Gigabyte GA-B85M-D2V Socket 1150 VGA DVI HD Audio Micro ATX Motherboard GIGABYTE 8 Series motherboards support the latest 4th Generation Intel Core processors, bringing together a unique blend of features & technologies that offer the absolute ultimate platform for your next PC build. From high current capable digital power delivery, performance-enhancing caching technologies, exclusive high-end audio features, advanced networking & device charging, gold plated hardware connectors & of course, killer good looks, GIGABYTE 8 series motherboards are in a class of their own. Next Gen Intel 8 Series Platform The latest Intel 8 Series platform offers significant improvements in performance & power consumption with the latest 4th generation Intel Core processors & Intel B85 chipsets. As well as a boost in overall productivity, the latest HD4600 Intel processor graphics provide native 4K resolution playback over standard HDMI connectivity, with significantly higher frame rates in the latest DX11 3D game titles. CPU Support for Intel Core„¢ i 7 processors/ Intel Core„¢ i 5 processors/ Intel Core„¢ i 3 processors/ Intel Pentium processors/ Intel Celeron processors in the LGA1150 package L3 cache varies with CPU (Please refer "CPU Support List" for more information.) Chipset Intel B85 Express Chipset Memory 2 x 1.5V DDR3 DIMM sockets supporting up to 16 GB of system memory * Due to a Windows 32-bit operating system limitation, when more than 4 GB of physical memory is installed, the actual memory size displayed will be less than the size of the physical memory installed. Dual channel memory architecture Support for DDR3 1600/1333 MHz memory modules Support for non-ECC memory modules Support for Extreme Memory Profile (XMP) memory modules (Please refer " Memory Support List" for more information.) Onboard Graphics Integrated Graphics Processor: 1 x D-Sub port, supporting a maximum resolution of 1920x 1200 1 x DVI-D port, supporting a maximum resolution of 1920x 1200 * The DVI-D port does not support D-Sub connection by adapter. Maximum shared memory of 1 GB Audio Realtek ALC887 codec High Definition Audio 2/4/5.1/7.1-channel * To configure 7.1-channel audio, you have to use an HD front panel audio module & enable the multi-channel audio feature through the audio driver. LAN Realtek Gb E LAN chip (10/100/1000 Mbit) Expansion Slots 1 x PCI Express x 16 slot, running at x 16 (The PCI Express x 16 slot conforms to PCI Express 3.0 standard.) 2 x PCI Express x 1 slot (All PCI Express x 1 slots conform to PCI Express 2.0 standard.) Storage Interface Chipset: 4 x SATA 6 Gb/s connectors (SATA3 0~SATA3 3) 2 x SATA 3 Gb/s connectors (SATA2 4~SATA2 5) USB (Universal Serial Bus) Chipset: 4 USB (Universal Serial Bus) 3.0/2.0 ports (2 ports on the back panel, 2 ports available through the internal USB (Universal Serial Bus) header) 8 USB (Universal Serial Bus) 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB (Universal Serial Bus) headers) Internal I/O Connectors 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 4 x SATA 6 Gb/s connectors 2 x SATA 3 Gb/s connectors 1 x CPU fan header 1 x system fan header 1 x front panel header 1 x front panel audio header 1 x USB (Universal Serial Bus) 3.0/2.0 header 2 x USB (Universal Serial Bus) 2.0/1.1 headers 1 x serial port header 1 x Clear CMOS jumper Back Panel Connectors 1 x PS/2 keyboard port 1 x PS/2 mouse port 1 x D-Sub port 1 x DVI-D port 2 x USB (Universal Serial Bus) 3.0/2.0 ports 4 x USB (Universal Serial Bus) 2.0/1.1 ports 1 x RJ-45 port 3 x audio jacks (Line In, Line Out, Mic In) I/O Controller i TE I/O Controller Chip H/W Monitoring System voltage detection CPU/ System temperature detection CPU/ System fan speed detection CPU/ System overheating warning CPU/ System fan fail warning CPU/ System fan speed control * Whether the fan speed control function is supported will depend on the cooler you install. BIOS 2 x 32 Mbit flash Use of licensed AMI EFI BIOS Support for Dual BIOS Pn P 1.0a, DMI 2.0, SM BIOS 2.6, ACPI 2.0a Unique Features Support for Q-Flash Support for Xpress Install Support for APP Center * Available applications in APP Center may differ by motherboard model. Supported functions of each application may also differ depending on motherboard specifications. @BIOS Easy Tune EZ Setup USB (Universal Serial Bus) Blocker Smart Time Lock Smart Recovery 2 Support for ON/OFF Charge Bundle Software Norton Internet Security (OEM version) Intel Rapid Start Technology Intel Smart Connect Technology Operating System Support for Windows 8/7 Form Factor Micro ATX Form Factor; 22.6cm x 17.4cm ...

