Gigabyte GTX 750 Ti 4GB GDDR5 Dual-link DVI HDMI PCI-E Grpahics Card Powered by NVIDIA Ge Force GTX 750 Ti GPU Integrated with industry's best 4GB GDDR5 memory & 128-bit memory interface OC Edition
- Core Clock: Base 1059 M Hz / Boost 1137 M Hz (Standard- Base:1020 M Hz Boost:1085 M Hz) Features Dual-link DVI-I / DVI-D / HDMI*2 System power supply requirement: 400W WINDFORCE 2X cooling system GIGABYTE introduces WINDFORCE, the latest cooling technology that differentiates the brands graphics cards from the rest. GIGABYTE understands that a fan is crucial to the graphics card, so only the fan with the most efficiency is selected for WINDFORCE. Unique Blade Fan Design The airflow is spilt through the triangle design at the fan edge, & is guided smoothly through the fan by special 3D stripe curve design. At the same time, it effectively enhanced the cooling capacity while reducing air turbulence. Up to 4 displays on a Single Card Support up to four displays on a single card. Satisfy your multi-screen setup, high definition & extreme gaming experience. Gold Plated HDMI x 2 Gold plated, durable large contact area connectors have been used for optimum signal transfer between connections. Dual HDMI design lets users experience broader, richer gaming environments with better resolution on a single card. Specifications Chipset Ge Force GTX 750 Ti Core Clock Base/ Boost clock: 1059/ 1137 MHz (standard:1020/1085) Memory Clock 5400 MHz Process Technology 28 nm Memory Size 4 GB Memory Bus 128 bit Card Bus PCI-E 3.0 Memory Type GDDR5 Direct X 12 Open GL 4.4 PCB Form ATX Digital max resolution 4096 X 2160 (via 2 HDMI) Analog max resolution 2048 x 1536 Multi-view 4 I/O Dual-link DVI-I*1/DVI-D*1/HDMI*2 Card size H=42 mm, L=197 mm, W=127 mm Power requirement 400W (with one 6-pin external power connector)
...

