Gigabyte offers the exclusive WINDFORCE 2x 100 mm fansink equipped with " Triangle Cool" technology to reach a better cooling performance. The patent pending technology combines fin with clip module in a special triangle shape. With the original anti-turbulence structure plus the triangle cooling design, it enhances the efficiency of heat dissipation dramatically by minimizing the flow of turbulence between fans. The instinctive user interface, easier to monitoring & adjusting all important settings. Users can set up monitoring, GPU clock, memory clock, fan, GPU voltage, memory voltage, OSD, online support & update driver, BIOS directly. ...

With selected cards purchased from 10th July 2013 whilst stock last receive a FREE full game download coupon for Tom Clancy’s Splinter Cell Blacklist when you Gear Up with Ge Force GTX. Offer on selected cards only, not available on ex-display cards. Powered by NVIDIA Ge Force GTX 660 Ti GPU Integrated with the first 2048MB GDDR5 memory & 192-bit memory interface Features Dual link DVI-I/ DVI-D/ HDMI/ Display Port Core Clock: Base / Boost clock:1032 / 1111 MHz Support PCI Express 3.0 x 16 bus interface Support NVIDIA 3D Vision™ Surround & SLI technologies Support NVIDIA CUDA™ Technology Support NVIDIA Phys X™ Technology Support NVIDIA FXAA / TXAA Technology Support NVIDIA Adaptive Vertical Sync Technology System power supply requirement: 450W GPU
-
- Chipset Manufacturer
- n Vidia
- Chipset Model Name
- Ge Force GTX
- Chipset Additional Information
- OC Edition
- Cooling System
- Fan Interfaces/ Ports
-
- Video Card Bus Type
- PCI Express
- Video Card Bus Version
- 3.0 x 16
- DVI Port
- 2 (1 x DVI-I Dual-Link • 1 x DVI-D Single-Link)
- HDMI Port
- 1 x HDMI
- Display Port
- 1 x Display Port Memory
-
- Memory Size
- 2048 MB
- Memory Clock
- 6008 MHz
- Memory Type
- GDDR5
- Memory Width
- 192 bit Resolution
-
- Multiple Monitor Support (Max)
- 4
- DVI (Digital) resolution (Max)
- 2560 x 1600 Pixels System Requirements
-
- System Requirements
- Power Requirement
- 450W Physical
-
- Form Factor
- Graphics Card
- Width
- 13.7 cm
- Depth
- 26.6 cm
- Height
- 4.2 cm














































...

GPU
- GTX 660 Ti Core Clock (MHz)
- Base: 1032 M Hz, Boost: 1111 M Hz Stream Processor
- 1344 Mem Clock (MHz)
- 6008



...

GIGABYTE Super Overclock Series Powered by NVIDIA Ge Forece GTX 680 GPU Integrated with the first 2048MB GDDR5 memory & 256-bit memory interface Features Dual-link DVI-I / DVI-D / HDMI / Display Port Equipped GIGABYTE WINDFORCE 5X thermal design Core Clock: Base / Boost clock:1137 / 1202 MHz Support PCI Express 3.0 x 16 bus interface Support NVIDIA 3D Vision™ Surround & SLI technologies Support NVIDIA CUDA™ Technology Support NVIDIA Phys X™ Technology Support NVIDIA FXAA / TXAA Technology Support NVIDIA Adaptive Vertical Sync Technology System power supply requirement: 650W

Specification
- Chipset
- Ge Force GTX 680 PCB Form
- ATX Core Clock
- Base clock: 1137 MHz
- Boost clock: 1202 MHz Shader Clock
- N/A Memory Clock
- 6200 MHz Process Technology
- 28 nm Memory Size
- 2048MB Memory Bus
- 256 bit Card Bus
- PCI-E 3.0 Memory Type
- GDDR5 Direct X
- 11.1 Open GL
- 4.3 I/O
- Dual-link DVI-Ix 1, DVI-Dx 1, Display Portx 1, HDMIx 1 Digital max resolution
- 2560 x 1600 Analog max resolution
- 2048 x 1536 Multi-view
- 4 Card size
- H= 64mm, L=303 mm, W=148 mm Power requirement
- 650 W





















...

Specifications Graphics Engine
- NVIDIA Ge Force GTX 690 Bus Standard
- PCI Express 3.0 Open GL
- Open GL 4.2 Video Memory
-



...

