The Easy Coder PX Series printers are rugged, metal, high-performance printers designed to excel in demanding 24/7-duty applications. The PX6i features a maximum print width of 6 inches. The open, modular design ensures the printer is easy to adapt, maintain & service. The PX series printers print instantly from first to last label at up to 12 inches per second. This is ideal for on demand & compliance labeling applications with variable data requiring immediate results. The combination of powerful individually controlled micro-step motors, generously dimensioned power supply, & new sophisticated thermal management printhead ensures high-quality labels each & every time. Designed for easy integration into manufacturing environments, the PX series printers can be mounted in virtually any position. The versatile form factor facilitates the addition of add-ons such as an automatic label applicator. Up to seven wired & wireless connectivity interfaces can be used simultaneously eliminating connectivity restrictions & supporting additional devices. The PX series printers are the first bar code label printer to integrate Intermec's Readiness Indicator (IRI) light. Part of the Intermec Smart System, this light provides a visual cue to the operating state of the Easy Coder PX series printer. Participating in concert with other Intermec Smart System devices, the Easy Coder PX series printer communicates with the Smart System Console which displays status, provides access to configuration, eases installation of new printers, & assists in identifying printer consumables that require replenishment. The Easy Coder PX series printers can operate as stand alone devices executing user-defined programs thereby eliminating the need for a PC. These printers can operate production line machinery, including scanners, scales, other printers & conveyor as well as access information directly from the network host. The printers are fully programmable & are able to change with the application as needed, providing additional functionality & continued investment protection. The Easy Coder PX series printers are true high-performance, 24/7-duty printers for those who expect more from their industrial printers. ...

6" Label, Ticket & Tag Printer The Easy Coder PX Series printers are rugged, metal, high-performance printers designed to excel in demanding 24/7-duty applications. The PX6i features a maximum print width of 6 inches. The open, modular design ensures the printer is easy to adapt, maintain & service. The PX series printers print instantly from first to last label at up to 12 inches per second. This is ideal for on demand & compliance labeling applications with variable data requiring immediate results. The combination of powerful individually controlled micro-step motors, generously dimensioned power supply, & new sophisticated thermal management printhead ensures high-quality labels each & every time. Designed for easy integration into manufacturing environments, the PX series printers can be mounted in virtually any position. The versatile form factor facilitates the addition of add-ons such as an automatic label applicator. Up to seven wired & wireless connectivity interfaces can be used simultaneously eliminating connectivity restrictions & supporting additional devices. The PX series printers are the first bar code label printer to integrate Intermec's Readiness Indicator (IRI) light. Part of the Intermec Smart System, this light provides a visual cue to the operating state of the Easy Coder PX series printer. Participating in concert with other Intermec Smart System devices, the Easy Coder PX series printer communicates with the Smart System Console which displays status, provides access to configuration, eases installation of new printers, & assists in identifying printer consumables that require replenishment. The Easy Coder PX series printers can operate as stand alone devices executing user-defined programs thereby eliminating the need for a PC. These printers can operate production line machinery, including scanners, scales, other printers & conveyor as well as access information directly from the network host. The printers are fully programmable & are able to change with the application as needed, providing additional functionality & continued investment protection. The Easy Coder PX series printers are true high-performance, 24/7-duty printers for those who expect more from their industrial printers. Features Outstanding performance & print quality – prints up to 115 six-inch long compliance labels per minute Reliable – sturdy all-metal construction provides 24/7 printing in harsh industrial environments Investment protection – easily adapts to changing host environments & applications Intermec’s Readiness Indicator (IRI) light is a standard feature that facilitates printer management Modular design for integration into automated labelling applications Supports st&-alone printer applications, eliminating the expense of PCs Emulates & replaces competitive & older Intermec printers Flexible connectivity enables use of up to seven wired & wireless interfaces simultaneously Interchangeable printhead provides choice of 203 or 300 dpi print resolution Specifications DT/TTR Universal FW 16M/32M 300 DPI ...

