CPU 4th Generation Intel Core i 7 / Core i 5 / Core i 3 / Pentium / Celeron processors for LGA 1150 socket Please refer to CPU Support for compatible CPU; the above description is for reference only Chipset Intel H81 Express Chipset Main Memory Support two DDR3 DIMMs 1066/1333/1600 MHz, up to 16GB Max Supports Dual-Channel mode Slots 1 x PCIe 2.0 x 16 slot 1 x PCIe x 1 slot On-Board SATA SATAIII controller integrated in Intel H81 chipset Up to 6 Gb/s transfer speed Supports two SATAIII ports (SATA1~2) by H81 SATAII controller integrated in Intel H81 chipset Up to 3 Gb/s transfer speed Supports two SATAII ports (SATA3~4) by H81 USB (Universal Serial Bus) 3.0 2 x USB (Universal Serial Bus) 3.0 ports on the back panel Audio Chip integrated by Realtek ALC887 Flexible 8-channel audio with jack sensing Compliant with Azalia 1.0 spec LAN Supports LAN 10/100/1000 Fast Ethernet by Realtek RTL8111G Internal I/O Connectors 1 x ATX 24-Pin power connector 1 x 4-pin ATX 12V power connector 2 x SATAIII connectors 2 x SATAII connectors 2 x USB (Universal Serial Bus) 2.0 connectors 1 x Serial port connector 1 x Trusted Platform Module (TPM) header 1 x Chasis intrusion connector 1 x Front Panel Audio connector Back Panel I/O Ports 1 x PS/2 keyboard port 1 x PS/2 mouse port 4 x USB (Universal Serial Bus) 2.0 ports 2 x USB (Universal Serial Bus) 3.0 ports 1 x RJ45 LAN Jack 1 x 3 in 1 audio jack 1 x Graphics card port 1 x DVI-D port BIOS The motherboard BIOS provides " Plug & Play" BIOS which detects the peripheral devices & expansion cards of the board automatically. The motherboard provides a Desktop Management Interface (DMI) function which records your motherboard specifications.

Dimensions 22.6cm (L) x 17.3cm (W) Micro-ATX Form Factor Mounting 6 mounting holes

...

Packed with features, loads of ports, high quality cooling & the MSI Command Centre make this a motherboard to be reckoned with. Add in the Intel H87 Express Chipset & Click BIOS 4 technology & the MSI H87-G43 is definitely a board for gamers & DIY builders to consider. Loaded With Features Scroll down the page for the full technical

