The SAPPHIRE HD 5450 graphic cards offer the most features & functionality in their class with complete Direct X 11 support & the world’s most advanced graphics, display features & technologies. Specifications GPU 650 MHz Core Clock 40 nm Chip 80 x Stream Processors Video Memory 1024 MB Size 64 -bit DDR3 1334 MHz Effective Outputs 1 x D-Sub (VGA) 1 x Single-Link DVI-D 1 x Display Port 1.2

Dimensions 168 (W) x 72.87 (H) x 25 (D) mm Size. 1 x slot System Requirements PCI Express based PC is required with one X16 lane graphics slot available on the motherboard Certified power supplies are recommended 1024MBMinimum of system memory Installation software requires CD-ROM drive DVD playback requires DVD drive Blu-ray / HD DVD playback requires Blu-ray / HD DVD drive 400 Watt Power Supply is required

...

The SAPPHIRE HD 5450 graphic cards offer the most features & functionality in their class with complete Direct X 11 support & the world’s most advanced graphics, display features & technologies*. The HD 5450 Series is designed to give you stunning high definition entertainment from your PC, whether Blu-ray/HD DVD discs or other HD sources.** Also, you can get an amazing entertainment experience with Direct X 11 & Windows 7*** via HD5450. Specification: Output: D-Sub (VGA) 1 x Dual-Link DVI 1 x HDMI GPU: 650 MHz Core Clock 40 nm Chip 80 x Stream Processors Video Memory 1024 MB Size 64 -bit DDR3 1334 MHz Effective Dimension
- 168 (W) x 72.87 (H) x 25 (D) mm Size. Software
- Driver CD System Requirements: PCI Express based PC is required with one X16 lane graphics slot available on the motherboard. Certified power supplies are recommended. Please refer to: http://support.amd.com/us/certified/power-supplies/ Pages/listing.aspx 1024MBMinimum of system memory. Installation software requires CD-ROM drive. DVD playback requires DVD drive. Blu-ray / HD DVD playback requires Blu-ray / HD DVD drive. For an AMD Cross Fire X system, a second same AMD Radeon graphics card, an AMD Cross Fire X Ready motherboard & one AMD Cross Fire X Bridge Interconnect cable per graphics card (optional) are required. 400 Watt Power Supply is required. For best cooling performance, a chassis installed with at least one 120mm or 90mm fan is required.

...

Specifications Outputs 1x D-Sub (VGA) 1 x HDMI 1 x Dual-Link DVI-D GPU 650 MHz Core Clock 40 nm Chip Video Memory 1024 MB Size 64-bit DDR3 1333 MHz Effective Dimension 168 (W) x 72.87 (H) x 25 (D) mm Size 1 x slot System Requirements PCI Express based PC is required with one X16 lane graphics slot available on the motherboard. Certified power supplies are recommended. Please refer to: http://support.amd.com/us/certified/power-supplies/ Pages/listing.aspx 1024MB Minimum of system memory. Installation software requires CD-ROM drive. DVD playback requires DVD drive. Blu-ray / HD DVD playback requires Blu-ray / HD DVD drive. For an AMD Cross Fire X system, a second same AMD Radeon graphics card, an AMD Cross Fire X Ready motherboard & one AMD Cross Fire X Bridge Interconnect cable per graphics card (optional) are required. 400 Watt Power Supply is required. For best cooling performance, a chassis installed with at least one 120mm or 90mm fan is required. ...

The SAPPHIRE HD 5450 graphic cards offer the most features & functionality in their class with complete Direct X 11 support & the worlds most advanced graphics, display features & technologies. The HD 5450 Series is designed to give you stunning high definition entertainment from your PC, whether Blu-ray/HD DVD discs or other HD sources Microsoft Direct X 11 Support ATI Stream technology 40nm Process Technology PCI Express 2.1 support Microsoft Windows 7 Support Enhanced Anisotropic Filtering Accelerated Video Transcoding Display Flexibility Dolby True HD & DTSHD Master Audio TM Support ATI Power Play Technology ATI Avivo Technology HDMI 1.3 Specifications Output DL-DVI-I, HDMI, VGA Graphics Core clock: 650 M Hz Memory Clock: 1600 M Hz Effective 1024MB / 64-bit DDR3 memory interface PCI-E x 16 (PCI-E 2.1) interface Single slot passive heatsink ...

Sapphire HD 5450 2GB DDR3 VGA DVI HDMI PCI-E Graphics Card The ATI Radeon HD 5450 graphics processors offer the most features & functionality in their class with complete Direct X 11 support & the world’s most advanced graphics, display features & technologies. Specification: Output: 1 D-Sub (VGA) 1 x Dual-Link DVI 1 x HDMI GPU: 650 MHz Core Clock 40 nm Chip 80 x Stream Processors Video Memory: 2048 MB Size 64 -bit DDR3 1334 MHz Effective Dimension
- 190 (L)x 22 (W)x 94 (H) mm Size. Software
- Driver CD System Requirements: PCI Express based PC is required with one X16 lane graphics slot available on the motherboard. Certified power supplies are recommended. Please refer to: http://support.amd.com/us/certified/power-supplies/ Pages/listing.aspx 1024MBMinimum of system memory. Installation software requires CD-ROM drive. DVD playback requires DVD drive. Blu-ray / HD DVD playback requires Blu-ray / HD DVD drive. 400 Watt Power Supply is required.

...

