TOP-selected 1085 M Hz cores run 105 MHz higher than reference for smoother gameplay. Direct CU achieves 20% lower temps with twice the dissipation area & 6X greater airflow than conventional design. DIGI+ VRM with Super Alloy Power delivers superior efficiency, reliability, & performance. GPU Tweak helps you modify clock speeds, voltages, fan performance & more, all via an intuitive interface. Specifications Graphics Engine
- Nvidia Ge Force GTX 660 Bus Standard
- PCI-Express 3.0 Video Memory
- 2048MB GDDR5 GPU Boost Clock
- 1085 M Hz GPU Base Clock
- 1020 M Hz Cuda Cores
- 960 Memory Clock
- 6008 M Hz (1502 M Hz GDDR5) Memory Interface
- 192bit Outputs
- Dual DVI, Display Port, HDMI HDCP compliant
- Yes Power consumption
- Up to 150W (1 x 6pin power adapter required)










...

Asus Geforce GTX 750 1GB GDDR5 DVI HDMI PCI-E Graphics Card Dust-proof fan resists dust & particles for 25% longer graphics card longevity. Premium alloys in power delivery components defeat heat for cards that run 15% faster & last 2.5 times longer than reference. 1137 MHZ engine clock for better performance & outstanding gaming experience. GPU Tweak helps you modify clock speeds, voltages, fan performance & more, all via an intuitive interface. GPU Tweak Streaming let you share on-screen action in real time – so others can watch live as games are played. Specifications: Graphics Engine
- NVIDIA Ge Force GTX 750 Bus Standard
- PCI Express 3.0 Video Memory
- GDDR5 1024MB Engine Clock GPU Boost Clock: 1137 MHz GPU Base Clock: 1059 MHz CUDA Core
- 512 Memory Clock
- 1253 MHz (5010 MHz GDDR5 ) Memory Interface
- 128-bit Resolution D-Sub Max Resolution: 2048x 1536 DVI Max Resolution: 2560x 1600 Interface D-Sub Output: Yes x 1 DVI Output: Yes x 1 (DVI-D) HDMI Output: Yes x 1 HDCP Support: Yes Power Consumption up to 75 Wno additional PCIe power required Software ASUS GPU Tweak & Driver ASUS Features OC Series Super Alloy Power

Dimensions 7.28 " x 4.53 " x 1.41 " Inch 18.49 x 11.50 x 3.58 Centimeter







...

Dust-proof fan resists dust & particles for 25% longer graphics card longevity. Premium alloys in power delivery components defeat heat for cards that run 15% faster & last 2.5 times longer than reference. GPU Tweak helps you modify clock speeds, voltages, fan performance & more, all via an intuitive interface. GPU Tweak Streaming let you share on-screen action in real time “ so others can watch live as games are played. Graphics Engine
- NVIDIA Ge Force GTX 750 Ti Bus Standard
- PCI Express 3.0 Video Memory
- GDDR5 2GB Engine Clock: GPU Boost Clock: 1085 MHz GPU Base Clock: 1020 MHz CUDA Core
- 640 Memory Clock
- 1350 MHz (5400 MHz GDDR5 ) Memory Interface
- 128-bit Resolution
- DVI Max Resolution: 2560x 1600 Interface: D-Sub Output: Yes x 1 DVI Output: Yes x 2 (DVI-D) HDMI Output: Yes x 1 HDCP Support: Yes Power Consumption up to 150W1 additional 6 pin PCIe power required Software: ASUS GPU Tweak & Driver ASUS Features Super Alloy Power Dimensions: 7.165 " x 4.527 " x 1.53 " Inch 18.2 x 11.5 x 3.9 Centimeter






...