Gigabyte GA-B85M-DS3H Socket 1150 VGA DVI HDMI 7.1 Channel Audio m ATX Motherboard CPU Support for Intel Core i 7 processors/ Intel Core i 5 processors/ Intel Core i 3 processors/ Intel Pentium processors/ Intel Celeron processors in the LGA1150 package L3 cache varies with CPU (Please refer "CPU Support List" for more information.) Chipset Intel B85 Express Chipset Memory 4 x 1.5V DDR3 DIMM sockets supporting up to 32 GB of system memory * Due to a Windows 32-bit operating system limitation, when more than 4 GB of physical memory is installed, the actual memory size displayed will be less than the size of the physical memory installed. Dual channel memory architecture Support for DDR3 1600/1333 MHz memory modules Support for non-ECC memory modules Support for Extreme Memory Profile (XMP) memory modules (Please refer " Memory Support List" for more information.) Onboard Graphics Integrated Graphics Processor
- Intel HD Graphics support: 1 x D-Sub port, supporting a maximum resolution of 1920x 1200 1 x DVI-D port, supporting a maximum resolution of 1920x 1200 * The DVI-D port does not support D-Sub connection by adapter. 1 x HDMI port, supporting a maximum resolution of 4096 x 2160 @ 24 Hz / 2560 x 1600 @ 60 Hz * Support for HDMI 1.4a version. Maximum shared memory of 1 GB Audio Realtek ALC887 codec High Definition Audio 2/4/5.1/7.1-channel * To configure 7.1-channel audio, you have to use an HD front panel audio module & enable the multi-channel audio feature through the audio driver. LAN Realtek Gb E LAN chip (10/100/1000 Mbit) Expansion Slots 1 x PCI Express x 16 slot, running at x 16 (The PCIEX16 slot conforms to PCI Express 3.0 standard.) 2 x PCI Express x 1 slots (The PCI Express x 1 slot conforms to PCI Express 2.0 standard.) Storage Interface Chipset: 4 x SATA 6 Gb/s connectors (SATA3 0/1/2/3) 2 x SATA 3 Gb/s connectors (SATA2 4/5) USB (Universal Serial Bus) Chipset: 4 x USB (Universal Serial Bus) 3.0/2.0 ports (2 ports on the back panel, 2 ports available through the internal USB (Universal Serial Bus) header) 8 x USB (Universal Serial Bus) 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB (Universal Serial Bus) headers) Internal I/O Connectors 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 4 x SATA 6 Gb/s connectors 2 x SATA 3 Gb/s connectors 1 x CPU fan header 1 x system fan header 1 x front panel header 1 x front panel audio header 1 x USB (Universal Serial Bus) 3.0/2.0 header 2 x USB (Universal Serial Bus) 2.0/1.1 headers 1 x serial port header 1 x parallel port header 1 x Clear CMOS jumper Back Panel Connectors 1 x PS/2 keyboard/mouse port 1 x D-Sub port 1 x DVI-D port 1 x HDMI port 2 x USB (Universal Serial Bus) 3.0/2.0 ports 4 x USB (Universal Serial Bus) 2.0/1.1 ports 1 x RJ-45 port 3 x audio jacks (Line In, Line Out, Mic In) I/O Controller i TE I/O Controller Chip H/W Monitoring System voltage detection CPU/ System temperature detection CPU/ System fan speed detection CPU overheating warning CPU/ System fan fail warning CPU/ System fan speed control * Whether the fan speed control function is supported will depend on the cooler you install. BIOS 2 x 64 Mbit flash Use of licensed AMI EFI BIOS Support for Dual BIOS Pn P 1.0a, DMI 2.7, Wf M 2.0, SM BIOS 2.7, ACPI 5.0 Unique Features Support for Q-Flash Support for Xpress Install Support for APP Center * Available applications in APP Center may differ by motherboard model. Supported functions of each application may also differ depending on motherboard specifications. @BIOS Easy Tune EZ Setup USB (Universal Serial Bus) Blocker Smart Time Lock Smart Recovery 2 Support for ON/OFF Charge Bundle Software Norton Internet Security (OEM version) Intel Rapid Start Technology Intel Smart Connect Technology Intel Small Business Advantage Operating System
- Support for Windows 8/7 Form Factor Micro ATX Form Factor; 22.6cm x 19.3cm

...

Like all Gigabyte motherboards the GA-B85M-HD3 not only supports 4th generation Intel Core processors but is also packed with features that make it an ideal choice for both PC builders & gamers. All Solid Caps This Gigabyte motherboard is equipped with All Solid Capacitors. These caps last far longer than the capacitors in other boards as they are rated to work at higher temperatures. HDMI The HDMI interface on the board is able to transmit uncompressed video & audio up to 1080p. & with the built-in DVI support the quality of display is maximised on devices such as computer monitors & projectors. Easy Tune & BIOS Gigabyte Easy Tune enables the user to easily adjust & optimise their system settings. With Smart Fan 2 all the fans can be individually configured to improve speed & airflow. The BIOS too has been updated & its enhanced graphical interface makes it easy to adjust & optimise settings from within the BIOS. The board also features Gigabyte Dual BIOS. This exclusive technology protects the motherboard from attack or failure with both a main BIOS & backup BIOS. Small Business Advantage The Gigabyte GA-B85M-HD3 motherboard supports Intel Small Business Advantage with its increased security, data back-up, energy centre & PC health centre. Features of the Gigabyte GAB85MHD3 Socket 1150 HDMI DVI MATX Motherboard B85 chipset Supports 4th Generation Intel Core Processors All Solid State Caps HDMI Interface Intel Small Business Advantage Dual BIOS technology Smart Fan 2 Manufacturers ID: GA-B85M-HD3 Gigabyte GAB85MHD3 Socket 1150 HDMI DVI MATX Motherboard Technical

