This micro ATX board from Biostar is loaded with features. It also has the potential for plenty of power. The Intel B85 chipset supports their fourth generation of i 5 & i 7 processors & with a maximum of 32GB of RAM capacity from up to 4-DIMM DDR3-1600/1333 slots this board can form the basis of a very powerful micro form system. PURO Hi-Fi Audio Technology The highlight feature of the Biostar Hi-Fi B85S3+ motherboard is the built-in headphone amplifier & support for PURO Hi-Fi. Amazing sound is standard on all Biostar boards & the Hi-Fi B85S3+ is no different. Movies & games benefit from the booming audio produced by this board. HDMI The HDMI slot provides full high definition video support. & the HDMI 3D Visual feature enables stunning displays of 3D content from connected devices. Add in 4K2K super high resolution support for incredibly bright & clear images. Security The Biostar Hi-Fi B85S3+ motherboard comes bundled with Intel Small Business Advantage 2.0. This new platform boosts security & comes with five applications including; Software Monitor, Data Backup & Restore, USB (Universal Serial Bus) Blocker, PC Health Centre & Energy Saver. Applications that massive increase security & efficiency of any system. Features Of The Biostar Hi-Fi B85S3+ Motherboard Intel B85 Chipset Windows 8 compatible Support for PURO Hi-Fi Supports BIO-Remote Support for Charge Booster Built-in headphone amplifier Technical

Specification Biostar Hi-Fi B85S3+ Socket 1150 VGA DVI HDMI 6 Channel Audio Micro ATX Motherboard Chipset Intel B85 CPU Support Intel Core™ i 7 LGA 1150 Processor Intel Core™ i 5 LGA 1150 Processor Intel Core™ i 3 LGA 1150 Processor Intel Pentium LGA 1150 Processor Maximum CPU TDP (Thermal Design Power): 95 Watt Memory Support Dual Channel DDR3 1600/1333/1066 MHz 4 x DDR3 DIMM Memory Slot Max. Supports up to 32GB Memory Expansion Slot 1 x PCI-E x 16 3.0 Slot 2 x PCI-E x 1 2.0 Slot 1 x PCI Slot Storage 4 x SATA3 Connector 2 x SATA2 Connector USB (Universal Serial Bus) 2 x USB (Universal Serial Bus) 3.0 Port 1 x USB (Universal Serial Bus) 3.0 Header 4 x USB (Universal Serial Bus) 2.0 Port 2 x USB (Universal Serial Bus) 2.0 Header LAN Realtek RTL8111F
- 10/100/1000 Controller Integrated Video By CPU model Supports DX11.1 Supports HDCP CODEC Realtek ALC892 8-Channel Blu-ray Audio Rear I/O 1 x PS/2 Keyboard/ Mouse 2 x USB (Universal Serial Bus) 3.0 Port 4 x USB (Universal Serial Bus) 2.0 Port 1 x HDMI Connector 1 x DVI Connector 1 x VGA Port 1 x RJ-45 Port 6 x Audio Connector Internal I/O 1 x Printer Header 1 x USB (Universal Serial Bus) 3.0 Header 2 x USB (Universal Serial Bus) 2.0 Header 4 x SATA3 6 Gb/s Connector 2 x SATA2 3 Gb/s Connector 1 x Front Audio Header 1 x Front Panel Header 1 x S/PDIF-OUT Header 1 x CPU FAN Header 2 x System FAN Header 1 x Serial Header 1 x CIR Header Dimension Micro ATX Form Factor Dimension: 24.4cm x 23cm (W x L ) OS Support Support Windows 7 / 8 Accessories 2 x SATA Cable 1 x I/O Shield 1 x DVD Driver 1 x Quick Guide


...

Biostar Hi-Fi H170S3H Ver. 6.x Socket 1151 DVI-D HDMI 8-Channel HD Audio Micro ATX Motherboard Chipset
- Intel H170 CPU SUPPORT
...