Gigabyte GV-N760OC-4GD 4GB GDDR5 Dual DVI HDMI Display Port PCI-E Graphics Card Keeping the same 450W Cooling capacity using only 2 slots, the New WINDFORCE 3X 450W cooling system is equipped with two 8mm & four 6mm cooper heat-pipes, inclined fans, & GIGABYTE g Triangle Coolh technology. This not only provides an effective heat dissipation capacity but GPU Boost 2.0 technology also enables higher performance due to a lower temperature. Chipset Ge Force
- GTX 760 Memory Clock
- 6008 MHz Process Technology
- 28 nm Memory Size
- 4096 MB Memory Bus
- 256 bit Core Clock
- Base / Boost clock F1085 (std.980) / 1150 (std.1033) MHz Card Bus
- PCI-E 3.0 Memory Type
- GDDR5 Direct X
- 11.1 Open GL
- 4.3 PCB Form
- ATX Digital max resolution
- 4096 X 2160 (via a single HDMI connector & not supported with two DVI connectors) Analog max resolution
- 2048 x 1536 Multi-view
- 4 I/O: DVI-I*1 DVI-D*1 Display Port*1 HDMI*1 Card size
- L=292mm, W=129mm, H=43mm Power requirement
- 500W (with one 6-pin & one 8-pin external power connectors) NVIDIA Features NVIDIA Ge Force Experience Want to know the best settings to play your games? Ge Force Experience will figure it out for you. Ge Force Experience connects you to NVIDIA’s cloud datacenter to download optimal game settings tailored to your PC based on your CPU, GPU & monitor. Optimal settings maximize image quality while maintaining great performance so you get the best experience. A built-in interactive screenshot viewer helps you learn more about each setting & their benefits. The Ge Force Experience application automatically notifies you of new driver releases from NVIDIA. With a single click, you’ll be able to update the driver directly, without leaving your desktop. NVIDIA Kepler GPU Architecture NVIDIAs Kepler GPU architecture has been designed from the ground up not just for maximum performance in the latest Direct X 11 games, but optimal performance per watt. The new SMX streaming multiprocessor is twice as efficient as the prior generation & the new geometry engine draws triangles twice as fast. The result is world class performance & the highest image quality in an elegant & power efficient graphics card. NVIDIA TXAA Technology Film studios invest enormous resources in developing advanced technologies & post-production effects to deliver visually spectacular experiences for movie-goers. For games to achieve this level of fidelity, developers need new anti–aliasing technologies that deliver a viewing experience that eliminates the distraction of unrealistic, jagged lines (”jaggies”) & aliased shimmering–without compromising performance. NVIDIA is making this happen today, bringing cinema-quality graphics to life in blockbuster gaming titles with an innovative new temporal antialiasing technology called TXAA. Available exclusively on Ge Force GTX Kepler-powered GPUs, TXAA is designed to be directly integrated into game engines. Plus, it combines the raw power of MSAA (multi–sample anti–aliasing) with a temporal filter & sophisticated resolve filters similar to those used in CG films. The end result is a smoother, more lifelike image than any other comparable technique. NVIDIA FXAA Technology FXAA is a NVIDIA-developed post-processing technique that selectively blurs a game’s graphics to tackle unsightly jagged edges & high-contrast pixel deviation. Gaining popularity amongst developers due to its low performance impact & its ability to anti-alias transparent textures & details, FXAA is highly recommended for low-end & mid-range systems. NVIDIA GPU Boost 2.0 Technology Up until now, GPUs have operated at a fixed clock speed when playing 3D games, even if they have the potential to run faster. GPU Boost intelligently monitors graphics work load & increases the clock speed whenever possible. The result is that the GPU always performs at its peak & you get the highest framerate possible. With NVIDIA GPU Boost 2.0 Enjoy new levels of customization with advanced controls like GPU temperature target, overclocking, & overvoltage. NVIDIA Adaptive V-Sync Technology Nothing is more distracting than framerate stuttering & screen tearing. The first tends to occur when framerates are low, the second when framerates are high. Adaptive V-Sync is a smarter way to render frames. At high framerates, V-sync is enabled to eliminate tearing, at low frame rates, its disabled to minimize stuttering. It gets rid of distractions so you can get on with gaming. NVIDIA Phys X Technology Phys X is designed specifically for hardware acceleration by powerful processors with hundreds of cores. Combined with the tremendous parallel processing capability of the GPU, Phys X will provide an exponential increase in physics processing power & will take gaming to a new level delivering rich, immersive physical gaming environments. NVIDIA CUDA Technology NVIDIA CUDA technology is the world’s only C language environment that enables programmers & developers to write software to solve complex computational problems in a fraction of the time by tapping into the many-core parallel processing power of GPUs. With millions of CUDA-capable GPUs already deployed, thousands of software programmers are already using the free CUDA software tools to accelerate applications—from video & audio encoding to oil & gas exploration, product design, medical imaging, & scientific research. NVIDIA Surround with up to 4 Monitors Nothing is as breathtaking as playing your favorite games across three monitors. At 5760 x 1080, the expanded field of view fully engages human peripheral vision & provides for the most immersive experience in racing & flight simulators. Add in a fourth display to keep tabs on chat, email or web while you are gaming. NVIDIA 3D Vision NVIDIA 3D Vision brings a fully immersive, stereoscopic 3D experience to the PC. A combination of high-tech wireless glasses & advanced software, 3D Vision transforms hundreds of PC games into full stereoscopic 3D. Get up to 2x monitor & keyboard brightness with NVIDIA 3D Light Boost technology. In addition, you can enjoy 3D movies & 3D digital photographs from 3 D Vision Live.com in eye popping, crystal-clear quality. NVIDIA SLI Technology Used by the most demanding gamers worldwide, SLI lets you link up to three Ge Force GTX 780s together for astounding performance. & with NVIDIA’s track record for fast & frequent software updates, you’ll not only get the best performance in existing games, but future games too.















...