Incredible Performance Make way for the Asus GTX 750 Ti OC 2GB GDDR5 Dual DVI HDMI graphic card, this card means business. It arrives with dual fans, GPU tweak technology & premium alloys. The fans are optimised for maximum airflow driving twice the amount of normal air across the cooling fins. The other amazing enhancement from Asus on the GTX 750 Ti OC 2GB GDDR5 Dual DVI HDMI PCI-E Graphics card is the three times quieter cooling from the fans, Asus have managed to reduce the fan noise levels whilst increasing the effectiveness of the twin fans giving the GTX 750 Ti “ Incredible Performance”. Don't take my word for it, the card is that good it has won awards: It has won the Overclock 3D.NET gamers choice outright. They know their stuff because these are gamers. Another well known company by gamers is KITGURU & after their review they have awarded the Asus GTX 750 Ti OC 2GB GDDR5 Dual DVI HDMI PCI-E Graphics card one of their most sought after accolades; the ' Worth Buying' Award. What do buyers of this card think? 70% rated this graphics card at 10/10 No buyer left any negative comments Features buyer loved Speed, Price & power consumption Features buyers didn’t like – “ None” David Herne Bay IT Engineer Good Points + excellent card for the money, also needs little power so will run on 350w PSU Bad Points − Reviewer left no comment Review Rating 10/10 David Bath Good Points + This graphics card gave my pc a new lease of life. Combined with the SSD drive it has turned into a beast. Bad Points − None as yet. Totally happy Review Rating 10/10 8 out of 10 Jeremy S. York's Good Points + Simple fit, quiet less power consumption faster card. Bad Points − None yet, am I expecting some? Review Rating 10/10 Specifications: Model
- GT X750TI-OC-2GD5 Graphic Engine NVIDIA Ge Force GTX750TI Bus Standard PCI Express 3.0 Open GL Open GL 4.4 Video memory 2GB GDDR5 Engine Clock (Base)1072MHZ (overclocked) Engine clock (boost) 1150 MHz (overclocked) Cuda Cores 64 Memory Clock 1350 MHz (5400 MHz GDDR5) Memory Interface 128 bit DVI Max. Resolution 2560*1600 D-sub Output 1x Native DVI Output 2x Native Dual-link DVI-D HDMI Output 1 x Native HDMI HDCP Compliant YES Sofwarehouse Bundled ASUS GPU Tweak & Driver Dimenision 21.8 x 11.5 x 3.9 cm Verdict: "it's a rocket sled on rails" Asus GTX 750 Ti OC 2GB GDDR5 Dual DVI HDMI NVIDIA Features NVIDIA Ge Force Experience Want to know the best settings to play your games? Ge Force Experience will figure it out for you. Ge Force Experience connects you to NVIDIA’s cloud datacenter to download optimal game settings tailored to your PC based on your CPU, GPU & monitor. Optimal settings maximize image quality while maintaining great performance so you get the best experience. A built-in interactive screenshot viewer helps you learn more about each setting & their benefits. The Ge Force Experience application automatically notifies you of new driver releases from NVIDIA. With a single click, you’ll be able to update the driver directly, without leaving your desktop. NVIDIA TXAA Technology Film studios invest enormous resources in developing advanced technologies & post-production effects to deliver visually spectacular experiences for movie-goers. For games to achieve this level of fidelity, developers need new anti–aliasing technologies that deliver a viewing experience that eliminates the distraction of unrealistic, jagged lines (”jaggies”) & aliased shimmering–without compromising performance. NVIDIA is making this happen today, bringing cinema-quality graphics to life in blockbuster gaming titles with an innovative new temporal antialiasing technology called TXAA. Available exclusively on Ge Force GTX Kepler-powered GPUs, TXAA is designed to be directly integrated into game engines. Plus, it combines the raw power of MSAA (multi–sample anti–aliasing) with a temporal filter & sophisticated resolve filters similar to those used in CG films. The end result is a smoother, more lifelike image than any other comparable technique. NVIDIA FXAA Technology FXAA is a NVIDIA-developed post-processing technique that selectively blurs a game’s graphics to tackle unsightly jagged edges & high-contrast pixel deviation. Gaining popularity amongst developers due to its low performance impact & its ability to anti-alias transparent textures & details, FXAA is highly recommended for low-end & mid-range systems. NVIDIA GPU Boost 2.0 Technology Up until now, GPUs have operated at a fixed clock speed when playing 3D games, even if they have the potential to run faster. GPU Boost intelligently monitors graphics work load & increases the clock speed whenever possible. The result is that the GPU always performs at its peak & you get the highest framerate possible. With NVIDIA GPU Boost 2.0 Enjoy new levels of customization with advanced controls like GPU temperature target, overclocking, & overvoltage. NVIDIA Adaptive V-Sync Technology Nothing is more distracting than framerate stuttering & screen tearing. The first tends to occur when framerates are low, the second when framerates are high. Adaptive V-Sync is a smarter way to render frames. At high framerates, V-sync is enabled to eliminate tearing, at low frame rates, it's disabled to minimize stuttering. It gets rid of distractions so you can get on with gaming. NVIDIA Phys X Technology Phys X is designed specifically for hardware acceleration by powerful processors with hundreds of cores. Combined with the tremendous parallel processing capability of the GPU, Phys X will provide an exponential increase in physics processing power & will take gaming to a new level delivering rich, immersive physical gaming environments. NVIDIA CUDA Technology NVIDIA CUDA technology is the world’s only C language environment that enables programmers & developers to write software to solve complex computational problems in a fraction of the time by tapping into the many-core parallel processing power of GPUs. With millions of CUDA-capable GPUs already deployed, thousands of software programmers are already using the free CUDA software tools to accelerate applications—from video & audio encoding to oil & gas exploration, product design, medical imaging, & scientific research. NVIDIA Surround with up to 4 Monitors Nothing is as breathtaking as playing your favorite games across three monitors. At 5760 x 1080, the expanded field of view fully engages human peripheral vision & provides for the most immersive experience in racing & flight simulators. Add in a fourth display to keep tabs on chat, email or web while you are gaming. NVIDIA 3D Vision NVIDIA 3D Vision brings a fully immersive, stereoscopic 3D experience to the PC. A combination of high-tech wireless glasses & advanced software, 3D Vision transforms hundreds of PC games into full stereoscopic 3D. Get up to 2x monitor & keyboard brightness with NVIDIA 3D Light Boost technology. In addition, you can enjoy 3D movies & 3D digital photographs from 3 D Vision Live.com in eye popping, crystal-clear quality.
...

