One component of a robust solution that, when paired with a base unit (part 89008 or 89009, sold separately), extends your VGA & 3.5mm audio signals up to 300 meters over a Cat 5E UTP cable, & distributes the signal to up to 4 monitors, projectors, or displays. Ideal for applications when your VGA monitor needs to be placed beyond the average 30 meter VGA cable limitation, and/or you want to split the signal to multiple displays. Driving a VGA signal over Cat 5E helps you take advantage of your UTP cable infrastructure already there for a cost-effective & reliable installation. The Tru Link VGA over Cat 5 solution is ideal for applications when you need to place your computer in remote location. This is common in digital signage applications for retail stores, houses of worship, classrooms, & boardrooms where you need video presentation in one room, but want the computer to be out of sight & in a safe & secure environment. With the Tru Link VGA + 3.5mm audio over Cat 5 Extender, you can place your display across the room, on another floor, or in another building while your computer remains in a convenient location. ...

One component of a robust solution that, when paired with a base unit, extends your VGA signal up to 300 meters over a Cat 5E UTP cable, & distributes the signal to up to 4 monitors, projectors, or displays. Ideal for applications when your VGA monitor needs to be placed beyond the average 30 meter VGA cable limitation, and/or you want to split the signal to multiple displays. Driving a VGA signal over Cat 5E helps you take advantage of your UTP cable infrastructure already there for a cost-effective & reliable installation. The Tru Link VGA over Cat 5 solution is ideal for applications when you need to place your computer in remote location. This is common in digital signage applications for retail stores, houses of worship, classrooms, & boardrooms where you need video presentation in one room, but want the computer to be out of sight & in a safe & secure environment. With the Tru Link VGA over Cat 5 Extender, you can place your display across the room, on another floor, or in another building while your computer remains in a convenient location. Product Specifications •
Colour: Black • UPC: 757120890072 • Warranty: 1 Year • Weight: 0.446kg •

Volume: 1.536 CCM •

Size: 9.53cm x 3.81cm x 3.18cm • Power Supply: DC 12V/600m A • Supports the following resolutions using Cat 5E cabling: • • Resolution at 50m: 2048 x 1536 pixels • • SXGA resolution at 100m: 1280 x 1024 pixels • • XGA resolution at 180m: 1024 x 768 pixels • • SVGA resolution at 200m: 800 x 600 pixels • • VGA resolution at 300m: 640 x 480 pixels • Supports the following resolutions using Cat 6 cabling: • • Resolution at 30m: 1920 x 1440 pixels • • SXGA resolution at 50m: 1280 x 1024 pixels • • SVGA resolution at 100m: 800 x 600 pixels System Requirements: • Remote Unit
- Part 89007 (included) • Base Unit (sold separately)
- Part 89005 (1-Port) or Part 89006 (4-Port) • One Cat 5E UTP patch cable • An HD15 connection on the computer • An HD15 connection on each monitor, projector, or other display device • An HD15 male to male cable for the computer & for each connected display device






...

The Tru Link TV to PC converter accepts s-video or composite video signals & converts them to VGA HD15 for high-resolution image display on a PC monitor. By using this converter, you can display videos, cable or satellite TV or your video game console on a PC monitor. The converter uses the de-interlace chipset on the market which enables it to provide a truly high-quality picture. No software is required & connecting the device is simple. Within minutes you can be watching your DVD collection, satellite receiver or be playing video games on any PC. The converter has a small footprint which makes it easy to fit in tight spaces & great for traveling. A built-in switch offers convenient switching between devices connected to the converter & your PC. ...

Compliant to USB (Universal Serial Bus) 3.0 Super Speed specifications; connect your Super Speed USB (Universal Serial Bus) peripheral for TEN TIMES the transmission rate of USB (Universal Serial Bus) 2.0! ...

This fully rated Mini-USB cable provides transfer rates up to 480 Mbps & easily attaches to any Mini-USB device. Mini-USB cable is designed to connect from the USB (Universal Serial Bus) port on a hub, PC or Mac to a USB (Universal Serial Bus) device, including digital cameras, mobile phones & PDAs. Use this cable as a replacement for your current cable or a second cable for traveling. ...

