Biostar H81MHV3 Ver. 7.x Socket 1150 VGA HDMI 6-Channel HD Audio Micro ATX Motherboard Chipset Intel H81 CPU SUPPORT Intel Core i 7 LGA 1150 Processor Intel Core i 5 LGA 1150 Processor Intel Core i 3 LGA 1150 Processor Intel Pentium LGA 1150 Processor Maximum CPU TDP (Thermal Design Power): 95 Watt MEMORY Support Dual Channel DDR3 1600/1333/1066 MHz 2 x DDR3 DIMM Memory Slot Max. Supports up to 16GB Memory EXPANSION SLOT 1 x PCI-E x 16 2.0 Slot 1 x PCI-E x 1 2.0 Slot STORAGE 2 x SATA3 Connector 2 x SATA2 Connector USB (Universal Serial Bus) 2 x USB (Universal Serial Bus) 3.0 Port 2 x USB (Universal Serial Bus) 2.0 Port 2 x USB (Universal Serial Bus) 2.0 Header LAN Realtek RTL8111G
- 10/100/1000 Controller INTEGRATED VIDEO By CPU model Supports DX11.1 CODEC Realtek ALC662 6-Channel HD Audio REAR I/O 1 x PS/2 Mouse 1 x PS/2 Keyboard 2 x USB (Universal Serial Bus) 3.0 Port 2 x USB (Universal Serial Bus) 2.0 Port 1 x HDMI Connector 1 x VGA Port 1 x RJ-45 Port 3 x Audio Connector INTERNAL I/O 2 x USB (Universal Serial Bus) 2.0 Header 2 x SATA3 6 Gb/s Connector 2 x SATA2 3 Gb/s Connector 1 x Front Audio Header 1 x Front Panel Header 1 x CPU FAN Header 1 x System FAN Header 1 x Serial Header H/W Monitoring CPU / System Temperature Monitoring CPU / System Fan Monitoring Smart / Manual CPU Fan Control System Voltage Monitoring DIMENSION Micro ATX Form Factor Dimension: 19cm x 17cm (W x L ) OS SUPPORT Support Windows 7 / 8 / 8.1 Bundle Software BIO-Remote 2 Smart Speed LAN FEATURES Windows 8 Ready Supports Solid capacitor Supports Charger Booster Supports BIOS Online Update
...

Biostar H81MLC Ver.7.x Socket 1150 VGA 8-Channel Blu-ray Audio Micro ATX Motherboard Specifications: Chipset
- Intel H81 CPU SUPPORT:
...

Biostar Hi-Fi A70U3P Ver. 6.0/6.1 Socket FM2+ VGA HDMI 6-Channel HD Audio Micro ATX Motherboard Chipset AMD A70M CPU SUPPORT AMD A10 Processor AMD A8 Processor AMD A6 Processor AMD A4 Processor AMD E2 Processor AMD Athlon II X4 Processor Maximum CPU TDP (Thermal Design Power): 100 Watt MEMORY Support Dual Channel DDR3 2600 (OC)/2400 (OC)/2133/1866/1600/1333/1066/800 MHz 2 x DDR3 DIMM Memory Slot Max. Supports up to 32GB Memory EXPANSION SLOT 1 x PCI-E x 16 3.0 Slot (supported by FM2+ CPU) 1 x PCI-E x 1 2.0 Slot 1 x PCI Slot STORAGE 4 x SATA3 Connector Support SATA RAID: 0, 1, 10 USB (Universal Serial Bus) 2 x USB (Universal Serial Bus) 3.0 Port 1 x USB (Universal Serial Bus) 3.0 Header 2 x USB (Universal Serial Bus) 2.0 Port 2 x USB (Universal Serial Bus) 2.0 Header LAN Realtek RTL8111G
- 10/100/1000 Controller INTEGRATED VIDEO By CPU model AMD Dual Graphics Technology Supports DX11.1 Supports HDCP CODEC Realtek ALC662 6-Channel HD Audio REAR I/O 1 x PS/2 Mouse 1 x PS/2 Keyboard 2 x USB (Universal Serial Bus) 3.0 Port 2 x USB (Universal Serial Bus) 2.0 Port 1 x HDMI Connector 1 x VGA Port 1 x RJ-45 Port 3 x Audio Connector INTERNAL I/O 1 x USB (Universal Serial Bus) 3.0 Header 2 x USB (Universal Serial Bus) 2.0 Header 4 x SATA3 6 Gb/s Connector 1 x Front Audio Header 1 x Front Panel Header 1 x CPU Fan Header 1 x System Fan Header 1 x Serial Header H/W MONITORING CPU / System Temperature Monitoring CPU / System Fan Monitoring Smart / Manual CPU Fan Control System Voltage Monitoring DIMENSION Micro ATX Form Factor Dimension: 23.5cm x 17.8cm (W x L ) OS SUPPORT Support Windows XP / 7 / 8 / 8.1 BUNDLE SOFTWARE BIO-Remote 2 Smart Speed LAN FEATURES Supports PURO Hi-Fi Supports 100% Solid capacitor Supports BIOS-Flasher Supports Charger Booster Supports BIOS Online Update
...