Specification CPU
- Support for Intel Core 4th Generation LGA 1150 Processors (Go to GIGABYTEs website for the latest CPU support list.) Chipset
- Intel H87 Express Chipset Memory
- 2x DDR3 1600/1333 MHz memory modules * Due to Windows 32-bit operating system limitation, when more than 4 GB of physical memory is installed, the actual memory size displayed will be less than 4 GB. Onboard Graphics 1x D-Sub, 1x DVI-D (1920x 1200 max res), 1x HDMI (1920x 1200 max res) Audio
- ALC 887 Chip Multi-Graphics
- NA LAN
- 1 x Realtek 811F-VL w/ ESD Protection Expansion Slots
-
- 1 x PCI Express x 16 slots, running at x 16*
- 2 x PCI Express x 1 slot
- 1 x PCI Slots Storage Interface
-
- 4 x SATA 6 Gb/s connectors
- 2 x SATA 3 Gb/s connectors USB (Universal Serial Bus)
-
- USB (Universal Serial Bus) 3: 2x on the back panel, 2x via USB (Universal Serial Bus) internal front header
- USB (Universal Serial Bus) 2: 4x on the back panel, 4x via USB (Universal Serial Bus) internal headers Internal I/O Connectors
-
- 1 x 24-pin ATX main power connector,
- 1 x 8-pin ATX 12V power connector,
- 4 x SATA 6 Gb/s connector,
- 2 x SATA 3 Gb/s connectors,
- 1 x CPU fan header,
- 1 x system fan headers,
- 1 x front panel header,
- 1 x front panel audio header,
- 2 x USB (Universal Serial Bus) 2.0/1.1 headers,
- 1 x USB (Universal Serial Bus) 3.0/2.0 headers,
- 1 x LPT header,
- 1 x COM header,
- 1 x clearing CMOS jumper Back Panel Connectors
-
- 1 x PS/2 Keyboard/ Mouse port
- 1 x D-Sub
- 1 x DVI-D
- 1 x HDMI
- 2 x USB (Universal Serial Bus) 3.0/2.0 ports
- 4 x USB (Universal Serial Bus) 2.0/1.1 ports
- 1 x RJ-45 ports
- 3 x audio jacks BIOS
- 2 x EFI BIOS Chips, Support for Dual BIOS Form Factor
- m ATX Form Factor; 24.4 x 17.4cm










































...

Gigabyte GA-C1037UN-EU Socket Dual-core Celeron VGA HDMI 7.1-channel audio Mini-ITX Motherboard CPU Built in with an Intel Dual-core Celeron 1037U processor (1.8 GHz) * Do not disassemble the onboard CPU/chipset & the heatsinks by yourself to avoid damage to these components. 2 MB L3 cache Chipset Intel NM70 Chipset Memory 2 x 1.5V DDR3 DIMM sockets supporting up to 16 GB of system memory * Due to a Windows 32-bit operating system limitation, when more than 4 GB of physical memory is installed, the actual memory size displayed will be less than the size of the physical memory installed. Dual channel memory architecture Support for DDR3 1600/1333 MHz memory modules (Please refer " Memory Support List" for more information.) Onboard Graphics Integrated Graphics Processor: 1 x D-Sub port 1 x HDMI port, supporting a maximum resolution of 1920x 1200 * Support for HDMI 1.4 version. Maximum shared memory of 1 GB& Scaron;& Scaron; Audio Realtek ALC887 codec High Definition Audio 2/4/5.1/7.1-channel * To configure 7.1-channel audio, you have to use an HD front panel audio module & enable the multi-channel audio feature through the audio driver. LAN 2 x Realtek Gb E LAN chips (10/100/1000 Mbit) * Teaming is not supported. Expansion Slots 1 x PCI slot Storage Interface Chipset: 1 x SATA 6 Gb/s connector (SATA3 0) 2 x SATA 3 Gb/s connectors (SATA2 1~2) 1 x e SATA 3 Gb/s connector on the back panel & Scaron;& Scaron; JMicron JMB368 chip: 1 x IDE connector supporting ATA-133/100/66/33 & up to 2 IDE devices USB (Universal Serial Bus) Chipset: 8 x USB (Universal Serial Bus) 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB (Universal Serial Bus) headers) Internal I/O Connectors 1 x 24-pin ATX main power connector 1 x 4-pin ATX 12V power connector 1 x IDE connector 1 x SATA 6 Gb/s connector 2 x SATA 3 Gb/s connectors 1 x CPU fan header 1 x system fan header 1 x front panel header 1 x front panel audio header 2 x USB (Universal Serial Bus) 2.0/1.1 headers 1 x parallel port header 1 x serial port header 1 x Clear CMOS jumper 1 x chassis intrusion header Back Panel Connectors 1 x PS/2 keyboard port 1 x PS/2 mouse port 1 x D-Sub port 1 x serial port 1 x HDMI port 4 x USB (Universal Serial Bus) 2.0/1.1 ports 1 x e SATA 3 Gb/s connector 2 x RJ-45 ports 3 x audio jacks (Line In, Line Out, Mic In) I/O Controller i TE I/O Controller Chip H/W Monitoring System voltage detection CPU/ System temperature detection CPU/ System fan speed detection * Whether the fan speed detect function is supported will depend on the cooler you install. System fan speed control * Whether the fan speed control function is supported will depend on the cooler you install. BIOS 2 x 32 Mbit flash Use of licensed AMI EFI BIOS Support for Dual BIOS Pn P 1.0a, DMI 2.7, Wf M 2.0, SM BIOS 2.7, ACPI 5.0 Unique Features Support for @BIOS Support for Q-Flash Support for Xpress Install Support for Easy Tune * Available functions in Easy Tune may differ by motherboard model. Support for Smart Recovery 2 Support for Auto Green Support for ON/OFF Charge Bundle Software Norton Internet Security (OEM version) Intel Smart Connect Technology Operating System Support for Windows 8.1/8/7/XP Form Factor Mini-ITX Form Factor; 17.0cm x 17.0cm ...