Biostar Hi-Fi H170Z3 Ver. 5.x Socket LGA1151 VGA DVI-D HDMI Display Port 8-Channel Audio Micro ATX Motherboard Intel H170 chipset The Intel H170 chipset is a single-chipset design to support socket 1151 Intel 6th generation Intel Core processor-based platform. Provides excellent performance & increased bandwidth & stability. Intel H170 chipset can also enable i GPU function, letting users enjoy the latest Intel integrated graphic performance. The PC platform features enhanced adaptive performance that adds speed when you need it. When combined with advanced system responsiveness, the platform delivers the ultimate PC experience. Intel LGA 1151 6th Generation Intel Core Processor support The 6th generation Intel Core processors are based on 5th generation Intel Core processor architecture, with the latest 14nm process to maximize the processor platform. Based on the new LGA 1151 socket, 5th generation Intel Core processors with graphics with DX12 & OCL2.0 cores, the overall performance will meet your dem&. Hi-Fi A combination of exclusive hardware & software design including "ground-isolation circuit design", an independent audio power, & "a built=on-board amplifier", with all these hardware features gives you the best audio quality & performance. As for software, we offer you a free bundle utility " Multi-Channel Calibration" which normally you'll find in high level sound systems; this feature means that you can auto detect your location; with a user friendly interface, you can easily adjust the volume of every speakers to make a well balanced surround sound. & of course, the built-on-board amplifier always gives you a super powerful sound comparing to other motherboards. Specifications: Chipset: Intel H170 CPU SUPPORT: Intel Core i 7 LGA 1151 Processor Intel Core i 5 LGA 1151 Processor Intel Core i 3 LGA 1151 Processor Intel Pentium LGA 1151 Processor Maximum CPU TDP (Thermal Design Power): 95 Watt MEMORY: Support Dual Channel DDR3L 1866 (OC)/1600/ 1333 MHz Support Dual Channel DDR4 2133/ 1866 MHz 2 x DDR3 DIMM Memory Slot 2 x DDR4 DIMM Memory Slot Max. Supports up to 16 (DDR3L)/ 32 (DDR4)GB Memory EXPANSION SLOT: 1 x PCI-E x 16 3.0 Slot 1 x PCI-E x 1 3.0 Slot 2 x PCI Slot STORAGE: 4 x SATA3 Connector 1 x SATA Express 16 Gb/s Connector Support SATA RAID: 0, 1, 5, 10 Support PCI-E Storage RAID: 0, 1 1 x M.2 Key M 32 Gb/s Connector USB: 4 x USB (Universal Serial Bus) 3.0 Port 1 x USB (Universal Serial Bus) 3.0 Header 2 x USB (Universal Serial Bus) 2.0 Port 2 x USB (Universal Serial Bus) 2.0 Header LAN: Intel I219V
- Gigabit Ethernet PHY Support Super LAN Surge Protection INTEGRATED VIDEO: By CPU model Supports DX12 Supports HDCP CODEC: Realtek ALC892 8-Channel Blu-ray Audio Support Biostar Hi-Fi REAR I/O: 1 x PS/2 Keyboard 4 x USB (Universal Serial Bus) 3.0 Port 2 x USB (Universal Serial Bus) 2.0 Port 1 x HDMI Connector, resolution up to 4096 x 2160 @24 Hz, compliant with HDMI 1.4a 1 x Display Port Connector, resolution up to 4096 x 2304 @60 Hz 1 x DVI-D Connector, resolution up to 1920 x 1200 @60 Hz 1 x VGA Port, resolution up to 1920 x 1200 @60 Hz 1 x RJ-45 Port 6 x Audio Connector INTERNAL I/O: 1 x Printer Header 1 x USB (Universal Serial Bus) 3.0 Header 2 x USB (Universal Serial Bus) 2.0 Header 4 x SATA3 6 Gb/s Connector 1 x SATA Express 16 Gb/s Connector 1 x M.2 Key M 32 Gb/s Connector 1 x Front Audio Header 1 x Front Panel Header 1 x S/PDIF-Out Header 1 x CPU Fan Header 2 x System Fan Header 1 x Serial Header 1 x CIR Header H/W MONITORING: CPU / System Temperature Monitoring CPU / System Fan Monitoring Smart / Manual CPU / System Fan Control System Voltage Monitoring DIMENSION: Micro ATX Form Factor Dimension: 24.4cm x 24.4cm (W x L ) OS SUPPORT: Support Windows 7 / 8.1 (x 64) / 10 (x 64) BUNDLE SOFTWARE: Bull Guard Smart Ear headphone Utility BIO-Remote 2 BIO-Remote Smart Speed LAN

Features: Supports Double Hi-Fi Supports 100% Solid capacitor Supports Charger Booster II Supports BIOS Online Update


...