Specifications Outputs 1 D-Sub (VGA) 1 x Dual-Link DVI 1 x HDMI GPUs 650 MHz Core Clock 40 nm Chip 80 x Stream Processors Video Memory 512 MB Size 64 -bit DDR3 1334 MHz Effective Dimension
- 146 (W) x 120 (H) x 25 (D) mm Size Software
- Driver CD System Requirements PCI Express based PC is required with one X16 lane graphics slot available on the motherboard. Certified power supplies are recommended. Please refer to: http://support.amd.com/us/certified/power-supplies/ Pages/listing.aspx 1024MBMinimum of system memory. Installation software requires CD-ROM drive. DVD playback requires DVD drive. Blu-ray / HD DVD playback requires Blu-ray / HD DVD drive. For an AMD Cross Fire X system, a second same AMD Radeon graphics card, an AMD Cross Fire X Ready motherboard & one AMD Cross Fire X Bridge Interconnect cable per graphics card (optional) are required. 400 Watt Power Supply is required. For best cooling performance, a chassis installed with at least one 120mm or 90mm fan is required.

...

Packed with the latest GPU technologies, the Radeon HD 6450 graphics processor is a next-generation visual upgrade, HDMI 1.4a for stereoscopic (3D) displays, Displayport 1.2 as well as 2nd generation support for Direct X 11 for the most versatile solution for everyday computing. Output 1x D-Sub (VGA) 1 x Dual-Link DVI 1 x HDMI 1.4a GPU 625 MHz Core Clock 40 nm Chip 160 x Stream Processors Memory 1024 MB Size 64 -bit DDR3 1334 MHz Effective Dimension 146 (L)x 22 (W)x 94 (H) mm Size. Software Driver CD System Requirements PCI Express based PC is required with one X16 lane graphics slot available on the motherboard. Certified power supplies are recommended. Please refer to: http://support.amd.com/us/certified/power-supplies/ Pages/listing.aspx 1024MBMinimum of system memory. Installation software requires CD-ROM drive. DVD playback requires DVD drive. Blu-ray / HD DVD playback requires Blu-ray / HD DVD drive. 400 Watt Power Supply is required. For best cooling performance, a chassis installed with at least one 120mm or 90mm fan is required. ...

The SAPPHIRE HD 6450 Fle X incorporates this SAPPHIRE exclusive feature into a mainstream graphics card & delivers the most cost-effective Eyefinity solution available for increased productivity in tasks such as editing or business applications. It can also be used in multi-screen information display systems where three low cost monitors can be directly connected to each Fle X card installed. The SAPPHIRE HD 6450 Fle X can support three DVI monitors in Eyefinity mode & deliver a true SLS (Single Large Surface) work area. The first two monitors are connected to the DVI outputs, as usual. A third DVI monitor can be connected to the HDMI output with the passive cable adapter supplied. Thus three DVI monitors can be used in Eyefinity mode without any additional investment. Specification: Output
- 1 x Dual-Link DVI 1 x HDMI (with 3D) 1 x Single-Link DVI-D GPU
- 625 MHz Core Clock 40 nm Chip 160 x Stream Processors Video Memory
- 1024 MB Size 64 -bit DDR3 1600 MHz Effective Dimension
- 180 (L)x 110 (W)x 43 (H) mm Size. Software
- Driver CD System Requirements: PCI Express based PC is required with one X16 lane graphics slot available on the motherboard. Certified power supplies are recommended. 1024MBMinimum of system memory. Installation software requires CD-ROM drive. DVD playback requires DVD drive. Blu-ray / HD DVD playback requires Blu-ray / HD DVD drive. 400 Watt Power Supply is required.




...

Packed with the latest GPU technologies, the Radeon™ HD 6450 graphics processor is a next-generation visual upgrade that delivers Eyefinity multi-display technology, HDMI 1.4a for stereoscopic (3D) displays as well as 2nd generation support for Direct X 11 for the most versatile solution for everyday computing. Specification: Output: 1 D-Sub (VGA) 1 x Dual-Link DVI 1 x HDMI (with 3D) GPU: 625 MHz Core Clock 40 nm Chip 160 x Stream Processors Video Memory: 2048 MB Size 64 -bit DDR3 1334 MHz Effective Dimension
- 190 (L)x 22 (W)x 94 (H) mm Size. Software
- Driver CD System Requirements: PCI Express based PC is required with one X16 lane graphics slot available on the motherboard. Certified power supplies are recommended. Please refer to: http://support.amd.com/us/certified/power-supplies/ Pages/listing.aspx 1024MBMinimum of system memory. Installation software requires CD-ROM drive. DVD playback requires DVD drive. Blu-ray / HD DVD playback requires Blu-ray / HD DVD drive. For an AMD Cross Fire X system, a second same AMD Radeon graphics card, an AMD Cross Fire X™ Ready motherboard & one AMD Cross Fire X Bridge Interconnect cable per graphics card (optional) are required. 400 Watt Power Supply is required.

...

Packed with the latest GPU technologies, the Radeon™ HD 6570 graphics processors offer advanced video & display features, HDMI 1.4a for stereoscopic (3D) displays, as well as 2nd generation support for Direct X 11 to offer the ultimate in versatility for the everyday computing desktop. Output 1 x D-Sub (VGA) 1 x Dual-Link DVI 1 x HDMI 1.4a GPU 650 MHz Core Clock 40 nm Chip 480 x Stream Processors Memory 2048 MB Size 128 -bit DDR3 1600 MHz Effective Dimension 169 (L) x 19 (W)x 94 (H) mm Size. Software Driver CD ...