GA-E350N WIN8 (rev. 1.0) AMD E-350D + A45 FCH All new design of Ultra Durable 4 classic Integrated new generation of AMD Dual-Core E-350D APU Features DDR3 1333+ for remarkable system performance Integrated AMD Radeon HD 6310 graphics (Direct X11) 60mm x 60mm quiet & high performance active APU fansink cooling for robust system endurance PCI interface for wide-range expansion card selections 8-channel ALC887 high definition audio CODEC enables high quality & realistic sound field experience Integrated HDMI interface for Full HD 1080 Blu-ray playback with HDCP Hi-Speed USB (Universal Serial Bus) & LPT/RS-232 connectors provide rich connectivity selection for your devices Compatible with Window 7 that delivers the best operation experience

Specification APU 1. Built in with an AMD E-350D Dual-Core processor 2. Built in with an AMD Radeon™ HD 6310 (Direct X 11) graphics core Chipset 1.AMD A45 FCH Memory 1.2 x 1.5V DDR3 DIMM sockets supporting up to 16 GB of system memory (Note 1) 2. Single channel memory architecture 3. Support for DDR3 1333 (O.C.)/1066 MHz memory modules (Please refer "CPU Support List" for more information.) Onboard Graphics Integrated in the APU: 1.1 x D-Sub port 2.1 x HDMI port, supporting a maximum resolution of 1920x 1200 Audio 1. Realtek ALC887 codec 2. High Definition Audio 3.2/4/5.1/7.1-channel (Note 2) 4. Support for S/PDIF Out LAN 1. Realtek Gb E LAN chip (10/100/1000 Mbit) Expansion Slots 1.1 x PCI slot Storage Interface Chipset: 1.4 x SATA 3 Gb/s connectors supporting up to 4 SATA 3 Gb/s devices USB (Universal Serial Bus) Chipset: 1. Up to 8 USB (Universal Serial Bus) 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB (Universal Serial Bus) headers) Internal I/O Connectors 1.1 x 24-pin ATX main power connector 2.1 x 4-pin ATX 12V power connector 3.4 x SATA 3 Gb/s connectors 4.1 x APU fan header 5.1 x system fan header 6.1 x front panel header 7.1 x front panel audio header 8.1 x S/PDIF Out header 9.2 x USB (Universal Serial Bus) 2.0/1.1 headers 10.1 x chassis intrusion header 11.1 x power LED header 12.1 x Clear CMOS jumper Back Panel Connectors 1.1 x PS/2 keyboard port 2.1 x PS/2 mouse port 3.1 x parallel port 4.1 x serial port 5.1 x D-Sub port 6.1 x HDMI port 7.4 x USB (Universal Serial Bus) 2.0/1.1 ports 8.1 x RJ-45 port 9.3 x audio jacks (Line In/ Line Out/ Microphone) I/O Controller 1.i TE I/O Controller Chip H/W Monitoring 1. System voltage detection 2.APU/ System temperature detection 3.APU/ System fan speed detection 4.APU overheating warning 5. System fan speed control (Note 3) BIOS 1.2 x 32 Mbit flash 2. Use of licensed AMI EFI BIOS 3. Support for Dual BIOS™ 4. Pn P 1.0a, DMI 2.0, SM BIOS 2.6, ACPI 2.0a Unique Features 1. Support for @BIOS 2. Support for Q-Flash 3. Support for Xpress Install 4. Support for Easy Tune (Note 4) 5. Support for Smart Recovery 2 6. Support for Auto Green 7. Support for ON/OFF Charge 8. Support for Q-Share Operating System 1. Support for Microsoft Windows 8/7/ Vista/XP Form Factor 1. Mini-ITX Form Factor; 17.0cm x 17.0cm

...