Gigabyte has introduced the Gigabyte GTX 750 Ti 2GB GDDR5 Dual DVI HDMI PCI-E Graphics Card. This is an ultra durable card which features Dual Link DV-I/DV-D/HDMI 2. The card supports PCI express 3.0 with a 16 x bus interface. The GTX has a power requirement of 400watts & supports 4k at 60 Hz via two HDMI connections. This card is based around NVidia’s Maxwell GPU & is a fast performer. It can play many of the latest games at high resolutions & is a real mainstream card. The GTX 750 Ti has twin DVI ports & twin HDMI ports available for gaming, multimedia, home cinema or editing. It utilizes copper heat pipe technology to remove heat from the fin system as fast as possible. It uses Wind Force 2X Anti-turbulence-Parallel inclined fin design. These two ultra quiet PWM fans & two copper heat pipes are there to maximise the air channel through the graphics card vents which creates a more effective airflow system in the chassis. Unpacking it from the box the first thing that grabs your attention is the size of these dual fans. Gigabyte haven't stopped there either as they have a big aluminium heat sync to spread the heat. The fans are optimised for maximum airflow driving twice the amount of normal air across the cooling fins. The fans on the card are surprisingly quiet while cooling. The end result is a very quick graphics card from Gigabyte at a really sensible price from ebuyer. What do buyers of this of card think? 76% of buyers rated this graphics card at 9/10 Features buyer’s love: Speed & Price Charles Good Points + High cuda compute capability which is why I bought it for parallel programming. Haven't played any video games yet but I can't imagine not getting good performance out of the card. Bad Points − Quite thick (wide) Review Rating 9/10 Lloyd Ipswch build many PCs. Good Points + Great GPU. Near silent operation. Great aesthetic Price inline with other GTX 750 Tis. Bad Points − Requires 6 pin power supply
- Some people will view this as a positve, but as the MSI version of this card proves, this Maxwell chip is capable of overclocking using the power is receives via the motherboard alone. Review Rating 9/10 Chipset
- Ge Force GTX 750 Ti Memory Clock
- 5400 MHz Process Technology
- 28 nm Memory Size
- 2048MB Memory Bus
- 128 bit Core Clock
- Base:1033 M Hz Boost:1111 M Hz (Standard- Base:1020 M Hz Boost:1085 M Hz) Card Bus
- PCI-E 3.0 Memory Type
- GDDR5 Direct X
- 11.2 Open GL
- 4.4 PCB Form
- ATX Digital max resolution
- 4096 X 2160 (via 2 HDMI) Analog max resolution
- 2048 x 1536 Multi-view
- 4 I/O
- Dual-link DVI-I*1/DVI-D*1/HDMI*2 Card size
- L=204mm, W=144 mm, H=42mm Power requirement
- 400W GDDR5 Dual DVI HDMI PCI-E Graphics Card NVIDIA Features NVIDIA Ge Force Experience Want to know the best settings to play your games? Ge Force Experience will figure it out for you. Ge Force Experience connects you to NVIDIA’s cloud datacenter to download optimal game settings tailored to your PC based on your CPU, GPU & monitor. Optimal settings maximize image quality while maintaining great performance so you get the best experience. A built-in interactive screenshot viewer helps you learn more about each setting & their benefits. The Ge Force Experience application automatically notifies you of new driver releases from NVIDIA. With a single click, you’ll be able to update the driver directly, without leaving your desktop. NVIDIA TXAA Technology Film studios invest enormous resources in developing advanced technologies & post-production effects to deliver visually spectacular experiences for movie-goers. For games to achieve this level of fidelity, developers need new anti–aliasing technologies that deliver a viewing experience that eliminates the distraction of unrealistic, jagged lines (”jaggies”) & aliased shimmering–without compromising performance. NVIDIA is making this happen today, bringing cinema-quality graphics to life in blockbuster gaming titles with an innovative new temporal antialiasing technology called TXAA. Available exclusively on Ge Force GTX Kepler-powered GPUs, TXAA is designed to be directly integrated into game engines. Plus, it combines the raw power of MSAA (multi–sample anti–aliasing) with a temporal filter & sophisticated resolve filters similar to those used in CG films. The end result is a smoother, more lifelike image than any other comparable technique. NVIDIA FXAA Technology FXAA is a NVIDIA-developed post-processing technique that selectively blurs a game’s graphics to tackle unsightly jagged edges & high-contrast pixel deviation. Gaining popularity amongst developers due to its low performance impact & its ability to anti-alias transparent textures & details, FXAA is highly recommended for low-end & mid-range systems. NVIDIA GPU Boost 2.0 Technology Up until now, GPUs have operated at a fixed clock speed when playing 3D games, even if they have the potential to run faster. GPU Boost intelligently monitors graphics work load & increases the clock speed whenever possible. The result is that the GPU always performs at its peak & you get the highest framerate possible. With NVIDIA GPU Boost 2.0 Enjoy new levels of customization with advanced controls like GPU temperature target, overclocking, & overvoltage. NVIDIA Adaptive V-Sync Technology Nothing is more distracting than framerate stuttering & screen tearing. The first tends to occur when framerates are low, the second when framerates are high. Adaptive V-Sync is a smarter way to render frames. At high framerates, V-sync is enabled to eliminate tearing, at low frame rates, it's disabled to minimize stuttering. It gets rid of distractions so you can get on with gaming. NVIDIA Phys X Technology Phys X is designed specifically for hardware acceleration by powerful processors with hundreds of cores. Combined with the tremendous parallel processing capability of the GPU, Phys X will provide an exponential increase in physics processing power & will take gaming to a new level delivering rich, immersive physical gaming environments. NVIDIA CUDA Technology NVIDIA CUDA technology is the world’s only C language environment that enables programmers & developers to write software to solve complex computational problems in a fraction of the time by tapping into the many-core parallel processing power of GPUs. With millions of CUDA-capable GPUs already deployed, thousands of software programmers are already using the free CUDA software tools to accelerate applications—from video & audio encoding to oil & gas exploration, product design, medical imaging, & scientific research. NVIDIA Surround with up to 4 Monitors Nothing is as breathtaking as playing your favorite games across three monitors. At 5760 x 1080, the expanded field of view fully engages human peripheral vision & provides for the most immersive experience in racing & flight simulators. Add in a fourth display to keep tabs on chat, email or web while you are gaming. NVIDIA 3D Vision NVIDIA 3D Vision brings a fully immersive, stereoscopic 3D experience to the PC. A combination of high-tech wireless glasses & advanced software, 3D Vision transforms hundreds of PC games into full stereoscopic 3D. Get up to 2x monitor & keyboard brightness with NVIDIA 3D Light Boost technology. In addition, you can enjoy 3D movies & 3D digital photographs from 3 D Vision Live.com in eye popping, crystal-clear quality.

















