The Eaton EX UPS, part of the Pulsar Series, offers high availability, flexibility & minimum total cost of ownership for Servers, data storage, network equipment, telephony VOIP, medical equipment & industrial processes. Delivering on-line double conversion protection in Tower or versatile Rack & Tower format. ...

Hot Swap MBP provides a maintenance bypass for all UPSs up to 3 k VA: UPSs can be hot swapped or upgrade without interrupting the power supply. Hot Swap MBP has an IEC16A input connector with retaining clip for compatibility with any UPS now & in the future from Eaton UPS SYSTEMS or any other supplier. Hot Swap MBP units can be installed as required; at the back, side, top of the UPSs, or rack-mounted. ...

Hot Swap MBP provides a maintenance bypass for all UPSs up to 3 k VA: UPSs can be hot swapped or upgrade without interrupting the power supply. Hot Swap MBP has an IEC16A input connector with retaining clip for compatibility with any UPS now & in the future from Eaton UPS SYSTEMS or any other supplier. Hot Swap MBP units can be installed as required; at the back, side, top of the UPSs, or rack-mounted. ...

Monitoring: highly accurate individual outlet, branch circuit, & full e PDU monitoring for V, W, A & k Whrs (1% accuracy above 2A). Also monitor temperature & humidity in the rack via optional sensors. Switching: individual outlet, sequencing of outlets with delays or cycling enables remote reboot of equipment. Control: Monitor & control remotely over Ethernet & via Advanced LCD screen on the unit. Communication protocols include HTTP / HTTPS, DHCP, SNMP v 1 & v 3, SNTP, SMTP, Telnet, IPv 4 & IPv 6. ...

Eaton e PDU’s are enclosure-based Power Distribution Units, designed to provide reliable, cost effective power distribution together with highly accurate monitoring & control for IT equipment in the Data centre. Two key trends have emerged in the Data centre: the increasing demand for power from today’s IT equipment, & also the increasing cost of power. Couple these with the worldwide growth in demand for data centres & IT servers, & it is clear that Data centre managers are facing increasing pressure to manage & optimise their available power. To effectively be able to manage power for growth, & manage the increasing associated costs, Data centre managers need an accurate view of the power & energy being consumed in the data centre, from row to rack, & right down to the individual server level. Only then can we truly understand the power usage & optimise the available power Eaton e PDUs enable the Data Centre manager to Optimise & utilise all available power Control the operational expenditure of running a Data Centre Effectively manage & plan for new & existing infrastructure Intelligent Power Distribution Maximise your available power, choose your required level of monitoring whether it is true k Whr, V, W & A consumption to enable you to utilise all of your available power, or switching to give full control & remote reboot options, or combine the two to fully manage the rack power. Intelligent Power Monitoring Manage your power consumption, accurately monitor the level of power being drawn by the rack, to the breaker branch or outlet group, right down to the individual server level, so you can control your operational expenditure Intelligent Power Control Complete control of your power distribution through remote & secure individual outlet switching, sequencing & cycling to allow for control & rebooting of servers & related IT equipment. Intelligent Power for the Data Centre Maximum availability – designed specifically for the data centre environment, designed for reliable & consistent power distribution, designed to last. Multiple technologies & multiple input & output possibilities are available Intelligent Power Manager Supervise your data centre power distribution – Eaton e PDUs are designed to be easy to set up & maintain, either through your existing SNMP software or through Eaton’s Intelligent Power Manager software. ...