Hi-Fi Power Audio power is an important factor in audio quality. Most AV equipment isolates the power supply for each analog & digital signal to gather high-quality sound reproduction. Equipped with BIOSTAR Hi-Fi Power technology, it will utilize audio components with independent power design for a significant reduction in electronic noise & superb sound quality. Hi-Fi Ground BIOSTAR Hi-Fi Ground presents noise-blocking multi-layer PCB design which isolates analog audio signals from digital sources. The unique PCB layout is ideal for exceptional clarity & high fidelity sound. Its focused on improving sound quality beyond the regular motherboard designs. Hi-Fi 192/24 BIOSTAR Hi-Fi series motherboards have a sampling rate of 192k Hz/24-bit which delivers a high quality audio through an analog connection to your home theater system, multi-channel speakers & high-end headphone. You can enjoy real Blu-ray grade high-definition sound that youve never experienced before. Hi-Fi AMP The built-in amplifier can drive major high-end headphones with over 100d B loads & offer wide b&-width, low noise, high slew rate & low distortion audio source from front panel I/O. Gaming enthusiasts can enjoy a fuller range of dynamic sound with crisper details & less distortion. Features
- Supported Socket FM2 processors AMD A-series/ E2-series processor Supported AMD Mutil Core (x 4, x 2) AMD 100W processor support AMD A85X Chipset 4 DIMM supported DDR3-2400 (OC)/ 2133/ 1866/ 1600/ 1333/ 1066/ 800 Supported SATA 6 Gb/s 2X speed than current SATA 3G Supported USB (Universal Serial Bus) 3.0 AMD Dual Graphics Technology 100% X.D.C solid capacitor BIOSTAR Puro Hi-Fi

Specification
- Chipset
- AMD A85X CPU SUPPORT
-
- AMD A10 Processor
- AMD A8 Processor
- AMD A6 Processor
- AMD A4 Processor
- AMD E2 Processor
- AMD Athlon™ II X4 Processor
- Maximum CPU TDP (Thermal Design Power): 100 Watt MEMORY
- Support Dual Channel DDR3 2400 (OC)/2133/1866/1600/1333/1066/800 MHz
- 4 x DDR3 DIMM Memory Slot
- Max. Supports up to 64GB Memory EXPANSION SLOT
-
- 2 x PCI-E x 16 2.0 Slot (x 16 + x 4)
- 2 x PCI-E x 1 2.0 Slot
- 2 x PCI Slots STORAGE -
- 8 x SATA3 Connector
- Support SATA RAID: 0, 1, 5, 10 USB (Universal Serial Bus)
-
- 2 x USB (Universal Serial Bus) 3.0 Port
- 1 x USB (Universal Serial Bus) 3.0 Header
- 4 x USB (Universal Serial Bus) 2.0 Port
- 2 x USB (Universal Serial Bus) 2.0 Header
- LAN Realtek RTL8111F
- 10/100/1000 Controller INTEGRATED VIDEO
-
- By CPU model
- AMD Dual Graphics Technology
- Supports DX11
- Supports HDCP CODEC
- Realtek ALC892 8-Channel Blu-ray Audio REAR I/O -
- 1 x PS/2 Keyboard
- 2 x USB (Universal Serial Bus) 3.0 Port
- 4 x USB (Universal Serial Bus) 2.0 Port
- 1 x HDMI Connector
- 1 x DVI Connector
- 1 x VGA Port
- 1 x RJ-45 Port
- 6 x Audio Connector INTERNAL I/O -
- 1 x USB (Universal Serial Bus) 3.0 Header
- 2 x USB (Universal Serial Bus) 2.0 Header
- 8 x SATA3 6 Gb/s Connector
- 1 x Front Audio Header
- 1 x Front Panel Header
- 1 x S/PDIF-OUT Header
- 1 x CPU FAN Header
- 2 x System FAN Header
- 1 x Serial Header
- 1 x CIR Header DIMENSION
- ATX Form Factor Dimension: 30.5cm x 23.5cm (W x L ) OS SUPPORT
- Support Windows XP / Vista / 7 / 8 FEATURES -
- Windows 8 Compatible
- Supports PURO Hi-Fi
- Supports Smart Speed LAN
- Supports BIO-Remote 2
- Supports BIO-Remote
- Supports 100% Solid capacitor
- Supports Rapid Switch
- Supports Rapid Debug 3
- Supports BIOS-Flasher
- Supports Charger Booster
- Supports BIOS Online Update

































