...

Powered by NVIDIA Ge Force GTX 750 Ti GPU Integrated with the first 2048MB GDDR5 memory & 128-bit memory interface Core Clock: Base 1020 M Hz / Boost 1085 M Hz Features Dual-link DVI-I / DVI-D / HDMI*2 Support PCI Express 3.0 x 16 bus interface System power supply requirement: 400W As opposed to the stereotype, GIGABYTE is able to maximize fan size to 10cm with the latest cooling design. With a 10cm fan, the card is virtually silent that its noise level runs much lower Support up to four displays on a single card. Satisfy your multi-screen setup, high definition & extreme gaming experience. Specifications Chipset
- Ge Force GTX 750 Ti Core Clock Base / Boost clock
- 1020 / 1085 MHz Memory Clock
- 5400 MHz Process Technology
- 28 nm Memory Size
- 2048 MB Memory Bus
- 128 bit Card Bus
- PCI-E 3.0 Memory Type
- GDDR5 Direct X
- 12 Open GL
- 4.4 PCB Form
- ATX Digital max resolution 4096 X 2160 Analog max resolution 2048 x 1536 Multi-view
- 4 I/O
- Dual-link DVI-I*1/DVI-D*1/HDMI*2 Card size
- L=184mm, W=136mm, H=43mm Power requirement
- 400W














...