Ge Force GTX 760 is the must have 2014 gamers graphic card. The Gigabyte GTX 760 OC Windforce 2GB GDDR5 Dual DVI HDMI Display Port PCI-E Graphics Card is a powerhouse for graphics, it brings you fast, smooth, quiet performance in all your favourite titles. It is full of next gen features. The engineering of this card lets you point the settings & resolutions in graphics-intensive games skyward. This card takes gameplay to the next level, this card is “ Insanely Powerful”. Switch on NVIDIA GPU Boost 2.0 for max clock speeds, Phys X & TXAA™ for great graphics, & NVIDIA SHIELD™ compatibility for incredible gaming graphics which leave the competition in awe. Upgrading software & drivers can be a pain but with the Gigabyte GTX 760 OC Windforce 2GB GDDR5 Dual DVI HDMI Display Port PCI-E Graphics Card you can instantly access the latest game-ready drivers automatically. Seeing the NVIDIA Ge Force GTX 760 in action shows you how much of a powerful graphics card it is. It gives you the fast, smooth, colourful & quiet gaming experience you are looking for in all of your favourite games. The GTX 760 OC (overclock) brings together a whole host of hardware physics and software performance features, plus next-gen technology innovations which let you reach new levels in frame rates by upping the settings & resolutions in todays most intensive games. The GTX 760 is brilliant, the day a new game launches you can optimize settings with one click using Ge Force Experience™. You can even auto-record all your greatest gaming moments with NVIDIA Shadow Play. What do buyers of this of card think? 88% of buyers rated this graphics card at 10/10 Features buyer’s love: Speed & Price Triple quiet fans Features buyers didn’t like – “size” David Good Points + This is an insanely powerful graphics card, ive been pulling roughly 190fps in MSIs stress tester. Its well worth the money if youre into gaming. Bad Points − Its huge so make sure it will fit in your case! Review Rating 10/10 Timothy North Somerset Experienced hobbyist PC builder Good Points + Easy to install, as one would expect. Quiet in use: Ive not yet given it a real workout with something like Crysis, but the three large fans would be expected to keep things cool without too spinning too fast. I bought this card in order to have 2 DVI & 1 HDMI connected: my previous cards backplane layout made that impossible. Bad Points − None: its all good. Review Rating 10/10 WINDFORCE 3X Cooling system with Composite Heat-Pipes Powered by NVIDIA Ge Force GTX 760 GPU Integrated with 2GB GDDR5 memory, 256-bit memory interface Features Dual-link DVI-I/ DVI-D / HDMI / Display Port BASE:1085 M Hz / BOOST:1150 MHz System power supply requirement: 500W Br&-new instinctive user interface, easier to monitoring & adjusting all important settings. Users can set up MONITORING, GPU CLOCK, MEMORY CLOCK, FAN, GPU VOLTAGE, Memory VOLTAGE, OSD, ONLINE SUPPORT & update driver, BIOS directly. Specifications Chipset
- Ge Force GTX 760 Core Clock
- Base / Boost clockï14;š1085 / 1150 MHz Memory Clock
- 6008 MHz Process Technology
- 28 nm Memory Size
- 2048MB Memory Bus
- 256 bit Card Bus
- PCI-E 3.0 Memory Type
- GDDR5 Direct X
- 11.1 Open GL
- 4.3 PCB Form
- ATX Digital max resolution
- 4096 X 2160 (via a single HDMI connector & not supported with two DVI connectors) Analog max resolution
- 2048 x 1536 Multi-view
- 4 I/O
- DVI-I*1, DVI-D*1, Display Port*1, HDMI*1 Card size
- L=295mm W=129mm H=43mm Power requirement
- 500W Gigabyte GTX 760 OC Windforce 2GB GDDR5 Dual DVI HDMI Display Port PCI-E Graphics Card GIGABYTE Exclusive Features Windforce 3X 450W Cooling System Keeping the same 450W Cooling capacity using only 2 slots, the New WINDFORCE 3X 450W cooling system is equipped with two 8mm & four 6mm cooper heat-pipes, inclined fans, & GIGABYTE “ Triangle Cool” technology. This not only provides an effective heat dissipation capacity but GPU Boost 2.0 technology also enables higher performance due to a lower temperature. Ultra Durable VGA Ultra Durable VGA board provides dramatic cooling effect on lowering both GPU & memory temperature by doubling the copper inner layer of PCB. GIGABYTE Ultra Durable VGA can lower GPU temperature by 5% to 10%. Ultra Durable VGA board reduces voltage ripples in normal & transient state, thus effectively lowers noises & ensures higher overclocking capability. GIGABYTE Ultra Durable VGA graphic accelerators improve overclocking capability by 10% to 30%. Ultra Durable VGA board allows more bandwidth for electron passage & reduces circuit impedance. The less circuit impedance, the more stable flow of current & can effectively improve power efficiency. GIGABYTE Ultra Durable VGA can lower power switching loss by 10% to 30%. OC GURU II Br&-new instinctive user interface, easier to monitor & adjust all important settings. Users can set up MONITORING, GPU CLOCK, MEMORY CLOCK, FAN, GPU VOLTAGE, Memory VOLTAGE, OSD, ONLINE SUPPORT & update driver, BIOS directly. NVIDIA Features NVIDIA Ge Force Experience Want to know the best settings to play your games? Ge Force Experience will figure it out for you. Ge Force Experience connects you to NVIDIA’s cloud datacenter to download optimal game settings tailored to your PC based on your CPU, GPU & monitor. Optimal settings maximize image quality while maintaining great performance so you get the best experience. A built-in interactive screenshot viewer helps you learn more