1202 MHz boost clock for up to 7.7% faster game performance. Direct CU II with 0d B fan technology lets you enjoy light games in complete silence, & hardcore gaming 58% cooler with 3X-quieter performance. Premium alloys in power delivery components defeat heat for cards that run 15% faster & last 2.5 times longer than reference. G-sync supports to deliver the smoothest & fastest faming experience by synchronizing display refresh rates to the GPU, eliminating screen tearing & minimizing display stutter & input lag. GPU Tweak helps you modify clock speeds, voltages, fan performance & more, all via an intuitive interface. GPU Tweak Streaming share on-screen action in real time – so others can watch live as games are played. Specifications Graphics Engine
- NVIDIA Ge Force GTX 750 Ti Bus Standard
- PCI Express 3.0 Video Memory
- GDDR5 2GB Engine Clock
- GPU Boost Clock: 1202 MHz, GPU Base Clock: 1124 MHz CUDA Core
- 640 Memory Clock
- 5400 MHz (MHz GDDR5 ) Memory Interface
- 128-bit Interface
- DVI Output: Yes x 1 (DVI-I), HDMI Output: Yes x 1, Display Port: Yes x 1 (Regular DP), HDCP Support: Yes Power Consumption
- up to 75 Wno additional PCIe power required

Dimensions
- 7.7 " x 4.8 " x 1.5 " Inch, 19.6 x 12.2 x 3.81 Centimeter Note To have the best cooling performance, ASUS STRIX-GTX750TI-OC-2GD5 extends the fansink to 2 slots. Please double check you Chassis & Motherboard dimension prior to purchase to make sure it fits in your system! Note that the actual boost clock will vary depending on actual system conditions.











...

Direct CU Mini with vapor chamber offers 20% (7.5&8451;) cooler & 3X quieter performance New & advanced Cool Tech Fan drives wider airflow to keep critical components cool Direct Power ensures stable performance with 56% less impedance & a 17% cooler PCB Super Alloy Power components increase product longevity by up to 2.5X compared to reference GPU Tweak helps you modify clock speeds, voltages, fan performance & more, all via an intuitive interface Graphics Engine
- NVIDIA Ge Force GTX 760 Bus Standard
- PCI Express 3.0 Video Memory
- GDDR5 2GB Engine Clock: GPU Boost Clock: 1072 MHz GPU Base Clock: 1006 MHz CUDA Core
- 1152 Memory Clock
- 6008 MHz (1502 MHz GDDR5 ) Memory Interface
- 256-bit Resolution
- DVI Max Resolution: 2560x 1600 Interface: DVI Output: Yes x 1 (DVI-I), Yes x 1 (DVI-D) HDMI Output: Yes x 1 Display Port: Yes x 1 (Regular DP) Accessories
- 1 x Power cable Software
- ASUS GPU Tweak & Driver ASUS

