MSI A88XM-E35 V2 Socket FM2+ VGA DVI-D HDMI Micro-ATX Motherboard CPU AMD A-Series/ Athlon„¢ Processors* for the FM2+ package Also support FM2 A-Series/ Athlon„¢ Processors Please refer to CPU Support for compatible CPU; the above description is for reference only. Chipset AMD A88X Chipset Main Memory 2 x DDR3 memory slots supporting up to 32GB Supports DDR3 1333/ 1600/ 1866/ 2133* (*OC) MHz Dual channel memory architecture Supports non-ECC, un-buffered memory Supports AMD Memory Profile (AMP) Supports Extreme Memory Profile (XMP) For the support status of AMP/XMP memory modules, please take MSIs Memory Support list as reference. Slots 1 PCI Express 3.0 x 16 slot* 1 PCI Express 2.0 x 1 slot 1 PCI slot Only FM2+ processors can support PCIe 3.0 Graphics 1 x VGA port, supporting a maximum resolution of 1920x 1200 @ 60 Hz, 24bpp 1 x DVI-D port, supporting a maximum resolution of 2560x 1600@60 Hz, 24bpp/ 1920x 1200 @ 60 Hz, 24bpp 1 x HDMI port, supporting a maximum resolution of 4096x 2160@24 Hz, 36bpp*/ 3840x 2160@30 Hz, 36bpp*/ 1920x 1200@120 Hz, 36bpp & 1920x 1200@60 Hz, 36bpp Only support when using an FM2+ APU On-Board SATA 6 x SATA 6 Gb/s ports by AMD A88X Supports storage & data transfers at up to 6 Gb/s SATA1~6 ports support RAID 0/1/5/10 modes by AMD A88X Audio Chipset integrated by Realtek ALC887 Flexible 8-channel audio with jack sensing Compliant with Azalia 1.0 Spec LAN Supports Gigabit LAN by Realtek RTL8111G Supports 10 Mb/s, 100 Mb/s & 1000 Mb/s Compliance with PCI-Express Bus

Specification v 1.0a Internal I/O Connectors 1 x 24-pin ATX main power connector 1 x 4-pin ATX 12V power connector 6 x SATA 6 Gb/s connectors 2 x USB (Universal Serial Bus) 2.0 connectors (supports additional 4 USB (Universal Serial Bus) 2.0 ports) 1 x USB (Universal Serial Bus) 3.0 connector (supports additional 2 USB (Universal Serial Bus) 3.0 ports) 1 x 4-pin CPU fan connector 1 x 4-pin system fan connector 1 x 3-pin system fan connector 1 x Front panel audio connector 2 x System panel connector 1 x Chassis Intrusion connector 1 x TPM module connector 1 x Serial port connector 1 x Parallel port connector 1 x Clear CMOS jumper 2 x USB (Universal Serial Bus) power jumpers Back Panel I/O Ports 1 x PS/2 keyboard port 1 x PS/2 mouse port 4 x USB (Universal Serial Bus) 2.0 ports, 2 x USB (Universal Serial Bus) 3.0 ports 1 x VGA port 1 x DVI-D port 1 x HDMI port 1 x LAN (RJ45) port 3 x audio jacks This platform supports dual-display function (HDMI+VGA, HDMI+DVI, VGA+DVI) & triple-display function (HDMI+VGA+DVI) MSI Reminds You... The graphic output can only work with CPUs with GPUs core inside. Dimension Micro-ATX (22.6 cm x 21.6 cm) Mounting 6 mounting holes

...