Gigabyte Ge Force GTX 750 Ti 2GB GDDR5 Dual-Link DVI HDMI Display Port PCI-E Graphics Card Chipset Ge Force GTX 750 Ti Memory Clock 5400 MHz Core Clock Base:1033 M Hz Boost:1111 M Hz (Standard- Base:1020 M Hz Boost:1085 M Hz) Process Technology 28 nm Memory Size 2048 MB Memory Bus 128 bit Card Bus PCI-E 3.0 Memory Type GDDR5 Direct X 11.2 Open GL 4.4 PCB Form Low Profile Digital max resolution 4096 X 2160 Analog max resolution 2048 x 1536 Multi-view 4 I/O Dual-link DVI-I*1/ Display Port/HDMI*2 Card size L=175mm, W=121mm, H=42mm Power requirement 400W

Includes:: Low Profile Brackets

...

Gigabyte GTX 750 Ti 4GB GDDR5 Dual-link DVI HDMI PCI-E Grpahics Card Powered by NVIDIA Ge Force GTX 750 Ti GPU Integrated with industry's best 4GB GDDR5 memory & 128-bit memory interface OC Edition
- Core Clock: Base 1059 M Hz / Boost 1137 M Hz (Standard- Base:1020 M Hz Boost:1085 M Hz) Features Dual-link DVI-I / DVI-D / HDMI*2 System power supply requirement: 400W WINDFORCE 2X cooling system GIGABYTE introduces WINDFORCE, the latest cooling technology that differentiates the brands graphics cards from the rest. GIGABYTE understands that a fan is crucial to the graphics card, so only the fan with the most efficiency is selected for WINDFORCE. Unique Blade Fan Design The airflow is spilt through the triangle design at the fan edge, & is guided smoothly through the fan by special 3D stripe curve design. At the same time, it effectively enhanced the cooling capacity while reducing air turbulence. Up to 4 displays on a Single Card Support up to four displays on a single card. Satisfy your multi-screen setup, high definition & extreme gaming experience. Gold Plated HDMI x 2 Gold plated, durable large contact area connectors have been used for optimum signal transfer between connections. Dual HDMI design lets users experience broader, richer gaming environments with better resolution on a single card. Specifications Chipset Ge Force GTX 750 Ti Core Clock Base/ Boost clock: 1059/ 1137 MHz (standard:1020/1085) Memory Clock 5400 MHz Process Technology 28 nm Memory Size 4 GB Memory Bus 128 bit Card Bus PCI-E 3.0 Memory Type GDDR5 Direct X 12 Open GL 4.4 PCB Form ATX Digital max resolution 4096 X 2160 (via 2 HDMI) Analog max resolution 2048 x 1536 Multi-view 4 I/O Dual-link DVI-I*1/DVI-D*1/HDMI*2 Card size H=42 mm, L=197 mm, W=127 mm Power requirement 400W (with one 6-pin external power connector)
...