Features: Direct CU Mini Series OC Series Super Alloy Power Dimensions: 6.7 " x 4.8 " x 1.6 " Inch 17.01 x 12.19 x 4.06 Centimeter NVIDIA Features NVIDIA Ge Force Experience Want to know the best settings to play your games? Ge Force Experience will figure it out for you. Ge Force Experience connects you to NVIDIA’s cloud datacenter to download optimal game settings tailored to your PC based on your CPU, GPU & monitor. Optimal settings maximize image quality while maintaining great performance so you get the best experience. A built-in interactive screenshot viewer helps you learn more about each setting & their benefits. The Ge Force Experience application automatically notifies you of new driver releases from NVIDIA. With a single click, you’ll be able to update the driver directly, without leaving your desktop. NVIDIA Kepler GPU Architecture NVIDIAs Kepler GPU architecture has been designed from the ground up not just for maximum performance in the latest Direct X 11 games, but optimal performance per watt. The new SMX streaming multiprocessor is twice as efficient as the prior generation & the new geometry engine draws triangles twice as fast. The result is world class performance & the highest image quality in an elegant & power efficient graphics card. NVIDIA TXAA Technology Film studios invest enormous resources in developing advanced technologies & post-production effects to deliver visually spectacular experiences for movie-goers. For games to achieve this level of fidelity, developers need new anti–aliasing technologies that deliver a viewing experience that eliminates the distraction of unrealistic, jagged lines (”jaggies”) & aliased shimmering–without compromising performance. NVIDIA is making this happen today, bringing cinema-quality graphics to life in blockbuster gaming titles with an innovative new temporal antialiasing technology called TXAA. Available exclusively on Ge Force GTX Kepler-powered GPUs, TXAA is designed to be directly integrated into game engines. Plus, it combines the raw power of MSAA (multi–sample anti–aliasing) with a temporal filter & sophisticated resolve filters similar to those used in CG films. The end result is a smoother, more lifelike image than any other comparable technique. NVIDIA FXAA Technology FXAA is a NVIDIA-developed post-processing technique that selectively blurs a game’s graphics to tackle unsightly jagged edges & high-contrast pixel deviation. Gaining popularity amongst developers due to its low performance impact & its ability to anti-alias transparent textures & details, FXAA is highly recommended for low-end & mid-range systems. NVIDIA GPU Boost 2.0 Technology Up until now, GPUs have operated at a fixed clock speed when playing 3D games, even if they have the potential to run faster. GPU Boost intelligently monitors graphics work load & increases the clock speed whenever possible. The result is that the GPU always performs at its peak & you get the highest framerate possible. With NVIDIA GPU Boost 2.0 Enjoy new levels of customization with advanced controls like GPU temperature target, overclocking, & overvoltage. NVIDIA Adaptive V-Sync Technology Nothing is more distracting than framerate stuttering & screen tearing. The first tends to occur when framerates are low, the second when framerates are high. Adaptive V-Sync is a smarter way to render frames. At high framerates, V-sync is enabled to eliminate tearing, at low frame rates, its disabled to minimize stuttering. It gets rid of distractions so you can get on with gaming. NVIDIA Phys X Technology Phys X is designed specifically for hardware acceleration by powerful processors with hundreds of cores. Combined with the tremendous parallel processing capability of the GPU, Phys X will provide an exponential increase in physics processing power & will take gaming to a new level delivering rich, immersive physical gaming environments. NVIDIA CUDA Technology NVIDIA CUDA technology is the world’s only C language environment that enables programmers & developers to write software to solve complex computational problems in a fraction of the time by tapping into the many-core parallel processing power of GPUs. With millions of CUDA-capable GPUs already deployed, thousands of software programmers are already using the free CUDA software tools to accelerate applications—from video & audio encoding to oil & gas exploration, product design, medical imaging, & scientific research. NVIDIA Surround with up to 4 Monitors Nothing is as breathtaking as playing your favorite games across three monitors. At 5760 x 1080, the expanded field of view fully engages human peripheral vision & provides for the most immersive experience in racing & flight simulators. Add in a fourth display to keep tabs on chat, email or web while you are gaming. NVIDIA 3D Vision NVIDIA 3D Vision brings a fully immersive, stereoscopic 3D experience to the PC. A combination of high-tech wireless glasses & advanced software, 3D Vision transforms hundreds of PC games into full stereoscopic 3D. Get up to 2x monitor & keyboard brightness with NVIDIA 3D Light Boost technology. In addition, you can enjoy 3D movies & 3D digital photographs from 3 D Vision Live.com in eye popping, crystal-clear quality. NVIDIA SLI Technology Used by the most demanding gamers worldwide, SLI lets you link up to three Ge Force GTX 780s together for astounding performance. & with NVIDIA’s track record for fast & frequent software updates, you’ll not only get the best performance in existing games, but future games too.










...

Dual Ge Force GTX 760 GPUs provide 14% faster game performance Exclusive Direct CU II with 8 heatpipes deliver 20% cooler & vastly quieter than GTX 690 Acclaimed DIGI+ VRM joins superior quality 12-phase Super Alloy Power to drive precise digital control for enhanced performance, reliability, & card longevity Japan-made black metallic capacitors 20% better temperature endurance & 5X longer lifetime usage MARS LED light pulsates in red when the card is active GPU Tweak: modify clock speeds, voltage & more via an intuitive interface Graphics Engine
- NVIDIA Ge Force GTX 760x 2 Bus Standard
- PCI Express 3.0 Video Memory
- GDDR5 4GB GPU Boost Clock: 1072 MHz GPU Base Clock: 1006 MHz CUDA Core
- 2304 Memory Clock
- 6004 MHz (1501 MHz GDDR5 ) Memory Interface
- 512-bit DVI Output: Yes x 2 (DVI-I), Yes x 1 (DVI-D) HDMI Output: Yes x 1 (via DVI to HDMI adaptor x 1 ) Display Port: Yes x 1 (Mini DP) HDCP Support: Yes