about each setting & their benefits. The Ge Force Experience application automatically notifies you of new driver releases from NVIDIA. With a single click, you’ll be able to update the driver directly, without leaving your desktop. NVIDIA Kepler GPU Architecture NVIDIAs Kepler GPU architecture has been designed from the ground up not just for maximum performance in the latest Direct X 11 games, but optimal performance per watt. The new SMX streaming multiprocessor is twice as efficient as the prior generation & the new geometry engine draws triangles twice as fast. The result is world class performance & the highest image quality in an elegant & power efficient graphics card. NVIDIA TXAA Technology Film studios invest enormous resources in developing advanced technologies & post-production effects to deliver visually spectacular experiences for movie-goers. For games to achieve this level of fidelity, developers need new anti–aliasing technologies that deliver a viewing experience that eliminates the distraction of unrealistic, jagged lines (”jaggies”) & aliased shimmering–without compromising performance. NVIDIA is making this happen today, bringing cinema-quality graphics to life in blockbuster gaming titles with an innovative new temporal antialiasing technology called TXAA. Available exclusively on Ge Force GTX Kepler-powered GPUs, TXAA is designed to be directly integrated into game engines. Plus, it combines the raw power of MSAA (multi–sample anti–aliasing) with a temporal filter & sophisticated resolve filters similar to those used in CG films. The end result is a smoother, more lifelike image than any other comparable technique. NVIDIA FXAA Technology FXAA is a NVIDIA-developed post-processing technique that selectively blurs a game’s graphics to tackle unsightly jagged edges & high-contrast pixel deviation. Gaining popularity amongst developers due to its low performance impact & its ability to anti-alias transparent textures & details, FXAA is highly recommended for low-end & mid-range systems. NVIDIA G-SYNC Technology NVIDIA G-SYNC is a groundbreaking new innovation that casts aside decades-old thinking to create the smoothest, most responsive computer displays ever seen. A monitor module you can install yourself, or buy pre-installed in gamer-focused monitors, NVIDIA G-SYNC waves goodbye to the days of screen tearing, input lag, & eyestrain-inducing stuttering caused by decades-old tech lazily carried over from analog TVs to modern-day monitors. NVIDIA GPU Boost 2.0 Technology Up until now, GPUs have operated at a fixed clock speed when playing 3D games, even if they have the potential to run faster. GPU Boost intelligently monitors graphics work load & increases the clock speed whenever possible. The result is that the GPU always performs at its peak & you get the highest framerate possible. With NVIDIA GPU Boost 2.0 Enjoy new levels of customization with advanced controls like GPU temperature target, overclocking, & overvoltage. NVIDIA Adaptive V-Sync Technology Nothing is more distracting than framerate stuttering & screen tearing. The first tends to occur when framerates are low, the second when framerates are high. Adaptive V-Sync is a smarter way to render frames. At high framerates, V-sync is enabled to eliminate tearing, at low frame rates, its disabled to minimize stuttering. It gets rid of distractions so you can get on with gaming. NVIDIA Phys X Technology Phys X is designed specifically for hardware acceleration by powerful processors with hundreds of cores. Combined with the tremendous parallel processing capability of the GPU, Phys X will provide an exponential increase in physics processing power & will take gaming to a new level delivering rich, immersive physical gaming environments. NVIDIA CUDA Technology NVIDIA CUDA technology is the world’s only C language environment that enables programmers & developers to write software to solve complex computational problems in a fraction of the time by tapping into the many-core parallel processing power of GPUs. With millions of CUDA-capable GPUs already deployed, thousands of software programmers are already using the free CUDA software tools to accelerate applications—from video & audio encoding to oil & gas exploration, product design, medical imaging, & scientific research. NVIDIA Surround with up to 4 Monitors Nothing is as breathtaking as playing your favorite games across three monitors. At 5760 x 1080, the expanded field of view fully engages human peripheral vision & provides for the most immersive experience in racing & flight simulators. Add in a fourth display to keep tabs on chat, email or web while you are gaming. NVIDIA 3D Vision NVIDIA 3D Vision brings a fully immersive, stereoscopic 3D experience to the PC. A combination of high-tech wireless glasses & advanced software, 3D Vision transforms hundreds of PC games into full stereoscopic 3D. Get up to 2x monitor & keyboard brightness with NVIDIA 3D Light Boost technology. In addition, you can enjoy 3D movies & 3D digital photographs from 3 D Vision Live.com in eye popping, crystal-clear quality. NVIDIA SLI Technology Used by the most demanding gamers worldwide, SLI lets you link up to three Ge Force GTX 760s together for astounding performance. & with NVIDIA’s track record for fast & frequent software updates, you’ll not only get the best performance in existing games, but future games too.
















