Asus P9D-M Socket LGA1150 VGA U ATX Motherboard The ASUS P9D-M is a micro ATX form factor serverboard featuring the latest Intel Xeon E3-1200 v 3 processor family, dual Intel server-class I210 LAN ports, SATA 6 Gb/s, & digital power delivery. These make the P9D-M a great serverboard for small form factor servers, data centers, & SMB printer/file/mail/exchange servers. Processor / System Bus 1 x Socket LGA1150 Intel Xeon processor E3-1200 v 3 product family 4th Gen Intel Core i 3 processors Intel Pentium processors Intel Celeron processors Core Logic Intel C224 Chipset Memory Total Slots: 4 (2-channel) Capacity: Maximum up to 32GB UDIMM Memory Type: DDR3 1600/1333 UDIMM with ECC Memory Size: 8GB, 4GB, 2GB Expansion Slots Total Slot: 4 Slot Location 4: PCI-E x 8 (Gen 2 X4 Link) Slot Location 5: PCI-E x 8 (Gen 3 X4 Link) Slot Location 6: PCI-E x 16 (Gen 3 X8 Link) Slot Location 7: PCI-E x 8 (Gen 3 X4 Link) Follow SSI Location Form Factor
- U ATX (9.6"x 9.6") ASUS Features FAN speed control Rack Ready (Rack & Pedestal dual use) ASWM Enterprise Storage SATA Controller: Intel C224 4 x SATA3 6 Gb/s ports 2 x SATA2 3 Gb/s ports Intel Rapid Storage Technology Enterprise (RSTe) (For Windows Only) (Support Software RAID 0, 1, 5, 10 ) LSI Mega RAID (For Linux/ Windows) (Support Software RAID 0, 1, 10 ) Networking
- 2 x Intel I210AT + 1 x Mgmt LAN Graphic
- Aspeed AST2300 with 32MB VRAM On Board I/O 1 x TPM header 1 x PSU Power Connector (24-pin ATX power connector + 8-pin ATX 12V power connector) 1 x Management Connector, Onboard header for management card 1 x USB (Universal Serial Bus) 3.0 pin header, Up to 2 Devices 1 x USB (Universal Serial Bus) 2.0 pin header, Up to 2 Devices 1 x Internal A Type USB (Universal Serial Bus) Port*1 5 x Fan Header, 4pin 1 x SMBus 1 x Chassis Intruder 2 x Front LAN LED 1 x Serial Port Header 1 x SATA DOM Power connector*2 1 x VGA Header Back I/O Ports 1 x External Serial Port 4 x External USB (Universal Serial Bus) Port (2 x USB (Universal Serial Bus) 3.0, 2 x USB (Universal Serial Bus) 2.0) 1 x VGA Port 2 x RJ-45 + 1 x Mgmt LAN 1 x PS/2 KB/ Mouse Management Solution Software: ASWM Enterprise Out of Band Remote Management: Optional ASMB7-i KVM for KVM-over-Internet Regulatory Compliance
- CE, FCC (Class B) Environment Operation temperature: 10&8451; ~ 35&8451; Non operation temperature: -40&8451; ~ 70&8451; Non operation humidity: 20% ~ 90% (Non condensing) Product SKUs Standard Gift Box Pack Standard Bulk Pack Monitoring CPU Temperature Fan RPM Note *1 1 x USB (Universal Serial Bus) 2.0 connector *2 4-pin power connector



...

The ASUS P9D-X is a new UP serverboard designed as an Intel Denlow platform entry model to provide a cost & power-efficient platform. The P9D-X is based on the Intel C222 chipset, featuring three legacy PCI slots, dual server-class Intel Ethernet & digital power control. It is ideal for SMB, web, printer, file, & other entry-level server applications. Processor / System Bus 1 x Socket LGA1150 Intel Xeon processor E3-1200 v 3 product family 4th Gen Intel Core i 3 processors Intel Pentium processors Intel Celeron processors * Refer to asus for CPU Support list Core Logic Intel C222 Chipset Memory Total Slots: 4 (2-channel) Capacity: Maximum up to 32GB UDIMM Memory Type: DDR3 1600/1333 UDIMM with ECC Memory Size: 8GB, 4GB, 2GB Expansion Slots Total Slot: 6 Slot Location 1: PCI 32bit/33 M Hz Slot Location 2: PCI 32bit/33 M Hz Slot Location 3: PCI 32bit/33 M Hz Slot Location 4: PCI-E x 8 (Gen 2 X4 Link) Slot Location 6: PCI-E x 16 (Gen 3 X16 Link) Slot Location 7: MIO Slot for Audio card Follow SSI Location Form Factor ATX (12"x 9.6") ASUS Features FAN speed control Rack Ready (Rack & Pedestal dual use) ASWM Enterprise Storage SATA Controller: Intel C222 2 x SATA3 6 Gb/s ports 4 x SATA2 3 Gb/s ports Intel Rapid Storage Technology Enterprise (RSTe) (For Windows Only) (Support Software RAID 0, 1, 5, 10 ) Networking 2 x Intel I210AT Graphics Aspeed AST1300 with 64MB VRAM On Board I/O 1 x TPM header 1 x PSU Power Connector (24-pin ATX power connector + 8-pin ATX 12V power connector) 2 x USB (Universal Serial Bus) 2.0 pin header, Up to 4 Devices 1 x Internal A Type USB (Universal Serial Bus) Port*1 5 x Fan Header, 4pin 1 x Chassis Intruder 2 x Front LAN LED 1 x Serial Port Header 1 x SATA DOM Power connector*2 1 x VGA Header Back I/O Ports 1 x External Serial Port 4 x External USB (Universal Serial Bus) Port (2 x USB (Universal Serial Bus) 3.0, 2 x USB (Universal Serial Bus) 2.0) 1 x VGA Port 2 x RJ-45 1 x PS/2 KB/ Mouse ...