Dimensions
- 11 " x 4.38 " x 1.6 " Inch NVIDIA Features NVIDIA Ge Force Experience Want to know the best settings to play your games? Ge Force Experience will figure it out for you. Ge Force Experience connects you to NVIDIA’s cloud datacenter to download optimal game settings tailored to your PC based on your CPU, GPU & monitor. Optimal settings maximize image quality while maintaining great performance so you get the best experience. A built-in interactive screenshot viewer helps you learn more about each setting & their benefits. The Ge Force Experience application automatically notifies you of new driver releases from NVIDIA. With a single click, you’ll be able to update the driver directly, without leaving your desktop. NVIDIA Kepler GPU Architecture NVIDIAs Kepler GPU architecture has been designed from the ground up not just for maximum performance in the latest Direct X 11 games, but optimal performance per watt. The new SMX streaming multiprocessor is twice as efficient as the prior generation & the new geometry engine draws triangles twice as fast. The result is world class performance & the highest image quality in an elegant & power efficient graphics card. NVIDIA TXAA Technology Film studios invest enormous resources in developing advanced technologies & post-production effects to deliver visually spectacular experiences for movie-goers. For games to achieve this level of fidelity, developers need new anti–aliasing technologies that deliver a viewing experience that eliminates the distraction of unrealistic, jagged lines (”jaggies”) & aliased shimmering–without compromising performance. NVIDIA is making this happen today, bringing cinema-quality graphics to life in blockbuster gaming titles with an innovative new temporal antialiasing technology called TXAA. Available exclusively on Ge Force GTX Kepler-powered GPUs, TXAA is designed to be directly integrated into game engines. Plus, it combines the raw power of MSAA (multi–sample anti–aliasing) with a temporal filter & sophisticated resolve filters similar to those used in CG films. The end result is a smoother, more lifelike image than any other comparable technique. NVIDIA FXAA Technology FXAA is a NVIDIA-developed post-processing technique that selectively blurs a game’s graphics to tackle unsightly jagged edges & high-contrast pixel deviation. Gaining popularity amongst developers due to its low performance impact & its ability to anti-alias transparent textures & details, FXAA is highly recommended for low-end & mid-range systems. NVIDIA GPU Boost 2.0 Technology Up until now, GPUs have operated at a fixed clock speed when playing 3D games, even if they have the potential to run faster. GPU Boost intelligently monitors graphics work load & increases the clock speed whenever possible. The result is that the GPU always performs at its peak & you get the highest framerate possible. With NVIDIA GPU Boost 2.0 Enjoy new levels of customization with advanced controls like GPU temperature target, overclocking, & overvoltage. NVIDIA Adaptive V-Sync Technology Nothing is more distracting than framerate stuttering & screen tearing. The first tends to occur when framerates are low, the second when framerates are high. Adaptive V-Sync is a smarter way to render frames. At high framerates, V-sync is enabled to eliminate tearing, at low frame rates, its disabled to minimize stuttering. It gets rid of distractions so you can get on with gaming. NVIDIA Phys X Technology Phys X is designed specifically for hardware acceleration by powerful processors with hundreds of cores. Combined with the tremendous parallel processing capability of the GPU, Phys X will provide an exponential increase in physics processing power & will take gaming to a new level delivering rich, immersive physical gaming environments. NVIDIA CUDA Technology NVIDIA CUDA technology is the world’s only C language environment that enables programmers & developers to write software to solve complex computational problems in a fraction of the time by tapping into the many-core parallel processing power of GPUs. With millions of CUDA-capable GPUs already deployed, thousands of software programmers are already using the free CUDA software tools to accelerate applications—from video & audio encoding to oil & gas exploration, product design, medical imaging, & scientific research. NVIDIA Surround with up to 4 Monitors Nothing is as breathtaking as playing your favorite games across three monitors. At 5760 x 1080, the expanded field of view fully engages human peripheral vision & provides for the most immersive experience in racing & flight simulators. Add in a fourth display to keep tabs on chat, email or web while you are gaming. NVIDIA 3D Vision NVIDIA 3D Vision brings a fully immersive, stereoscopic 3D experience to the PC. A combination of high-tech wireless glasses & advanced software, 3D Vision transforms hundreds of PC games into full stereoscopic 3D. Get up to 2x monitor & keyboard brightness with NVIDIA 3D Light Boost technology. In addition, you can enjoy 3D movies & 3D digital photographs from 3 D Vision Live.com in eye popping, crystal-clear quality. NVIDIA SLI Technology Used by the most demanding gamers worldwide, SLI lets you link up to three Ge Force GTX 780s together for astounding performance. & with NVIDIA’s track record for fast & frequent software updates, you’ll not only get the best performance in existing games, but future games too.








...

This is the Asus Ge Force GTX 770, winner of both the VORTEZ GOLD Award & the five star player performance award. The GTX 770 Direct CU II 2GB GDDR5 HDMI DVI Display Port PCI-E Grpahics Card by Asus comes in with raised clock speeds, enhanced power delivery, overclocking & GPU Boost 2.0 making the GTX 770 a formiddable GPU. The card uses Direct CU II cooling & GPU tweak technology. The Direct CU II cooling has hightened levels of performance & lower levels of noise. Direct CU II has precision shaped SSU heatpipes which utilizes highly conductive copper & directly-centered GPU placement to double cooling efficiency in the same space. Also available on this card is DIGI+ VRM with 10-phase Super Alloy Power precise digital delivery for superior efficiency, reliability, & performance. GPU Tweak helps you modify clock speeds, voltages, fan performance & more, all via an intuitive software interface Specifications
- Graphics Engine
- Nvidia Ge Force GTX 770
- Bus Standard
- PCI Express 3.0
- Open GL
- Open GL 4.3
- Video MEmory
- 2040MB GDDR5
- GPU Boost Clock
- 1110 M Hz
- GPU Base Clock
- 1058 M Hz
- CUDA Cores
- 1536
- Memory Clock
- 7010 M Hz
- Memory Interface
- 256 bit
- DVI Output
- 1 x Native Dual-Link DVI-I; 1 x Native Dual-Link DVI-D
- HDMI Output
- 1 x Native HDMI
- HDCP Compliant
- Yes
- Display Port
- 1 x Native Display Port 1.2
-