Gigabyte GV-N760OC-4GD 4GB GDDR5 Dual DVI HDMI Display Port PCI-E Graphics Card Keeping the same 450W Cooling capacity using only 2 slots, the New WINDFORCE 3X 450W cooling system is equipped with two 8mm & four 6mm cooper heat-pipes, inclined fans, & GIGABYTE g Triangle Coolh technology. This not only provides an effective heat dissipation capacity but GPU Boost 2.0 technology also enables higher performance due to a lower temperature. Chipset Ge Force
- GTX 760 Memory Clock
- 6008 MHz Process Technology
- 28 nm Memory Size
- 4096 MB Memory Bus
- 256 bit Core Clock
- Base / Boost clock F1085 (std.980) / 1150 (std.1033) MHz Card Bus
- PCI-E 3.0 Memory Type
- GDDR5 Direct X
- 11.1 Open GL
- 4.3 PCB Form
- ATX Digital max resolution
- 4096 X 2160 (via a single HDMI connector & not supported with two DVI connectors) Analog max resolution
- 2048 x 1536 Multi-view
- 4 I/O: DVI-I*1 DVI-D*1 Display Port*1 HDMI*1 Card size
- L=292mm, W=129mm, H=43mm Power requirement
- 500W (with one 6-pin & one 8-pin external power connectors) NVIDIA Features NVIDIA Ge Force Experience Want to know the best settings to play your games? Ge Force Experience will figure it out for you. Ge Force Experience connects you to NVIDIA’s cloud datacenter to download optimal game settings tailored to your PC based on your CPU, GPU & monitor. Optimal settings maximize image quality while maintaining great performance so you get the best experience. A built-in interactive screenshot viewer helps you learn more about each setting & their benefits. The Ge Force Experience application automatically notifies you of new driver releases from NVIDIA. With a single click, you’ll be able to update the driver directly, without leaving your desktop. NVIDIA Kepler GPU Architecture NVIDIAs Kepler GPU architecture has been designed from the ground up not just for maximum performance in the latest Direct X 11 games, but optimal performance per watt. The new SMX streaming multiprocessor is twice as efficient as the prior generation & the new geometry engine draws triangles twice as fast. The result is world class performance & the highest image quality in an elegant & power efficient graphics card. NVIDIA TXAA Technology Film studios invest enormous resources in developing advanced technologies & post-production effects to deliver visually spectacular experiences for movie-goers. For games to achieve this level of fidelity, developers need new anti–aliasing technologies that deliver a viewing experience that eliminates the distraction of unrealistic, jagged lines (”jaggies”) & aliased shimmering–without compromising performance. NVIDIA is making this happen today, bringing cinema-quality graphics to life in blockbuster gaming titles with an innovative new temporal antialiasing technology called TXAA. Available exclusively on Ge Force GTX Kepler-powered GPUs, TXAA is designed to be directly integrated into game engines. Plus, it combines the raw power of MSAA (multi–sample anti–aliasing) with a temporal filter & sophisticated resolve filters similar to those used in CG films. The end result is a smoother, more lifelike image than any other comparable technique. NVIDIA FXAA Technology FXAA is a NVIDIA-developed post-processing technique that selectively blurs a game’s graphics to tackle unsightly jagged edges & high-contrast pixel deviation. Gaining popularity amongst developers due to its low performance impact & its ability to anti-alias transparent textures & details, FXAA is highly recommended for low-end & mid-range systems. NVIDIA GPU Boost 2.0 Technology Up until now, GPUs have operated at a fixed clock speed when playing 3D games, even if they have the potential to run faster. GPU Boost intelligently monitors graphics work load & increases the clock speed whenever possible. The result is that the GPU always performs at its peak & you get the highest framerate possible. With NVIDIA GPU Boost 2.0 Enjoy new levels of customization with advanced controls like GPU temperature target, overclocking, & overvoltage. NVIDIA Adaptive V-Sync Technology Nothing is more distracting than framerate stuttering & screen tearing. The first tends to occur when framerates are low, the second when framerates are high. Adaptive V-Sync is a smarter way to render frames. At high framerates, V-sync is enabled to eliminate tearing, at low frame rates, its disabled to minimize stuttering. It gets rid of distractions so you can get on with gaming. NVIDIA Phys X Technology Phys X is designed specifically for hardware acceleration by powerful processors with hundreds of cores. Combined with the tremendous parallel processing capability of the GPU, Phys X will provide an exponential increase in physics processing power & will take gaming to a new level delivering rich, immersive physical gaming environments. NVIDIA CUDA Technology NVIDIA CUDA technology is the world’s only C language environment that enables programmers & developers to write software to solve complex computational problems in a fraction of the time by tapping into the many-core parallel processing power of GPUs. With millions of CUDA-capable GPUs already deployed, thousands of software programmers are already using the free CUDA software tools to accelerate applications—from video & audio encoding to oil & gas exploration, product design, medical imaging, & scientific research. NVIDIA Surround with up to 4 Monitors Nothing is as breathtaking as playing your favorite games across three monitors. At 5760 x 1080, the expanded field of view fully engages human peripheral vision & provides for the most immersive experience in racing & flight simulators. Add in a fourth display to keep tabs on chat, email or web while you are gaming. NVIDIA 3D Vision NVIDIA 3D Vision brings a fully immersive, stereoscopic 3D experience to the PC. A combination of high-tech wireless glasses & advanced software, 3D Vision transforms hundreds of PC games into full stereoscopic 3D. Get up to 2x monitor & keyboard brightness with NVIDIA 3D Light Boost technology. In addition, you can enjoy 3D movies & 3D digital photographs from 3 D Vision Live.com in eye popping, crystal-clear quality. NVIDIA SLI Technology Used by the most demanding gamers worldwide, SLI lets you link up to three Ge Force GTX 780s together for astounding performance. & with NVIDIA’s track record for fast & frequent software updates, you’ll not only get the best performance in existing games, but future games too.















...