Chipset Intel H87 CPU SUPPORT Intel Core i 7 LGA 1150 Processor Intel Core i 5 LGA 1150 Processor Intel Core i 3 LGA 1150 Processor Intel Pentium LGA 1150 Processor Maximum CPU TDP (Thermal Design Power): 95 Watt MEMORY Support Dual Channel DDR3 1600/1333/1066 MHz 4 x DDR3 DIMM Memory Slot Max. Supports up to 32GB Memory EXPANSION SLOT 1 x PCI-E x 16 3.0 Slot 2 x PCI-E x 1 2.0 Slot 1 x PCI Slots STORAGE 6 x SATA3 Connector Support SATA RAID: 0, 1, 5, 10 Support Intel Smart Response Technology USB (Universal Serial Bus) 4 x USB (Universal Serial Bus) 3.0 Port 1 x USB (Universal Serial Bus) 3.0 Header 2 x USB (Universal Serial Bus) 2.0 Port 2 x USB (Universal Serial Bus) 2.0 Header LAN Realtek RTL8111F
- 10/100/1000 Controller INTEGRATED VIDEO By CPU model Supports DX11.1 Supports HDCP CODEC Realtek ALC892 8-Channel Blu-ray Audio REAR I/O 1 x PS/2 Keyboard/ Mouse 4 x USB (Universal Serial Bus) 3.0 Port 2 x USB (Universal Serial Bus) 2.0 Port 1 x HDMI Connector 1 x DVI Connector 1 x VGA Port 1 x RJ-45 Port 6 x Audio Connector INTERNAL I/O 1 x Printer Header 1 x USB (Universal Serial Bus) 3.0 Header 2 x USB (Universal Serial Bus) 2.0 Header 6 x SATA3 6 Gb/s Connector 1 x Front Audio Header 1 x Front Panel Header 1 x S/PDIF-OUT Header 1 x CPU FAN Header 2 x System FAN Header 1 x Serial Header 1 x CIR Header DIMENSION Micro ATX Form Factor Dimension: 24.4cm x 23cm (W x L ) OS SUPPORT Support Windows 7 / 8
...