...

Biostar Hi-Fi A88S3+ Socket FM2+ VGA DVI HDMI 8-Channel Audio Micro ATX Motherboard Specifications: Chipset
- AMD A88X CPU SUPPORT:
...

Biostar Hi-Fi A88ZN Ver. 5.x Socket FM2+ DVI HDMI 8-Channel Blu-ray Audio Mini ITX Motherboard Chipset AMD A88X CPU SUPPORT AMD A10 Processor AMD A8 Processor AMD A6 Processor AMD A4 Processor AMD E2 Processor AMD Athlon II X4 Processor Maximum CPU TDP (Thermal Design Power): 100 Watt MEMORY Support Dual Channel DDR3 2600 (OC)/2400 (OC)/2133/1866/1600/1333/1066/800 MHz 2 x DDR3 DIMM Memory Slot Max. Supports up to 32GB Memory EXPANSION SLOT 1 x PCI-E x 16 3.0 Slot (supported by FM2+ CPU) STORAGE 4 x SATA3 Connector 1 x m SATA Connector Support SATA RAID: 0, 1, 5, 10 USB (Universal Serial Bus) 2 x USB (Universal Serial Bus) 3.0 Port 1 x USB (Universal Serial Bus) 3.0 Header 4 x USB (Universal Serial Bus) 2.0 Port 2 x USB (Universal Serial Bus) 2.0 Header LAN Realtek RTL8111G
- 10/100/1000 Controller INTEGRATED VIDEO By CPU model AMD Dual Graphics Technology Supports DX11.1 Supports HDCP CODEC Realtek ALC892 8-Channel Blu-ray Audio Support Biostar Hi-Fi 3D REAR I/O 1 x PS/2 Keyboard 2 x USB (Universal Serial Bus) 3.0 Port 4 x USB (Universal Serial Bus) 2.0 Port 2 x HDMI Connector 1 x DVI (Dual Link) Connector 1 x RJ-45 Port 5 x Audio Connector 1 x S/PDIF Out Port INTERNAL I/O 1 x USB (Universal Serial Bus) 3.0 Header 2 x USB (Universal Serial Bus) 2.0 Header 4 x SATA3 6 Gb/s Connector 1 x m SATA/ Mini PCI-E Combo Connector 1 x Front Audio Header 1 x Front Panel Header 1 x CPU Fan Header 1 x System Fan Header H/W MONITORING CPU / System Temperature Monitoring CPU / System Fan Monitoring Smart / Manual CPU Fan Control System Voltage Monitoring DIMENSION Mini ITX Form Factor Dimension: 17cm x 17cm (W x L ) OS SUPPORT Support Windows XP / 7 / 8 / 8.1 BUNDLE SOFTWARE Bull Guard BIO-Remote 2 Biostar MAGIX Multimedia Software Suite Smart Speed LAN FEATURES Supports PURO Hi-Fi 3D Supports 100% Solid capacitor Supports BIOS-Flasher Supports Charger Booster Supports BIOS Online Update
...