The game is on with All-in-One! Based on the success of MSI's powerful gaming motherboards & graphics cards, MSI has successfully integrated all parts of a full-worthy & top performing gaming desktop into a large size Anti-glare display (specific model only), thereby creating the worlds first All-in-One PC for gaming enthusiasts. Covered by a top-notch audio solution this gaming All-in-One PC will impress both casual & enthusiastic gamers with visual awe & a striking performance. Gaming is for everyone! All around the world, gaming is done in various ways by various people. That's the reason why MSI Gaming All-in-One PC's are designed to fit the needs of various types of gamers. Whether you are young or old, play casual or hardcore, compute after school or in the night or use your PC for more than just gaming, the MSI Gaming All-in-One PC is your companion. Supersized & super sharp Powerful hardware needs a matching monitor to show it all off. That's why MSI's Gaming All-in-One PCs are featured with a large frameless anti-glare display (specific model only), capable of playing Full HD images & videos without the hassle of light reflections preventing you from seeing what's happening on your screen. Processor Intel Core i 7-4870HQ 2.5 G Hz Turbo boost up to 3.7 G Hz 6MB Cache Memory 16GB DDR3L RAM 1600 M Hz (max) Configuration 2 x 8GB Two SO-DIMMs sockets Hard Drive 1TB SATA HDD 7200rpm Optical Drive Tray-in DVD Super Multi Software Operating System: Windows 8.1 64bit Display 27” LED Multi-touch with Anti-Flicker & Less Blue Light Resolution 2560 x 1440 Non-Touch Graphics NVIDIA Ge Force GTX 970M 6GB GDDR5 Audio Yamaha Speakers 5W x 2 Networking LAN: Killer E2205 10/100/1000mbps Intel Dual Band Wireless-AC 7260 802.11ac Bluetooth Power Supply 230 Watt

Dimensions

Height: 482.96 mm

Depth: 66 mm

Width: 672.23 mm Weight: 16.15kg Interfaces HDMI VGA Mic-in/ Headphone-out 4 x USB (Universal Serial Bus) 3.0 port 2 x USB (Universal Serial Bus) 2.0 port Warranty / Misc 1 Year Manufacturer Warranty 2M-pixel Full HD







...

MSI AM1I Socket AM1 VGA DVI HDMI 8-channel (7.1) HD Audio Mini-ITX Motherboard Socket
- AM1 CPU (Max Support)
- AMD Socket AM1

...

Specifications CPU AMD Socket AM1 Athlon™ / Sempron™ Processors Please refer to CPU Support on MSI for compatible CPU; the above description is for reference only Main Memory 2 x DDR3 memory slots support up to 32GB Supports DDR3 1333/ 1600 MHz Single channel memory architecture Supports non-ECC, un-buffered memory * For the support status of AMP/XMP memory modules, please take MSI’s Memory Support list as reference * The Max. 32GB memory capacity can be supported with DIMMs of 16GB (or above). MSI will update Memory support list once the DIMMs are available on the market Remark: Due to a Windows 32-bit operating system limitation, when more than 4 GB of physical memory is installed, the actual memory size displayed will be less than the size of the physical memory installed Slots 1 x PCIe 2.0 x 16 slot, supports x 4 speed 2 x PCIe 2.0 x 1 slots Graphics 1 x VGA port, supporting a maximum resolution of 2048x 1280 1 x DVI-D port, supporting a maximum resolution of 1920x 1200 1 x HDMI port, supporting a maximum resolution of 4096x 2160 * Only supports dual-display function * HDMI port does not guarantee support to play for 4K video On-Board SATA 2 x SATA 6 Gb/s ports
- Supports storage & data transfers at up to 6 Gb/s Audio Chipset integrated by Realtek ALC887
- 7.1-Channel High Definition Audio LAN Supports Gigabit LAN by Realtek RTL8111G
- Supports 10 Mb/s, 100 Mb/s & 1000 Mb/s Back Panel I/O Ports 1 x PS/2 keyboard/mouse combo port 1 x VGA port 1 x DVI-D port 1 x HDMI port 2 x USB (Universal Serial Bus) 3.0 ports 4 x USB (Universal Serial Bus) 2.0 ports 1 x LAN (RJ45) port 3 x audio jacks Internal I/O Connectors 1 x 24-pin ATX main power connector 1 x 4-pin ATX 12V power connector 2 x SATA 6 Gb/s connectors 1 x USB (Universal Serial Bus) 3.0 connector (supports additional 2 USB (Universal Serial Bus) 3.0 ports) 2 x USB (Universal Serial Bus) 2.0 connectors (supports additional 4 USB (Universal Serial Bus) 2.0 ports) 1 x 3-pin CPU fan connector 1 x 4-pin system fan connector 1 x Front panel audio connector 1 x Serial port connector 1 x TPM connector 1 x System panel connector 1 x Chassis Intrusion connector 1 x Clear CMOS jumper * This platform supports dual-display function (HDMI+VGA, HDMI+DVI, VGA+DVI)

Dimensions Micro-ATX 22.6cm x 17.3cm 6 mounting holes




...