CPU Intel Socket 2011 for 2nd Generation Core i 7 Processors Supports Intel Turbo Boost Technology 2.0 * Refer to asus website for CPU support list Chipset Intel X79 Memory 8 x DIMM, Max. 64GB, DDR3 2400 (O.C.)/2133 (O.C.)/1866/1600/1333/1066 MHz Non-ECC, Un-buffered Memory Quad Channel Memory Architecture Supports Intel Extreme Memory Profile (XMP) * Hyper DIMM support is subject to the physical characteristics of individual CPUs. * Refer to asus website or user manual for the Memory QVL (Qualified Vendors Lists). Multi-GPU Support Supports NVIDIA 3-Way SLI Technology Supports AMD Quad-GPU Cross Fire X Technology Expansion Slots 2 x PCIe 3.0/2.0 x 16 (dual x 16) *1 1 x PCIe 3.0/2.0 x 16 (x 8 mode) *1 2 x PCIe 2.0 x 1 1 x PCI Storage Intel X79 chipset: 2 x SATA 6 Gb/s port (s), gray 4 x SATA 3 Gb/s port (s), blue Support Raid 0, 1, 5, 10 ASMedia ASM1061 controller: 2 x e SATA 6 Gb/s port (s), red LAN Realtek 8111F, 1 x Gigabit LAN Controller (s) Audio Realtek ALC892 8-Channel High Definition Audio CODEC
- Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking Audio Feature :
- Absolute Pitch 192k Hz/ 24-bit True BD Lossless Sound
- Blu-ray audio layer Content Protection
- Optical S/PDIF out port (s) at back panel USB (Universal Serial Bus) Ports ASMedia USB (Universal Serial Bus) 3.0 controller: 4 x USB (Universal Serial Bus) 3.0 port (s) (2 at back panel, blue, 2 at mid-board) Intel X79 chipset: 14 x USB (Universal Serial Bus) 2.0 port (s) (8 at back panel, black, 6 at mid-board) Overclocking Features Overclocking Protection :
- ASUS C.P.R. (CPU Parameter Recall) Special Features ASUS Dual Intelligent Processors 3 with New DIGI+ Power Control: ASUS TPU :
- Auto Tuning
- Turbo V ASUS EPU :
- EPU ASUS Digital Power Design :
- Industry leading Digital 6 + 2 Phase CPU Power Design
- Industry leading Digital 2 + 2 Phase DRAM Power Design
- CPU Power Utility
- DRAM Power Utility ASUS Exclusive Features :
- Remote GO!
- USB (Universal Serial Bus) BIOS Flashback
- Mem OK!
- AI Suite II
- Ai Charger
- ASUS UEFI BIOS EZ Mode featuring friendly graphics user interface
- USB (Universal Serial Bus) 3.0 Boost ASUS Quiet Thermal Solution :
- Stylish Fanless Design Heat-sink solution
- ASUS Fan Xpert+ ASUS EZ DIY :
- Direct Key
- ASUS O.C. Profile
- ASUS Crash Free BIOS 3
- ASUS EZ Flash 2
- ASUS My Logo 2
- Multi-language BIOS ASUS Q-Design :
- ASUS Q-Shield
- ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED)
- ASUS Q-Slot
- ASUS Q-DIMM
- ASUS Q-Connector Back I/O Ports 1 x PS/2 keyboard (violet) 1 x PS/2 mouse (green) 2 x e SATA 6 Gb/s 1 x LAN (RJ45) port (s) 2 x USB (Universal Serial Bus) 3.0 8 x USB (Universal Serial Bus) 2.0 1 x Optical S/PDIF out 6 x Audio jack (s) Internal I/O Ports 1 x USB (Universal Serial Bus) 3.0 connector (s) support (s) additional 2 USB (Universal Serial Bus) 3.0 port (s) (19-pin) 3 x USB (Universal Serial Bus) 2.0 connector (s) support (s) additional 6 USB (Universal Serial Bus) 2.0 port (s) 1 x TPM connector (s) 1 x COM port (s) connector (s) 2 x SATA 6 Gb/s connector (s) 4 x SATA 3 Gb/s connector (s) 1 x CPU Fan connector (s) (4 -pin) 1 x CPU OPT Fan connector (s) (4 -pin) 4 x Chassis Fan connector (s) (4 -pin) 1 x S/PDIF out header (s) 1 x 24-pin EATX Power connector (s) 1 x 8-pin ATX 12V Power connector (s) 1 x Front panel audio connector (s) (AAFP) 1 x System panel (s) (Q-Connector) 1 x Direct Key Button (s) 1 x DRCT header (s) 1 x Mem OK! button (s) 1 x Clear CMOS jumper (s) 1 x USB (Universal Serial Bus) BIOS Flashback button (s) BIOS 64 Mb Flash ROM, UEFI BIOS, Pn P, DMI2.0, Wf M2.0, SM BIOS 2.6, ACPI 2.0a, Multi-language BIOS, ASUS EZ Flash 2, ASUS Crash Free BIOS 3 Manageability Wf M 2.0, DMI 2.0, WOL by PME, WOR by PME, PXE Form Factor ATX Form Factor 12 inch x 9.6 inch (30.5 cm x 24.4 cm ) Note *1: This motherboard is ready to support PCIe 3.0 SPEC. Functions will be available when using PCIe 3.0-compliant devices. Please refer to asus for updated details.































