Deliver startlingly clear images in a more eco-friendly way with the edge LED display. High on performance & reliability, yet low on power consumption, it is ideal for projects where no compromise is accepted. &
- ; USB (Universal Serial Bus) Media Playback Enjoy your own media playback via the USB (Universal Serial Bus) port. Simply plug in a USB (Universal Serial Bus) drive & create your own signage content to convey the marketing messages you want, when you want them. With a wide range of media formats supported, this powerful media player offers an excellent picture & true flexibility. &
- ; Smart Power for energy saving The backlight intensity can be controlled & pre-set by the system to reduce the power consumption by up to 50%, which saves substantially on energy costs. &
- ; Full HD LED technology for brilliant images White LED's are solid state devices which light up to full, consistent brightness faster saving startup time. LED's are free from mercury content, which allows for eco-friendly recycling & disposal process. LED's allow for better dimming control of the LCD backlight, resulting in a super high contrast ratio. It also gives superior colour reproduction thanks to consistent brightness across the screen. &
- ; AMVA for wide-view super-high contrast, vivid images Philips AMVA LED display uses an advanced multi-domain vertical alignment technology which gives you super-high static contrast ratios for extra vivid & bright images. While standard applications are handled with ease, it is especially suitable for graphical demanding applications. Its optimised pixel management technology gives you a 178/178 degree extra wide viewing angle, resulting in crisp images. &
- ; Smart Control Software Suite Control & manage all of the signage displays on your network with this powerful software tool, which means that you can change the settings of your display centrally via an RJ45 or RS232 connection. Smart Control means that you can set the video input, modify the colour settings, set the display's ID when creating video walls & even diagnose each display's status, giving you all the power you need to manage your displays from one central location. &
- ; Connect your display & start sharing with DLNA Simply share & stream content from your mobile device or media player to your display with all DLNA compliant media devices. Connect each display with an ethernet cable & manage your content in real time within your local network. Simply connect your display & start sharing. &
- ; Schedule what you want, when you want You can freely schedule the right content at the right time to satisfy your customer information needs. Mix & manage your content over multiple video input signals such as USB (Universal Serial Bus), VGA, DVI & HDMI. Simply create one or more playlists with the scheduling function to be in control of your content 24 hours a day, 7 days a week. &
- ; Power consumption below the industry average Reduction of the electrical power required to operate a device. &
- ; Complies with Ro HS standards of care for the environment Philips designs & produces display products in compliance with strict Restriction of Hazardous Substances (Ro HS) standards that restrict lead & other toxic substances that can harm the environment. Technical

Specification Display 42” Screen Resolution: 1920 x 1080 @ 60 Hz Full HD Aspect ratio: 16:9 Typical Contrast ratio: 3000:1 Brightness: 250 cd/m 2 Response Time: 6.5ms Viewing angle: 178°/ 178° Pixel Pitch: 0.16 x 0.48mm Display Colours: 16.7M Connectivity VGA DVI-D HDMI USB (Universal Serial Bus) Component (RCA) Composite (RCA) 3.5-mm jack Audio Left/ Right (RCA) SPDIF Audio Left/ Right (RCA) RJ45 RS232C (in/out) 2.5 mm jack IR (in/out) 3.5 mm jack Features Speakers: 10W x 2 USB (Universal Serial Bus) Playback Video: 3G2 / 3GP / ASF / AVI / DAT / Div X / F4V / FLV / M2TS / M4V / MK3D / MKV / MOV / MP4 / MPE / MPEG / MPG / MTS / QT / TRP / TS / TTS / VOB / WEBM / WMV / Xvid USB (Universal Serial Bus) Playback Picture: BMP / GIF / JPEG / JPG USB (Universal Serial Bus) Playback Audio: AAC / AC3 / AIF / AIFF / AMR / EC3 / M4A / MP3 / OGA / OGG / WAV / WMA Anti-Glare coating 3D Combfilter Dynamic contrast enhancement VESA 400 x 400 Power Power consumption: 55 W Power consumption Standby mode: <0.5W

Dimensions 980.4 x 572.9 x 38.5mm (Wx Hx D)












...

Get even closer to your audience than ever before. Fast, precise & extremely durable, its high performance is matched by excellent reliability & functionality. &
- ; Optical touch technology for advanced user interaction A brand new level of interactivity is now available thanks to integrated optical touch technology. The sensors on the edge of the screen give you perfect clarity whilst at the same time offering multi-touch interaction, opening up all kinds of possibilities for new interactive applications. &
- ; Open Pluggable