...

OC to 1085 MHz (Std: 980 MHz) Ultra Durable VGATM Lower GPU temperature, Better Overclocking Capability, & Decrease Power Switching Loss GPU Boost 2.0 by NVIDIA Technology for intelligent monitoring of clock speed, ensuring that the GPU runs at its peak & the game is at its highest frame rate possible. It offers new levels of customization, including GPU temperature target, overclocking, & unlocked voltage. Support up to 4 displays at single card & Maximum 4K resolutions WINDFORCE 3X cooling design ï14;ˆwith Triangle Cool technology) Direct Heat Pipe touch technology (DHT) Windforce x 3 Its equipped with GIGABYTEs latest innovative " Triangle Cool" Technology (patent pending). With three ultra quiet PWM fans, one huge RAM Heatsink, & three 8mm copper heat pipes, " Triangle Cool" Technology enhances the speed of heat dissipation more effectively. Specifications GPU
- Ge Force GTX 760 Core Base Clock
- 1085 MHz (ref.980) Core Boost Clock
- 1150 MHz (ref.1046) Memory Clock
- 6008 MHz Memory Size
- 2048MB GDDR5 Bus Type
- PCI Express 3.0 Memory Bus
- 256-bit Cuda Cores
- 1344 Memory Type
- 64 Mx 32 Direct X 11.1
- Yes DVI Port
- DVI-I/DVI-D Display Port
- Yes HDCP
- Yes HDMI
- Yes













...