...

At the very top end of motherboard performance, the P9X79 series from ASUS brings you complete power, enhanced with unmatched flexibility & boundless tuning possibilities. These new boards launch with the world’s first digital power controls for both the CPU & memory, thanks to exclusive ASUS New DIGI+ Power Control Technology. They further put power right in your hand via UEFI BIOS, the most detailed & accessible BIOS ever, allowing you to tune your system to its full performance potential. While user-friendly from the ground-up, the P9X79 Series ships with the latest features, including exclusive ASUS SSD caching for one-click performance boosting through the benefits of solid state drive technology. You also get USB (Universal Serial Bus) BIOS Flashback for the easiest ever BIOS modification – all it takes is a USB (Universal Serial Bus) stick & one button press! Sign up for total power & performance insight with the new ASUS P9X79 Series. The world’s first Dual Intelligent Processors from ASUS pioneered twin on board chips – TPU (Turbo V Processing Unit) & EPU (Energy Processing Unit). Third generation Dual Intelligent Processors with New DIGI+ Power Control include two digital voltage regulator modules (VRMs). An all-new digital controller now allows ultra-precise DRAM tuning. EPU provides system energy saving & real time power management. TPU delivers a second micro-processor to free CPU resources as well as easy O.C. & an instant performance boost through an on-board switch or the easy O.C. tool, Turbo V EVO. ASUS Dual Intelligent Processors 3 with New DIGI+ Power Control: CPU Power: Industry leading Digital 8+2 Phase Power Design & CPU Power Utility DRAM Power: Industry leading Digital 2+2 Phase Power Design & DRAM Power Utility ASUS EPU & EPU switch: Automatically provides the most appropriate power usage to save power & money. ASUS TPU with Auto Tuning & Turbo V with Switch: Providing simple steps to easy overclocking. ASUS BT GO!: Bluetooth on-board for easy Folder Sync, BT Transfer, Shot & Send, BT to Net, Music Player, Personal Manager, BT Turbo Remote ASUS EFI BIOS (EZ Mode): The most flexible & easy to use Bios. ASUS SSD Caching: 3x Faster storage performance with one click USB (Universal Serial Bus) 3.0 Boost: Make USB (Universal Serial Bus) 3.0 speeds faster than ever (UASP Mode) Front Panel USB (Universal Serial Bus) 3.0 Support: Support for cases with front USB (Universal Serial Bus) 3.0 Mem OK!: Quickly ensures memory boot compatibility with failsafe settings. AI Suite II: One stop access to all Asus features. Ai Charger: Faster USB (Universal Serial Bus) charging speed. Fanless Design: Silent Heat-sink solution Fan Xpert+: Smart thermal control via fan speed detection. ASUS Q-Code: Allows easy fault diagnosis ASUS Q-Shield: Extra Secure I/O Shield ASUS Q-Slot: Easy access expansion slots. ASUS Q-DIMM: Easy access dimm slots. ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED): ASUS Q-Connector: Easy access front panel connector USB (Universal Serial Bus) BIOS Flashback: Flash your Bios in 1 easy step, no CPU or RAM required. ASUS O.C. Profile: Easily store multiple overclock profiles. Crash Free BIOS 3: Restore corrupted BIOS data from a USB (Universal Serial Bus) flash disk EZ Flash 2: Easily update your systems bios firmware. My Logo 2: Update your own windows boot screen. Percision Tweaker 2: Advanced overclocking tools. Multi-language BIOS: easily change Bios to your language. Asus Overclocking

Features: Precision Tweaker 2:
- v Core: Adjustable CPU voltage at 0.005V increment
- v TTCPU: Adjustable I/O voltage at 0.00625V increment
- v CCSA: 255-step system agent voltage control - v DRAM Bus: 160-step Memory voltage control
- v PCH: 96-step Chipset voltage control
- v CPU_PLL: 48-step CPU & PCH PLL voltage control SFS (Stepless Frequency Selection)
- BCLK/PEG frequency tuning from 80 M Hz up to 300 M Hz at 0.1 M Hz increment Overclocking Protection:
- ASUS C.P.R. (CPU Parameter Recall) Key specification: Form Factor: ATX, 12”x 9.6” (30.5cm x 24.4cm) CPU: Intel Socket 2011 for 2nd Generation Intel Core i 7 Processor Extreme Edition, Supports Intel Turbo Boost Technology 2.0 Chipset: Intel X79 Express Chipset Memory: 8 x DIMM, Max. 64GB, DDR3 2400 (O.C.)/2133 (O.C.)/1866/1600/1333/1066 MHz, ECC, Non-ECC, un-buffered Quad channel Memory Expansion Slots: 3 x PCIe 3.0 x 16 slots (dual @ x 16/x 16; triple @ x 16/x 8/x 8), 1 x PCIe 3.0 x 16 slot (PCIe x 16_3 @ x 8 speed), 2 x PCIe 2.0 x 1 slots Multi-GPU: Supports NVIDIA 3-Way SLI™ & AMD Quad-GPU Cross Fire X Technology Storage 1: Intel X79 Express Chipset: 2 x SATA 6 Gb/s ports with RAID 0, 1, 5 & 10 support, 4 x SATA 3 Gb/s ports with RAID 0, 1, 5 & 10 support Storage 2: Marvell 9128 SATA controller: 2 x SATA 6 Gb/s ports Storage 3: ASMedia 1061 SATA controller: 2 x Power e SATA 6 Gb/s ports LAN: Intel 82579V Gigabit LAN controller Audio: Realtek ALC 898 8-channel High Definition Audio CODEC Supports 192k Hz/ 24bit BD Lossless Sound USB: 3 x ASMedia USB (Universal Serial Bus) 3.0 controllers: 2 x USB (Universal Serial Bus) 3.0/2.0 ports at mid-board for front panel support: 4 x USB (Universal Serial Bus) 3.0/2.0 ports at back panel with 1 additional VIA Super Speed USB (Universal Serial Bus) USB: Intel X79 Express Chipset: 12 x USB (Universal Serial Bus) 2.0/1.1 ports (6 ports at mid-board, 6 ports at back panel) BT & Wi Fi: Bluetooth V2.1+EDR with ASUS BT GO! Utility, NO WIFI Bios