Biostar Hi-Fi Z87W socket 1150 VGA DVI HDMI 8-Channel Audio ATX Motherboard ntel Z87 chipset The Intel Z87 Express Chipset is a single-chipset design to support socket 1150 Intel 4th generation Intel Core processor-based platform. Provides excellent performance & increased bandwidth & stability. Intel Z87 Express Chipset can also enable i GPU function, letting users enjoy the latest Intel integrated graphic performance. The PC platform features enhanced adaptive performance that adds speed when you need it. When combined with advanced system responsiveness, the platform delivers the ultimate PC experience. Intel LGA 1150 4th Generation Intel Core Processor support The 4th generation Intel Core processors are based on 4th generation Intel Core processor architecture, with the latest 22nm process to maxinum the processor platform. Based on the new LGA 1150 socket, 4th generation Intel Core processors with graphics with DX11.1 & OCL1.2 cores, the overall performance will meet your dem&. Chipset Intel Z87 CPU SUPPORT Intel Core i 7 LGA 1150 Processor Intel Core i 5 LGA 1150 Processor Intel Core i 3 LGA 1150 Processor Intel Pentium LGA 1150 Processor Maximum CPU TDP (Thermal Design Power): 95 Watt MEMORY: Support Dual Channel DDR3 2800 (OC)/ 2600 (OC)/ 2400 (OC)/ 2200 (OC)/ 2133 (OC)/ 1866 (OC)/ 1800 (OC)/ 1600/ 1333/ 1066 MHz 4 x DDR3 DIMM Memory Slot Max. Supports up to 32GB Memory EXPANSION SLOT: 1 x PCI-E x 16 3.0 Slot 1 x PCI-E x 16 2.0 Slot (x 4) 2 x PCI-E x 1 2.0 Slot 2 x PCI Slot STORAGE: 6 x SATA3 Connector Support SATA RAID: 0, 1, 5, 10 Support Intel Smart Response Technology USB: 2 x USB (Universal Serial Bus) 3.0 Port 1 x USB (Universal Serial Bus) 3.0 Header 4 x USB (Universal Serial Bus) 2.0 Port 2 x USB (Universal Serial Bus) 2.0 Header LAN
- Realtek RTL8111F
- 10/100/1000 Controller INTEGRATED VIDEO: By CPU model Supports DX11.1 Supports HDCP CODEC
- Realtek ALC892 8-Channel Blu-ray Audio REAR I/O: 1 x PS/2 Keyboard 2 x USB (Universal Serial Bus) 3.0 Port 4 x USB (Universal Serial Bus) 2.0 Port 1 x HDMI Connector 1 x DVI Connector 1 x VGA Port 1 x RJ-45 Port 6 x Audio Connector INTERNAL I/O: 1 x USB (Universal Serial Bus) 3.0 Header 2 x USB (Universal Serial Bus) 2.0 Header 6 x SATA3 6 Gb/s Connector 1 x Front Audio Header 1 x Front Panel Header 1 x S/PDIF-OUT Header 1 x CPU FAN Header 4 x System FAN Header 1 x Serial Header 1 x CIR Header DIMENSION
- ATX Form Factor Dimension: 30.5cm x 22cm (W x L ) OS SUPPORT
- Support Windows 7 / 8 ACCESSORIES: 4 x SATA Cable 1 x I/O Shield 1 x DVD Driver 1 x User Manual

Features: Windows 8 Compatible Supports PURO Hi-Fi Supports Smart Speed LAN Supports BIO-Remote 2 Supports BIO-Remote Supports 100% Solid capacitor Supports Rapid Switch 2 Supports Rapid Debug 3 Supports Charger Booster Supports BIOS Online Update






...

Biostar Intel H170 Ver. 6.x Socket 1151 DVI-D HDMI 8 Channel HD Audio Micro ATX Motherboard Specifications: Chipset Intel H170 CPU SUPPORT Intel Core„¢ i 7 LGA 1151 Processor Intel Core„¢ i 5 LGA 1151 Processor Intel Core„¢ i 3 LGA 1151 Processor Intel Pentium LGA 1151 Processor Maximum CPU TDP (Thermal Design Power): 95 Watt MEMORY Support Dual Channel DDR4 2133/ 1866 MHz 4 x DDR4 DIMM Memory Slot Max. Supports up to 64GB Memory EXPANSION SLOT 2 x PCI-E x 16 3.0 Slot (x 16 + x 4) 2 x PCI-E x 1 3.0 Slot STORAGE 2 x SATA3 Connector 1 x SATA Express Connector Support SATA RAID: 0, 1, 5, 10 Support PCI-E Storage RAID: 0, 1 1 x M.2 Key M 32 Gb/s Connector USB (Universal Serial Bus) 4 x USB (Universal Serial Bus) 3.0 Port 2 x USB (Universal Serial Bus) 3.0 Header 2 x USB (Universal Serial Bus) 2.0 Port 2 x USB (Universal Serial Bus) 2.0 Header LAN Intel I219V
- Gigabit Ethernet PHY INTEGRATED VIDEO By CPU model Supports DX12 Supports HDCP CODEC Realtek ALC887 8-Channel HD Audio Support Biostar Hi-Fi REAR I/O 1 x PS/2 Mouse 1 x PS/2 Keyboard 4 x USB (Universal Serial Bus) 3.0 Port 2 x USB (Universal Serial Bus) 2.0 Port 2 x HDMI Connector, resolution up to 4096 x 2160 @24 Hz, compliant with HDMI 1.4a 1 x DVI-D Connector, resolution up to 1920 x 1200 @60 Hz 1 x RJ-45 Port 3 x Audio Connector INTERNAL I/O 2 x USB (Universal Serial Bus) 3.0 Header 2 x USB (Universal Serial Bus) 2.0 Header 2 x SATA3 6 Gb/s Connector 1 x SATA Express Connector 1 x M.2 Key M 32 Gb/s Connector 1 x Front Audio Header 1 x Front Panel Header 1 x CPU Fan Header 2 x System Fan Header 1 x Serial Header 1 x 5050 LED Header H/W MONITORING CPU / System Temperature Monitoring CPU / System Fan Monitoring Smart / Manual CPU Fan Control System Voltage Monitoring DIMENSION Micro ATX Form Factor Dimension: 24.4cm x 23cm (W x L ) OS SUPPORT Support Windows 7 / 8.1 (x 64) / 10 (x 64) BUNDLE SOFTWARE Racing GT Utility Bull Guard Smart Ear headphone Utility BIO-Remote 2 FEATURES Supports PURO Hi-Fi GT TOUCH Supports 100% Solid capacitor Supports BIOS-Flasher Supports Charger Booster Supports BIOS Online Update
...