Compliant to USB (Universal Serial Bus) 3.0 Super Speed specifications; connect your Super Speed USB (Universal Serial Bus) peripheral for TEN TIMES the transmission rate of USB (Universal Serial Bus) 2.0! ...

Overview This hub connects up to 2 USB (Universal Serial Bus) 2.0 devices with just one cable. Two USB (Universal Serial Bus) A female ports will receive your mice, printers, hubs, or other USB (Universal Serial Bus) devices without them being cluttered together. Unlike traditional USB (Universal Serial Bus) hubs, this cable can slide behind your desk & out of the way, or connect on the front of a desktop so you would not need to reach in the back of the PC. With its small form factor it eliminates the clutter associated with traditional hubs, & lets you spread out your devices. Bus-powered, so it requires no external power adapters. Compliant with USB (Universal Serial Bus) 2.0 specifications; compatible with both PCs & Macs. Input: (1) USB (Universal Serial Bus) Type A Male Output: (2) USB (Universal Serial Bus) Type A Female ...

This USB (Universal Serial Bus) Superbooster Extender Kit is a brilliant solution for long length USB (Universal Serial Bus) limitations. Put your USB (Universal Serial Bus) devices where you want them with Cables to Go's Tru Link USB (Universal Serial Bus) Superbooster. This pocket-sized device extends the distance of a USB (Universal Serial Bus) device to a host computer up to 45 meters so you can place your USB (Universal Serial Bus) camera, printer, web cam, keyboard/mouse extension, or any other USB (Universal Serial Bus) device exactly where you want it! This booster is powerful yet simple, with no drivers to install or special software required, it's compatible with any computer that supports USB (Universal Serial Bus). This Plug-&-Play device consists of a base unit & a remote unit connected together by a standard CAT5, CAT5e, CAT6 or CAT6a network cable. Simply connect your cables to your device; then connect to your computer & USB (Universal Serial Bus) peripheral & you're up & running. Bus-powered, it requires no external power source. Instead, the Superbooster has internal DC power conditioning circuits to maintain the proper voltage to the remote device so no external power is required for either the base or remote units. It is compliant with USB (Universal Serial Bus)

Specification 1.1.

...

The Select High Speed HDMI Cable with Ethernet is the perfect solution for connecting multimedia source devices in home theatre, desktop or commercial audio video applications requiring high speed HDMI features. The CL2 rated cable jacket is designed to meet the requirements for in-wall installations. The Ethernet capabilities of the cable allow a user to connect multiple Ethernet enabled HDMI devices through a single Ethernet connection. Experience the latest HDMI features including: • 4K@50/60, (2160p), which is 4 times the clarity of 1080p/60 video resolution • 3D video, Deep Colour & x.v. Colour™ • Dolby True HD, DTS-HD Master Audio & up to 32 audio channels for a multi-dimensional immersive audio experience • Up to 1536k Hz audio sample frequency for the highest audio fidelity • Simultaneous delivery of dual video streams to multiple users on the same screen • Simultaneous delivery of multi-stream audio to multiple users (up to 4) • Support for the wide angle theatrical 21:9 video aspect ratio • Dynamic synchronization of video & audio streams • CEC extensions for control of consumer electronics devices through a single control point This fully-functional, high bandwidth cable is tested to perform at industry standards & is backed by a lifetime warranty. ...

This High Speed HDMI to HDMI Micro Cable with Ethernet is perfect for connecting a smartphone, tablet or other mobile device to an HD display for home theatre or desktop applications. The Ethernet capabilities of the cable allow a user to connect multiple Ethernet enabled HDMI devices through a single Ethernet connection. Experience the latest HDMI features including: • 4K@50/60, (2160p), which is 4 times the clarity of 1080p/60 video resolution • 3D video, Deep Colour & x.v. Colour™ • Dolby True HD, DTS-HD Master Audio & up to 32 audio channels for a multi-dimensional immersive audio experience • Up to 1536k Hz audio sample frequency for the highest audio fidelity • Simultaneous delivery of dual video streams to multiple users on the same screen • Simultaneous delivery of multi-stream audio to multiple users (up to 4) • Support for the wide angle theatrical 21:9 video aspect ratio • Dynamic synchronization of video & audio streams • CEC extensions for control of consumer electronics devices through a single control point ...