APU FM2 Socket: AMD A series processors AMD Athlon™series processors (Please refer to Gigabytes "CPU Support List" for more information.) Chipset AMD A55 Memory 2 x 1.5V DDR3 DIMM sockets supporting up to 32 GB of system memory * Due to a Windows 32-bit operating system limitation, when more than 4 GB of physical memory is installed, the actual memory size displayed will be less than the size of the physical memory installed. Dual channel memory architecture Support for DDR3 1866/1600/1333/1066 MHz memory modules Support for AMD Memory Profile (AMP) memory modules (Please refer to Gigabytes " Memory Support List" for more information.) Onboard Graphics APU: * To use the onboard graphics ports, you must install an AMD APU with integrated graphics. 1 x HDMI port, supporting a maximum resolution of 1920x 1200 Audio Realtek ALC887 codec High Definition Audio 2/4/5.1/7.1-channel * To configure 7.1-channel audio, you have to use an HD front panel audio module & enable the multi-channel audio feature through the audio driver. Support for S/PDIF Out LAN Realtek Gb E LAN chip (10/100/1000 Mbit) Expansion Slots 1 x PCI Express x 16 slot, running at x 16 4 x PCI Express x 1 slots (All PCI Express slots conform to PCI Express 2.0 standard.) 2 x PCI slots Multi-Graphics Technology Support for AMD Dual Graphics technology * Only A series APUs support AMD Dual Graphics. Storage Interface Chipset: 6 x SATA 3 Gb/s connectors supporting up to 6 SATA 3 Gb/s devices Support for RAID 0, RAID 1, RAID 10, & JBOD USB (Universal Serial Bus) Chipset: Up to 14 USB (Universal Serial Bus) 2.0/1.1 ports (6 ports on the back panel, 8 ports available through the internal USB (Universal Serial Bus) headers) Internal I/O Connectors 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 6 x SATA 3 Gb/s connectors 1 x APU fan header 3 x system fan headers 1 x front panel header 1 x front panel audio header 1 x S/PDIF Out header 4 x USB (Universal Serial Bus) 2.0/1.1 headers 1 x Clear CMOS jumper 1 x Trusted Platform Module (TPM) header Back Panel Connectors 1 x PS/2 keyboard port 1 x PS/2 mouse port 1 x serial port 1 x HDMI port 6 x USB (Universal Serial Bus) 2.0/1.1 ports 1 x RJ-45 port 3 x audio jacks (Line In/ Line Out/ Microphone) I/O Controller i TE I/O Controller Chip H/W Monitoring System voltage detection APU/ System temperature detection APU/ System/ Power fan speed detection APU overheating warning APU/ System/ Power fan fail warning APU/ System fan speed control * Whether the APU/system fan speed control function is supported will depend on the APU/system cooler you install. BIOS 2 x 32 Mbit flash Use of licensed AMI EFI BIOS Support for Dual BIOS Pn P 1.0a, DMI 2.0, SM BIOS 2.6, ACPI 2.0a Unique Features Support for @BIOS Support for Q-Flash Support for Xpress Install Support for Easy Tune * Available functions in Easy Tune may differ by motherboard model. Support for Smart Recovery 2 Support for Auto Green Support for ON/OFF Charge Support for 3TB+ Unlock Support for Q-Share Bundle Software Norton Internet Security (OEM version) Operating System Support for Microsoft Windows 8/7/ Vista/XP Form Factor ATX Form Factor; 30.5cm x 19.0cm Remark Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors' website or 3rd party website. Most hardware/software vendors may no longer offer drivers to support Win 9X/ME/2000/XP SP1/SP2. If drivers are available from the vendors, we will update them on the GIGABYTE website. ...

