Technical
Specification Projection Projection System: DLP Native Resolution: WXGA (1280 x 800) Brightness*: 3200AL Contrast Ratio: 13000:1 Display
Colour: 1.07 Billion Colours Lens: F=2.59-2.86, f=21-25.6mm Aspect Ratio: Native 16:10 (5 aspect ratio selectable) Throw Ratio: 1.5
- 1.8 (62" @ 2m) Image Size (Diagonal): 39"~300" Zoom Ratio: 1.2:1 Lamp Type: 203W Keystone Adjustment: 1D, Vertical +/- 40 degrees Projection Offset: 125% ±5% Resolution Support: VGA (640 x 480) to WUXGA_RB (1920 x 1200) *RB = Reduced Blanking Horizontal Frequency: 15~102 KHz Vertical Scan Rate: 23~120 Hz Interface Computer in (D-sub 15pin) x 2 (Share with component) Monitor out (D-sub 15pin) x 1 Composite video in (RCA) x 1 S-Video in (Mini-DIN 4 pin) x 1 HDMI x 1 Audio in (Mini Jack) x 2 Audio out (Mini Jack) x 1 Speaker 2W x 1 USB (Universal Serial Bus) (Type B) x 1 RS232 (DB-9pin) x 1 IR Receiver x 1 (Front)
Dimensions Wx Hx D 302.8 x 111.8 x 221.8 mm (with feet) 302.8 x 103.8 x 221.8 mm (without feet) Weight: 2.3kg HDTV Compatibility 480i, 480p, 576i, 576p, 720p, 1080i, 1080p Power Power Supply: AC100 to 240 V, 50 to 60 Hz Power Consumption: Normal 253W, Eco 212W, Standby <0.5W Accessories Lens Cover Remote Control w/ Battery Power Cord (by region) User Manual CD Quick Start Guide Warranty Card (by region) VGA (D-sub 15pin) Cable