Features: 64 Mb Flash ROM, UEFI BIOS, Pn P, DMI2.0, Wf M2.0, SM BIOS 2.6, ACPI 2.0a, Multi-language BIOS, ASUS EZ Flash 2, ASUS Crash Free BIOS 3 Manageability: Wf M 2.0, DMI 2.0, WOL by PME, WOR by PME, PXE * This motherboard is ready to support PCIe 3.0 SPEC Back Panel I/O Ports: 1 x Bluetooth module 1 x Optical S/PDIF Output port 1 x LAN (RJ-45) port 2 x Power e SATA 6G ports 4 x USB (Universal Serial Bus) 3.0/2.0 ports (blue) 6 x USB (Universal Serial Bus) 2.0/1.1 ports 1 x USB (Universal Serial Bus) BIOS Flashback button 8-channel Audio I/O Internal I/O Connectors: 1 x USB (Universal Serial Bus) 3.0/2.0 connector support additional 2 USB (Universal Serial Bus) ports (19-pin) 3 x USB (Universal Serial Bus) 2.0/1/1 connectors support additional 6 USB (Universal Serial Bus) ports 4 x SATA 6 Gb/s connectors 4 x SATA 3 Gb/s connectors 1 x CPU Fan connector (4-pin) 1 x CPU Opt Fan connectors (4-pin) 4 x Chassis Fan connectors (4-pin) 1 x Front panel audio connector (AAFP) 1 x S/PDIF Out header 1 x Clear CMOS button 1 x 24-pin EATX Power connector 1 x 8-pin EATX 12V Power connector 1 x System Panel (Q-Connector) 1 x Mem OK! Button 1 x EPU switch 1 x TPU switch 1 x PWR button 1 x Reset button










...

