MSI R9 290X 4GB GDDR5 Dual DVI HDMI Display Port Graphics Card Gaming App: OC Mode “ Tune up core clock & fan speed to gain a best performance. Gaming Mode “ Provide a stable gaming experience with higher core clock. Silent Mode “ The best operating environment with extremely low noise. Product

Specification Product Name
- R9 290X GAMING 4G GPU
- AMD Radeon R9 290X Codename
- Hawaii XT Processors
- 2816 Units Core Clock (OC Mode)
- 1040 MHz Memory Clock
- 5000 MHz Memory Size
- 4G GDDR5 Memory Bus
- 512 bits Outputs Display Port / HDMI DL DVI-D*2 Card Dimension
- 276 x 127 x 39 mm Form Factor
- ATX Technology Support: Afterburner OC
- GPU/VDDCI Direct X
- 11.2 Open GL
- 4.3 Multi-GPU Technology
- Cross Fire, 4-way (SW) Multi-Display Technology
- Eyefinity 3D Technology
- HD3D Power Saving Tech.
- Power Tune HDCP Capable
- Y Accessory Driver CD
- Y Installation Guide
- Y Power Cable
- 6pin*1, 8pin*1






















...

A graphics card is the single most important element for more FPS. As gamers, we understand that not just any graphics card "will do". That's why we bring you the best of the best. We don't want to bug you with noise & heat, but we DO want to give you more performance. With MSI GAMING series graphics cards you get just that. Core/ Memory 1040 M Hz Core (OC mode) 1030 M Hz (Gaming mode) 1000 M Hz (Silent mode) 8192MB GDDR5 5500 M Hz Memory Video Output Function Dual-link DVI-D x 2 HDMI x 1 (version 1.4a) Display Port x 1 (version 1.2) Specifications Graphics Engine
- AMD Radeon™ R9 290X Bus Standard
- PCI Express x 16 3.0 Memory Type
- GDDR5 Memory Size (MB)
- 8192 Memory Interface
- 512 bits Core Clock Speed (MHz) 1040 M Hz (OC mode) 1030 M Hz (Gaming mode) 1000 M Hz (Silent mode) Memory Clock Speed (MHz)
- 5500 Memory Bandwidth (GB/sec)
- 320 DVI Output
- DL-DVI-Dx 2 Max Resolution: 2560 x 1600 @60 Hz HDMI-Output
- 1 (version 1.4a)
- Max Resolution: 3840x 2160 @30 Hz-30bpp
- 4096x 2160 @24 Hz-24bpp Display Port
- 1 (version 1.2)
- Max Resolution: 4096x 2160 @ 50 Hz Multi-GPU Technology
- Cross Fire, 4-way (SW) HDCP Support
- Y Power consumption (W)
- 250 HDMI Support
- Y Recommended Power Supply (W)
- 750 Dual-link DVI
- Y Power Connectors
- 1x 8-pin, 1x 6pin RAMDACs
- 400 Direct X Version Support
- 12 Open GL Version Support
- 4.3 Cross Fire Support
- Y, 4-ways (SW) Card Dimension (mm)
- 276x 127x 39 Weight
- 1010g

























...

“ Free AMD Radeon Rewards download coupon GOLD from 28th April 2014 whilst stocks last with selected cards. Offer on selected cards only, not available on ex-display cards.” MSI R9 290X LIGHTNING 4GB GDDR5 Dual DVI HDMI Display Port PCI-E Graphics Card Product

Specification Product Name
- R9 290X LIGHTNING GPU
- AMD Radeon R9 290X Codename
- Hawaii XT Processors
- 2816 Units Core Clock
- 1080 MHz Memory Clock
- 5000 MHz Memory Size
- 4GB GDDR5 Memory Bus
- 512 bits Outputs Display Port / HDMI DL-DVI-D*2 Power Consumption
- 250W Card Dimension
- 302x 131x 55 mm Card Weight
- 1580g Form Factor
- ATX Technology Support Afterburner OC
- GPU/ Memory/VDDCI Direct X
- 11.2 Open GL
- 4.3 Multi-GPU
- Cross Fire, 4-way (SW) Multi-Display
- Eyefinity 3D Technology
- HD3D Power Saving
- Power Tune HDCP Capable
- Y





















...

“ Free AMD Radeon Rewards download coupon GOLD from 28th April 2014 whilst stocks last with selected cards. Offer on selected cards only, not available on ex-display cards.” Specifications Graphics Engine
- AMD Radeon R9 295X2 Interface
- PCI Express x 16 3.0 Memory Type
- GDDR5 Memory Size (MB)
- 8192 Memory Interface
- 512 bits x 2 Core Clock Speed (MHz)
- 1018 Mhz Memory Clock Speed (MHz)
- 5000 DVI Output
- 1 (Dual-link DVI-D) Mini Display Port
- 4 HDCP Support
- Y HDMI Support
- Y Dual-link DVI
- Y Display Output (Max Resolution)
- 2560x 1600 RAMDACs
- 400 Direct X Version Support
- 11.2 Open GL Version Support
- 4.3 Cross Fire Support
- Y, 2-way Card Dimension (mm)
- Card: 307x 111x 65, Cooler: 153x 120x 63

















...