MSI B150 GAMING M3 Socket LGA 1151 DVI-D HDMI 7.1-Channel HD Audio ATX Motherboard Specifications CPU Supports 6th Gen Intel Core i 3/i 5/i 7 processors, & Intel Pentium & Celeron processors for Socket LGA1151 Please refer to CPU Support for compatible CPU; the above description is for reference only. Chipset: Intel B150 Chipset Main Memory: 4 x DDR4 memory slots, support up to 64GB Supports DDR4 2133 MHz* Dual channel memory architecture Supports ECC, un-buffered memory Supports Intel Extreme Memory Profile (XMP) Slots: 2 x PCIe 3.0 x 16 slots* 2 x PCIe 3.0 x 1 slots 3 x PCI slots The PCI_E4 slot will only run PCIe 3.0 x 1 speed when the PCI_E1 or PCI_E3 slot is installed a device. Onboard Graphics: 1 x HDMI port, supports a maximum resolution of 4096x 2160@24 Hz, 2560x 1600@60 Hz 1 x DVI-D port, supports a maximum resolution of 1920x 1200@60 Hz Multi-GPU: Supports 2-Way AMD Cross Fire Technology Storage: Intel B150 Chipset 6 x SATA 6 Gb/s ports 1 x M.2 slot Supports PCIe 3.0 x 4 & SATA 6 Gb/s standards, 4.2cm/ 6cm/ 8cm length M.2 SSD cards Supports PCIe 3.0 x 4 NVMe Mini-SAS SSD with Turbo U.2 Host Card (optional)* The Turbo U.2 Host Card is not included, please purchase separately. SATAe port is backward compatible with SATA. USB: Intel B150 Chipset 6 x USB (Universal Serial Bus) 3.1 Gen 1 (Super Speed USB) ports (4 ports on the back panel, 2 ports available through the internal USB (Universal Serial Bus) connector) 6 x USB (Universal Serial Bus) 2.0 (High-speed USB) ports (4 ports on the back panel, 2 ports available through the internal USB (Universal Serial Bus) connectors) (Optional) Audio: Realtek ALC1150 Codec 7.1-Channel High Definition Audio Supports S/PDIF output LAN: 1 x Killer E2400 Gigabit LAN controller Internal I/O Connectors 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 6 x SATA 6 Gb/s connectors 1 x SATAe connector 1 x USB (Universal Serial Bus) 2.0 connector (supports additional 2 USB (Universal Serial Bus) 2.0 ports) 1 x USB (Universal Serial Bus) 3.1 Gen 1 connector (supports additional 2 USB (Universal Serial Bus) 3.1 Gen 1 ports) 2 x 4-pin CPU fan connectors 3 x 4-pin system fan connectors 1 x Front panel audio connector 2 x Front panel connectors 1 x TPM module connector 1 x Chassis Intrusion connector 1 x Clear CMOS jumper 1 x Serial port connector 1 x Parallel port connector 1 x Slow mode switch Back Panel I/O Ports: 1 x PS/2 keyboard/ mouse port 4 x USB (Universal Serial Bus) 2.0 ports 1 x DVI-D port 1 x HDMI port 4 x USB (Universal Serial Bus) 3.1 Gen 1 ports 1 x LAN (RJ45) port 1 x Optical S/PDIF OUT connector 5 x OFC audio jacks BIOS: The motherboard BIOS provides " Plug & Play" BIOS which detects the peripheral devices & expansion cards of the board automatically. The motherboard provides a Desktop Management Interface (DMI) function which records your motherboard specifications. Dimension: 12 in. x 9.6 in. (30.4 cm x 24.4 cm) ATX Form Factor Mounting: 9 mounting holes ...