Specifications CPU Intel Socket 2011 for 2nd Generation Core i 7 Processors Supports Intel Turbo Boost Technology 2.0 * Refer to asus for CPU support list Chipset Intel X79 Memory 8 x DIMM, Max. 64GB, DDR3 2400 (O.C.)/2133 (O.C.)/1866/1600/1333/1066 MHz Non-ECC, Un-buffered Memory Quad Channel Memory Architecture Supports Intel Extreme Memory Profile (XMP) * Hyper DIMM support is subject to the physical characteristics of individual CPUs. * Refer to asus or user manual for the Memory QVL (Qualified Vendors Lists). Multi-GPU Support Supports NVIDIA Quad-GPU SLI Technology Supports AMD Quad-GPU Cross Fire X Technology Expansion Slots 2 x PCIe 3.0/2.0 x 16 (dual x 16) *1 1 x PCIe 3.0/2.0 x 16 (x 8 mode) *1 2 x PCIe 2.0 x 1 1 x PCI Storage Intel X79 chipset: 2 x SATA 6 Gb/s port (s), white 4 x SATA 3 Gb/s port (s), blue Support Raid 0, 1, 5, 10 ASMedia ASM1061 controller: 1 x Power e SATA 6 Gb/s port (s), green 1 x e SATA 6 Gb/s port (s), red LAN Intel 82579V, 1 x Gigabit LAN Controller (s) Audio Realtek ALC892 8-Channel High Definition Audio CODEC
- Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking Audio Feature :
- Absolute Pitch 192k Hz/ 24-bit True BD Lossless Sound
- Blu-ray audio layer Content Protection
- DTS Ultra PC II
- DTS Connect
- Optical S/PDIF out port (s) at back panel IEEE 1394 VIA 6315N controller 1 x IEEE 1394a port (s) (1 at back panel) USB (Universal Serial Bus) Ports ASMedia USB (Universal Serial Bus) 3.0 controller: 4 x USB (Universal Serial Bus) 3.0 port (s) (4 at back panel, blue) Intel X79 chipset: 14 x USB (Universal Serial Bus) 2.0 port (s) (6 at back panel, black+white, 8 at mid-board) Special Features ASUS Dual Intelligent Processors 3 with New DIGI+ Power Control: ASUS TPU :
- Auto Tuning
- Turbo V
- TPU switch ASUS EPU :
- EPU
- EPU switch ASUS Digital Power Design :
- Industry leading Digital 8 + 2 Phase CPU Power Design
- Industry leading Digital 2 + 2 Phase DRAM Power Design
- CPU Power Utility
- DRAM Power Utility ASUS Exclusive Features :
- Mem OK!
- AI Suite II
- Ai Charger
- ASUS UEFI BIOS EZ Mode featuring friendly graphics user interface
- USB (Universal Serial Bus) 3.0 Boost ASUS Quiet Thermal Solution :
- Stylish Fanless Design Heat-sink solution
- ASUS Fan Xpert+ ASUS EZ DIY :
- USB (Universal Serial Bus) BIOS Flashback
- ASUS Q-Shield
- ASUS O.C. Profile
- ASUS Crash Free BIOS 3
- ASUS EZ Flash 2
- ASUS My Logo 2
- Multi-language BIOS ASUS Q-Design :
- ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED)
- ASUS Q-Slot
- ASUS Q-DIMM
- ASUS Q-Connector Back I/O Ports 1 x PS/2 keyboard/mouse combo port (s) 1 x e SATA 6 Gb/s 1 x Power e SATA 6 Gb/s 1 x IEEE 1394a 1 x LAN (RJ45) port (s) 4 x USB (Universal Serial Bus) 3.0 6 x USB (Universal Serial Bus) 2.0 (one port can be switched to USB (Universal Serial Bus) BIOS Flashback) 1 x Optical S/PDIF out 6 x Audio jack (s) 1 x USB (Universal Serial Bus) BIOS Flashback Button (s) Internal I/O Ports 4 x USB (Universal Serial Bus) 2.0 connector (s) support (s) additional 8 USB (Universal Serial Bus) 2.0 port (s) 1 x TPM connector (s) 1 x COM port (s) connector (s) 2 x SATA 6 Gb/s connector (s) 4 x SATA 3 Gb/s connector (s) 1 x CPU Fan connector (s) (4 -pin) 4 x Chassis Fan connector (s) (4 -pin) 1 x Optional Fan connector (s) (4 -pin) 1 x S/PDIF out header (s) 1 x 24-pin EATX Power connector (s) 1 x 8-pin ATX 12V Power connector (s) 1 x Front panel audio connector (s) (AAFP) 1 x System panel (s) (Q-Connector) 1 x Mem OK! button (s) 1 x TPU switch (es) 1 x EPU switch (es) 1 x Clear CMOS jumper (s) BIOS 64 Mb Flash ROM, UEFI BIOS, Pn P, DMI2.0, Wf M2.0, SM BIOS 2.6, ACPI 2.0a, Multi-language BIOS, ASUS EZ Flash 2, ASUS Crash Free BIOS 3 Manageability Wf M 2.0, DMI 2.0, WOL by PME, WOR by PME, PXE Form Factor ATX Form Factor 12 inch x 9.6 inch (30.5 cm x 24.4 cm ) Note *1: This motherboard is ready to support PCIe 3.0 SPEC. Functions will be available when using PCIe 3.0-compliant devices. Please refer to Asus for updated details.
































...

Asus P9X79-E WS Socket 2011 8-Channel HD Audio CEB Motherboard CPU: Intel Socket 2011 for 2nd Generation Core™ i 7 Processors Intel Socket 2011 for Xeon E5-1600 processors Intel Socket 2011 for Xeon E5-2600 processors Supports Intel Turbo Boost Technology 2.0 Chipset
- Intel X79 Memory: 8 x DIMM, Max. 64GB, DDR3 2400 (O.C.)/2133 (O.C.)/1866 (O.C.)/1600/1333/1066 MHz ECC, Non-ECC, Un-buffered Memory Quad Channel Memory Architecture Supports Intel Extreme Memory Profile (XMP) Multi-GPU Support: Supports NVIDIA 4-Way SLI Technology Supports AMD 4-Way Cross Fire X Technology Expansion Slots
- 7 x PCIe 3.0/2.0 x 16 (single x 16 or dual x 16/x 16 or triple x 16/x 16/x 16 or quad x 16/x 16/x 16/x 16 or seven x 16/x 8/x 8/x 8/x 16/x 8/x 8, black+blue) * Storage: Intel X79 chipset: 2 x SATA 6 Gb/s port (s), white 4 x SATA 3 Gb/s port (s), blue Support Raid 0, 1, 5, 10 Marvell PCIe 9230 controller: 4 x SATA 6 Gb/s port (s), white Support Raid 0, 1, 10 ASMedia PCIe SATA controller: 2 x e SATA 6 Gb/s port (s), red Support port multiplier support LAN
- Intel I210, 2 x Gigabit LAN Controller (s) Audio: Realtek ALC1150 8-Channel High Definition Audio CODEC
- Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking Audio Feature :
- Absolute Pitch 192k Hz/ 24-bit True BD Lossless Sound
- DTS Surround Sensation Ultra PC
- Optical S/PDIF out port (s) at back panel IEEE 1394: VIA 6315N controller 1 x IEEE 1394a port (s) USB (Universal Serial Bus) Ports: ASMedia USB (Universal Serial Bus) 3.0 controller: 4 x USB (Universal Serial Bus) 3.0/2.0 port (s) (2 at back panel, blue, 2 at mid-board) Intel X79 chipset: 13 x USB (Universal Serial Bus) 2.0 port (s) (10 at back panel, black, 3 at mid-board) Workstation Feature: 7 x PCIe x 16 slot (s) Quick Gate: 1 x vertical USB (Universal Serial Bus) 2.0 on board ASUS WS Diag. LED ASUS Dr. Power Special