With selected cards purchased from 4th September 2013 whilst stock last receive a FREE game download coupon for Batman Arkham Origin. Offer on selected cards only, not available on ex-display cards. From 29th October 2013 whilst stocks last also receive a FREE game download coupon for Assassins Creed Black Flag & Splinter Cell Blacklist. Offer on selected cards only, not available on ex-display cards. OC GURU II with GPU Boost 2.0 Technology Technology for intelligent monitoring of clock speed, ensuring that the GPU runs at its peak & the game is at its highest frame rate possible. It offers new levels of customization, including GPU temperature target, overclocking, & unlocked voltage. 2048 MB Memory & 256-bit Memory interface With high capacity memory, it can fulfill the multi-screen & high definition application for gamer to satisfy a real gaming spirits., NEW WINDFORCE 3X 2 Slot 450W fan sink with “ Triangle Cool” Keeping the same Cooling capacity at 450W with just only 2 slot size, the New WINDFORCE 3X 2 slot 450W build with two 8mm and four 6mm cooper heat-pipe, in cline fan, & GIGABYTE “ Triangle Cool” technology not only provide an effectively heat dissipation but also a silent working environment. 8-Phase power benefits with GPU Boost 2.0 Better than the reference design which only have 5-phase power supply, GV-N770OC-2GD future with powerful 8-phase power can benefits to the GPU Boost 2.0 & get the higher performance by the flexibility power supply. NVIDIA Ge Force Experience one-click drivers & settings Get the best gaming, with NVIDIA Ge Force Experience™ one-click drivers & settings.

Specification GPU
- Ge Force GTX 770 Core Base Clock
- 1137 M Hz Core Boost Clock
- 1189 M Hz Memory Clock
- 7010 M Hz Memory Size
- 2048MB GDDR5 Bus Type
- PCI Express 3.0 Memory Bus
- 256-bit CUDA Cores
- 1536 Memory Type
- 64 Mx 32 Direct X 11.1
- Yes DVI Port
- DVI-I/DVI-D Display Port
- Yes HDCP
- Yes HDMI
- Yes 8-Pin Power Connector x 1 6-Pin Power Connector x 1















...

With selected cards purchased from 4th September 2013 whilst stock last receive a FREE game download coupon for Batman Arkham Origin. Offer on selected cards only, not available on ex-display cards. From 29th October 2013 whilst stocks last also receive a FREE game download coupon for Assassins Creed Black Flag & Splinter Cell Blacklist. Offer on selected cards only, not available on ex-display cards.
- OC GURU II with GPU Boost 2.0 Technology Technology for intelligent monitoring of clock speed, ensuring that the GPU runs at its peak & the game is at its highest frame rate possible. It offers new levels of customization, including GPU temperature target, overclocking, & unlocked voltage.
- 3072 MB Memory & 384-bit Memory interface With high capacity memory, it can fulfill the multi-screen & high definition application for gamer to satisfy a real gaming spirits.,
- NEW WINDFORCE 3X 2 Slot 450W fan sink with “ Triangle Cool” Keeping the same Cooling capacity at 450W with just only 2 slot size, the New WINDFORCE 3X 2 slot 450W build with two 8mm and four 6mm cooper heat-pipe, in cline fan, & GIGABYTE “ Triangle Cool” technology not only provide an effectively heat dissipation but also a silent working environment.

Specification
-
- GPU
- Ge Force GTX 780
- Core Base Clock
- 954 MHz (Ref 863)
- Core Boost Clock
- 1006 MHz (Ref 900)
- Memory Clock
- 6008 MHz
- Memory Size
- 3072MB GDDR5
- Bus Type
- PCI Express 3.0
- Memory Bus
- 384-bit
- CUDA Cores
- 2304
- Memory type
- 64 Mx 32
- Direct X 11.1
- Yes
- DVI Port
- DVI-I /DVI-D
- Display Port
- Yes
- HDCP
- Yes
- HDMI
- Yes
- NEW 3D MARK (FS)
- Default: 7965 Extreme: 4292



































...