Biostar Hi-Fi B150S1 Ver. 6.x Socket 1151 VGA DVI-D 8-Channel HD Audio Micro ATX Motherboard Intel B150 chipset The Intel B150 chipset is a single-chipset design to support socket 1151 Intel 6th generation Intel Core processor-based platform. Provides excellent performance & increased bandwidth & stability. Intel B150 chipset can also enable i GPU function, letting users enjoy the latest Intel integrated graphic performance. The PC platform features enhanced adaptive performance that adds speed when you need it. When combined with advanced system responsiveness, the platform delivers the ultimate PC experience. Intel LGA 1151 6th Generation Intel Core Processor support The 6th generation Intel Core processors are based on 5th generation Intel Core processor architecture, with the latest 14nm process to maximize the processor platform. Based on the new LGA 1151 socket, 5th generation Intel Core processors with graphics with DX12 & OCL2.0 cores, the overall performance will meet your dem&. Chipset Intel B150 CPU SUPPORT Intel Core i 7 LGA 1151 Processor Intel Core i 5 LGA 1151 Processor Intel Core i 3 LGA 1151 Processor Intel Pentium LGA 1151 Processor Maximum CPU TDP (Thermal Design Power): 95 Watt MEMORY: Support Dual Channel DDR3L 1866 (OC)/1600/ 1333 MHz 2 x DDR3 DIMM Memory Slot Max. Supports up to 16GB Memory EXPANSION SLOT: 1 x PCI-E x 16 3.0 Slot 2 x PCI-E x 1 3.0 Slot STORAGE 4 x SATA3 Connector USB: 4 x USB (Universal Serial Bus) 3.0 Port 1 x USB (Universal Serial Bus) 3.0 Header 2 x USB (Universal Serial Bus) 2.0 Port 2 x USB (Universal Serial Bus) 2.0 Header LAN
- Realtek RTL8111H
- 10/100/1000 Controller INTEGRATED VIDEO By CPU model Supports DX12 Supports HDCP CODEC Realtek ALC887 8-Channel HD Audio Support Biostar Hi-Fi REAR I/O 1 x PS/2 Mouse 1 x PS/2 Keyboard 4 x USB (Universal Serial Bus) 3.0 Port 2 x USB (Universal Serial Bus) 2.0 Port 1 x DVI-D Connector, resolution up to 1920 x 1200 @60 Hz 1 x VGA Port, resolution up to 1920 x 1200 @60 Hz 1 x RJ-45 Port 3 x Audio Connector INTERNAL I/O 1 x USB (Universal Serial Bus) 3.0 Header 2 x USB (Universal Serial Bus) 2.0 Header 4 x SATA3 6 Gb/s Connector 1 x Front Audio Header 1 x Front Panel Header 1 x CPU Fan Header 1 x System Fan Header 1 x Serial Header H/W MONITORING CPU / System Temperature Monitoring CPU / System Fan Monitoring Smart / Manual CPU Fan Control System Voltage Monitoring DIMENSION Micro ATX Form Factor Dimension: 22.6cm x 18.5cm (W x L ) OS SUPPORT Support Windows 7 / 8.1 (x 64) / 10 (x 64) BUNDLE SOFTWARE: Bull Guard Smart Ear headphone Utility BIO-Remote 2 Smart Speed LAN FEATURES Supports PURO Hi-Fi (Rear) Supports 100% Solid capacitor Supports Charger Booster Supports BIOS Online Update

...

Biostar Hi-Fi B85N 3D Ver. 5.x Socket 1150 VGA DVI HDMI 8-Channel Blu-ray Audio Mini ITX Motherboard Specifications: Chipset
-
...

Chipset Intel B85 CPU SUPPORT Intel Core i 7 LGA 1150 Processor Intel Core i 5 LGA 1150 Processor Intel Core i 3 LGA 1150 Processor Intel Pentium LGA 1150 Processor Maximum CPU TDP (Thermal Design Power) 95 Watt MEMORY Support Dual Channel DDR3 1600/1333/1066 MHz 2 x DDR3 DIMM Memory Slot Max. Supports up to 16GB Memory EXPANSION SLOTS 1 x PCI-E x 16 3.0 Slot 1 x PCI-E x 16 2.0 Slot (x 4) 1 x PCI-E x 1 2.0 Slot STORAGE 4 x SATA3 Connector 2 x SATA2 Connector USB (Universal Serial Bus) 2 x USB (Universal Serial Bus) 3.0 Port 1 x USB (Universal Serial Bus) 3.0 Header 2 x USB (Universal Serial Bus) 2.0 Port 2 x USB (Universal Serial Bus) 2.0 Header LAN Realtek RTL8111F
- 10/100/1000 Controller INTEGRATED VIDEO By CPU model Supports DX11.1 Supports HDCP CODEC Realtek ALC662 6-Channel HD Audio REAR I/O 1 x PS/2 Mouse 1 x PS/2 Keyboard 2 x USB (Universal Serial Bus) 3.0 Port 2 x USB (Universal Serial Bus) 2.0 Port 1 x DVI Connector 1 x VGA Port 1 x RJ-45 Port 3 x Audio Connector INTERNAL I/O 1 x Printer Header 1 x USB (Universal Serial Bus) 3.0 Header 2 x USB (Universal Serial Bus) 2.0 Header 4 x SATA3 6 Gb/s Connector 2 x SATA2 3 Gb/s Connector 1 x Front Audio Header 1 x Front Panel Header 1 x CPU FAN Header 1 x System FAN Header 1 x Serial Header 1 x CIR Header