Powerware Model 5130 UPS 1250 VA The newest uninterruptible power system (UPS) addition to the Powerware series, the Eaton 5130 UPS system delivers more power quality performance in less space, at a value price. This new UPS power supply offers more power protection in the same as or smaller footprint than previous-generation equivalents, plus new power performance features. The 5130 resolves outages, sags, surges, under-voltage & over-voltage conditions”and supplies clean, conditioned power to all connected equipment. This UPS is particularly well suited for protecting: IT & networking equipment, such as routers, switches, servers, wireless devices, storage systems, security systems & PC/workstation clusters Telecom equipment, such as PBXs, Vo IP components & EDGE/3G/ Wi MAX wireless networking equipment The 5130 is value-priced, but it also delivers features you would normally expect to find in much higher-priced systems, such as: load segment control, hot-swappable battery modules, long battery runtime options, multiple communication options, high output power factor & high power density”all in a sleek, modern package. Product Description - Eaton PW5130i 1250-XL2U
- UPS
- 1.15 k W
- 1250 VA Manufacturer Warranty - 2 years warranty

Dimensions (Wx Dx H) - 44.1 cm x 50.9 cm x 8.6 cm Weight - 24.3kg Networking - RS-232, USB (Universal Serial Bus) Device Type
- UPS
- external Battery - Lead Acid 7.2 Ah Input Voltage
- AC 230 V Output Voltage - AC 184-265 V Power Provided - 1.15 k W / 1250 VA Output Connector (s) - 8 x power IEC 320 EN 60320 C13 Battery Form Factor - Internal Rack Size - 2U Run Time (Up To) - 5 min at full load







...

Powerware Model 5130 UPS 1700 VA The newest uninterruptible power system (UPS) addition to the Powerware series, the Eaton 5130 UPS system delivers more power quality performance in less space, at a value price. This new UPS power supply offers more power protection in the same as or smaller footprint than previous-generation equivalents, plus new power performance features. The 5130 resolves outages, sags, surges, under-voltage & over-voltage conditions & supplies clean, conditioned power to all connected equipment. This UPS is particularly well suited for protecting: IT & networking equipment, such as routers, switches, servers, wireless devices, storage systems, security systems & PC/workstation clusters Telecom equipment, such as PBXs, Vo IP components & EDGE/3G/ Wi MAX wireless networking equipment The 5130 is value-priced, but it also delivers features you would normally expect to find in much higher-priced systems, such as: load segment control, hot-swappable battery modules, long battery runtime options, multiple communication options, high output power factor & high power density”all in a sleek, modern package. Product Description - Eaton PW5130i 1750-XL2U
- UPS
- 1.6 k W
- 1750 VA Manufacturer Warranty - 2 years warranty

Dimensions (Wx Dx H) - 44.1 cm x 50.9 cm x 8.6 cm Weight - 26.6kg Networking - RS-232, USB (Universal Serial Bus) Device Type - UPS
- external Battery - Lead Acid 9 Ah Input Voltage
- AC 230 V Output Voltage - AC 184-265 V Power Provided - 1.6 k W / 1750 VA Output Connector (s)
- 8 x power IEC 320 EN 60320 C13 Battery Form Factor - Internal Rack Size - 2U Run Time (Up To) - 3 min at full load Please note: networking components such as switches, routers, UPS & wireless devices require that speeds & standards be consistent throughout the network to gain optimum performance. To avoid compatibility clashes or for advice, please contact us on solutions@ebuyer.com.







...

Powerware Model 5130 UPS 2500 VA The newest uninterruptible power system (UPS) addition to the Powerware series, the Eaton 5130 UPS system delivers more power quality performance in less space, at a value price. This new UPS power supply offers more power protection in the same as or smaller footprint than previous-generation equivalents, plus new power performance features. The 5130 resolves outages, sags, surges, under-voltage & over-voltage conditions & supplies clean, conditioned power to all connected equipment. This UPS is particularly well suited for protecting: IT & networking equipment, such as routers, switches, servers, wireless devices, storage systems, security systems & PC/workstation clusters Telecom equipment, such as PBXs, Vo IP components & EDGE/3G/ Wi MAX wireless networking equipment The 5130 is value-priced, but it also delivers features you would normally expect to find in much higher-priced systems, such as: load segment control, hot-swappable battery modules, long battery runtime options, multiple communication options, high output power factor & high power density”all in a sleek, modern package. Product Description - Eaton PW5130i 2500-XL2U
- UPS
- 2.25 k W
- 2500 VA Manufacturer Warranty - 2 years warranty