NVIDIA Features NVIDIA Ge Force Experience Want to know the best settings to play your games? Ge Force Experience will figure it out for you. Ge Force Experience connects you to NVIDIA’s cloud datacenter to download optimal game settings tailored to your PC based on your CPU, GPU & monitor. Optimal settings maximize image quality while maintaining great performance so you get the best experience. A built-in interactive screenshot viewer helps you learn more about each setting & their benefits. The Ge Force Experience application automatically notifies you of new driver releases from NVIDIA. With a single click, you’ll be able to update the driver directly, without leaving your desktop. NVIDIA Kepler GPU Architecture NVIDIAs Kepler GPU architecture has been designed from the ground up not just for maximum performance in the latest Direct X 11 games, but optimal performance per watt. The new SMX streaming multiprocessor is twice as efficient as the prior generation & the new geometry engine draws triangles twice as fast. The result is world class performance & the highest image quality in an elegant & power efficient graphics card. NVIDIA TXAA Technology Film studios invest enormous resources in developing advanced technologies & post-production effects to deliver visually spectacular experiences for movie-goers. For games to achieve this level of fidelity, developers need new anti–aliasing technologies that deliver a viewing experience that eliminates the distraction of unrealistic, jagged lines (”jaggies”) & aliased shimmering–without compromising performance. NVIDIA is making this happen today, bringing cinema-quality graphics to life in blockbuster gaming titles with an innovative new temporal antialiasing technology called TXAA. Available exclusively on Ge Force GTX Kepler-powered GPUs, TXAA is designed to be directly integrated into game engines. Plus, it combines the raw power of MSAA (multi–sample anti–aliasing) with a temporal filter & sophisticated resolve filters similar to those used in CG films. The end result is a smoother, more lifelike image than any other comparable technique. NVIDIA FXAA Technology FXAA is a NVIDIA-developed post-processing technique that selectively blurs a game’s graphics to tackle unsightly jagged edges & high-contrast pixel deviation. Gaining popularity amongst developers due to its low performance impact & its ability to anti-alias transparent textures & details, FXAA is highly recommended for low-end & mid-range systems. NVIDIA G-SYNC Technology NVIDIA G-SYNC is a groundbreaking new innovation that casts aside decades-old thinking to create the smoothest, most responsive computer displays ever seen. A monitor module you can install yourself, or buy pre-installed in gamer-focused monitors, NVIDIA G-SYNC waves goodbye to the days of screen tearing, input lag, & eyestrain-inducing stuttering caused by decades-old tech lazily carried over from analog TVs to modern-day monitors. NVIDIA GPU Boost 2.0 Technology Up until now, GPUs have operated at a fixed clock speed when playing 3D games, even if they have the potential to run faster. GPU Boost intelligently monitors graphics work load & increases the clock speed whenever possible. The result is that the GPU always performs at its peak & you get the highest framerate possible. With NVIDIA GPU Boost 2.0 Enjoy new levels of customization with advanced controls like GPU temperature target, overclocking, & overvoltage. NVIDIA Adaptive V-Sync Technology Nothing is more distracting than framerate stuttering & screen tearing. The first tends to occur when framerates are low, the second when framerates are high. Adaptive V-Sync is a smarter way to render frames. At high framerates, V-sync is enabled to eliminate tearing, at low frame rates, its disabled to minimize stuttering. It gets rid of distractions so you can get on with gaming. NVIDIA Phys X Technology Phys X is designed specifically for hardware acceleration by powerful processors with hundreds of cores. Combined with the tremendous parallel processing capability of the GPU, Phys X will provide an exponential increase in physics processing power & will take gaming to a new level delivering rich, immersive physical gaming environments. NVIDIA CUDA Technology NVIDIA CUDA technology is the world’s only C language environment that enables programmers & developers to write software to solve complex computational problems in a fraction of the time by tapping into the many-core parallel processing power of GPUs. With millions of CUDA-capable GPUs already deployed, thousands of software programmers are already using the free CUDA software tools to accelerate applications—from video & audio encoding to oil & gas exploration, product design, medical imaging, & scientific research. NVIDIA Surround with up to 4 Monitors Nothing is as breathtaking as playing your favorite games across three monitors. At 5760 x 1080, the expanded field of view fully engages human peripheral vision & provides for the most immersive experience in racing & flight simulators. Add in a fourth display to keep tabs on chat, email or web while you are gaming. NVIDIA 3D Vision NVIDIA 3D Vision brings a fully immersive, stereoscopic 3D experience to the PC. A combination of high-tech wireless glasses & advanced software, 3D Vision transforms hundreds of PC games into full stereoscopic 3D. Get up to 2x monitor & keyboard brightness with NVIDIA 3D Light Boost technology. In addition, you can enjoy 3D movies & 3D digital photographs from 3 D Vision Live.com in eye popping, crystal-clear quality. NVIDIA SLI Technology Used by the most demanding gamers worldwide, SLI lets you link up to three Ge Force GTX 780s together for astounding performance. & with NVIDIA’s track record for fast & frequent software updates, you’ll not only get the best performance in existing games, but future games too. Gigabyte GTX 780 GHZ Edition 3GB GDDR5 Dual DVI HDMI Display Port PCI-E Graphics Card NEW WINDFORCE 3X 2 SLOT 450W cooling system Keeping the same 450W Cooling capacity using only 2 slots, the New WINDFORCE 3X 450W cooling system is equipped with two 8mm & four 6mm cooper heat-pipes, inclined fans, & GIGABYTE g Triangle Coolh technology. This not only provides an effective heat dissipation capacity but GPU Boost 2.0 technology also enables higher performance due to a lower temperature. Chipset Ge Force
- GTX 780 Memory Clock
- 6008 MHz Core Clock
- Base / Boost clock F1019 / 1071 MHz Process Technology
- 28 nm Memory Size
- 3072 MB Memory Bus
- 384 bit Card Bus
- PCI-E 3.0 Memory Type
- GDDR5 Direct X
- 11.2 Open GL
- 4.3 PCB Form
- ATX Digital max resolution
- 4096 X 2160 (via a single HDMI connector & not supported with two DVI connectors) Analog max resolution
- 2048 x 1536 Multi-view
- 4 I/O
- Dual-link DVI-I*1 / DVI-D*1 / Display Port*1 / HDMI*1 Card size
- L=292mm, W=129mm, H=43mm Power requirement
- 600W (with two 8-pin external power connectors)
