Biostar Intel B150 Ver. 5.x Socket 1151 VGA DVI-D HDMI 8 Channel Blu-ray Audio ATX Motherboard Specifications: Chipset Intel B150 CPU SUPPORT Intel Core i 7 LGA 1151 Processor Intel Core i 5 LGA 1151 Processor Intel Core i 3 LGA 1151 Processor Intel Pentium LGA 1151 Processor Maximum CPU TDP (Thermal Design Power): 95 Watt MEMORY Support Dual Channel DDR4 2133/ 1866 MHz 4 x DDR4 DIMM Memory Slot Max. Supports up to 64GB Memory EXPANSION SLOT 2 x PCI-E x 16 3.0 Slot (x 16 + x 4) 1 x PCI-E x 1 3.0 Slot 3 x PCI Slot STORAGE 4 x SATA3 Connector 1 x SATA Express 16 Gb/s Connector USB (Universal Serial Bus) 4 x USB (Universal Serial Bus) 3.0 Port 1 x USB (Universal Serial Bus) 3.0 Header 2 x USB (Universal Serial Bus) 2.0 Port 2 x USB (Universal Serial Bus) 2.0 Header LAN Intel I219V
- Gigabit Ethernet PHY INTEGRATED VIDEO By CPU model Supports DX12 Supports HDCP CODEC Realtek ALC892 8-Channel Blu-ray Audio Support Blu-ray Audio Support HD Audio Support Biostar Hi-Fi REAR I/O 1 x PS/2 Keyboard 4 x USB (Universal Serial Bus) 3.0 Port 2 x USB (Universal Serial Bus) 2.0 Port 1 x HDMI Connector, resolution up to 4096 x 2160 @24 Hz, compliant with HDMI 1.4a 1 x DVI-D Connector, resolution up to 1920 x 1200 @60 Hz 1 x VGA Port, resolution up to 1920 x 1200 @60 Hz 1 x RJ-45 Port 6 x Audio Connector INTERNAL I/O 1 x USB (Universal Serial Bus) 3.0 Header 2 x USB (Universal Serial Bus) 2.0 Header 4 x SATA3 6 Gb/s Connector 1 x SATA Express 16 Gb/s Connector 1 x Front Audio Header 1 x Front Panel Header 1 x S/PDIF-Out Header 1 x CPU Fan Header 2 x System Fan Header 1 x Serial Header 1 x 5050 LED Header H/W MONITORING CPU / System Temperature Monitoring CPU / System Fan Monitoring Smart / Manual CPU / System Fan Control System Voltage Monitoring DIMENSION ATX Form Factor Dimension: 30.5cm x 22cm (W x L ) OS SUPPORT Support Windows 7 / 8.1 (x 64) / 10 (x 64) BUNDLE SOFTWARE Racing GT Utility Bull Guard BIO-Remote 2 FEATURES Supports Double Hi-Fi GT TOUCH Supports 100% Solid capacitor Supports Charger Booster Supports BIOS Online Update
...