Features: ASUS Xtreme Design: ASUS TPU :- TPU switch ASUS EPU :- EPU ASUS Digital Power Design :
- Industry leading Digital 8 + 2 Phase CPU Power Design
- Industry leading Digital 2 + 2 Phase DRAM Power Design
- CPU Power Utility
- DRAM Power Utility ASUS Exclusive Features :
- Mem OK!
- AI Suite II
- Ai Charger+
- Front Panel USB (Universal Serial Bus) 3.0 Support
- ASUS UEFI BIOS EZ Mode featuring friendly graphics user interface
- ASUS SSD Caching II
- USB (Universal Serial Bus) 3.0 Boost ASUS Quiet Thermal Solution :
- Stylish Fanless Design Heat-pipe solution
- ASUS Fan Xpert+ ASUS EZ DIY :
- USB (Universal Serial Bus) BIOS Flashback
- ASUS O.C. Profile
- ASUS Crash Free BIOS 3
- ASUS EZ Flash 2
- ASUS My Logo 2
- Multi-language BIOS ASUS Q-Design :
- ASUS Q-Shield
- ASUS Q-Code
- ASUS Q-Slot
- ASUS Q-DIMM
- ASUS Q-Connector Back I/O Ports: 1 x PS/2 keyboard/mouse combo port (s) 2 x e SATA 6 Gb/s 2 x LAN (RJ45) port (s) 2 x USB (Universal Serial Bus) 3.0 (blue) 10 x USB (Universal Serial Bus) 2.0 (one port can be switched to USB (Universal Serial Bus) BIOS Flashback) 1 x Optical S/PDIF out 8 x Audio jack (s) 1 x USB (Universal Serial Bus) BIOS Flashback Button (s) Internal I/O Ports: 1 x USB (Universal Serial Bus) 3.0 connector (s) support (s) additional 2 USB (Universal Serial Bus) 3.0 port (s) (19-pin) 1 x USB (Universal Serial Bus) 2.0 connector (s) support (s) additional 2 USB (Universal Serial Bus) 2.0 port (s) 1 x Vertical USB (Universal Serial Bus) 2.0 port (s) 1 x TPM connector (s) 1 x COM port (s) connector (s) 6 x SATA 6 Gb/s connector (s) 4 x SATA 3 Gb/s connector (s) 1 x CPU Fan connector (s) (4 -pin) 1 x CPU OPT Fan connector (s) (4 -pin) 4 x Chassis Fan connector (s) (4 -pin) 1 x S/PDIF out header (s) 1 x 8-pin EATX 12 V Power connector 1 x 6-pin EATX 12 V_1 Power connector (s) 1 x 24-pin EATX Power connector (s) 1 x Front panel audio connector (s) (AAFP) 1 x System panel (s) (Q-Connector) 1 x Chassis Intrusion connector (s) 1 x Mem OK! button (s) 1 x TPU switch (es) 1 x EPU switch (es) 1 x Power-on button (s) 1 x Reset button (s) 1 x Clear CMOS jumper (s) 1 x Dr. Power switch BIOS
- 64 Mb Flash ROM, UEFI BIOS, Pn P, DMI2.0, Wf M2.0, SM BIOS 2.6, ACPI 2.0a, Multi-language BIOS, ASUS EZ Flash 2, ASUS Crash Free BIOS 3 Manageability
- Wf M 2.0, DMI 2.0, WOL by PME, WOR by PME, PXE Operating System: Fedora 17 Windows 8 32/64-bit Windows 7 32/64-bit Red Hat Enterprise Linux WS 6.3 32/64-bit Open SUSE 12.2 Ubuntu Desktop 12.10 Form Factor: CEB Form Factor 12 inch x 10.5 inch (30.48 cm x 26.67 cm )


































...

High Color Accuracy with Low Delta E Each PA238Q is pre-calibrated with a maximum & Delta;E (Delta E) of less than 5. Ensures precise reading of color input & guarantees excellent color fidelity 178° Wide Viewing Angle PA238Q adopts 178° of horizontal & vertical viewing angle that eradicates color shift on your screen no matter where & how you look at it Flawless Gradation with 10-bit Look-up Table PA238Q's built-in internal 10-bit Look-up Table can produce greater depth for each RGB colors than 8-bit Look-up Table in conventional monitors. Resulting in smooth gradation & accurate color resolution Quick Fit Virtual Scale The ASUS-exclusive Quick Fit built in the monitor provides real-size document, photo, & grid mode on top of the operating windows on the screen. It can activated via a hotkey on monitor & used as a guide to accurately view & edit photos. Versatile Comfort with Ergonomic Design The ergonomically-designed PA238Q Professional Monitor comes with swivel, tilt, pivot, & height adjustments for ideal viewing position. Customized Color Adjustment Customized hue & saturation control with 6 color adjustment allows user to adjust six colors (red, green, blue, cyan, magenta & yellow) independently without effecting other colors. Picture-in-Picture & Picture-by-Picture Picture-in-Picture & Picture-by-Picture allows users to view images from different signals in almost anyway they want Hassle-Free Connection PA238Q comes with rich connectivity including Display Port, HDMI, DVI, D-sub. It is also equipped with four USB (Universal Serial Bus) 2.0 ports so that users could easily connect PA238Q to many peripherals, such as USB (Universal Serial Bus) drives, keyboard, mouse, digital camera, etc. Mercury-free LED-backlit panel Embedded LED backlight panel helps power saving & environmental protection with no mercury usage. Award-winning Design Reddot Design Award winner 2011 & International Design Excellence Award'11 Technical

Specification Display

Size: 23” Resolution: 1920 x 1080 IPS Panel Aspect Ratio: 16:9 Response Time: 6ms ASUS Smart Contrast Ratio: 50000000:1 Brightness: 250 cd/m-square Viewing Angle: 178°/178° Display

Colour: 16.7M Pixel Pitch: 0.2652mm Interfaces D-Sub x 1 DVI-D x 1 HDMI x 1 Display Port x 1 USB (Universal Serial Bus) (1 x upstream, 4 x downstream) Features Tilt: -5°to 20° Swivel Pivot Height Adjustable Stand VESA 100 x 100 SPLENDID Video Intelligence Technology Trace Free Technology Power Power Consumption On: <25.9W Power Consumption Saving Mode: <1W

Dimensions & Weight

Dimensions with Stand (Wx Hx D): 548.8 x 495.7 x 201mm Weight: 5.5kg









...