...

Features with 2880 CUDA cores OC GURU II with GPU Boost 2.0 Technology Technology for intelligent monitoring of clock speed, ensuring that the GPU runs at its peak & the game is at its highest frame rate possible. It offers new levels of customization, including GPU temperature target, overclocking, & unlocked voltage. 3072 MB Memory & 384-bit Memory interface With high capacity memory, it can fulfill the multi-screen & high definition application for gamer to satisfy a real gaming spirits., Specifications Base Clock
- 876 Hz Boost Clock
- 928 M Hz Memory Clock
- 7000MHZ Effective CUDA Cores
- 2880 Bus Type
- PCI-Express 3.0 Memory Detail
- 3072MB GDDR5 Memory Bit Width
- 384bit






...

Gigabyte GTX 780 Ti 3GB GDDR5 Dual DVI HDMI Display Port PCI-E Graphics Card NEW WINDFORCE 3X 2 SLOT 450W cooling system Keeping the same 450W Cooling capacity using only 2 slots, the New WINDFORCE 3X 450W cooling system is equipped with two 8mm & four 6mm cooper heat-pipes, inclined fans, & GIGABYTE Triangle Cool technology. This not only provides an effective heat dissipation capacity but GPU Boost 2.0 technology also enables higher performance due to a lower temperature. Chipset Ge Force
- GTX 780 Ti Memory Clock
- 7000 MHz Process Technology
- 28 nm Memory Size
- 3072 MB Memory Bus
- 384 bit Core Clock
- Base / Boost clockï14;š1020 / 1085 MHz Card Bus
- PCI-E 3.0 Memory Type
- GDDR5 Direct X
- 11.2 Open GL
- 4.4 PCB Form
- ATX Digital max resolution
- 4096 X 2160 (via a single HDMI connector & not supported with two DVI connectors) Analog max resolution
- 2048 x 1536 Multi-view
- 4 I/O DVI-I*1 DVI-D*1 Display Port*1 HDMI*1 Card size
- L=292mm, W=129mm, H=43mm Power requirement
- 600W (with two 8-pin external power connectors) NVIDIA Features NVIDIA Ge Force Experience Want to know the best settings to play your games? Ge Force Experience will figure it out for you. Ge Force Experience connects you to NVIDIA’s cloud datacenter to download optimal game settings tailored to your PC based on your CPU, GPU & monitor. Optimal settings maximize image quality while maintaining great performance so you get the best experience. A built-in interactive screenshot viewer helps you learn more about each setting & their benefits. The Ge Force Experience application automatically notifies you of new driver releases from NVIDIA. With a single click, you’ll be able to update the driver directly, without leaving your desktop. NVIDIA Kepler GPU Architecture NVIDIAs Kepler GPU architecture has been designed from the ground up not just for maximum performance in the latest Direct X 11 games, but optimal performance per watt. The new SMX streaming multiprocessor is twice as efficient as the prior generation & the new geometry engine draws triangles twice as fast. The result is world class performance & the highest image quality in an elegant & power efficient graphics card. NVIDIA TXAA Technology Film studios invest enormous resources in developing advanced technologies & post-production effects to deliver visually spectacular experiences for movie-goers. For games to achieve this level of fidelity, developers need new anti–aliasing technologies that deliver a viewing experience that eliminates the distraction of unrealistic, jagged lines (”jaggies”) & aliased shimmering–without compromising performance. NVIDIA is making this happen today, bringing cinema-quality graphics to life in blockbuster gaming titles with an innovative new temporal antialiasing technology called TXAA. Available exclusively on Ge Force GTX Kepler-powered GPUs, TXAA is designed to be directly integrated into game engines. Plus, it combines the raw power of MSAA (multi–sample anti–aliasing) with a temporal filter & sophisticated resolve filters similar to those used in CG films. The end result is a smoother, more lifelike image than any other comparable technique. NVIDIA FXAA Technology FXAA is a NVIDIA-developed post-processing technique that selectively blurs a game’s graphics to tackle unsightly jagged edges & high-contrast pixel deviation. Gaining popularity amongst developers due to its low performance impact & its ability to anti-alias transparent textures & details, FXAA is highly recommended for low-end & mid-range systems. NVIDIA G-SYNC Technology NVIDIA G-SYNC is a groundbreaking new innovation that casts aside decades-old thinking to create the smoothest, most responsive computer displays ever seen. A monitor module you can install yourself, or buy pre-installed in gamer-focused monitors, NVIDIA G-SYNC waves goodbye to the days of screen tearing, input lag, & eyestrain-inducing stuttering caused by decades-old tech lazily carried over from analog TVs to modern-day monitors. NVIDIA GPU Boost 2.0 Technology Up until now, GPUs have operated at a fixed clock speed when playing 3D games, even if they have the potential to run faster. GPU Boost intelligently monitors graphics work load & increases the clock speed whenever possible. The result is that the GPU always performs at its peak & you get the highest framerate possible. With NVIDIA GPU Boost 2.0 Enjoy new levels of customization with advanced controls like GPU temperature target, overclocking, & overvoltage. NVIDIA Adaptive V-Sync Technology Nothing is more distracting than framerate stuttering & screen tearing. The first tends to occur when framerates are low, the second when framerates are high. Adaptive V-Sync is a smarter way to render frames. At high framerates, V-sync is enabled to eliminate tearing, at low frame rates, its disabled to minimize stuttering. It gets rid of distractions so you can get on with gaming. NVIDIA Phys X Technology Phys X is designed specifically for hardware acceleration by powerful processors with hundreds of cores. Combined with the tremendous parallel processing capability of the GPU, Phys X will provide an exponential increase in physics processing power & will take gaming to a new level delivering rich, immersive physical gaming environments. NVIDIA CUDA Technology NVIDIA CUDA technology is the world’s only C language environment that enables programmers & developers to write software to solve complex computational problems in a fraction of the time by tapping into the many-core parallel processing power of GPUs. With millions of CUDA-capable GPUs already deployed, thousands of software programmers are already using the free CUDA software tools to accelerate applications—from video & audio encoding to oil & gas exploration, product design, medical imaging, & scientific research. NVIDIA Surround with up to 4 Monitors Nothing is as breathtaking as playing your favorite games across three monitors. At 5760 x 1080, the expanded field of view fully engages human peripheral vision & provides for the most immersive experience in racing & flight simulators. Add in a fourth display to keep tabs on chat, email or web while you are gaming. NVIDIA 3D Vision NVIDIA 3D Vision brings a fully immersive, stereoscopic 3D experience to the PC. A combination of high-tech wireless glasses & advanced software, 3D Vision transforms hundreds of PC games into full stereoscopic 3D. Get up to 2x monitor & keyboard brightness with NVIDIA 3D Light Boost technology. In addition, you can enjoy 3D movies & 3D digital photographs from 3 D Vision Live.com in eye popping, crystal-clear quality. NVIDIA SLI Technology Used by the most demanding gamers worldwide, SLI lets you link up to three Ge Force GTX 760s together for astounding performance. & with NVIDIA’s track record for fast & frequent software updates, you’ll not only get the best performance in existing games, but future games too.















...

WINDFORCE 3X 450W Cooling system 8+2 phase VRM power design Powered by NVIDIA Ge Force GTX 780 Ti GPU Integrated with industrys best 3GB GDDR5 memory 384-bit memory interface Features Dual-link DVI-I/ DVI-D / HDMI / Display Port BASE:876 MHz / BOOST:928 MHz System power supply requirement: 600W Keeping the same 450W Cooling capacity using only 2 slots, the New WINDFORCE 3X 450W cooling system is equipped with two 8mm & four 6mm cooper heat-pipes, inclined fans, & GIGABYTE “ Triangle Cool” technology. This not only provides an effective heat dissipation capacity but GPU Boost 2.0 technology also enables higher performance due to a lower temperature. Specifications Chipset
- Ge Force GTX 780 Ti Memory Clock
- 7000 MHz Process Technology
- 28 nm Memory Size
- 3072 MB Memory Bus
- 384 bit Core Clock
- Base / Boost clock:876 / 928 MHz Card Bus
- PCI-E 3.0 Memory Type
- GDDR5 Direct X
- 11.2 Open GL
- 4.4 PCB Form
- ATX Digital max resolution
- 4096 X 2160 (via a single HDMI connector & not supported with two DVI connectors) Analog max resolution
- 2048 x 1536 Multi-view
- 4 I/O
- DVI-I*1, DVI-D*1, Display Port*1, HDMI*1 Card size
- L=292mm, W=129mm, H=43mm Power requirement
- 600W (with two 8-pin external power connectors)
















...