Dimensions
- 10.7x 5.2x 1.36inches NVIDIA Features NVIDIA Ge Force Experience Want to know the best settings to play your games? Ge Force Experience will figure it out for you. Ge Force Experience connects you to NVIDIA’s cloud datacenter to download optimal game settings tailored to your PC based on your CPU, GPU & monitor. Optimal settings maximize image quality while maintaining great performance so you get the best experience. A built-in interactive screenshot viewer helps you learn more about each setting & their benefits. The Ge Force Experience application automatically notifies you of new driver releases from NVIDIA. With a single click, you’ll be able to update the driver directly, without leaving your desktop. NVIDIA Kepler GPU Architecture NVIDIAs Kepler GPU architecture has been designed from the ground up not just for maximum performance in the latest Direct X 11 games, but optimal performance per watt. The new SMX streaming multiprocessor is twice as efficient as the prior generation & the new geometry engine draws triangles twice as fast. The result is world class performance & the highest image quality in an elegant & power efficient graphics card. NVIDIA TXAA Technology Film studios invest enormous resources in developing advanced technologies & post-production effects to deliver visually spectacular experiences for movie-goers. For games to achieve this level of fidelity, developers need new anti–aliasing technologies that deliver a viewing experience that eliminates the distraction of unrealistic, jagged lines (”jaggies”) & aliased shimmering–without compromising performance. NVIDIA is making this happen today, bringing cinema-quality graphics to life in blockbuster gaming titles with an innovative new temporal antialiasing technology called TXAA. Available exclusively on Ge Force GTX Kepler-powered GPUs, TXAA is designed to be directly integrated into game engines. Plus, it combines the raw power of MSAA (multi–sample anti–aliasing) with a temporal filter & sophisticated resolve filters similar to those used in CG films. The end result is a smoother, more lifelike image than any other comparable technique. NVIDIA FXAA Technology FXAA is a NVIDIA-developed post-processing technique that selectively blurs a game’s graphics to tackle unsightly jagged edges & high-contrast pixel deviation. Gaining popularity amongst developers due to its low performance impact & its ability to anti-alias transparent textures & details, FXAA is highly recommended for low-end & mid-range systems. NVIDIA GPU Boost 2.0 Technology Up until now, GPUs have operated at a fixed clock speed when playing 3D games, even if they have the potential to run faster. GPU Boost intelligently monitors graphics work load & increases the clock speed whenever possible. The result is that the GPU always performs at its peak & you get the highest framerate possible. With NVIDIA GPU Boost 2.0 Enjoy new levels of customization with advanced controls like GPU temperature target, overclocking, & overvoltage. NVIDIA Adaptive V-Sync Technology Nothing is more distracting than framerate stuttering & screen tearing. The first tends to occur when framerates are low, the second when framerates are high. Adaptive V-Sync is a smarter way to render frames. At high framerates, V-sync is enabled to eliminate tearing, at low frame rates, its disabled to minimize stuttering. It gets rid of distractions so you can get on with gaming. NVIDIA Phys X Technology Phys X is designed specifically for hardware acceleration by powerful processors with hundreds of cores. Combined with the tremendous parallel processing capability of the GPU, Phys X will provide an exponential increase in physics processing power & will take gaming to a new level delivering rich, immersive physical gaming environments. NVIDIA CUDA Technology NVIDIA CUDA technology is the world’s only C language environment that enables programmers & developers to write software to solve complex computational problems in a fraction of the time by tapping into the many-core parallel processing power of GPUs. With millions of CUDA-capable GPUs already deployed, thousands of software programmers are already using the free CUDA software tools to accelerate applications—from video & audio encoding to oil & gas exploration, product design, medical imaging, & scientific research. NVIDIA Surround with up to 4 Monitors Nothing is as breathtaking as playing your favorite games across three monitors. At 5760 x 1080, the expanded field of view fully engages human peripheral vision & provides for the most immersive experience in racing & flight simulators. Add in a fourth display to keep tabs on chat, email or web while you are gaming. NVIDIA 3D Vision NVIDIA 3D Vision brings a fully immersive, stereoscopic 3D experience to the PC. A combination of high-tech wireless glasses & advanced software, 3D Vision transforms hundreds of PC games into full stereoscopic 3D. Get up to 2x monitor & keyboard brightness with NVIDIA 3D Light Boost technology. In addition, you can enjoy 3D movies & 3D digital photographs from 3 D Vision Live.com in eye popping, crystal-clear quality. NVIDIA SLI Technology Used by the most demanding gamers worldwide, SLI lets you link up to three Ge Force GTX 780s together for astounding performance. & with NVIDIA’s track record for fast & frequent software updates, you’ll not only get the best performance in existing games, but future games too.





