Specification of the MSI H87-G43 but here are a few highlights. Click BIOS 4 Specially optimised for Windows 8 the MSI Click BIOS 4 feature helps your system run faster & more efficiently. There are some very useful functions here & all can be controlled from an easy to navigate graphical interface. Have complete control of your system with the Hardware Monitor. This feature allows you check all your primary components from one handy display. Similarly the Board Explorer enables you to observe all the different ports & connected devices. One of the standout qualities of the MSI H87-G43 motherboard is the ability to store up to 8 OC profiles. & the OC Profile Preview feature means that you can compere the current system settings with any one of the stored profiles. Command Centre Command Centre can be downloaded from the Apple App Store or Google Play. This useful app means that you can control your motherboard from your mobile device. But from Command Centre you can also fine tune the performance of all your fans enabling you to balance air flow with reduced noise. You can also speed up your system from within the Command Centre by creating a RAMDisk to store all your most used files. OC Genie 4 The OC Genie 4 function is the ultimate one button overclocking solution. Simply push the button & the MSI H87-G43 will overclock your system for you. Features Of The MSI Socket 1150 HDMI D-Sub DVI 7.1-channel Audio ATX Motherboard Intel H87 Express Chipset Support for 4th Gen Intel Core™/ Pentium/ Celeron processors for the LGA 1150 socket USB (Universal Serial Bus) 3.0 + SATA 6 Gb AMD Crossfire support Easy to install OC Genie 4 for automatic overclocking Click BIOS 4 PCI Express Generation 3 for faster transfer rates What Other Buyers Have Said On Reevoo “ Has more ports than you can shake a stick at. All the usual expansion ports plus USB3 on the board & headers. Works solidly & keeps very cool.” Paul “ Super easy to use / install.” Rachel " Great board, nice & easy, with a great BIOS." Alexander Technical Specifications CPU 4th Generation Intel Core i 7 / Core i 5 / Core i 3 / Pentium / Celeron processors for LGA 1150 socket Chipset Intel H87 Express Chipset Main Memory - Support four DDR3 DIMMs 1066/1333/1600 MHz. up to 64GB Max
- Supports Dual-Channel mode
- Supports non-ECC, un-buffered memory
- Supports Intel Extreme Memory Profile (XMP) Slots 1 x PCIe 3.0 x 16 slot 1 x PCIe 2.0 x 16 slot - PCI_E4 supports up to PCIe 2.0 x 4 speed 2 x PCIe 2.0 x 1 slots 3 x PCI slots On-Board SATA SATAIII controller integrated in Intel H87 chipset Up to 6 Gb/s transfer speed. Supports six SATAIII ports (SATA1~6) by H87 Supports Intel Smart Response Technology, Intel Rapid Start Technology & Intel Smart Connect Technology Supports Intel Core processors on Windows 7 & Windows 8. RAID
- SATA1~6 support Intel Rapid Storage Technology enterprise (AHCI/ RAID 0/ 1/ 5/ 10) by Intel H87 USB (Universal Serial Bus) Intel H87 Express Chipset
- 4 x USB (Universal Serial Bus) 3.0 ports (2 ports on the back panel, 2 ports available through the internal USB (Universal Serial Bus) connectors)
- 10 x USB (Universal Serial Bus) 2.0 ports (6 ports on the back panel, 4 ports available through the internal USB (Universal Serial Bus) connectors) Audio Realtek ALC892 Codec
- 7.1-Channel High Definition Audio LAN 1x Realtek 8111E Gigabit LAN controller Internal I/O Connectors ATX 24-Pin power connector 8-pin ATX 12V power connector 2 x 4-pin CPU fan connectors 3 x 4-pin system fan connectors 1 x Clear CMOS jumper 6 x Serial ATAIII connectors 2 x USB (Universal Serial Bus) 2.0 connectors (supports additional 4 USB (Universal Serial Bus) 2.0 ports) 1 x USB (Universal Serial Bus) 3.0 connector (supports additional 2 USB (Universal Serial Bus) 3.0 ports) 1 x Serial port connector 1 x Parallel port connector 2 x System panel connectors 1 x Trusted Platform Module (TPM) header 1 x Front Panel Audio connector 1 x Chassis Intrusion connector Back Panel I/O Ports 1 x PS/2 keyboard/ mouse combo port 6 x USB (Universal Serial Bus) 2.0 ports 2 x USB (Universal Serial Bus) 3.0 ports 1 x RJ45 LAN Jack 1 x 6 in 1 audio jack 1 x VGA port, supporting a maximum resolution of 1920x 1200 @60 Hz, 24bpp 1 x DVI-D port, supporting a maximum resolution of 1920x 1200 @60 Hz, 24bpp 1 x HDMI port, supporting a maximum resolution of 4096x 2160 @24 Hz, 24bpp/ 2560x 1600 @60 Hz, 24bpp/ 1920x 1080 @60 Hz, 36bpp This platform supports dual-display & triple-display function Multi-GPU Support Supports 2-Way AMD Cross Fire TM Technology Supports Windows 7 & Windows 8. BIOS The motherboard BIOS provides " Plug & Play" BIOS which detects the peripheral devices & expansion cards of the board automatically. The motherboard provides a Desktop Management Interface (DMI) function which records your motherboard specifications. Dimension 12.0 in. x 9.6 in. (30.5 cm x 24.4 cm) ATX Form Factor Mounting 9 mounting holes Product MSI Socket 1150 HDMI D-Sub DVI 7.1-channel Audio ATX Motherboard








...