AMD High-Bandwidth Memory HBM technology, featuring a wide-interface 4096-bit memory architecture Higher bandwidth performance & less power consumption than DDR4 & GDDR5 AMD HD3D Technology Stereoscopic 3D display/glasses & Blu-ray 3D support Stereoscopic 3D gaming support 3rd party Stereoscopic 3D middleware software support MSI Afterburner Overclocking Utility Monitor fan speed profile In-game video recording i OS/ Android remote control Built-in Direct X12 benchmark Product Name
- R9 Fury X 4G Model
- V803 GPU
- AMD Radeon™ R9 Fury X Codename
- Fiji XT Processors
- 4096 Units Boost / Base Core Clock
- 1050 MHz Memory Clock
- 1000 MHz Memory Size
- 4GB HBM Memory Bus
- 4096bit HBM Output
- Display Portx 3/HDMI x 1 Power Consumption / Connectors
- 350W / 8-pin x 2

Dimensions (mm) / Weight (g)
- Card: 195x 115x 39 Cooler:153x 118x 64/1494 Form Factor
- ATX














...

Next-Gen Thermal Design: Twin Frozr V Torx Fan Maximizes airflow & dispersion. Super SUArchitecture Improves dissipation efficiency through special heatpipelayout. Zero Frozr Fans stop spinning in low load to keep the card quiet & increase lifetime. Airflow Control technology Deflects airflow towards heatpipesto improve thermal efficiency. Gaming App Easy Tuning–OC, Gaming & Silent modes adjust Graphics Card settings based on user requirements. Eye Rest: Dedicated color profiles for Gaming, movies & Eye Rest, allow to custom visual related setting what you like. LED control choose from 5 unique lighting modes to set the right ambience for their gaming moments with just one click Military Class 4 Components Certified to MIL-STD-810G standards for top stability & quality. Built with Hi-c CAP, Solid CAP, & New SFC components. Product

Specification Model Name R7 370 GAMING 2G Model V305 GPU AMD Radeon R7 370 Codename Trinidad Processors 1024 Units Core Boost/ Base Clock (OC) 1050 / 1000 MHz Memory Clock (OC) 5700 MHz Memory Size 2GB GDDR5 Memory Bus 256 bits Output Display Port/HDMI DL-DVI-I/DL-DVI-D Power Consumption/ Connector 110 W / 6-pin x 1 Dimension / Weight 258x 132x 37 mm / 620 g Form Factor ATX Technology Support Afterburner OC GPU Direct X 12 Open GL 4.4 Multi-GPU Cross Fire TM Multi-Display Eyefinity 3D Technology HD3D Power Saving Power Tune HDCP Capable Yes

...

MSI Radeon R9 290X 4GB GDDR5 Dual DVI HDMI Display Port PCI-E Graphics Card A graphics card is the single most important element for more FPS. As gamers, we understand that not just any graphics card "will do". Thats why we bring you the best of the best. We dont want to bug you with noise & heat, but we DO want to give you more performance. With MSI GAMING series graphics cards you get just that. Graphics Engine
- AMD Radeon R9 290X Interface
- PCI Express x 16 3.0 Memory Type
- GDDR5 Memory Size (MB)
- 4096 Memory Interface
- 512 bits Core Clock Speed (MHz) 1040 M Hz Core (OC mode) 1030 M Hz Core (Gaming mode) 1000 M Hz Core (Silent mode) Memory Clock Speed (MHz)
- 5000 DVI Output
- 2 (Dual-link DVI-D) HDMI-Output
- 1 (version 1.4a) Display Port
- 1 HDCP Support
- Y HDMI Support
- Y Dual-link DVI
- Y Display Output (Max Resolution)
- 2560x 1600 RAMDACs
- 400 Direct X Version Support
- 11.2 Open GL Version Support
- 4.3 Cross Fire Support
- Y, 4-ways (SW) Card Dimension (mm)
- 276x 127x 39mm

















...