...

Asus GTX780-DC2 3GB GDDR5 Dual DVI HDMI Display Port PCI-E Graphics Card Graphics Engine NVIDIA Ge Force GTX 780 Bus Standard PCI Express 3.0 Video Memory GDDR5 3GB Engine Clock GPU Boost Clock: 902 MHz GPU Base Clock: 863 MHz CUDA Core 2304 Memory Clock 6008 MHz (1502 MHz GDDR5 ) Memory Interface 384-bit Interface DVI Output: Yes x 1 (DVI-I), Yes x 1 (DVI-D) HDMI Output: Yes x 1 Display Port: Yes x 1 (Regular DP) HDCP Support: Yes Power Consumption up to 300 Wadditional 6+8 pin PCIe power required Software ASUS GPU Tweak & Driver ASUS Features Direct CU Series Super Alloy Power

Dimensions 11.3 " x 5.8 " x 1.6 " Inch 28.7 x 14.73 x 4.06 Centimeter

...

ASUS Ge Force GTX 780 Direct CU II graphics cards feature an ASUS-designed PCB & a completely new look for the Direct CU II cooler, as well as DIGI+ VRM digital power delivery & robust Super Alloy Power components. Ge Force GTX 780 Direct CU II cards use an NVIDIA GK110-300 GPU with 2304 CUDA cores. They ship with 3GB GDDR5 video memory on a 384-bit interface. For avid PC gamers who demand ultra-high detail & readiness for resolutions beyond full HD 1080p, Ge Force GTX 780 Direct CU II cards deliver extreme cooling, stability, & endurance well above reference card standards. Graphics Engine
- NVIDIA Ge Force GTX 780 Bus Standard
- PCI Express 3.0 Video Memory
- GDDR5 3GB Engine Clock GPU Boost Clock: 941 MHz GPU Base Clock: 889 MHz CUDA Core
- 2304 Memory Clock
- 6008 MHz (1502 MHz GDDR5 ) Memory Interface
- 384-bit Interface: DVI Output: Yes x 1 (DVI-I), Yes x 1 (DVI-D) HDMI Output: Yes x 1 Display Port: Yes x 1 (Regular DP) HDCP Support: Yes Power Consumption
- up to 300 Wadditional 6+8 pin PCIe power required Software
- ASUS GPU Tweak & Driver ASUS Features Direct CU Series OC Series Super Alloy Power Dimensions: 11.3 " x 5.8 " x 1.6 " Inch 28.7 x 14.73 x 4.06 Centimeter To have the best cooling performance, ASUS GTX780-DC2OC-3GD5 extends the fansink to 2 slots. Please double check you Chassis & Motherboard dimension prior to purchase to make sure it fits in your system! Note that the actual boost clock will vary depending on actual system conditions. For more information, please visit http://www.geforce.com/ Specifications are subject to change without notice. PCB color & bundled software versions are change without notice. Brand & product names mentioned are trademarks of their respective company. The new Ge Force GTX 780 marks an evolution in gaming performance—an insanely fast, smooth, & whisper-quiet experience. It’s perfectly tuned to today’s most advanced gaming technologies with Ge Force Experience for one-click driver & setting optimisation, plus NVIDIA Phys X & TXAA for smooth, sharp graphics. With GTX 780, experience pure performance. ASUS Exclusive Features DIGI+ VRM with Super Alloy Power Acclaimed DIGI+ VRM has been applied via a 10-phase power design that uses digital voltage regulators to minimize power noise by 30%, enhance power efficiency by 15%, widen voltage modulation tolerance, & improve overall stability & longevity by 2.5 times over reference. GPU Tweak Overclocking is made real-time & intuitive with ASUS GPU Tweak utility. It not only means that you can optimize clock speeds, voltage & fan speeds on up to four graphics cards independently or simultaneously, you can also select between GPU Tweak’s Standard or Advanced modes depending on your level of experience. For gamers out there, GPU Tweak enables instantaneous in-game video recording up to 720p resolution so you can share clips with the community easily. Cool Tech Fan Proprietary Cool Tech fan consists of a hybrid blade & bearing design, with inner radial blower & outer flower-type blades. These provide multi-directional airflow to accelerate heat removal & enable highly stable graphics performance. Direct CU II Exclusive Direct CU II thermal design