Military Class 4 MSI's new Military Class 4 components support you while you are questing, racing, battling & shooting your way to the top. MSI's Military Class 4 components deliver record-breaking stability when you need to keep cool in the heat of battle. The new standard in stability built on a proven technology of high quality components. CPU 4th Generation Intel Core i 7 / Core i 5 / Core i 3 / Pentium / Celeron processors for LGA 1150 socket Please refer to CPU Support for compatible CPU; the above description is for reference only. Chipset Intel H87 Express Main Memory Support two DDR3 DIMMs 1066/1333/1600 MHz, up to 16GB Max Supports Dual-Channel mode Slots 1 x PCIe 3.0 x 16 slot 1 x PCIe x 1 slot On-Board SATA
- SATAIII controller integrated in Intel H87 chipset
- Up to 6 Gb/s transfer speed.
- Supports four SATAIII ports (SATA1~4) by H87 USB (Universal Serial Bus) 2 x USB (Universal Serial Bus) 3.0 ports on the back panel 8 x USB (Universal Serial Bus) 2.0 ports (4 ports on the back panel, 4 ports available through the internal USB (Universal Serial Bus) connectors) Audio Chip integrated by Realtek ALC887 Flexible 8-channel audio with jack sensing Compliant with Azalia 1.0 spec LAN 1x Realtek 8111G Gigabit LAN controller Internal I/O Connectors
- 1 x ATX 24-Pin power connector
- 1 x 4-pin ATX 12V power connector
- CPU x 1 / System x 2 FAN connectors
- Clear CMOS jumper
- 4 x SATAIII connectors
- 2 x USB (Universal Serial Bus) 2.0 connectors
- 1 x Serial port connector
- 1 x Trusted Platform Module (TPM) header
- 1 x Front Panel Audio connector
- 1 x Chassis Intrusion connector Back Panel I/O Ports
- 1 x PS/2 keyboard port
- 1 x PS/2 mouse port
- 2 x USB (Universal Serial Bus) 3.0 ports
- 4 x USB (Universal Serial Bus) 2.0 ports
- 1 x RJ45 LAN jack
- 1 x 3 in 1 audio jack
- 1 x D-Sub port with max. resolution up to 1920x 1200 @60 Hz
- 1 x HDMI port with max. resolution up to 4096x 2160 @24 Hz, 24bpp/ 2560x 1600 @60 Hz, 24bpp/ 1920x 1080 @60 Hz, 36bpp BIOS The motherboard BIOS provides " Plug & Play" BIOS which detects the peripheral devices & expansion cards of the board automatically. The motherboard provides a Desktop Management Interface (DMI) function which records your motherboard specifications. Dimension 22.6cm (L) x 17.3cm (W) Micro-ATX Form Factor




















...