Specification Slot Developed for the Digital Signage market, the Open Pluggable

Specification (OPS) slot is designed to make changing or upgrading your media player mere childs play. Simply plug your media player in to the display & you’re ready. No matter whether you have an entry level, mid-range or high-end media player, OPS is fully compatible bringing you a lower TCO over the longer term. &
- ; Smart insert in the back cover to place a small PC Professional PCs are part of most public signage installations. Quite often they increase the overall depth of the display & cause a lot of cable clutter. So we have designed this display with Smart insert in the back cover, which is ideal for the integration of a professional small form factor PC. On top of that, the cable management system offers a great solution to keep your cables neat & professional-looking. &
- ; Designed for 24/7 operation Because business never sleeps, our signage displays are designed for 24/7 use. Taking advantage of superior components to ensure a higher level of quality, you can count on this range of models for complete around-the-clock reliability. &
- ; Full HD LED technology for brilliant images White LEDs are solid state devices which light up to full, consistent brightness faster saving startup time. LEDs are free from mercury content, which allows for eco-friendly recycling & disposal process. LEDs allow for better dimming control of the LCD backlight, resulting in a super high contrast ratio. It also gives superior colour reproduction thanks to consistent brightness across the screen. &
- ; IPS wide view technology for image & colour accuracy Philips IPS displays uses an advanced technology, which gives you extra-wide viewing angles of 178/178 degrees, making it possible to view the display from almost any angle — even in portrait mode. IPS displays give you remarkably crisp images with vivid colours, particularly suitable for professional video wall & menu board applications, which demand colour accuracy & consistent brightness at all times. &
- ; True multi touch with 5 simultaneous touch points Enjoy a more interactive experience with up to 5 touch points at the same time. Ideal for when you have more than one user to interact with your application simultaneously, the 5 touch points offer an extremely cost-effective solution. &
- ; USB (Universal Serial Bus) Plug-&-Play compatible Simply connect the display via USB (Universal Serial Bus) to your media player for automatic touch recognition. The USB (Universal Serial Bus) connector is HID compliant, providing true plug-&-play operation. &
- ; Compatible with all leading operating systems Our touch displays are software-independent & support Windows 8, Windows 7, Vista, XP, Mac OS & Linux. &
- ; Smart Control Software Suite Control & manage all of the signage displays on your network with this powerful software tool, which means that you can change the settings of your display centrally via an RJ45 or RS232 connection. Smart Control means that you can set the video input, modify the colour settings, set the displays ID when creating video walls & even diagnose each displays status, giving you all the power you need to manage your displays from one central location. &
- ; Portrait mode operability This display can also be safely & reliably mounted in portrait position. Technical

Specification Display 42” Screen Resolution: 1920 x 1080 @ 60 Hz Full HD Aspect ratio: 16:9 Typical Contrast ratio: 1300:1 Dynamic Contrast ratio: 500, 000:1 Brightness: 450 cd/m 2 Response Time: 12ms Viewing angle: 178°/ 178° Pixel Pitch: 0.485 x 0.485mm Display Colours: 1.06B Interactivity Multi-touch technology: Optical Sensing Touch points: 5 simultaneous touchpoints Plug & Play: HID compliant Protection glass: 4mm tempered safety glass Connectivity VGA DVI-D HDMI Display Port (1.1a) Component (RCA) Composite (RCA) 3.5-mm jack Audio Left/ Right (RCA) RJ45 RS232C (in/out) D-Sub 9 USB (Universal Serial Bus) Features Speakers: 10W x 2 Placement: Landscape / Portrait Signal Loop Through: DVI / RS232 / VGA Network Controllable: RS232 / RJ45 Picture performance: Advanced colour control PIP Screen-saving functions: Pixel shift, Low brightness Keyboard control: Hidden / Lockable Anti-Glare coating 3D Combfilter Dynamic contrast enhancement VESA 400 x 400 / 400 x 200 / 200 x 200 Power 90 ~ 240V AC, 50/60 Hz Power consumption: 120 W Power consumption Standby mode: <0.5W

Dimensions 976.16 x 569.5 x 79.8mm (Wx Hx D)


















...

Open Pluggable

Specification Slot Developed for the Digital Signage market, the Open Pluggable

Specification



...

Enjoy the unique combination of stunning picture quality & high performance that delivers your marketing messages to your audience ...

Product features &
- ; USB (Universal Serial Bus) Media Playback Enjoy your own media playback via the USB (Universal Serial Bus)
...

Philips BDL4651VH 117 cm (46inch ) LCD Monitor
- 8.50 ms
- 1920 x 1080
- 16.7 Million Colours
- 1500 cd/m-square
-




...

Product features &
- ; USB (Universal Serial Bus) Media Playback Enjoy your own media playback via the USB (Universal Serial Bus)
...

Deliver your marketing messages or vital information in style with the high-definition LCD display. With pictures so clear & vivid, your audience will be spellbound. The BDL5545E is a state-of-the-art LCD display which offers full high definition widescreen resolution of 1080 progressive lines, each with 1920 pixels. This in turn gives you some of the most stunning picture quality around. It produces brilliant flicker-free progressive scan pictures with optimum brightness & superb colors. The vibrant & sharp images will provide you & your audience with an enhanced, enjoyable viewing experience. ...