True Color, Always Gorgeous: Professional Pre-calibrated IPS 16:10 1920 x 1200 LED-backlit Monitor Professional-grade color fidelity with pre-calibrated &8710;E <5 for industry-leading color accuracy True, precise colors on a 100% s RGB, 16:10 aspect ratio, 1920 x 1200 optimal A+ IPS panel The world's first monitor with four USB (Universal Serial Bus) 3.0 ports for 10X faster transfer ASUS-exclusive innovations like Quick Fit, Splendid™ & 5-Way navigation key for enhanced productivity A comfortable viewing experience with award-winning ergonomic design with tilt, swivel, pivot & height adjustments True Color, Always Gorgeous Experience professional-grade color fidelity & reproduction with the ASUS PA248Q Pro Art series LCD display. Each PA248Q guarantees industry-leading color accuracy, having been pre-calibrated to minimize the color different to &8710;E < 5 right out of box. The PA248Q delivers 100% s RGB color reproduction on its 16:10, 1920 x 1200 optimal HD A+ IPS panel with 178° ultra-wide viewing angle. It is the world’s first monitor with four USB (Universal Serial Bus) 3.0 ports, ensuring enhanced productivity thanks to data transfer speeds that are up to 10X faster than Current USB (Universal Serial Bus) 2.0 standards. The True Color Pre-calibrated right out-of box The out-of-box settings are impressive as each PA248Q is pre-calibrated at factory to prove the best color accuracy. To ensure that each PA248Q produces the most accurate & consistent color, we carefully measure its &8710;E & gamma value & track its gray-scaling. It even supports both Gamma 2.2 for PC & Gamma 1.8 for Mac – offering users more flexibilities to work with. Each PA248Q guarantees industry-leading color accuracy, having been calibrated to minimize color difference to &8710;E (Delta E) of less than 5 – ensuring precise reading of color input & guarantees excellent color fidelity. Optimal HD A+ IPS Panel The ASUS PA248Q features a 16:10 aspect ratio, 1920 x 1200 A+ IPS LED-backlit panel for 100% s RGB & 72% NTSC color reproduction; addititionally, along with a 178° wide viewing angle, it ensures quality visuals & minimal onscreen color shift from almost any viewing position. ASUS Smart Contrast Ratio With ASUS Smart Contrast Ratio (ASCR) of 80, 000, 000:1 & 300cd/m-square of brightness, the ASUS PA248Q enhances display contrast & sharpness – by adjusting the luminance of the backlight to achieve the darkness black & brightest white – delivering lifelike visuals. Customized Color Adjustment Customized hue & saturation control with 6 color adjustment allows user to adjust six colors (red, green, blue, cyan, magenta & yellow) independently without effecting other colors Ultra-Smooth Visuals ASUS PA248Q also delivers ultra-smooth visuals thanks to a 6ms (GTG) response time – ensuring users have a lag-free viewing experience when it comes to watching movies or playing games. Games played under the PA248Q are more vivid – as all details can be seen & true color can be shown with the PA248Q. Extensive Connectivity The World’s First Monitor with Four USB (Universal Serial Bus) 3.0 Ports PA248Q sets a standard by being the world’s first monitor with four USB (Universal Serial Bus) 3.0 ports; users can easily plug in their devices & experience ultra-fast transmission speeds that are up to 10 times* that of current USB (Universal Serial Bus) 2.0 standards. Expand your visual horizon with multi-display setup An extensive array of connectivity & high compatibility options are available with the PA248Q including Display Port, HDMI, DVI & D-Sub; the PA248Q also allows users to use up to two or three displays simultaneously. With award-winning design, fast response time & advanced visual technology, Display Port-ready PA248Q gives you a leading multi-display experience – so you can see all the true color & every detail brilliantly. ASUS Exclusive Innovation & Design Splendid™ Video Intelligence Technology ASUS Splendid™ Video Intelligence Technology is built upon a color engine that automatically analyzes & determines the nature of the user’s current task, thereafter adjusting the display’s parameters according to ensure color accuracy & image fidelity. Six preset modes (Scenery, Theater, s RGB, standard & two user modes) can be selected via a designated hotkey. Intuitive 5 Way Navigation Key The PA248Q has a 5-way navigation key that acts as a joystick that gives access to the Quick Fit Virtual Scale function along with all OSD functions & settings. Customizable OSD Shortcuts The PA248Q features customizable OSD shortcuts through two designated hotkeys for quick access to the 10 most frequently used OSD functions. Picture-in-Picture & Picture-by-Picture ASUS exclusive innovations Picture-in-Picture (PIP) & Picture-by-Picture (PBP) allows users to view images from different signals in almost anyway they want. PIP & PBP let users view images from different signals & let them switch between the main & PIP source, including audio, easily. Quick Fit Virtual Scale Function ASUS included its exclusive Quick Fit Virtual Scale Function with the PA248Q, allowing users to preview photos & documents on screen in their actual sizes prior to printing. It can activated via a hotkey on monitor & used as a guide to accurately view & edit photos. in addition, the PA248Q also comes with a choice of seven different background colors for users to choose from. Supporting Formats: Document: A4, letter Photo: 8”x 10”, 5”x 7”, 4”x 6”, 3”x 5”, 2”x 2” Grid: Alignment, Centimeters, Inches Ergonomic, Award-winning Design As with most ASUS displays, the PA248Q has an ergonomic design, with tilt, swivel, pivot & height adjustment to give users a comfortable viewing experience. Its design has garnered accolades at the reddot Design awards & International Design Excellence Awards (IDEA). Technical

