The AT-GS900 series of unmanaged Gigabit Layer 2+ switches offer seamless & simple connectivity to your existing network infrastructure. Wall, desk, & rack-mounting options give you the flexibility to chose a model that meets your deployment needs. Please note: networking components such as switches, routers & wireless devices require that speeds & standards be consistent throughout the network to gain optimum performance. To avoid compatibility clashes or for advice, please contact us on solutions@ebuyer.com. ...

Founded with the goal of producing reliable, standards-based networking products, Allied Telesis bridges the gap left by other Ethernet networking manufacturers, whose solutions are limited in scope or cost-prohibitive. The AT-MCF2000AC module is an AC power supply unit for the AT-MCF2000 series of media converter chassis The power supply module has two LEDs
- PSU
- FAN

Specification Input Voltage 100-240 VAC 50/60 Hz Output Voltage 12 volts & 3.3 volts Operating Temperature: 0° C to 40° C
- (32° F to 104° F) Storage Temperature: -20° C to 70° C
- (-° 4F to 158° F) Operating Humidity: Less than 80% noncondensing Storage Humidity: Less than 95% noncondensing Maximum Operating Altitude: 3, 048 m (10, 000 ft) Maximum Nonoperating Altitude: 4, 000 m (13, 000 ft)





...

The Allied Telesis AT-FS716 series provides powerful 10/100 switching solutions to desktop & small network environments. Each switch features full autonegotiating 10/100 ports, which automatically detect speed & duplex modes of attached devices & allow the switch to automatically configure for the best possible performance. Choose from 5, 8, 16, or 24 port models. With both internal or external power supplies, the AT-FS700 series can meet a multitude of power requirements. Wall, desk, & rack mounting options give users ultimate flexibility in choosing a model to meet their physical deployment requirements. The AT-FS700 series switches are fully auto-configuring requiring minimal or no set-up by the user. The autosensing ports allow seamless & simple connectivity between existing 10 Mbps Ethernet & 100 Mbps Fast Ethernet UTP devices, & all units can be installed in minutes. All models are equipped with a MDI/MDIX port (s) for simple connection to other hubs & switches. Front panel LEDs allow users to monitor the switch status providing simple "at a glance" management. Please note: networking components such as switches, routers & wireless devices require that speeds & standards be consistent throughout the network to gain optimum performance. To avoid compatibility clashes or for advice, please contact us on solutions@ebuyer.com. ...

The Allied Telesis' range of Fast Ethernet media converters allows users to extend the size of UTP networks with the use of fiber cabling. Converting between 100 Base-TX or 100 Base-FX Multi-mode & 100 Base-FX Single-mode " Long Haul" quickly & reliably, the AT-MC103LH & AT-MC104LH can be used to extend networks with up to 40km of fiber. The AT-MC103LH (with UTP connection) features an internal MDI/MDIX switch, allowing the converter to be connected to a PC, hub or switch with a simple UTP cable. Both media converters also allow the installer to test the integrity of fiber connection, by forcing the converters to communicate over the fiber cable. This Link Test feature allows installers to check for cable faults without the need for expensive fiber optic test equipment. Please note: networking components such as switches, routers, UPS & wireless devices require that speeds & standards be consistent throughout the network to gain optimum performance. To avoid compatibility clashes or for advice, please contact us on solutions@ebuyer.com. ...

Allied Telesis' simply connects the IP world with affordable, highly reliable, end-to-end networking solutions. The company's broad line of networking products builds systems that meet today's demand for efficient, effective connectivity
- in small networks, across the enterprise, & over remote links. Allied Telesis' makes the most challenging network designs a reality, with a variety of products for network systems that optimize for any distance, speed, security or legacy integration priority. For maximum protection against service interruption, Allied Telesis' offers a hot-swappable auxiliary power supply unit, the AT-PWR4. The AT-PWR4 provides automatic load balancing for one or two power supplies & on-the-fly switching in case of power supply failure.
...