Biostar Intel B150 Ver. 6.x Socket 1151 VGA DVI-D 8 Channel HD Audio Micro ATX Motherboard Specifications: Chipset Intel B150 CPU SUPPORT Intel Core„¢ i 7 LGA 1151 Processor Intel Core„¢ i 5 LGA 1151 Processor Intel Core„¢ i 3 LGA 1151 Processor Intel Pentium LGA 1151 Processor Maximum CPU TDP (Thermal Design Power): 95 Watt MEMORY Support Dual Channel DDR4 2133/ 1866 MHz 2 x DDR4 DIMM Memory Slot Max. Supports up to 32GB Memory EXPANSION SLOT 1 x PCI-E x 16 3.0 Slot 2 x PCI-E x 1 3.0 Slot STORAGE 4 x SATA3 Connector USB (Universal Serial Bus) 4 x USB (Universal Serial Bus) 3.0 Port 1 x USB (Universal Serial Bus) 3.0 Header 2 x USB (Universal Serial Bus) 2.0 Port 2 x USB (Universal Serial Bus) 2.0 Header LAN Realtek RTL8111H
- 10/100/1000 Controller Support Super LAN Surge Protection INTEGRATED VIDEO By CPU model Supports DX12 Supports HDCP CODEC Realtek ALC887 8-Channel HD Audio Support Biostar Hi-Fi REAR I/O 1 x PS/2 Mouse 1 x PS/2 Keyboard 4 x USB (Universal Serial Bus) 3.0 Port 2 x USB (Universal Serial Bus) 2.0 Port 1 x DVI-D Connector, resolution up to 1920 x 1200 @60 Hz 1 x VGA Port, resolution up to 1920 x 1200 @60 Hz 1 x RJ-45 Port 3 x Audio Connector INTERNAL I/O 1 x USB (Universal Serial Bus) 3.0 Header 2 x USB (Universal Serial Bus) 2.0 Header 4 x SATA3 6 Gb/s Connector 1 x Front Audio Header 1 x Front Panel Header 1 x CPU Fan Header 1 x System Fan Header 1 x Serial Header H/W MONITORING CPU / System Temperature Monitoring CPU / System Fan Monitoring Smart / Manual CPU Fan Control System Voltage Monitoring DIMENSION Micro ATX Form Factor Dimension: 22.6cm x 18.5cm (W x L ) OS SUPPORT Support Windows 7 / 8.1 (x 64) / 10 (x 64) BUNDLE SOFTWARE Bull Guard Smart Ear headphone Utility BIO-Remote 2 Smart Speed LAN FEATURES Supports PURO Hi-Fi (Rear) Supports 100% Solid capacitor Supports Charger Booster Supports BIOS Online Update
...

Specifications Chipset Intel NM70 CPU Intel Celeron 1037U Dual-Core 1.8 G Hz Processor MEMORY Support Dual Channel DDR3 1600/1333 MHz 2 x DDR3 DIMM Memory Slot Max. Supports up to 16GB Memory EXPANSION SLOT 1 x PCI-E x 16 2.0 Slot (x 8) STORAGE 1 x SATA3 Connector 3 x SATA2 Connector USB (Universal Serial Bus) 4 x USB (Universal Serial Bus) 2.0 Port 2 x USB (Universal Serial Bus) 2.0 Header LAN Realtek RTL8111F
- 10/100/1000 Controller INTEGRATED VIDEO: Intel HD Graphics Max. shared memory 1759MB (DVMT) Supports DX11 Supports HDCP CODEC Realtek ALC662 6-Channel HD Audio REAR I/O 1 x PS/2 Mouse 1 x PS/2 Keyboard 4 x USB (Universal Serial Bus) 2.0 Port 1 x HDMI Connector 1 x VGA Port 1 x RJ-45 Port 3 x Audio Connector INTERNAL I/O 1 x Printer Header 2 x USB (Universal Serial Bus) 2.0 Header 1 x SATA3 6 Gb/s Connector 3 x SATA2 3 Gb/s Connector 1 x Front Audio Header 1 x Front Panel Header 1 x S/PDIF-OUT Header 1 x CPU FAN Header 1 x System FAN Header 1 x Serial Header DIMENSION Mini ITX Form Factor Dimension: 17cm x 17cm (W x L ) OS SUPPORT Support Windows XP / Vista / 7 / 8 FEATURES Windows 8 Ready Supports Smart Speed LAN Supports BIO-Remote 2 Supports Solid capacitor Supports BIOS-Flasher Supports Charger Booster Supports BIOS Online Update
...