APU FM2 Socket AMD A series processors AMD Athlon series processors (Please refer To Gigabytes "CPU Support List" for more information.) Chipset AMD A55 Memory 2 x 1.5V DDR3 DIMM sockets supporting up to 32 GB of system memory * Due to a Windows 32-bit operating system limitation, when more than 4 GB of physical memory is installed, the actual memory size displayed will be less than the size of the physical memory installed. Dual channel memory architecture Support for DDR3 1866/1600/1333/1066 MHz memory modules Support for AMD Memory Profile (AMP) memory modules (Please refer to Gigabytes " Memory Support List" for more information.) Onboard Graphics APU: * To use the onboard graphics ports, you must install an AMD APU with integrated graphics. 1 x D-Sub port 1 x DVI-D port, supporting a maximum resolution of 2560x 1600 * Support for 2560x 1600 resolution requires both a monitor & cable that support Dual Link DVI * The DVI-D port does not support D-Sub connection by adapter Audio Realtek ALC887 codec High Definition Audio 2/4/5.1/7.1-channel * To configure 7.1-channel audio, you have to use an HD front panel audio module & enable the multi-channel audio feature through the audio driver Support for S/PDIF Out LAN Realtek Gb E LAN chip (10/100/1000 Mbit) Expansion Slots 1 x PCI Express x 16 slot, running at x 16 1 x PCI Express x 1 slot (All PCI Express slots conform to PCI Express 2.0 standard.) 1 x PCI slot Multi-Graphics Technology Support for AMD Dual Graphics technology * Only A series APUs support AMD Dual Graphics Storage Interface Chipset: 4 x SATA 3 Gb/s connectors supporting up to 4 SATA 3 Gb/s devices Support for RAID 0, RAID 1, RAID 10, & JBOD USB (Universal Serial Bus) Chipset: Up to 8 USB (Universal Serial Bus) 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB (Universal Serial Bus) headers) Internal I/O Connectors 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 4 x SATA 3 Gb/s connectors 1 x APU fan header 1 x system fan header 1 x front panel header 1 x front panel audio header 1 x S/PDIF Out header 2 x USB (Universal Serial Bus) 2.0/1.1 headers 1 x serial port header 1 x Clear CMOS jumper Back Panel Connectors 1 x PS/2 keyboard port 1 x PS/2 mouse port 1 x D-Sub port 1 x DVI-D port 4 x USB (Universal Serial Bus) 2.0/1.1 ports 1 x RJ-45 port 3 x audio jacks (Line In/ Line Out/ Microphone) I/O Controller i TE I/O Controller Chip H/W Monitoring System voltage detection APU/ System temperature detection APU/ System fan speed detection APU overheating warning APU/ System fan fail warning APU/ System fan speed control * Whether the APU/system fan speed control function is supported will depend on the APU/system cooler you install BIOS 2 x 32 Mbit flash Use of licensed AMI EFI BIOS Support for Dual BIOS Pn P 1.0a, DMI 2.0, SM BIOS 2.6, ACPI 2.0a Unique Features Support for @BIOS Support for Q-Flash Support for Xpress Install Support for Easy Tune * Available functions in Easy Tune may differ by motherboard model. & Scaron;& Scaron; Support for Smart Recovery 2 Support for Auto Green Support for ON/OFF Charge Support for 3TB+ Unlock Support for Q-Share Bundle Software Norton Internet Security (OEM version) Operating System Support for Microsoft Windows 8/7/ Vista/XP Form Factor Micro ATX Form Factor; 22.5cm x 17.4cm Remark Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors' website or 3rd party website. Most hardware/software vendors may no longer offer drivers to support Win 9X/ME/2000/XP SP1/SP2. If drivers are available from the vendors, we will update them on the GIGABYTE website. ...

APU FM2 Socket: AMD A series processors AMD Athlon series processors (Please refer "CPU Support List" on Gigabytes website for more information.) Chipset AMD A55 Memory 2 x 1.5V DDR3 DIMM sockets supporting up to 64 GB of system memory * The maximum 64 GB of system memory can be supported using 16 GB (or above) memory modules. GIGABYTE will update the memory support list on the official website when the memory modules are available on the market. * Due to a Windows 32-bit operating system limitation, when more than 4 GB of physical memory is installed, the actual memory size displayed will be less than the size of the physical memory installed. Dual channel memory architecture Support for DDR3 1866/1600/1333/1066 MHz memory modules Support for AMD Memory Profile (AMP)/ Extreme Memory Profile (XMP) memory modules “ Memory support is dependent on memory module compatibility & system OS”. (Please refer " Memory Support List" on Gigabytes website for more information.) Onboard Graphics APU: * To use the onboard graphics ports, you must install an AMD APU with integrated graphics. 1 x D-Sub port 1 x DVI-D port, supporting a maximum resolution of 2560x 1600 * Support for 2560x 1600 resolution requires both a monitor & cable that support Dual Link DVI. * The DVI-D port does not support D-Sub connection by adapter. 1 x HDMI port, supporting a maximum resolution of 1920x 1200 Audio Realtek ALC887 codec& Scaron; High Definition Audio& Scaron; 2/4/5.1/7.1-channel * To configure 7.1-channel audio, you have to use an HD front panel audio module & enable the multi-channel audio feature through the audio driver. Support for S/PDIF Out LAN Realtek Gb E LAN chip (10/100/1000 Mbit) Expansion Slots 1 x PCI Express x 16 slot, running at x 16 1 x PCI Express x 1 slot (All PCI Express slots conform to PCI Express 2.0 standard.) 1 x PCI slot Multi-Graphics Technology Support for AMD Dual Graphics technology * Only A series APUs support AMD Dual Graphics. Storage Interface Chipset: 4 x SATA 3 Gb/s connectors supporting up to 4 SATA 3 Gb/s devices Support for RAID 0, RAID 1, RAID 10, & JBOD USB (Universal Serial Bus) Chipset: Up to 8 USB (Universal Serial Bus) 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB (Universal Serial Bus) headers) Internal I/O Connectors 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 4 x SATA 3 Gb/s connectors 1 x APU fan header 1 x system fan header 1 x front panel header 1 x front panel audio header 1 x S/PDIF Out header 2 x USB (Universal Serial Bus) 2.0/1.1 headers 1 x serial port header 1 x Clear CMOS jumper Back Panel Connectors 1 x PS/2 keyboard/mouse port 1 x D-Sub port 1 x DVI-D port 1 x HDMI port 4 x USB (Universal Serial Bus) 2.0/1.1 ports 1 x RJ-45 port 3 x audio jacks (Line In/ Line Out/ Microphone) I/O Controller i TE I/O Controller Chip H/W Monitoring System voltage detection APU/ System temperature detection APU/ System fan speed detection APU overheating warning APU/ System fan fail warning APU/ System fan speed control * Whether the APU/system fan speed control function is supported will depend on the APU/system cooler you install. BIOS 2 x 32 Mbit flash Use of licensed AMI EFI BIOS Support for Dual BIOS Pn P 1.0a, DMI 2.0, SM BIOS 2.6, ACPI 2.0a Unique Features Support for @BIOS Support for Q-Flash Support for Xpress Install Support for Easy Tune * Available functions in Easy Tune may differ by motherboard model Support for Smart Recovery 2 Support for Auto Green Support for ON/OFF Charge Support for 3TB+ Unlock Support for Q-Share Operating System Support for Microsoft Windows 8/7/ Vista/XP Form Factor Micro ATX Form Factor; 22.5cm x 17.4cm ...