Dimensions (Wx Dx H) - 44.1 cm x 63.4 cm x 8.6 cm Weight - 33.8kg Networking - RS-232, USB (Universal Serial Bus) Device Type - UPS
- external Battery - Lead Acid 7.2 Ah Input Voltage
- AC 230 V Output Voltage
- AC 184-265 V Power Provided - 2.25 k W / 2500 VA Output Connector (s) - 9 x power IEC 320 EN 60320 C13, power IEC 320 EN 60320 C19 Battery Form Factor - Internal Rack Size - 2U Run Time (Up To) - 3 min at full load Please note: networking components such as switches, routers, UPS & wireless devices require that speeds & standards be consistent throughout the network to gain optimum performance. To avoid compatibility clashes or for advice, please contact us on solutions@ebuyer.com.







...

Powerware Model 5130 UPS 3000 VA The newest uninterruptible power system (UPS) addition to the Powerware series, the Eaton 5130 UPS system delivers more power quality performance in less space, at a value price. This new UPS power supply offers more power protection in the same as or smaller footprint than previous-generation equivalents, plus new power performance features. The 5130 resolves outages, sags, surges, under-voltage & over-voltage conditions & supplies clean, conditioned power to all connected equipment. This UPS is particularly well suited for protecting: IT & networking equipment, such as routers, switches, servers, wireless devices, storage systems, security systems & PC/workstation clusters Telecom equipment, such as PBXs, Vo IP components & EDGE/3G/ Wi MAX wireless networking equipment The 5130 is value-priced, but it also delivers features you would normally expect to find in much higher-priced systems, such as: load segment control, hot-swappable battery modules, long battery runtime options, multiple communication options, high output power factor & high power density”all in a sleek, modern package. Product Description - Eaton PW5130i 3000-XL2U
- UPS
- 2.7 k W
- 3000 VA Manufacturer Warranty - 2 years warranty

Dimensions (Wx Dx H) - 44.1 cm x 63.4 cm x 8.6 cm Weight - 33.8kg Networking - RS-232, USB (Universal Serial Bus) Device Type - UPS
- external Battery - Lead Acid 9 Ah Input Voltage
- AC 230 V Output Voltage - AC 184-265 V Power Provided - 2.7 k W / 3000 VA Output Connector (s) - 9 x power IEC 320 EN 60320 C13, power IEC 320 EN 60320 C19 Battery Form Factor - Internal Rack Size - 2U Run Time (Up To) - 3 min at full load Please note: networking components such as switches, routers, UPS & wireless devices require that speeds & standards be consistent throughout the network to gain optimum performance. To avoid compatibility clashes or for advice, please contact us on solutions@ebuyer.com.






...

Powerware Model 9130 UPS 1500 VA The 9130 uninterruptible power system (UPS), part of the Powerware series, delivers optimal power quality, provides superior power management, resolves utility power protection problems & supplies continuous power conditioning to all connected equipment. Incorporating more than 40 years of UPS power supply design experience, the newly available 9130 delivers essential power protection for IT & networking data center equipment, medical systems, manufacturing process control”or anywhere critical equipment & applications require clean, continuous power. Product Details Product Description
- Eaton PW9130i 1500T-XL
- UPS
- 1.35 k W
- 1500 VA Manufacturer Warranty - 2 years warranty

Dimensions (Wx Dx H)
- 16 cm x 43 cm x 23 cm Weight
- 19kg Networking
- RS-232, USB (Universal Serial Bus) Device Type
- UPS
- external Battery - Lead Acid 9 Ah Input Voltage
- AC 230 V Output Voltage
- ± 3% Power Provided
- 1.35 k W / 1500 VA Output Connector (s)
- 6 x power IEC 320 EN 60320 C13 Battery Form Factor
- Internal Run Time (Up To)
- 5 min at full load Please note: networking components such as switches, routers, UPS & wireless devices require that speeds & standards be consistent throughout the network to gain optimum performance. To avoid compatibility clashes or for advice, please contact us on solutions@ebuyer.com.
















...