Biostar Intel Z170 Ver. 5.x Socket 1151 VGA DVI-D HDMI 8 Channel Blu-ray Audio ATX Motherboard Specifications: Chipset Intel Z170 CPU SUPPORT Intel Core i 7 LGA 1151 Processor Intel Core i 5 LGA 1151 Processor Intel Core i 3 LGA 1151 Processor Intel Pentium LGA 1151 Processor Maximum CPU TDP (Thermal Design Power): 95 Watt MEMORY Support Dual Channel DDR4 3200 (OC)/ 2133/ 1866 MHz 4 x DDR4 DIMM Memory Slot Max. Supports up to 64GB Memory EXPANSION SLOT 4 x PCI-E x 16 3.0 Slot (x 16, x 8, x 4- from SB, x 4- from SB) 3 x PCI-E x 1 3.0 Slot (2 slot share PCIE port w/ PCI-Ex 16@x 4) STORAGE 3 x SATA Express 16 Gb/s Connector Support SATA RAID: 0, 1, 5, 10 Support PCI-E Storage RAID: 0, 1, 5 1 x M.2 Key M 32 Gb/s Connector USB (Universal Serial Bus) 1 x USB (Universal Serial Bus) 3.1 Type-C Port 5 x USB (Universal Serial Bus) 3.0 Port 1 x USB (Universal Serial Bus) 3.0 Header 2 x USB (Universal Serial Bus) 2.0 Header LAN Intel I219V
- Gigabit Ethernet PHY MULTI GRAPHICS AMD 3way Cross Fire X INTEGRATED VIDEO By CPU model Supports DX12 Supports HDCP CODEC Realtek ALC898 8 Channel Blu-ray Audio Support Blu-ray Audio Support HD Audio Support Biostar Hi-Fi REAR I/O 1 x PS/2 1 x USB (Universal Serial Bus) 3.1 Type-C Port 5 x USB (Universal Serial Bus) 3.0 Port 2 x HDMI Connector, resolution up to 4096 x 2160 @24 Hz, compliant with HDMI 1.4 1 x DVI-D Connector, resolution up to 1920 x 1200 @60 Hz 1 x VGA Port, resolution up to 1920 x 1200 @60 Hz 1 x RJ-45 Port 6 x Audio Connector INTERNAL I/O 1 x USB (Universal Serial Bus) 3.0 Header 2 x USB (Universal Serial Bus) 2.0 Header 3 x SATA Express 16 Gb/s Connector 1 x M.2 Key M 32 Gb/s Connector 1 x Front Audio Header 1 x Front Panel Header 1 x S/PDIF-Out Header 2 x CPU Fan Header 3 x System Fan Header 1 x TPM Header 1 x LN2 Switch 1 x 5050 LED Header H/W MONITORING CPU / System Temperature Monitoring CPU / System Fan Monitoring Smart / Manual CPU / System Fan Control System Voltage Monitoring OVERVOLTAGE CPU Vcore/ VSA/ VCC_IO/ VGT/ VCC_PLL_OC/ DDR/ DDR VPP/ PCH 1.0V DIMENSION ATX Form Factor Dimension: 30.5cm x 24.4cm (W x L ) OS SUPPORT Support Windows 7 / 8.1 (x 64) / 10 (x 64) BUNDLE SOFTWARE Racing GT Utility Bull Guard BIO-Remote 2 Intel Rapid Storage Technology (include Intel Smart Response Technology) FEATURES Supports Double Hi-Fi GT TOUCH Supports 100% Solid capacitor Supports Rapid Debug 3 Supports Charger Booster Supports BIOS Online Update
...
