Solid. Reliable. A new type of computing device that lets you compute in small spaces, the Intel Compute Stick enables you to transform a display into a thin client platform via an HDMI* port. Ready to go out-of-the box, the Intel Compute Stick has a quad-core Intel Atom™ processor & offers the performance, quality, & value you expect from Intel. The system performs just like your other computers—simply plug it into any HDMI display, connect your wireless keyboard & mouse & you’re ready to connect & collaborate in call centres, computer labs—or anywhere you’re working. Instant connection With built-in 802.11bgn wireless, you can connect & collaborate right out of the box. No wires Bluetooth* 4.0 lets you connect a wireless keyboard & mouse for clutter free computing. Cloud access made simple Built-in Wi Fi lets you store & access files in the cloud, making it easy to work wherever & whenever Storage On-board storage for easy access to local images & files. A Micro SD card slot for access to additional files. Connectivity & expandability Wi Fi 802.11bgn & Bluetooth* 4.0 for Internet access & wireless peripherals. USB (Universal Serial Bus) 2.0 port for additional peripherals such as printers. HDMI* connectivity for sound & display. Productivity Windows 10* or Ubuntu for your choice of operating system, plus built-in memory, & power adapter with USB (Universal Serial Bus) cable. Processor Intel Atom Quad-Core Processor Z3735F 1.33 G Hz 2MB Cache Memory 2GB 1333 M Hz DDR3L Hard Drive 32GB e MMC Micro SDXC v 3.0 slot with UHS I-Support (on side) Optical Drive None Software Operating System: Windows 10 with Bing Graphics Intel HD Audio Multi-channel digital audio via HDMI* interface Networking Wireless: IEEE 802.11 b/g/n & Bluetooth* 4.0 Power Supply 5V/2A Wall-wart style Micro USB power connector & cable

Dimensions Width 103mm Depth 37mm Height 12mm Interfaces 1 x USB (Universal Serial Bus) 2.0 1 x HDMI Warranty/ Miscellaneous 2 Year Manufacturer Warranty

...

The Intel Core i 3 processor is the perfect entry point for a fast, responsive PC experience. This processor comes equipped with Intel HD graphics, an advanced video engine that delivers smooth, high-quality HD video playback, & advanced 3D capabilities, providing an ideal graphics solution for everyday computing. A smart choice for home & office, the Intel Core i 3 processor also features Intel Hyper-Threading technology, which enables each core of your processor to work on two tasks at the same time, delivering the performance you need for smart multitasking. Do not let too many open applications slow you & your PC down. Get smart performance now. Specifications Model
- Intel i 3 2100 Frequency
- 3100 M Hz Socket
- 1155 Cache
- 3MB L3 Shared Thermal Power Design
- 65W Package
- Retail boxed

Includes:: intel reference heatsink & fan







...

The Intel Core i 3 processor is the perfect entry point for a fast, responsive PC experience. This processor comes equipped with Intel HD graphics, an advanced video engine that delivers smooth, high-quality HD video playback, & advanced 3D capabilities, providing an ideal graphics solution for everyday computing. A smart choice for home & office, the Intel Core i 3 processor also features Intel Hyper-Threading technology, which enables each core of your processor to work on two tasks at the same time, delivering the performance you need for smart multitasking. Do not let too many open applications slow you & your PC down. Get smart performance now. Specifications Processor Number
- i 3-2105 Number of Cores
- 2 Number of Threads
- 4 Clock Speed
- 3.1 GHz Bus/ Core Ratio
- 31 DMI
- 5 GT/s Instruction Set
- 64-bit Instruction Set Extensions
- SSE4.1/4.2, AVX Embedded Options Available
- No Lithography
- 32 nm Max TDP
- 65 W Graphics Specifications Processor Graphics
- Intel HD Graphics 3000 Graphics Base Frequency
- 850 MHz Graphics Max Dynamic Frequency
- 1.1 GHz Intel Quick Sync Video
- Yes Intel In Tru 3D Technology
- Yes Intel Insider
- Yes Intel Flexible Display Interface (Intel FDI)
- Yes Intel Clear Video HD Technology
- Yes Dual Display Capable
- Yes Package Specifications Max CPU Configuration
- 1 TCASE
- 69.1°C Package Size
- 37.5mm x 37.5mm Sockets Supported
- FCLGA1155























...

The Intel Core i 3 processor is the perfect entry point for a fast, responsive PC experience. This processor comes equipped with Intel HD graphics, an advanced video engine that delivers smooth, high-quality HD video playback, & advanced 3D capabilities, providing an ideal graphics solution for everyday computing. A smart choice for home & office, the Intel Core i 3 processor also features Intel Hyper-Threading technology, which enables each core of your processor to work on two tasks at the same time, delivering the performance you need for smart multitasking. Do not let too many open applications slow you & your PC down. Get smart performance now Specifications Processor Number
- i 3-2120 Number of Cores
- 2 Number of Threads
- 4 Clock Speed
- 3.3 GHz Intel Smart Cache
- 3 MB Bus/ Core Ratio
- 33 DMI
- 5 GT/s Instruction Set
- 64-bit Instruction Set Extensions
- SSE4.1/4.2, AVX Embedded Options Available
- Yes Lithography
- 32 nm Max TDP
- 65 W Graphics Specifications Processor Graphics
- Intel HD Graphics 2000 Graphics Base Frequency
- 850 MHz Graphics Max Dynamic Frequency
- 1.1 GHz Intel Quick Sync Video
- Yes Intel In Tru 3D Technology
- Yes Intel Insider
- Yes Intel Flexible Display Interface (Intel FDI)
- Yes Intel Clear Video HD Technology
- Yes Dual Display Capable
- Yes Package Specifications Max CPU Configuration
- 1 TCASE
- 69.1°C Package Size
- 37.5mm x 37.5mm Sockets Supported - FCLGA1155 Advanced Technologies Intel Hyper-Threading Technology
- Yes Intel Virtualization Technology (VT-x)
- Yes Intel 64
- Yes Idle States
- Yes Enhanced Intel Speed Step Technology
- Yes Thermal Monitoring Technologies
- Yes Intel Fast Memory Access
- Yes Intel Flex Memory Access
- Yes Execute Disable Bit
- Yes
































...