MSI Radeon R9 380 Gaming 2GB GDDR5 Dul-Link DVI-D DVI-I HDMI Display Port PCI-E Graphics Card Next-Gen Thermal Design: Twin Frozr V Torx Fan Maximizes airflow & dispersion. Super SUArchitecture Improves dissipation efficiency through Special heatpipelayout. Zero Frozr Fans stop spinning in low load to keep the card quiet & increase lifetime. Airflow Control technology Deflects airflow towards heatpipesto improve thermal efficiency. Gaming App Easy Tuning–OC, Gaming & Silent modes adjust Graphics Card settings based on user requirements. Eye Rest: Dedicated color profiles for Gaming, movies & Eye Rest, allow to custom visual related setting what you like. LED control choose from 5 unique lighting modes to set the right ambience for their gaming moments with just one click Military Class 4 Components Certified to MIL-STD-810G standards for top stability & quality. Built with Hi-c CAP, Solid CAP, & New SFC components. Product

Specification Model Name
- R9 380 GAMING 2G GPU
- AMD Radeon™ R9 380 Codename
- Antigua Processors
- 1792 Units Core Clock (OC)
- 1000 MHz Memory
- Clock (OC) 5600 MHz Memory
- Size 2GB GDDR5 Memory
- Bus 256 bits Output
- Display Port/HDMI DL-DVI-I/DL-DVI-D Power Consumption/ Connector
- 190 W / 6-pin x 2 Dimension / Weight
- 268x 138x 40mm / 943 g Form Factor
- ATX Technology Support Afterburner OC
- GPU Direct X
- 12 Open GL
- 4.4 Multi-GPU
- Cross Fire TM Multi-Display
- Eyefinity 3D Technology
- HD3D Power Saving
- Power Tune HDCP Capable
- Yes





















...

MSI Radeon R9 380 GAMING 4GB GDDR5 Dual-Link DVI-D HDMI Display Port PCI-E Graphics card Next-Gen Thermal Design: Twin Frozr V Torx Fan Maximizes airflow & dispersion. Super SUArchitecture Improves dissipation efficiency through special heatpipelayout. Zero Frozr Fans stop spinning in low load to keep the card quiet & increase lifetime. Airflow Control technology Deflects airflow towards heatpipesto improve thermal efficiency. Gaming App Easy Tuning–OC, Gaming & Silent modes adjust Graphics Card settings based on user requirements. Eye Rest: Dedicated color profiles for Gaming, movies & Eye Rest, allow to custom visual related setting what you like. LED control
- choose from 5 unique lighting modes to set the right ambience for their gaming moments with just one click Military Class 4 Components Certified to MIL-STD-810G standards for top stability & quality. Built with Hi-c CAP, Solid CAP, & New SFC components. Product

Specification Model Name
- R9 380 GAMING 4G GPU
- AMD Radeon™ R9 380 Codename
- Antigua Processors
- 1792 Units Core Clock (OC)
- 1000 MHz Memory Clock (OC)
- 5800 MHz Memory Size
- 4GB GDDR5 Memory Bus
- 256 bits Output
- Display Port/HDMI DL-DVI-I/DL-DVI-D Power Consumption/ Connector
- 190 W / 6-pin x 2 Dimension / Weight
- 268x 138x 40mm / 943 g Form Factor
- ATX Technology Support Afterburner OC
- GPU Direct X
- 12 Open GL
- 4.4 Multi-GPU
- Cross Fire TM Multi-Display
- Eyefinity 3D Technology
- HD3D Power Saving
- Power Tune HDCP Capable
- Yes






















...

MSI Radeon R9 390 Gaming 8GB GDDR5 Dual-Link DVI-D HDMI Display Port PCI-E Graphics card Next-Gen Thermal Design: Twin Frozr V Torx Fan Maximizes airflow & dispersion. Super Pipe Improves dissipation through efficient heatpipelayout. Zero Frozr Fans stop spinning in low load to keep the card quiet & increase lifetime. Airflow Control technology Deflects airflow towards heatpipesto improve thermal efficiency. Gaming App Easy Tuning–OC, Gaming & Silent modes adjust Graphics Card settings based on user requirements. Eye Rest: Dedicated color profiles for Gaming, movies & Eye Rest, allow to custom visual related setting what you like. LED control choose from 5 unique lighting modes to set the right ambience for their gaming moments with just one click Military Class 4 Components Certified to MIL-STD-810G standards for top stability & quality. Built with Hi-c CAP, Solid CAP, & New SFC components. Product

Specification Model Name
- R9 390 GAMING 8G GPU
- AMD Radeon™ R9 390 Codename
- Grenada PRO Processors
- 2560 Units Core Clock (OC)
- 1060 MHz Memory Clock (OC)
- 6100 MHz Memory Size
- 8GB GDDR5 Memory Bus
- 512 bits Output
- Display Port/HDMI DL-DVI-D x 2 Power Consumption/ Connector
- 275 W / 6-pin x 1, 8-pin x 1 Dimension / Weight
- 277x 129x 51 mm / 1312g Form Factor
- ATX Technology Support Afterburner OC
- GPU Direct X
- 12 Open GL
- 4.4 Multi-GPU
- Cross Fire TM Multi-Display
- Eyefinity 3D Technology
- HD3D Power Saving
- Power Tune HDCP Capable
- Yes





















...