Dimensions Micro ATX Form Factor Dimension: 24.4cm x 18cm (W x L ) OS SUPPORT Support Windows 7 / 8 FEATURES Windows 8 Compatible Supports PURO Hi-Fi Supports Smart Speed LAN Supports BIO-Remote 2 Supports BIO-Remote Supports Solid capacitor Supports Charger Booster Supports BIOS Online Update


...

This micro ATX board from Biostar is loaded with features. It also has the potential for plenty of power. The Intel B85 chipset supports their fourth generation of i 5 & i 7 processors & with a maximum of 32GB of RAM capacity from up to 4-DIMM DDR3-1600/1333 slots this board can form the basis of a very powerful micro form system. PURO Hi-Fi Audio Technology The highlight feature of the Biostar Hi-Fi B85S3+ motherboard is the built-in headphone amplifier & support for PURO Hi-Fi. Amazing sound is standard on all Biostar boards & the Hi-Fi B85S3+ is no different. Movies & games benefit from the booming audio produced by this board. HDMI The HDMI slot provides full high definition video support. & the HDMI 3D Visual feature enables stunning displays of 3D content from connected devices. Add in 4K2K super high resolution support for incredibly bright & clear images. Security The Biostar Hi-Fi B85S3+ motherboard comes bundled with Intel Small Business Advantage 2.0. This new platform boosts security & comes with five applications including; Software Monitor, Data Backup & Restore, USB (Universal Serial Bus) Blocker, PC Health Centre & Energy Saver. Applications that massive increase security & efficiency of any system. Features Of The Biostar Hi-Fi B85S3+ Motherboard Intel B85 Chipset Windows 8 compatible Support for PURO Hi-Fi Supports BIO-Remote Support for Charge Booster Built-in headphone amplifier Technical

Specification Biostar Hi-Fi B85S3+ Socket 1150 VGA DVI HDMI 6 Channel Audio Micro ATX Motherboard Chipset Intel B85 CPU Support Intel Core™ i 7 LGA 1150 Processor Intel Core™ i 5 LGA 1150 Processor Intel Core™ i 3 LGA 1150 Processor Intel Pentium LGA 1150 Processor Maximum CPU TDP (Thermal Design Power): 95 Watt Memory Support Dual Channel DDR3 1600/1333/1066 MHz 4 x DDR3 DIMM Memory Slot Max. Supports up to 32GB Memory Expansion Slot 1 x PCI-E x 16 3.0 Slot 2 x PCI-E x 1 2.0 Slot 1 x PCI Slot Storage 4 x SATA3 Connector 2 x SATA2 Connector USB (Universal Serial Bus) 2 x USB (Universal Serial Bus) 3.0 Port 1 x USB (Universal Serial Bus) 3.0 Header 4 x USB (Universal Serial Bus) 2.0 Port 2 x USB (Universal Serial Bus) 2.0 Header LAN Realtek RTL8111F
- 10/100/1000 Controller Integrated Video By CPU model Supports DX11.1 Supports HDCP CODEC Realtek ALC892 8-Channel Blu-ray Audio Rear I/O 1 x PS/2 Keyboard/ Mouse 2 x USB (Universal Serial Bus) 3.0 Port 4 x USB (Universal Serial Bus) 2.0 Port 1 x HDMI Connector 1 x DVI Connector 1 x VGA Port 1 x RJ-45 Port 6 x Audio Connector Internal I/O 1 x Printer Header 1 x USB (Universal Serial Bus) 3.0 Header 2 x USB (Universal Serial Bus) 2.0 Header 4 x SATA3 6 Gb/s Connector 2 x SATA2 3 Gb/s Connector 1 x Front Audio Header 1 x Front Panel Header 1 x S/PDIF-OUT Header 1 x CPU FAN Header 2 x System FAN Header 1 x Serial Header 1 x CIR Header Dimension Micro ATX Form Factor Dimension: 24.4cm x 23cm (W x L ) OS Support Support Windows 7 / 8 Accessories 2 x SATA Cable 1 x I/O Shield 1 x DVD Driver 1 x Quick Guide


...