MSI B150A GAMING PRO Socket 1151 DVI HDMI 8-channel HD Audio Motherboard GAME IN STYLE MSI Performance GAMING motherboards deliver a polished gaming experience, whether you are racking up frags on the battlefield, questing for the latest unlocks or trying to level up your favorite gaming character. The Performance GAMING series motherboards offer a unique, customizable, design & distinguished look & feel with the best options tailored to gamers. SPECIFICATIONS CPU support Supports 6th Gen Intel Core / Pentium / Celeron Processors CPU socket LGA 1151 Chipset Intel B150 chipset Graphics interface 2 * PCI-E 3.0 x 16 slots, AMD Cross Fire„¢ support Display interface HDMI, DVI (Requires CPU Graphics) 4 DIMMs, Dual Channel DDR4-2133 Memory support Supports ECC memory, un-buffered memory Expansion slots 2 * PCI-E x 1 slots, 3 * PCI slots SATA 6 * SATA 6 Gb/s (2 ports reserved for SATA Express) USB (Universal Serial Bus) / IEEE 1394 2 * USB (Universal Serial Bus) 3.1 Gen 2, 6 * USB (Universal Serial Bus) 3.1 Gen 1, 4 * USB (Universal Serial Bus) 2.0 LAN Intel I219-V Gigabit LAN Audio 8-channel (7.1) HD Audio with Audio Boost 3 I/O OVERVIEW Gaming Device Port USB (Universal Serial Bus) 3.1 Gen 1 MSI GAMING LAN Audio connectors USB (Universal Serial Bus) 2.0 DVI Port USB (Universal Serial Bus) 3.1 Gen 2 HDMI Port USB (Universal Serial Bus) 3.1 Gen 1 Optical S/PDIF Out ...

MSI B150M BAZOOKA Socket 1151 HDMI DVI-D 8-channel Audio Motherboard Equip yourself with the MSI Arsenal GAMING series motherboards, packed with an arsenal of gaming features, to improve your game. Stable, high quality Military Class components, enhanced audio & LAN will make your gaming experience truly amazing. Arsenal GAMING motherboards ensure non-stop online gaming whether at home or at a LAN party. DDR4 BOOST By fully isolating the memory circuitry from other components, DDR4 Boost ensures the memory signal to stay pure for maximum performance & stability. AMBIENT LIGHT Arsenal GAMING motherboards come with a subtle ambient LED light on the back of the motherboard adding to the GAMING look & feel. AUDIO BOOST Audio Boost ensures you can enjoy true high quality sound when playing games, watching movies & listening to music. SPECIFICATIONS CPU support Supports 6th Gen Intel Core / Pentium / Celeron Processors CPU socket LGA 1151 Chipset Intel B150 Chipset Graphics interface 1* PCI-E 3.0 x 16 slot Display Interface HDMI, DVI “ Requires Processor Graphics Memory support 4 DIMMs, Dual Channel DDR4-2133 Expansion slots 2 * PCI-E x 1 slots M.2 / SATA 6 * SATA 6 Gb/s (2 ports reserved for SATA Express) USB (Universal Serial Bus) 6* USB (Universal Serial Bus) 3.1 Gen 1, 6 * USB (Universal Serial Bus) 2.0 LAN 10/100/1000 Mbps LAN Audio 8-channel (7.1) HD Audio I/O OVERVIEW Mouse port HDMI port DVI-D port LAN port Audio Connectors Keyboard port USB (Universal Serial Bus) 2.0 ports USB (Universal Serial Bus) 3.1 Gen 1 ports USB (Universal Serial Bus) 3.1 Gen 1 ports ...