The AT-GS2002/SP Ethernet bridging converters are designed to extend the distance of your network by interconnecting LAN devices that are physically separated by large distances. These bridging converters have the functionality to connect any managed/unmanaged 10 Mbps, 100 Mbps, or 1000 Mbps (1 Gbps) switch or hub using standard 10/100/1000T RJ-45 connections & convert the electrical signal to fiber optical signal via its SFP port. ...

The Allied Telesis AT-FS700FC series switches provide powerful 10/100 switching solutions with 100FX backbone connectivity to desktop & small network environments. Full auto-negotiating 10/100 ports automatically detect speed & duplex modes of attached devices & allow the switch to automatically configure for the best possible performance. The AT-FS717FC is rackmountable. Each AT-FS700FC series switch also provides an additional fiber optic interface port to allow deployment up to 2km from other network connections. The AT-FS700FC series switches are fully auto-configuring requiring minimal or no setup by the user. The auto-sensing ports allow seamless & simple connectivity between existing 10 Mbps Ethernet & 100 Mbps Fast Ethernet UTP devices & all units can be installed in minutes. Front panel LEDs allow users to monitor the switch status providing simple "at a glance" management. Allied Telesis is the worldwide leader in unmanaged Ethernet devices & offers proven reliability, industry recognized quality & unique support. Please note: networking components such as switches, routers & wireless devices require that speeds & standards be consistent throughout the network to gain optimum performance. To avoid compatibility clashes or for advice, please contact us on solutions@ebuyer.com. ...

Allied Telesis simply connects the IP world with affordable, highly reliable, end-to-end networking solutions. The companys broad line of networking products builds systems that meet todays demand for efficient, effective connectivity
- in small networks, across the enterprise, & over remote links. Allied Telesis makes the most challenging networks designs a reality, with a variety of products for network systems that optimize for any distance, speed, security or legacy integration priority. &, as always, Allied Telesis commitment to quality, efficiency, security, ease of use & low cost of ownership is backed by the industrys best warranties & technical support.
...

The AT-FS708LE is an ideal fit for small business networks. The robust metal chassis can be mounted to the wall or desktop. The AT-FS708LE is fully auto-configuring, which means minimal set up for you. Auto-sensing ports connect existing 10 Mbps Ethernet & 100 Mbps Fast Ethernet UTP devices seamlessly. Auto MDI/MDIX on all ports easily connect other hubs & switches. The user friendly front panel shows ongoing switch status & simplifies troubleshooting. Please note: networking components such as switches, routers & wireless devices require that speeds & standards be consistent throughout the network to gain optimum performance. To avoid compatibility clashes or for advice, please contact us on solutions@ebuyer.com. ...

Allied Telesis'' AT-MC1004 Gigabit Ethernet media converters extend the reach of Gigabit Ethernet networks through the use of multi-mode & single-mode fiber-optic cabling. By converting 1000T copper connections to 1000SX or LX connections, these Gigabit Ethernet media converters can extend segment lengths up to 10km. Although the provisioning of Gigabit Ethernet connections is becoming relatively inexpensive, thanks in part to the availability of lower-cost copper Gigabit network adapters, the distance limitations of copper cabling make fiber segments a necessity in most networks. Small, comparatively inexpensive copper to fiber Gigabit Ethernet media converters present a simple & very cost-effective way of connecting Gigabit Ethernet LANs over extended distances. To aid installation these media converters support an auto-sense MDI/MDIX port, allowing the media converter to connect directly with either a switch, PC adapter, or other Gigabit Ethernet device, using a standard cable. The AT-MC1004 Gigabit Ethernet media converters are powered by an external power supply for use in standalone applications. Where multiple media converters are used, up to 12 standalone devices can be inserted into the low-cost AT-MCR12 rackmount chassis, allowing all the converters to be powered by a single internal power supply. In critical applications, a second load sharing internal power supply can be installed into the rackmount chassis. ...
