Memory: 3072 MB Size 384 -bit GDDR5 6200 MHz Effective Dimension 276 (L)X121 (W)X45 (H) mm Size. 2.5 x slot Software: Driver CD SAPPHIRE Tri XX Utility Accessory Cross Fire Bridge Interconnect Cable 8-PIN to 4 PIN x 2 Power Cable HDMI 1.4a high speed 1.8 meter cable (Full Retail SKU only) ...

“ Free AMD Radeon Rewards download coupon GOLD from 30th April 2014 whilst stocks last with selected cards. Offer on selected cards only, not available on ex-display cards.” SAPPHIRE R9 280X Vapor-X model uses vapor-chamber cooling in the graphics cards, delivering highly efficient & quiet cooling. Factory overclocked to deliver increased performance over the standard model, the SAPPHIRE R9 280X Vapor-X model is a great choice for professional users as well as gamers.

Specification Display Support supports up to 3 display monitor (s) without Display Port 4 x Maximum Display Monitor (s) support To support 3rd monitor without Display Port cable connected, 2 of the 3 monitors should be the same model with DVI ports connected. The driver version should be v 13.12 or above. Output 1 x HDMI (with 3D) 1 x Display Port 1.2 1 x Dual-Link DVI-D 1 x Dual-Link DVI-I GPU 1000/ Boost:1100 MHz Core Clock 28 nm Chip 2048 x Stream Processors Video Memory 3072 MB Size 384 -bit GDDR5 6000 MHz Effective Dimension 308 (L)X108 (W)X35 (H) mm Size. 2 x slot Software Driver CD SAPPHIRE Tri XX Utility System Requirements PCI Express based PC is required with one X16 lane graphics slot available on the motherboard. 4096MBMinimum of system memory. Installation software requires CD-ROM drive. DVD playback requires DVD drive. Blu-ray / HD DVD playback requires Blu-ray / HD DVD drive. 750 Watt Power Supply is required. 1000 Watt Power Supply is recommended for Cross Fire X System. 2X150 Watt 8-pin PCI Express power connector is required. 4X150 Watt 8-pin PCI Express power connector is required for Cross Fire X system.

...

PRODUCT FEATURES 2nd Generation GCN Architecture AMD True Audio Technology Direct X 11.2 graphics Open GL 4.3 support AMD App Acceleration AMD Image quality enhancement technology AMD Cutting-edge integrated display support AMD Powerplay Power management technology AMD Power Tune technology AMD Zero Core Power technology AMD HD Media Accelerator Advanced audio capabilities Dolby True HD & DTS-HD Master Audio support HDMI 1.4a: quad HD/4K video support Mantle API

Specification GPU: AMD Radeon R9 290 Graphics Compute Units: 40 Stream Processors: 2560 unit 3D Clock: Up to 947 MHz Eclk Memory Clock: Up to 1250 MHz, Effective 5000 Mbps Memory Type: 4096 MB/ 512-Bit GDDR5 Bus Interface: PCI-E 3.0x 16 HDCP support: Yes External Power: PCIe Graphic External 1x 8; 1x 6 pin Cooling System: 2 slot blower fan Fan Speed Range: 20% to 40 % Target Operating Temperature: 95C Maximum Package Power: 208W Bracket: full height Software: Driver CD Crossfire Support: Native Crossfire up to 4 GPUs (Crossfire cable not required) OPERATING SYSTEM SUPPORT Windows XP (32 Bit/64 Bit) Windows Vista (32 Bit/64 Bit) Windows Media Center Edition 2005 Windows 7 (32bit/64bit) Windows 8 or 8.1 (32bit/64bit) SYSTEM REQUIREMENTS PCI Express based PC is required with one X16 lane graphics slot available on the motherboard 500W (or greater) power supply with one 150W 8-pin & one 75W 6-pin PCI Express power connector recommended Minimum 4GB of system memory Installation software requires CD-ROM drive DVD playback requires DVD drive & a DVD A display with digital input (HDMI, Display Port or DVI) is required Blu-ray playback requires Blu-ray drive & a Blu-ray disc 64-bit operating system highly recommended

...