Discover a new level of interaction with this multi touch LED display Get even closer to your audience than ever before. Fast, precise & extremely durable, its high performance is matched by ex cellent reliability & functionality. Optimized for public viewing • Full HD LED technology for brilliant images • IPS wide view technology for image & color accuracy Supreme audience interaction • True multi touch with 5 simultaneous touch points • USB (Universal Serial Bus) Plug-&-Play compatible • Optical touch technology for advanced user interaction • Compatible with all leading operating systems Operational flexibility • Open Pluggable

Specification Slot • Smart insert in the backcover to place a small pc • Smart Control Software Suite • Portrait mode operability • Designed for 24/7 operation Highlights Full HD LED technology White LED's are solid state devices which light up to full, consistent brightness faster saving startup time. LED's are free from mercury content which allows for eco-friendly recycling & disposal process. LED's allow for better dimming control of LCD backlight, resulting in super high contrast ratio. It also gives superior color reproduction thanks to consistent brightness across the screen IPS Display Technology Philips IPS displays uses an advanced technology which gives you extra wide viewing angles of 178/178 degree, making it possible to view the display from almost any angle
- even in portrait mode. IPS displays gives you remarkably crisp images with vivid colors, especially suitable for professional video wall & menuboard applications which demand color accuracy & consistent brightness at all times. Optical multi-touch A brand new level of interactivity is now available thanks to the integrated optical touch technology. The sensors on the edge of the screen give you perfect clarity whilst at the same time offering multi-touch interaction, opening up all kinds of possibilities for new interactive applications. USB (Universal Serial Bus) Plug-&-Play compatible Simply connect the display via USB (Universal Serial Bus) to your mediaplayer for automatic touch recognition. The USB (Universal Serial Bus) connector is HID compliant, providing true plug-&-play operation OPS Slot Developed for the Digital Signage market, the Open Pluggable

Specification (OPS) slot is designed to make changing or upgrading your media player mere child’s play. Simply plug your media player in to the display
- & you’re ready. No matter whether you have an entry level, mid-range or high-end media player, OPS is fully compatible bringing you a lower TCO over the longer term. Smart Insert Professional PC's are part of most public s ignage installations. Quite often they increase the overall depth to the display & cause a lot of cable clutter. So we have designed this display with Smart insert in the back cover which is ideal for the integration of a professional small form factor PC. On top of that, the cable management system offers a great solution to keep your cables neat & professional looking Software compatibility Our touch displays are software independent an d supports Windows 8, Windows 7, Vista, XP, Mac OS & Linux Smart Control Control & manage all of the signage displays o n your network with this powerful software tool which means that you can change the settings of your display centrally via an RJ45 or RS232 connection. Smart Control means that you can set the video input, modify the color settings, set the display's ID when creating video walls & even diagnose each display's status, giving you all the power you need to manage your displays from one central location. Designed for 24/7 operation Because business never sleeps, our signage dis plays are designed for 24/7 use. Taking advantage of superior components to ensure a higher level of quality, you can count on this range of models for complete around-the- clock reliability. Technical Specification Display 55” Screen Resolution: 1920 x 1080 @ 60 Hz Aspect Ratio: 16:9 Typical Contrast ratio: 1300:1 Dynamic Contrast ratio: 500, 000:1 Response Time: 12ms Brightness: 450 cd/m 2 Colour

Depth: 1.06B Viewing angle: 178° / 178° Pixel Pitch: 0.63 x 0.63mm Surface treatment: Anti-Glare coating Picture enhancement: 3/2
- 2/2 motion pull down, 3D Combfilter, Motion compens, deinterlacing, Progressive scan, 3D MA deinterlacing, Dynamic contrast enhancement Interactivity Multi-touch technology: Optical sensing Touch points: 5 simultaneous touchpoints Plug & play: HID compliant Protection Glass: 5mm tempered safety glass Connectivity VGA DVI-D HDMI Display Port Component (RCA) Composite (RCA) Audio input: Audio Left/ Right (RCA), 3.5 mm jack Audio output: Audio Left/ Right (RCA), External speaker connector External control: RJ45, RS232C (in/out) D-Sub 9 Other connections: USB (Universal Serial Bus), AC-out, OPS Features Placement: Landscape, Portrait Signal Loop Through: DVI, RS232, VGA Network controllable: RS232, RJ45 Picture performance: Advanced colour control Picture in picture: PIP Screen saving functions: Pixel Shift, Low Brightness VESA Mount: 400 x 400 mm, 400 x 200 mm, 200 x 200 mm Built-in speakers: 2 x 10W Power Power Source: 90
- 240 V AC, 50 / 60 Hz Power Consumption On: 140W Power Consumption (St&-By): <0.5W









...

Deliver your messages in style with this high performance display Enjoy the unique combination of stunning picture quality ...
