Remotely manage an industrial RS232 or RS422/485 serial device over an IP network, with redundant 10/100 Ethernet ports. The NETRS232485 Serial Device Server lets you remotely manage an industrial RS232/422/485 serial device over a local or wide area network (LAN/WAN), with redundant power inputs & dual 10/100 Mbps Ethernet ports. To minimize downtime, this intuitive dual Ethernet serial over IP solution maintains connection to your critical equipment by automatically switching to its secondary LAN port within 10 milliseconds of a network failure or disruption. Ideal for industrial environments, the serial to Ethernet device server accepts wide-range 12-48V DC power input via a terminal block or an optional DC jack, enabling you to add redundant power with a secondary adapter (e.g. 12V DC 1.5A Power Adapter SKU: IM12D1500P
- sold separately), keeping the device server functional in the event of power surges or failures. This device server supports baud rates up to 460.8 Kbps which provides a smooth, high-speed connection to your serial devices. The device server also offers support for HTTPS, SSH & SSL to ensure secure communication, while integrating remote Telnet configuration & support for IP, HTTP, ICMP, DHCP, ARP, TCP & UDP protocols. You can customize the serial device server to suit your application with versatile browser-based or virtual com port software configuration. Ensuring performance in harsh environments, this serial device server offers 8KV air, & 4KV contact ESD (Electrostatic Discharge) Protection, & features a rugged, IP-30 case design that is both DIN rail & wall-mountable, with an extended operating temperature range (-40°C to 70°C).
...

Connect to, configure & remotely manage an RS232 or RS422/485 serial device over a Wi Fi/wired connection. The NETRS232485W Wireless Serial over IP Device Server lets you remotely access & manage an industrial serial device over a Wi Fi or wired network, with the added benefit of redundant power inputs to prevent downtime in the event of a power surge or failure. To eliminate the hassle of laying additional Ethernet cable, this wireless device server lets you connect your RS232/422/485 serial device in a location where a wired network connection is unavailable, with support for 802.11 B/G Wi Fi connections & a 10/100 Mbps wired network port for added flexibility. Ideal for industrial environments, the serial to Ethernet device server accepts wide-range 12-48V DC power input via a terminal block or an optional DC jack, enabling you to add redundant power with a secondary adapter (e.g. 12V DC 1.5A Power Adapter SKU: IM12D1500P
- sold separately). This device server supports baud rates up to 230.4 Kbps which provides a smooth connection to your serial devices. The server also offers support for HTTPS, SSH & SSL to ensure secure communication, while integrating remote Telnet configuration & support for IP, HTTP, ICMP, DHCP, TCP & UDP protocols. You can customize the serial device server to suit your application with versatile browser-based or virtual com port software configuration. Ensuring performance in harsh environments, this serial device server offers 8KV air, & 4KV contact ESD (Electrostatic Discharge) protection & features a rugged, IP-30 case design that is both DIN rail & wall-mountable.
...

Connect to, configure & remotely manage an RS232 or RS422/485 serial device over a Wi Fi/wired connection. The NETRS232485W Wireless Serial over IP Device Server lets you remotely access & manage an industrial serial device over a Wi Fi or wired network, with the added benefit of redundant power inputs to prevent downtime in the event of a power surge or failure. To eliminate the hassle of laying additional Ethernet cable, this wireless device server lets you connect your RS232/422/485 serial device in a location where a wired network connection is unavailable, with support for 802.11 B/G Wi Fi connections & a 10/100 Mbps wired network port for added flexibility. Ideal for industrial environments, the serial to Ethernet device server accepts wide-range 12-48V DC power input via a terminal block or an optional DC jack, enabling you to add redundant power with a secondary adapter (e.g. 12V DC 1.5A Power Adapter SKU: IM12D1500P
- sold separately). This device server supports baud rates up to 230.4 Kbps which provides a smooth connection to your serial devices. The server also offers support for HTTPS, SSH & SSL to ensure secure communication, while integrating remote Telnet configuration & support for IP, HTTP, ICMP, DHCP, TCP & UDP protocols. You can customize the serial device server to suit your application with versatile browser-based or virtual com port software configuration. Ensuring performance in harsh environments, this serial device server offers 8KV air, & 4KV contact ESD (Electrostatic Discharge) protection & features a rugged, IP-30 case design that is both DIN rail & wall-mountable.
...

Add a galvanically isolated RS232 serial port with ESD protection through a USB (Universal Serial Bus) port
- DIN Rail Mountable.
...

Add a galvanically isolated RS232 serial port with ESD protection through a USB (Universal Serial Bus) port
- DIN Rail Mountable.
...

The Star Tech.com ISA single port serial expansion card is a high performance serial add-in card providing PC workstations with an additional COM port for the connection of external peripherals. The card supports transfer rates of up to 115.2 Kbps for fast serial data transfer. Jumpers on the card provide complete easy configuration & complete compatibility as a basic COM port for any operating system. ...

The Star Tech.com ISA single port serial expansion card is a high performance serial add-in card providing PC workstations with an additional COM port for the connection of external peripherals. The card supports transfer rates of up to 115.2 Kbps for fast serial data transfer. Jumpers on the card provide complete easy configuration & complete compatibility as a basic COM port for any operating system. ...

The Star Tech.com ISA single port serial expansion card is a high performance serial add-in card providing PC workstations with an additional COM port for the connection of external peripherals. The card supports transfer rates of up to 115.2 Kbps for fast serial data transfer. Jumpers on the card provide complete easy configuration & complete compatibility as a basic COM port for any operating system. ...

Low Profile PCI-Express 16C950 Serial Card. The PEX1S952LP 1 Port Low Profile Native PCI Express RS232 Serial Adapter Card with 16950 UART adds an RS232 (DB9) Serial Port with data rates up to 460 Kbps to a computer through an available low profile PCIe slot, while relying on a native, single-chip design (Oxford OXPCIe 952) that harnesses the capability of true PCI Express
- ensuring maximum performance & reliability & reducing the load applied to the CPU by as much as 48% over conventional (bridge chip) serial cards. The 1 port RS232 serial card features a half-height PCI Express mounting bracket that's designed specifically for low profile/small form factor computer cases, &

Includes:: an optional standard height bracket as well. Compatible with a broad range of operating systems including Windows & Linux for easy integration into mixed environments.


...

Low Profile PCI-Express 16C950 Serial Card. The PEX1S952LP 1 Port Low Profile Native PCI Express RS232 Serial Adapter Card with 16950 UART adds an RS232 (DB9) Serial Port with data rates up to 460 Kbps to a computer through an available low profile PCIe slot, while relying on a native, single-chip design (Oxford OXPCIe 952) that harnesses the capability of true PCI Express
- ensuring maximum performance & reliability & reducing the load applied to the CPU by as much as 48% over conventional (bridge chip) serial cards. The 1 port RS232 serial card features a half-height PCI Express mounting bracket that's designed specifically for low profile/small form factor computer cases, &

Includes:: an optional standard height bracket as well. Compatible with a broad range of operating systems including Windows & Linux for easy integration into mixed environments.


...