Intel Hyper-Threading technology Deliver two processing threads per physical core for a total of four threads for massive computational throughput. This 4-way multi-task processing allows each core of your processor to work on two tasks at the same time. Intel smart cache Intel smart cache is shared cache dynamically allocated to each processor core, based on workload. This efficient, dual-core-optimized implementation increases the probability that each core can access data from the fast cache, significantly reducing latency to frequently used data & improving performance. Intel HD graphics Provide superb visual performance for sharper images, richer color, & life-like video & audio. Specifications
- Processor
-
- Type / Form Factor
- Intel Core i 3 3210 (3rd Gen)
- Number of Cores
- Dual-Core
- Number of Threads
- 4 threads
- Cache
- 3 MB
- Cache Memory Details
- L3
- 3 MB
- Processor Qty
- 1
- Clock Speed
- 3.2 GHz
- Compatible Processor Socket
- LGA1155 Socket
- Manufacturing Process
- 22 nm
- Thermal Design Power
- 55 W Architecture Features
-
- Enhanced Speed Step technology
- Hyper-Threading Technology
- Integrated memory controller
- Execute Disable Bit capability
- Intel Virtualization Technology
- Intel 64 Technology
- Intel My Wi Fi Technology
- Intel Anti-Theft Technology
- Intel Advanced Vector Extensions (AVX)
- Thermal Monitoring Technologies
- Idle States
- Intel VT-x with Extended Page Tables (EPT) Cache Memory
- Installed Size
- 3 MB Integrated Graphics
-
- Type
- Intel HD Graphics 2500
- Base Frequency
- 650 MHz
- Max Dynamic Frequency
- 1.05 GHz
- Features
- Intel FDI, Intel Clear Video HD Technology, In TRU 3D
-
- - Technology, Intel Quick Sync Video, Intel Wireless Display (Wi Di), Intel Insider
















































...

Intel Core i 3-4130T 2.90 G Hz Soct 1150 3MB Cache Retail Boxed Status Launched Launch Date Q3'13 Processor Number i 3-4130T of Cores 2 of Threads 4 Clock Speed 2.9 GHz Intel Smart Cache 3 MB DMI2 5 GT/s of QPI Links 0 Instruction Set 64-bit Instruction Set Extensions SSE4.1/4.2 AVX2.0 Embedded Options Available No Lithography 22 nm Scalability 1S Only Max TDP 35 W Thermal Solution

Specification PCG 2013A Memory Specifications Max Memory Size (dependent on memory type) 32 GB Memory Types DDR3-1333/1600 of Memory Channels 2 Max Memory Bandwidth 25.6 GB/s ECC Memory Supported Yes Graphics Specifications Processor Graphics Intel HD graphics 4400 Graphics Base Frequency 200 MHz Graphics Max Dynamic Frequency 1.15 GHz Graphics Video Max Memory 1 GB Intel Quick Sync Video Yes Intel In Tru™ 3D Technology Yes Intel Wireless Display Yes Intel Clear Video HD Technology Yes of Displays Supported 3 Expansion Options PCI Express Revision 3.0 PCI Express Configurations Up to 1x 16, 2x 8, 1x 8/2x 4 Max of PCI Express Lanes 16 age Specifications Max CPU Configuration 1 TCASE 66.4 C Package Size 37.5mm x 37.5mm Graphics & IMC Lithography 22nm Sockets Supported FCLGA1150 Low Halogen Options Available See MDDS Advanced Technologies Intel Turbo Boost Technology No Intel v Pro Technology No Intel Hyper-Threading Technology Yes Intel Virtualization Technology (VT-x) Yes Intel Virtualization Technology for Directed I/O (VT-d) No Intel VT-x with Extended Page Tables (EPT) Yes Intel TSX-NI No Intel 64 Yes Idle States Yes Enhanced Intel Speed Step Technology Yes Thermal Monitoring Technologies Yes Intel Virtualization Technology for Itanium (VT-i) No Intel Stable Image Platform Program (SIPP) No

...

Specifications Model
- Intel i 3 4150 Family
- Intel Core i 3 Core Frequency
- 3.5 G Hz Bus Speed
- 5 GT/s DMI clock Multiplier
-




...

Specifications Socket
- Intel 1150 Family
- Intel Core i 3 Model Number
- i 3 4160 Frequency
- 3600 M Hz Bus Speed
-




...

Specifications Processor
- Intel Core i 3-4330 Socket
- Intel LGA 1150 Clock Speed
- 3.5 G Hz Number of Cores
- 2 Number



...

Specifications Family
- Intel Core i 3 Model Number
- Intel i 3 4340 Core Frequency
- 3.6 G Hz Socket
- Intel LGA 1150



...