MSI H97 GAMING 3 Socket LGA 1150 VGA DVI HDMI Display Port 7.1-Channel HD Audio ATX Motherboard CPU Supports 4th & 5th Generation Intel Core Processors, & Intel Pentium & Celeron Processors for Socket LGA1150 Please refer to CPU Support for compatible CPU; the above description is for reference only. Chipset Intel H97 Express Chipset Main Memory Support four DDR3 1066/1333/1600 MHz DRAM, 32GB Max Dual channel memory architecture Supports Intel Extreme Memory Profile (XMP) Supports non-ECC, un-buffered memory Slots 1 x PCIe 3.0 x 16 slot (PCI_E2, supports x 16 speed) 1 x PCIe 2.0 x 16 slot (PCI_E4, supports x 4 speed)* 2 x PCIe 2.0 x 1 slots 3 x PCI slots The PCIe x 1 slots (PCI_E1, PCI_E3) will be unavailable when installing an expansion card in the PCI_E4 slot. On-Board SATA Intel H97 Express Chipset 6 x SATA 6 Gb/s ports (SATA1~6) 1 x M.2 port* M.2 port supports M.2 SATA 6 Gb/s module M.2 port supports M.2 PCIe module up to 10 Gb/s speed** M.2 port supports 4.2cm/ 6cm/ 8cm length module Supports RAID 0, RAID1, RAID 5 & RAID 10*** Supports Intel Smart Response Technology, Intel Rapid Start Technology & Intel Smart Connect Technology**** The SATA5 & SATA6 ports will be unavailable when installing a module in the M.2 port. M.2 PCIe interface only supports UEFI option ROM, NOT support legacy option ROM. M.2 PCIe interface does not support RAID 0, RAID1, RAID 5 & RAID 10. Supports Intel Core processors on Windows 7 & Windows 8/ 8.1 USB (Universal Serial Bus) Intel H97 Express Chipset 6 x USB (Universal Serial Bus) 3.0 ports (4 ports on the back panel, 2 ports available through the internal USB (Universal Serial Bus) connectors) 6 x USB (Universal Serial Bus) 2.0 ports (2 ports on the back panel, 4 ports available through the internal USB (Universal Serial Bus) connectors) Audio Realtek ALC1150 Codec 7.1-Channel High Definition Audio Supports S/PDIF output LAN 1x Killer E2205 Gigabit LAN controller* The Killer Network Manager is only available for Windows 7 & Windows 8/8.1 currently. The supported drivers for other operating systems would be available on the website if provided by vendor. Multi-GPU Supports 2-Way AMD Cross Fire Technology* Supports Windows 7 & Windows 8/8.1. Internal I/O Connectors 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 6 x SATA 6 Gb/s connectors 2 x USB (Universal Serial Bus) 2.0 connectors (supports additional 4 USB (Universal Serial Bus) 2.0 ports) 1 x USB (Universal Serial Bus) 3.0 connector (supports additional 2 USB (Universal Serial Bus) 3.0 ports) 2 x 4-pin CPU fan connectors 3 x 4-pin system fan connectors 1 x Clear CMOS jumper 1 x Front panel audio connector 2 x System panel connectors 1 x TPM module connector 1 x Serial port connector 1 x Parallel port connector 1 x Chassis Intrusion connector 1 x Direct audio power connector 1 x Audio power switch Back Panel I/O Ports 1 x PS/2 keyboard/ mouse combo port 1 x LAN (RJ45) port 2 x USB (Universal Serial Bus) 2.0 ports 4 x USB (Universal Serial Bus) 3.0 ports 1 x VGA port, supporting a maximum resolution of 1920x 1200@60 Hz 1 x DVI-D port, supporting a maximum resolution of 1920x 1200@60 Hz 1 x HDMI port, supporting a maximum resolution of 4096x 2304@24 Hz, 2560x 1600@60 Hz, 3840x 2160@60 Hz, 1920x 1200@60 Hz 1 x Display Port, supporting a maximum resolution of 4096x 2304@24 Hz, 2560x 1600@60 Hz, 3840x 2160@60 Hz, 1920x 1200@60 Hz 6 x OFC audio jacks 1 x Optical S/PDIF OUT connector This plarform supports dual-display function & triple-display function BIOS The motherboard BIOS provides " Plug & Play" BIOS which detects the peripheral devices & expansion cards of the board automatically. The motherboard provides a Desktop Management Interface (DMI) function which records your motherboard specifications. Dimension 12 in. x 9.6 in. (30.5 cm x 24.4 cm) ATX Form Factor Mounting 9 mounting holes. ...

Supports 4th & 5th Gen Intel Core™/ Pentium/ Celeron processors for LGA 1150 socket Supports DDR3-1600 Memory M.2 + USB (Universal Serial Bus) 3.0 + SATA 6 Gb/s Military Class 4: finest top quality & Stability Guard-Pro: enhanced Protection & Power Efficiency OC Genie 4: Overclock in 1 Second Click BIOS 4: Easily Fine-tune Your System 4K UHD Support: Ultra-high Definition Visual Experience 4 Display Outputs: Display Port/HDMI/DVI/D-Sub Support PCI Express Gen 3: World's 1st PCI Express Gen 3 Motherboard Brand Multi-GPU: AMD Cross Fire Support Command Center: Control & Customize Your PC Settings Fast Boot: Quickly Boot Up & Enter OS in A Few Seconds Super RAID: Easily Setup & Configure Intel Technologies Intel Small Business Advantage 2.0: Streamiline PC Maintenance & Security ...

