The Star Tech.com PCI Post Diagnostics Card makes troubleshooting PC problems easy. Simply plug the card into a PCI slot on a malfunctioning PC, & the card reports any problems in the form of error codes on its LED display. These codes are then cross-referenced to the enclosed error code chart to pinpoint the cause of the problem. PC technicians & system builders can save hours of troubleshooting time & prevent non-defective parts from being replaced. You may have to refer to your motherboard manufacturers manual for motherboard specific error diagnostic codes. ...

The PCI2S4851050 2-Port PCI Serial Adapter Card (RS422/RS485) with 161050 UART adds two DB9 RS422/RS485 serial ports, using a single PCI expansion slot. The PCI serial card offers a high performance 16C1050 UART & supports both 2-wire & 4-wire RS485 modes. The card delivers an efficient single-chip design & a large 256-byte transit/receive FIFO buffer that work together to provide high-speed serial communication while reducing the overall load on the system CPU. With the included standard & low profile/half-height brackets, this PCI serial expansion card suits a broad range of system form factors, & is a perfect addition for connecting RS422/485 serial devices to a host computer. For added versatility, the RS422/RS485 adapter is able to accommodate 3.3 or 5V PCI/PCI-X slots. ...

Add an internal SATA port & an external SATA (e SATA) port to your desktop computer through a PCI expansion slot. This PCI based SATA Controller Card means that you can turn a PCI slot into one internal SATA & one external SATA (e SATA) connection. Supporting SATA 150 hard drives, & data transfer rates of up to 1.5 Gbps, this controller card is the perfect solution if you need an extra SATA port or want to externalize your storage. ...

Add RS232, RS485, & RS422 support to a PC with a single PCI add-on card. The PCI2S232485I PCI Serial adapter card lets you turn a PCI or PCI-X slot into 2 serial ports capable of communicating in RS-232, RS-422, or RS-485. This universal, all-in-one adapter not only features two DB9 serial ports that can be independently configured, but also supports nearly any configuration: RS-422, RS-485 2-wire, RS-485 4-wire, or RS-232 operating modes. Designed for reliability, this 2-port PCI Serial card also features built-in ESD (Electro-Static Discharge) protection to ensure that connected serial devices remain protected. ...

Add two Serial & two Parallel ports to your desktop system through a single PCI slot. The PCI2S2PMC 2S2P PCI Serial/ Parallel Combo Card (16C1050 UART) adds 2 RS232 serial, & 2 IEEE-1284 Parallel ports to your system, through a PCI slot. Supporting RS232 speeds up to 115.2 Kbps & parallel rates up to 1.5 Mbps, the serial/parallel adapter offers the added connectivity needed for industrial & business applications, while only occupying a single 3.3/5V PCI slot. This 2S-2P card offers a broad operating system compatibility list that

Includes:: Windows? 7, Windows Server 2003, XP, DOS? & Linux, for simple integration into mixed environments.

...

This PCI to Mini PCI Adapter Card lets you install Mini PCI cards (WIFI/ Wireless network, Fast Ethernet etc.) in a standard PCI slot on your desktop computer, saving the cost of duplicate purchases & allowing convenient swapability. The adapter card features a 3.3V regulator that allows the card to be installed in any kind of PCI or PCI-X slot. Plus, the Mini PCI adapter card

Includes:: a metal bracket for convenient mounting within the computer.

...

Install half-height/low profile x 1 PCI Express interface cards in a standard PCI expansion slot. The PCI1PEX1 PCI to PCI Express Adapter card lets you use low profile PCIe expansion cards in a server/desktop motherboard PCI slot. The adapter connects through a 32-bit PCI slot to provide a low profile PCIe x 1 slot in its place; a spare, full size bracket is included for installation in larger desktop or server expansion slots that can accommodate a full-sized card. The PCI to PCI Express Adapter features an innovative bracket design that adapts & secures the low profile PCI Express card into the converted slot, ensuring a versatile & economical solution for extending the usability of older PCI motherboards or using low profile PCIe cards that do not have PCI equivalents. ...

Install half-height/low profile x 1 PCI Express interface cards in a standard PCI expansion slot. The PCI1PEX1 PCI to PCI Express Adapter card lets you use low profile PCIe expansion cards in a server/desktop motherboard PCI slot. The adapter connects through a 32-bit PCI slot to provide a low profile PCIe x 1 slot in its place; a spare, full size bracket is included for installation in larger desktop or server expansion slots that can accommodate a full-sized card. The PCI to PCI Express Adapter features an innovative bracket design that adapts & secures the low profile PCI Express card into the converted slot, ensuring a versatile & economical solution for extending the usability of older PCI motherboards or using low profile PCIe cards that do not have PCI equivalents. ...

Install half-height/low profile x 1 PCI Express interface cards in a standard PCI expansion slot. The PCI1PEX1 PCI to PCI Express Adapter card lets you use low profile PCIe expansion cards in a server/desktop motherboard PCI slot. The adapter connects through a 32-bit PCI slot to provide a low profile PCIe x 1 slot in its place; a spare, full size bracket is included for installation in larger desktop or server expansion slots that can accommodate a full-sized card. The PCI to PCI Express Adapter features an innovative bracket design that adapts & secures the low profile PCI Express card into the converted slot, ensuring a versatile & economical solution for extending the usability of older PCI motherboards or using low profile PCIe cards that do not have PCI equivalents. ...

Add high quality VGA video to your server, POS system or PC through a PCI expansion slot. The PCIVGAV7 16 MB PCI VGA Video Card is the ideal addition to servers, thin clients, POS systems & Industrial PC systems that require a cost-effective, yet high quality graphics solution. The video cards low power consumption design eliminates the need for fan/heatsink video card cooling, making this card the ideal solution for embedded & critical environment applications. Based on the highly optimized memory Architecture of the efficient XGi Volari Z7 chipset, the PCIVGAV7 PCI VGA Video Card supports color depths of up to 16.7 Million colors, & supports 2D Resolutions of up to 1280x 1024 @60 Hz (32-bit) & 1600x 1200 @ 75 Hz (16-bit). ...