Specification Display 24.1” Screen IPS panel Resolution 1920 x 1200 ASUS Smart contrast ratio 0000000:1 Brightness 300 cd/m 2 Aspect ratio 16:10 Viewing angle 178° / 178° Pixel pitch 0.270mm Response time 6ms Colour depth 16.7M Power Power supply 110 – 240V Power consumption <45W Power Standby mode <1W Connectivity DVI-D HDMI VGA Display Port 3.5mm Mini-Jack 5x USB (Universal Serial Bus) ports Features HDCP support VESA 100 x 100 Tilt -5 to +20° Swivel, pivot & height adjustment functions Kensington security lock SPLENDID Video Intelligence Technology Auto. Adjustment

Dimensions With stand: 557.2 x 416.3 x 235mm (Wx Hx D) Without stand: 557.2 x 362.8 x 62mm



...

Experience professional-grade color fidelity & reproduction with the ASUS PA248QJ Pro Art series LCD display. The PA248QJ delivers 100% s RGB color reproduction on its 16:10, 1920 x 1200 optimal HD A+ IPS panel with 178° ultra-wide viewing angle. PA248QJ also provides the best color calibration solution of a monitor hood & Spyder 4 EXPRESS calibrator to achieve the color precision, accuracy, & consistency. It is the monitor with four USB (Universal Serial Bus) 3.0 ports, ensuring enhanced productivity thanks to data transfer speeds that are up to 10x faster than current USB (Universal Serial Bus) 2.0 standards. The ASUS PA248QJ features a 16:10 aspect ratio, 1920 x 1200 A+ IPS LED-backlit panel for 100% s RGB & 72% NTSC color reproduction; addititionally, along with a 178° wide viewing angle, it ensures quality visuals & minimal onscreen color shift from almost any viewing position. ...

True, Consistent Color Wide color gamut reproduces 99% of the Adobe RGB color space The ASUS PA249Q is pre-calibrated at the factory for the highest accuracy & outstanding color space reproduction – 99% Adobe RGB, 100% s RGB, & 120%* NTSC. With a wide color gamut of 99% Adobe RGB, the colors seen in photos will be reproduced faithfully & consistently in a way that cannot otherwise be on monitors with just an s RGB color space. 10-Bit color for smoother gradations The PA249Q offers 10-bit display color for over one billion onscreen colors & support 12 bit internal lookup table (LUT), which gives smoother gradations & a more natural transition between hues. Pre-calibrated right out-of-the box Each PA249Q guarantees industry-leading color accuracy, having been pre-calibrated to minimize the color difference to Delta E (&8710;E) of less than 3 – ensuring precise reading of color input & guarantees excellent color fidelity. Next-generation IPS display technology The ASUS PA249Q features AH-IPS (Advanced High-Performance In-Plane Switching) display technology for superior color accuracy, a brighter image from increased backlight transmission & lower power consumption. Each PA249Q also features a brightness rated at 350cd/m-square & an 80, 000, 000:1 ASUS Smart Contrast Ratio for enhanced image contrast. 6-axis independent color adjustment Customized hue & saturation control with 6 color adjustment means that you can adjust six colors (red, green, blue, cyan, magenta & yellow) independently without effecting other colors. Technical

Specification Panel

Size: Wide Screen 24.1" (61.13cm) 16:10 Panel Type: AH-IPS True Resolution: 1920x 1200 Pixel Pitch: 0.270mm Brightness (Max): 350 cd/&13217; ASUS Smart Contrast Ratio (ASCR): 80000000:1 Viewing Angle (CR&8807;10): 178° (H)/178° (V) Response Time: 6ms (Gray to Gray) Display Colors: 1073.7M (10bit) Trace Free Technology SPLENDID Video Intelligence Technology SPLENDID Video Preset Modes: 7 Modes (Adobe RGB Mode/s RGB Mode/ Scenery Mode/ Theater Mode/ Standard Mode/ User Mode) Color Temperature Selection: 4 Modes Color Accuracy: &9651;E&8806; 3 Gamma adjustment: Yes (Support Gamma 2.2/1.8 ) Color Adjustment: 6-axis adjustment (R, G, B, C, M, Y) Quick Fit (modes): Yes (Modes) Picture-in-Picture Picture-by-Picture HDCP support Signal Input: HDMI, D-Sub, Display Port, DVI-D Audio Output: 1.4 Earphone jack: 3.5mm Mini-Jack USB (Universal Serial Bus) Port (s): 1 x upstream, 4 x downstream Accessories Cable tie DVI cable VGA cable Power cord Display Port cable USB (Universal Serial Bus) 3.0 cable Quick start guide Support CD Warranty Card Color pre-calibration report



...