Specifications Graphics Engine
- AMD Radeon HD 6450 Bus Standard
- PCI Express x 16 2.1 Memory Type
- DDR3 Memory Size (MB)
-



...

MSI HD 6450 1GB DDR3 Dual DVI HDMI Display Port PCI-E Graphics Card Key

Features: Video Capture
- Predator:
-



...

MSI HD 6450 2GB DDR3 DVI HDMI Display Port PCI-E Graphics Card Key

Features: Low Profile Design:
- Low profile


...

MSI Afterburner overclocking utility Support GPU Overvoltage function. Support Kombustor to test user’s graphics cards. Support Real-Time Video Capturing function to record in-game scenes & share with friends. 8cm PWM fan with Propeller Blade technology 8cm PWM fan provides better dissipation than reference. Propeller Blade technology offers 20% more airflow than traditional fan design. AMD GHz Edition The default core clock is up to 1 G Hz. Provides better performance & visual experience. All Solid Capacitors 10 years ultra-long lifetime (under full load) Lower temperature & higher efficiency Aluminum core without explosion.

Specification
- Graphics Engine
- ATI Radeon HD 7770 Bus Standard
- PCI Express x 16 3.0 Memory Type
- GDDR5 Memory Size (MB)
- 1024 Memory Interface
- 128 bits Core Clock Speed (MHz)
- 1000 Memory Clock Speed (MHz)
- 4500 DVI Output
- 1 HDMI-Output
- 1 Display Port
- 1 HDCP Support
- Y HDMI Support
- Y Dual-link DVI
- Y Display Output (Max Resolution)
- 2560x 1600 RAMDACs
- 400 Direct X Version Support
- 11 Open GL Version Support
- 4.2 Card Dimension (mm)
- 193x 111x 38mm




















...

Free Never Settle Forever Bronze Games Coupon. Select 1 game from the AMD Redemption Portal. Valid with selected purchases from 20th August 2013 whilst coupon stocks last. Offer not available on ex display cards. MSI HD 7790 OC 2GB GDDR5 DVI HDMI Display Port PCI-E Graphics Card Key

Features: Propeller Blade Technology:
- 10 cm fan generates more airflow.
- MSIs exclusive Propeller Blade Technology.
- Increases 20% more airflow & cool down more components. Military Class III Components:
- Meet MIL-STD-810G standard to ensure the best stability & quality.
- Adopt All Solid CAP & SFC. MSI Afterburner Overclocking Utility:
- Support advanced fan speed control function.
- Support in-game video recording.
- Support wireless control by android/i OS handheld devices.
- Support built-in DX11 effect test. AMD HD3D technology:
- Stereoscopic 3D display/glasses & Blu-ray 3D support.
- Stereoscopic 3D gaming support.
- 3rd party Stereoscopic 3D middleware software support. Graphics Engine
- AMD Radeon HD 7790 Interface
- PCI Express x 16 3.0 Memory Type
- GDDR5 Memory Size (MB)
- 2048 Memory Interface
- 128 bits Core Clock Speed (MHz)
- 1050 Memory Clock Speed (MHz)
- 6000 DVI Output
- Dual-link DVI-I x 1, Dual-link DVI-D x 1 HDMI-Output
- 1 (version 1.4a) Display Port
- 1 (version 1.2) HDCP Support
- Y HDMI Support
- Y Dual-link DVI
- Y Display Output (Max Resolution)
- 2560x 1600 RAMDACs
- 400 Direct X Version Support
- 11 Open GL Version Support
- 4.2 Cross Fire Support
- Y Card Dimension (mm)
- 182 x 117 x 38mm Weight
- 410g

































...