Gigabyte GA-F2A58M-DS2 Socket FM2+ VGA DVI-D Micro ATX Motherboard APU FM2+ Socket: AMD A series processors AMD Athlon series processors (Please refer "CPU Support List" for more information.) Chipset
- AMD A58 Memory 2 x DDR3 DIMM sockets supporting up to 64 GB of system memory * Due to a Windows 32-bit operating system limitation, when more than 4 GB of physical memory is installed, the actual memory size displayed will be less than the size of the physical memory installed. * The maximum 64 GB of system memory can be supported using 16 GB (or above) memory modules. GIGABYTE will update the memory support list on the official website when the memory modules are available on the market. Dual channel memory architecture Support for DDR3 2400 (OC)/2133/1866/1600/1333 MHz memory modules Support for AMD Memory Profile (AMP)/ Extreme Memory Profile (XMP) memory modules (Please refer " Memory Support List" for more information.) Onboard Graphics Integrated Graphics Processor: 1 x D-Sub port, supporting a maximum resolution of 1920x 1200 1 x DVI-D port, supporting a maximum resolution of 2560x 1600 * Support for 2560x 1600 resolution requires both a monitor & cable that support Dual Link DVI. * The DVI-D port does not support D-Sub connection by adapter. Maximum shared memory of 2 GB Audio Realtek ALC887 codec High Definition Audio 2/4/5.1/7.1-channel * To configure 7.1-channel audio, you have to use an HD front panel audio module & enable the multi-channel audio feature through the audio driver. Support for S/PDIF Out LAN
- Realtek Gb E LAN chip (10/100/1000 Mbit) Expansion Slots 1 x PCI Express x 16 slot, running at x 16 (The PCI Express x 16 slot conforms to PCI Express 3.0 standard.) * To support PCI Express 3.0, you must install an FM2+ APU. 1 x PCI Express x 1 slot (The PCI Express x 1 slot conforms to PCI Express 2.0 standard.) 1 x PCI slot Multi-Graphics Technology Support for AMD Dual Graphics technology * Only A series APUs support AMD Dual Graphics. Storage Interface Chipset: 4 x SATA 3 Gb/s connectors Support for RAID 0, RAID 1, RAID 10, & JBOD USB (Universal Serial Bus) Chipset: 8 x USB (Universal Serial Bus) 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB (Universal Serial Bus) headers) Internal I/O Connectors 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 4 x SATA 3 Gb/s connectors 1 x APU fan header 1 x system fan header 1 x front panel header 1 x front panel audio header 1 x S/PDIF Out header 2 x USB (Universal Serial Bus) 2.0/1.1 headers 1 x serial port header 1 x Clear CMOS jumper Back Panel Connectors 1 x PS/2 keyboard/mouse port 1 x D-Sub port 1 x DVI-D port 4 x USB (Universal Serial Bus) 2.0/1.1 ports 1 x RJ-45 port 3 x audio jacks (Line In, Line Out, Mic In) I/O Controller i TE I/O Controller Chip H/W Monitoring System voltage detection APU/ System temperature detection APU/ System fan speed detection APU overheating warning APU/ System fan fail warning APU/ System fan speed control * Whether the fan speed control function is supported will depend on the cooler you install. BIOS 2 x 64 Mbit flash Use of licensed AMI UEFI BIOS Support for Dual BIOS Pn P 1.0a, DMI 2.7, Wf M 2.0, SM BIOS 2.7, ACPI 5.0 Unique Features Support for @BIOS Support for Q-Flash Support for Xpress Install Support for Easy Tune * Available functions in Easy Tune may differ by motherboard model. Support for Smart Recovery 2 Support for ON/OFF Charge Bundle Software Norton Internet Security (OEM version) Operating System Support for Windows 8.1/8/7 32-bit/64-bit Support for Windows XP 32-bit * To support Windows XP 32-bit, you must install an AMD FM2 Trinity APU. * It requires Service Pack 3 to support Windows XP driver installation. Form Factor Micro ATX Form Factor; 22.6cm x 17.4cm

...