The Easy Coder PX Series printers are rugged, metal, high-performance printers designed to excel in demanding 24/7-duty applications. The PX6i features a maximum print width of 6 inches. The open, modular design ensures the printer is easy to adapt, maintain & service. The PX series printers print instantly from first to last label at up to 12 inches per second. This is ideal for on demand & compliance labeling applications with variable data requiring immediate results. The combination of powerful individually controlled micro-step motors, generously dimensioned power supply, & new sophisticated thermal management printhead ensures high-quality labels each & every time. Designed for easy integration into manufacturing environments, the PX series printers can be mounted in virtually any position. The versatile form factor facilitates the addition of add-ons such as an automatic label applicator. Up to seven wired & wireless connectivity interfaces can be used simultaneously eliminating connectivity restrictions & supporting additional devices. The PX series printers are the first bar code label printer to integrate Intermec's Readiness Indicator (IRI) light. Part of the Intermec Smart System, this light provides a visual cue to the operating state of the Easy Coder PX series printer. Participating in concert with other Intermec Smart System devices, the Easy Coder PX series printer communicates with the Smart System Console which displays status, provides access to configuration, eases installation of new printers, & assists in identifying printer consumables that require replenishment. The Easy Coder PX series printers can operate as stand alone devices executing user-defined programs thereby eliminating the need for a PC. These printers can operate production line machinery, including scanners, scales, other printers & conveyor as well as access information directly from the network host. The printers are fully programmable & are able to change with the application as needed, providing additional functionality & continued investment protection. The Easy Coder PX series printers are true high-performance, 24/7-duty printers for those who expect more from their industrial printers. Features Outstanding performance & print quality – prints up to 115 six-inch long compliance labels per minute Reliable – sturdy all-metal construction provides 24/7 printing in harsh industrial environments Investment protection – easily adapts to changing host environments & applications Intermec’s Readiness Indicator (IRI) light is a standard feature that facilitates printer management Modular design for integration into automated labelling applications Supports st&-alone printer applications, eliminating the expense of PCs Emulates & replaces competitive & older Intermec printers Flexible connectivity enables use of up to seven wired & wireless interfaces simultaneously Interchangeable printhead provides choice of 203 or 300 dpi print resolution ...

Prints up to 115 six-inch long compliance labels per minute! Interchangeable printheads-203 or 300 dpi print resolution! Designed for easy integration into manufacturing environments, the Easy Coder PX6i printer can be mounted in virtually any position. The versatile form factor facilitates the addition of add-ons such as an automatic label applicator. Up to seven wired & wireless connectivity interfaces can be used simultaneously eliminating connectivity restrictions & supporting additional devices. The Easy Coder PX6i printer can operate as standalone devices executing user-defined programs thereby eliminating the need for a PC. The Easy Coder PX6i can operate production line machinery including scanners, scales & other printers & conveyors as well as access information directly from the network host, is fully programmable & is able to change with the application as needed. Ships with full-featured version of Label Shop START label design software. Features Strong, all-metal construction & superior throughput for 24x 7 printing in harsh industrial environments Ideal for high volume & compliance applications
- the PX4i prints at 406 dpi without loss of speed Modular design facilitates integration into automated labeling applications Smart Printing capabilities support st&-alone printer applications, eliminating PC expense & complexity All-in-one, user-selectable printer languages
- Fingerprint/ Direct Protocol (DP), IPL, ZSim & DSim
- in every printer Secure wireless connectivity: CCX & Wi Fi certified with WPA2 Integrated Ethernet, USB (Universal Serial Bus) host & device, & serial interface standard Internet Protocol v 6 (IPv 6) support Interchangeable print head provides choice of print resolution RFID option supports ISO18000
- 6B 6C/ EPC Gen 2 Specifications DT+TTR Tear-off RS232 Serial (DB9F)
- 115.2 Kbps Max USB (Universal Serial Bus) Port; USB (Universal Serial Bus) Host/ Boot, Ethernet Port Compact Flash slot Options: Parallel, Wi Fi Resolution: 203/300dpi Speed: 4-9"/s (100-225mm/s) Adjustable Media Sensor Universal PS (100-240V); Media/ Ribbon