MSI B150M MORTAR Socket LGA 1151 VGA DVI HDMI 8-channel HD Audio Motherboard Get ready to crush your enemies on the battlefield with MSI GAMING LAN. Featuring carefully selected components & smart bandwidth management software that automatically prioritizes games above other applications, to ensure the best online gaming experience without lag. Equip yourself with the MSI Arsenal GAMING series motherboards, packed with an arsenal of gaming features, to improve your game. Stable, high quality Military Class components, enhanced audio & LAN will make your gaming experience truly amazing. Arsenal GAMING motherboards ensure non-stop online gaming whether at home or at a LAN party. DDR4 BOOST By fully isolating the memory circuitry from other components, DDR4 Boost ensures the memory signal to stay pure for maximum performance & stability. AMBIENT LIGHT Arsenal GAMING motherboards come with a subtle ambient LED light on the back of the motherboard adding to the GAMING look & feel. AUDIO BOOST Audio Boost ensures you can enjoy true high quality sound when playing games, watching movies & listening to music. SPECIFICATIONS CPU support: Supports 6th Gen Intel Core / Pentium / Celeron Processors CPU socket: LGA 1151 Chipset: Intel B150 Chipset Graphics interface: 2* PCI-E 3.0 x 16 slots Display Interface: HDMI, DVI, VGA“ Requires Processor Graphics Memory support: 4 DIMMs, Dual Channel DDR4-2133 Expansion slots: 1 * PCI-E x 16 slot, 2 * PCI-E x 1 slots M.2 / SATA: 6 * SATA 6 Gb/s (2 ports reserved for SATA Express) SATA RAID: RAID 0, 1, 5, 10 “ Available on SATA1 to SATA6 USB: 6* USB (Universal Serial Bus) 3.1 Gen 1, 6 * USB (Universal Serial Bus) 2.0 LAN: 10/100/1000 Mbps LAN Audio: 8-channel (7.1) HD Audio ...

MSI B150M NIGHT ELF Socket LGA 1151 DVI 8-channel HD Audio Motherboard With Audio Boost 3, we're delivering the highest sound quality through the use of premium quality audio components. That way, you can enjoy breathtaking, crystal clear sound & music through 8-channel HD Audio or high impendence headphones & truly dominate the game. MSI Performance GAMING motherboards deliver a polished gaming experience, whether you are racking up frags on the battlefield, questing for the latest unlocks or trying to level up your favorite gaming character. The Performance GAMING series motherboards offer a unique, customizable, design & distinguished look & feel with the best options tailored to gamers. SPECIFICATIONS CPU support: Supports 6th Gen Intel Core / Pentium / Celeron Processors CPU socket: LGA 1151 Chipset: Intel B150 chipset Graphics interface: 2 * PCI-E 3.0 x 16 slot 2-way AMD Cross Fire support Display interface DVI (Requires CPU Graphics) Memory support: 4 DIMMs, Dual Channel DDR4-2133 Supports ECC memory, un-buffered memory Expansion slots: 2 * PCI-E x 1 slots SATA: 6 * SATA 6 Gb/s USB (Universal Serial Bus) / IEEE 1394: 6 * USB (Universal Serial Bus) 3.1 Gen 1, 6 * USB (Universal Serial Bus) 2.0 LAN: Intel I219-V Gigabit LAN Audio: 8-channel (7.1) HD Audio with Audio Boost 3 ...

MSI B150M PRO-VDH Socket LGA 1151 VGA DVI HDMI 8-channel HD Audio Motherboard Making your life easier is our business The PRO Series motherboards fit in any PC. Quality you can trust with top performance & clever business solutions are key aspects of these motherboards. Make your life easier & boost your business with the super stable, reliable & long-lasting PRO Series motherboards. SPECIFICATIONS CPU support: 6th Gen Intel Core / Pentium / Celeron processors CPU socket: LGA 1151 Chipset: Intel B150 Chipset Graphics interface: 1 * PCI-E 3.0 x 16 Display interface: HDMI, DVI-D, VGA “ Requires Processor Graphics Memory support: 4 DIMMs, Dual Channel DDR4-2133 MHz Expansion slots: 2 * PCI-E x 1 SATA: 6 * SATA 6 Gb/s (2 x ports from SATA Express port) USB: 6 * USB (Universal Serial Bus) 3.1 Gen 1, 6 * USB (Universal Serial Bus) 2.0 LAN: Realtek Gigabit Ethernet Audio: 8-channel (7.1) HD Audio with Audio Boost Others: COM / LPT pin header ...