Socket FM2+ supports AMD FM2+/FM2 A-series APU GIGABYTE Ultra Durable 4 Plus Technology GIGABYTE UEFI Dual BIOS GIGABYTE On/ Off Charge for USB (Universal Serial Bus) devices HDMI, Dual-link DVI, D-sub ports for Triple-Monitor support 8 USB (Universal Serial Bus) 2.0 & 4 SATA2 ports with RAID 0, 1, 10 support High ESD Protection on Gb E LAN & USB (Universal Serial Bus) ports All solid capacitors design GIGABYTE FM2+ series motherboards based on AMD A58 chipset & feature the new FM2+ APU socket, & are designed to get the most from forthcoming Kaveri AMD APUs, while preserving compatibility for current AMD FM2 APUs. FM2+ AMD APUs offer native support for 8 GT/s PCI Express gen 3.0 as well as DX11.1 support integrating the high performance ‘ Steamroller’ core. AMD socket FM2+ APUs also offer native support for 4K resolution displays on HDMI port. APU FM2+ Socket: AMD A series processors AMD Athlon™ series processors (Please refer "CPU Support List" on Gigabyte website for more information) Chipset AMD A58 Memory 2 x DDR3 DIMM sockets supporting up to 64 GB of system memory * The maximum 64 GB of system memory can be supported using 16 GB (or above) memory modules. GIGABYTE will update the memory support list on the official website when the memory modules are available on the market. * Due to a Windows 32-bit operating system limitation, when more than 4 GB of physical memory is installed, the actual memory size displayed will be less than the size of the physical memory installed. Dual channel memory architecture Support for DDR3 2400 (OC)/2133/1866/1600/1333 MHz memory modules Support for AMD Memory Profile (AMP)/ Extreme Memory Profile (XMP) memory modules (Please refer " Memory Support List" on Gigabyte website for more information) Onboard Graphics Integrated Graphics Processor: 1 x D-Sub port, supporting a maximum resolution of 1920x 1200 1 x DVI-D port, supporting a maximum resolution of 2560x 1600 * Support for 2560x 1600 resolution requires both a monitor & cable that support Dual Link DVI. * The DVI-D port does not support D-Sub connection by adapter 1 x HDMI port, supporting a maximum resolution of 4096x 2160 * The resolution of 4096x 2160 can be supported when using an FM2+ APU; the maximum resolution supported is 1920x 1200 when using an FM2 APU. * Support for HDMI 1.4a version. Maximum shared memory of 2 GB Audio Realtek ALC887 codec High Definition Audio 2/4/5.1/7.1-channel * To configure 7.1-channel audio, you have to use an HD front panel audio module & enable the multi-channel audio feature through the audio driver. Support for S/PDIF Out LAN Realtek Gb E LAN chip (10/100/1000 Mbit) Expansion Slots 1 x PCI Express x 16 slot, running at x 16 (The PCI Express x 16 slot conforms to PCI Express 3.0 standard.) * To support PCI Express 3.0, you must install an FM2+ APU 1 x PCI Express x 1 slot (The PCI Express x 1 slot conforms to PCI Express 2.0 standard.) 1 x PCI slot Multi-Graphics Technology Support for AMD Dual Graphics technology Only A series APUs support AMD Dual Graphics Storage Interface Chipset: 4 x SATA 3 Gb/s connectors Support for RAID 0, RAID 1, RAID 10, & JBOD USB (Universal Serial Bus) Chipset: 8 x USB (Universal Serial Bus) 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB (Universal Serial Bus) headers) Internal I/O Connectors 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 4 x SATA 3 Gb/s connectors 1 x APU fan header 1 x system fan header 1 x front panel header 1 x front panel audio header 1 x S/PDIF Out header 2 x USB (Universal Serial Bus) 2.0/1.1 headers 1 x serial port header 1 x Clear CMOS jumper Back Panel Connectors 1 x PS/2 keyboard/mouse port 1 x D-Sub port 1 x DVI-D port 1 x HDMI port 4 x USB (Universal Serial Bus) 2.0/1.1 ports 1 x RJ-45 port 3 x audio jacks (Line In, Line Out, Mic In) I/O Controller i TE I/O Controller Chip H/W Monitoring System voltage detection APU/ System temperature detection APU/ System fan speed detection APU overheating warning APU/ System fan fail warning APU/ System fan speed control * Whether the fan speed control function is supported will depend on the cooler you install BIOS 2 x 64 Mbit flash Use of licensed AMI UEFI BIOS Support for Dual BIOS Pn P 1.0a, DMI 2.7, Wf M 2.0, SM BIOS 2.7, ACPI 5.0 Unique Features Support for @BIOS Support for Q-Flash Support for Xpress Install Support for Easy Tune * Available functions in Easy Tune may differ by motherboard model Support for Smart Recovery 2 Support for ON/OFF Charge Operating System Support for Windows 8.1/8/7 32-bit/64-bit Support for Windows XP 32-bit * To support Windows XP 32-bit, you must install an AMD FM2 Trinity APU. * It requires Service Pack 3 to support Windows XP driver installation. Form Factor Micro ATX Form Factor; 22.6cm x 17.4cm Remark Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors' website or 3rd party website. Most hardware/software vendors may no longer offer drivers to support Win 9X/ME/2000/XP SP1/SP2. If drivers are available from the vendors, we will update them on the GIGABYTE website. ...