Size: 8.1" Dia / 18000" long

Width: 3.0-6.7" (76-170mm) Thkns: 0.003-0.010" LCD Display 23 element keypad Firmware: Direct Protocol & Fingerprint 8.xx, IPL 2.X, ZSIM, DSIM 32MB DRAM+16MB Flash Std Print length: 161'' (203dpi) & 109'' (300dpi) with 16MB SDRAM Whats in the box? User & Installation manuals Printer Companion CD Cleaning Card Product registration card Declaration of Conformity








...

Intermec Technologies, best known as the inventor of the world's most widely used bar code symbology, provides supply chain information products, services & systems to companies in hundreds of industries around the world. Its total solution approach offers companies assurance that, with Intermec's network of leading technology partners, Intermec & its team can provide complete answers to companies' supply chain information requirements, from concept to completion. ...

For outdoor surveillance & remote monitoring, the IC-9000 provides the best image quality in its class, & excellent performance. Its efficient bandwidth management offers 640x 480 resolution, 30 fps frame rate, real MPEG4 image compression ability. The IC-9000 provides motion detection function & E-mail/FTP notification. You can easily setup this function & receive the notification with the snapshot images through email and/or ftp when motion events are detected. ...

Features Specifically developed for forklift installations Enables fast & inexpensive installations Flexible & configurable to support changing application needs Available in both FCC & ETSI frequencies With its unique, mostly metal design, the Intermec Antenna Cell is an RFID antenna specifically developed for forklift installations where shock & vibration can far exceed the specifications of antennas designed for fixed RFID reader applications. Complete with mounting hardware, Antenna Cells can be mounted with no drilling, cutting or welding which enables fast & inexpensive installations for a single forklift or fleet deployments. Antenna Cells are available in both FCC & ETSI frequencies. Antenna Cells leverage another new product, the Adaptable Load Backrest (ALBR), developed in partnership with Cascade Corporation, the world’s leader in the design & manufacture of lift truck attachments. The Antenna Cells can be mounted into an ALBR in about a half hour, as opposed to spending a day of field engineering time to install RFID equipment onto a forklift the “old fashioned” way. Antenna Cells mounted into ALBRs are flexible & configurable for quick & inexpensive reconfigurations to support changing application needs such as converting from pallet tag reading to case level reading. This modular approach enables Antenna Cells to be interchangeable for quick replacement of damaged parts lessening slow downs in a busy operation. ...

Packaged in a small & lightweight, yet durable enclosure, the IF2 is suited for nearly any environment, including industrial warehouse & manufacturing operations & enterprise environments for asset & inventory management applications. The Intermec IF2 is a compact, cost-effective network reader designed to support diverse RFID applications in both enterprise & industrial environments that require a scalable RFID system with a low cost per read point. The IF2 is packaged in a durable enclosure for nearly any environment & is factory configured to operate in regions across the globe. ...

Intermecs rugged Low Profile Durable Asset Tag has been designed to provide superior performance & high durability on a variety of surfaces at a low cost. Utilizing the generation 2 silicon supporting 512 bits of user memory within a small, durable form factor, Intermecs Durable Asset Tag is suitable for tracking a wide variety of assets. The IT36 is tuned for a wide frequency band to include both FCC & ETSI regions & is optimized primarily for non-metal surfaces, such as reusable plastic containers & wooden & plastic pallets. The IT36 Low Profile Durable Asset Tag has been designed to provide superior performance & high durability at a low cost. ...

Intermec Technologies, best known as the inventor of the worlds most widely used bar code symbology, provides supply chain information products, services & systems to companies in hundreds of industries around the world. Its total solution approach offers companies assurance that, with Intermecs network of leading technology partners, Intermec & its team can provide complete answers to companies supply chain information requirements, from concept to completion. ...