Includes:: a direct-GPU contact 10mm copper heatpipe & 220% larger dissipation area to boost heat removal efficiency. It performs 30% cooler & 3X quieter than reference. NVIDIA Features NVIDIA Ge Force Experience Want to know the best settings to play your games? Ge Force Experience will figure it out for you. Ge Force Experience connects you to NVIDIA’s cloud datacenter to download optimal game settings tailored to your PC based on your CPU, GPU & monitor. Optimal settings maximize image quality while maintaining great performance so you get the best experience. A built-in interactive screenshot viewer helps you learn more about each setting & their benefits. The Ge Force Experience application automatically notifies you of new driver releases from NVIDIA. With a single click, you’ll be able to update the driver directly, without leaving your desktop. NVIDIA Kepler GPU Architecture NVIDIAs Kepler GPU architecture has been designed from the ground up not just for maximum performance in the latest Direct X 11 games, but optimal performance per watt. The new SMX streaming multiprocessor is twice as efficient as the prior generation & the new geometry engine draws triangles twice as fast. The result is world class performance & the highest image quality in an elegant & power efficient graphics card. NVIDIA TXAA Technology Film studios invest enormous resources in developing advanced technologies & post-production effects to deliver visually spectacular experiences for movie-goers. For games to achieve this level of fidelity, developers need new anti–aliasing technologies that deliver a viewing experience that eliminates the distraction of unrealistic, jagged lines (”jaggies”) & aliased shimmering–without compromising performance. NVIDIA is making this happen today, bringing cinema-quality graphics to life in blockbuster gaming titles with an innovative new temporal antialiasing technology called TXAA. Available exclusively on Ge Force GTX Kepler-powered GPUs, TXAA is designed to be directly integrated into game engines. Plus, it combines the raw power of MSAA (multi–sample anti–aliasing) with a temporal filter & sophisticated resolve filters similar to those used in CG films. The end result is a smoother, more lifelike image than any other comparable technique. NVIDIA FXAA Technology FXAA is a NVIDIA-developed post-processing technique that selectively blurs a game’s graphics to tackle unsightly jagged edges & high-contrast pixel deviation. Gaining popularity amongst developers due to its low performance impact & its ability to anti-alias transparent textures & details, FXAA is highly recommended for low-end & mid-range systems. NVIDIA G-SYNC Technology NVIDIA G-SYNC is a groundbreaking new innovation that casts aside decades-old thinking to create the smoothest, most responsive computer displays ever seen. A monitor module you can install yourself, or buy pre-installed in gamer-focused monitors, NVIDIA G-SYNC waves goodbye to the days of screen tearing, input lag, & eyestrain-inducing stuttering caused by decades-old tech lazily carried over from analog TVs to modern-day monitors. NVIDIA GPU Boost 2.0 Technology Up until now, GPUs have operated at a fixed clock speed when playing 3D games, even if they have the potential to run faster. GPU Boost intelligently monitors graphics work load & increases the clock speed whenever possible. The result is that the GPU always performs at its peak & you get the highest framerate possible. With NVIDIA GPU Boost 2.0 Enjoy new levels of customization with advanced controls like GPU temperature target, overclocking, & overvoltage. NVIDIA Adaptive V-Sync Technology Nothing is more distracting than framerate stuttering & screen tearing. The first tends to occur when framerates are low, the second when framerates are high. Adaptive V-Sync is a smarter way to render frames. At high framerates, V-sync is enabled to eliminate tearing, at low frame rates, its disabled to minimize stuttering. It gets rid of distractions so you can get on with gaming. NVIDIA Phys X Technology Phys X is designed specifically for hardware acceleration by powerful processors with hundreds of cores. Combined with the tremendous parallel processing capability of the GPU, Phys X will provide an exponential increase in physics processing power & will take gaming to a new level delivering rich, immersive physical gaming environments. NVIDIA CUDA Technology NVIDIA CUDA technology is the world’s only C language environment that enables programmers & developers to write software to solve complex computational problems in a fraction of the time by tapping into the many-core parallel processing power of GPUs. With millions of CUDA-capable GPUs already deployed, thousands of software programmers are already using the free CUDA software tools to accelerate applications—from video & audio encoding to oil & gas exploration, product design, medical imaging, & scientific research. NVIDIA Surround with up to 4 Monitors Nothing is as breathtaking as playing your favorite games across three monitors. At 5760 x 1080, the expanded field of view fully engages human peripheral vision & provides for the most immersive experience in racing & flight simulators. Add in a fourth display to keep tabs on chat, email or web while you are gaming. NVIDIA 3D Vision NVIDIA 3D Vision brings a fully immersive, stereoscopic 3D experience to the PC. A combination of high-tech wireless glasses & advanced software, 3D Vision transforms hundreds of PC games into full stereoscopic 3D. Get up to 2x monitor & keyboard brightness with NVIDIA 3D Light Boost technology. In addition, you can enjoy 3D movies & 3D digital photographs from 3 D Vision Live.com in eye popping, crystal-clear quality. NVIDIA SLI Technology Used by the most demanding gamers worldwide, SLI lets you link up to three Ge Force GTX 780s together for astounding performance. & with NVIDIA’s track record for fast & frequent software updates, you’ll not only get the best performance in existing games, but future games too.









...
