Keep your gutter and water butt free from
blockages with our Blockage Protection Package.
This kit includes a Gutter Mate Diverter & Filter
in Black, one Hedgehog Gutter Brush (4m x100mm)
in Black, a Fine Mesh Insert and a Water Butt
FreshaTank Microbial Disc. The Hedgehog Brush will
keep debris out of your gutters, is easy to
install, resilient and comes with a 10 year
manufacturer's guarantee. The Gutter Mate Diverter
& Filter filters out rubbish before it enters your
water butt. Buying this kit instead of all the
items individually will give you a 5% saving of
£3. Please note: The Gutter Mate Diverter and
Filter is also available in white or brown, so
please contact us directly if you would like
either colour. The Gutter Mate Diverter & Filter
includes: Black Gutter Mate Filter. Square to
round adaptor for Square Downpipes. Blanking Cap
for Diverter outlet, if needed. Hose Adaptor for
Water Butt. Screws and plugs for fitting Gutter
Mate to wall. 500mm of hose to connect Gutter Mate
to water butt or tank. Fixing screws and mounting
bracket.

Recycling and using rainwater in the garden is
easy with this 500L Rainwater Harvesting Package.
This kit includes a Gutter Mate Diverter & Filter
in Black, a 500 Litre Vertical Rainwater Tank, a
GPS-100A 230v Light-Duty Submersible Water Butt
Pump and pump fittings. The pump fittings include
a 2 metre suction and delivery hose, one 25mm
hosetail, two 25-40mm hose clips, a 1 inch BSP
Threaded Socket and a 1 inch BSP Tank Adaptor.
You'll be able to collect and use your recycled
rainwater all at the same time with this package.
Buying this kit instead of all the items
individually will give you a 5% saving of £20.
Please note: The Gutter Mate Diverter and Filter
is also available in white or brown, so please
contact us directly if you would like either
colour. The Gutter Mate Diverter & Filter
includes: Black Gutter Mate Filter. Square to
round adaptor for Square Downpipes. Blanking Cap
for Diverter outlet, if needed. Hose Adaptor for
Water Butt. Screws and plugs for fitting Gutter
Mate to wall. 500mm of hose to connect Gutter Mate
to water butt or tank. Fixing screws and mounting
bracket. Water Tank Technical Spec: Height: 930mm
Length: 1000mm Width: 630mm Weight: 27kg Capacity:
500 Litres Outlet: 1" BSP Lid: 8" Screwdown Pump
Technical Spec: Manual/Auto: Automatic Outlet
(mm): 19 & 25 kW: 0.1 Volt: 230V Flow (l/min): 70
Head (metres): 6 Free passage (mm): 3 Width (mm):
134 Length (mm): 155 Height (mm): 250 Dry weight
(kg): 2.8 Packing weight: 3.70

Keep all of your gutters and water butt free from
blockages with our 4 Brush Blockage Protection
Package. This kit includes a Gutter Mate Diverter
& Filter in Black, four Hedgehog Gutter Brushes
(4m x100mm) in Black, a Fine Mesh Insert and a
Water Butt FreshaTank Microbial Disc. The Hedgehog
Brushes will keep debris out of your gutters, are
easy to install, resilient and come with a 10
year manufacturer's guarantee. The Gutter Mate
Diverter & Filter filters out rubbish before it
enters your water butt. Buying this kit instead of
all the items individually will give you a 5%
saving of £5. Please note: The Gutter Mate
Diverter and Filter is also available in white or
brown, so please contact us directly if you would
like either colour. The Gutter Mate Diverter &
Filter includes: Black Gutter Mate Filter. Square
to round adaptor for Square Downpipes. Blanking
Cap for Diverter outlet, if needed. Hose Adaptor
for Water Butt. Screws and plugs for fitting
Gutter Mate to wall. 500mm of hose to connect
Gutter Mate to water butt or tank. Fixing screws
and mounting bracket.

How the Loft Gravity Feed System works Rainwater
falls onto the roof, down the down pipes, across
the Gutter Mate rainwater filter and into a water
storage tank, usually a below ground tank. When
demanded the rain water is pumped from the
underground tank through the control panel up to
the Smart Header Tank within the loft space. The
rainwater inside the Smart Header Tank will
gravity feed down to toilets and washing machines,
until the Smart Header Tank is nearly empty.
Inside the Smart Header Tank there are two
sensors, upper and lower. When the water level
drops to the lower sensor a message is sent to the
control panel to allow rainwater to enter the
Smart Header Tank. Rainwater will then fill the
Smart Header Tank until it reaches the upper
sensor. The pump will then shut down and not run
again until the water reaches the lower sensor.
The control unit automatically registers when
rainwater is not available and fills the Smart
Header Tank with mains water. This means that only
a minimum amount of water is used until the next
rainfall. Also if the water within the Smart
Header Tank is left unused the system will
automatically refresh the water every three days
to protect against any issues with water quality.
This loft gravity kit contains: a header tank and
pump.   This kit contains: Smart Header Tank: 100
litres capacity. 600mm (W) x 490mm (H) x 500mm (D)
Loft Gravity Feed: 380mm (W) x 270mm (H) x 95mm
(D) Submersible pump: to fit in your underground
storage tank Benefits: Constant water pressure Low
Energy Consumption Mains water backup Longer pump
life Simple operation More control

The Series 3 Submersible Rainwater Tank Pump is a
submersible pressure sensitive rainwater tank pump
- electronically controlled, centrifugal pump.
Built-in non-return valve and double dry-run
protection. Designed for rainwater harvesting
systems. The pump features a self-controlling
pressure switch dry run protection and a
non-return valve. It is suitable for total
immersion in tank water or it can be externally
connected to the tank above ground. The Series 3
will deliver up to 3.5 bar (household pressure is
around 2.5-4.0 bar). If connected to a hose or
tap, the pump will automatically start to pump
water when the tap or hose is turned on. The pump
delivers over 2500 litres per hour using a 1"
connector and uses 800 watts at 220-240v AC
delivered by a 10 metre cable. The pump is stable
on the floor of a water tank. The pump and
electrics are totally new, engineered to give
more reliable underwater performance. Now an alloy
bulkhead, pressure release gap and twin chamber
design prevent ingress of water to motor,
electrical components and to bearing oil. At the
factory each pump is tested individually, pumping
water through a pre-determined cycle to ensure
performance is to spec, and the performance of
each pump is automatically logged against its bar
code number to assure the client of its quality.
  The Series 3 is an electronically-controlled,
pressure-sensitive, submersible, centrifugal
pump.1. Pressure-sensitive (demand) pump switches
on and runs when there is a demand for water.2.
Max head (nominal) 35 metres, pump pressure
(nominal) at outlet 3.5 bar, max. suction 3
metres3. Dry-run Protection: when no water is
detected for 8 seconds, the pump is turned off by
the printed circuit board (PCB) in order to
protect the motor and pump from burning out.
Automatic reset after a period of 30 minutes. If
water is still not detected, subsequentreset
periods are 1.5 hours, 3 hours, 7 hours, 12
hours, 24 hours then back to the beginning of the
cycle. Additionally, a thermal switch, not
connected to the PCB, turns the pump off if motor
overheats. It resets when cool which make take
several hours.4. New: Alloy bulkhead, pressure
release gap and twin chamber design prevents
ingress of water to motor, electrical components
and to bearing oil.5. New: Double bearing seal
prevents egress of bearing oil.6. New: Alloy
bulkhead dissipates motor heat to water in the
second chamber.7. New: Logic processors in PCB
prevent other pump anomalies and permit factory
programming of reset timings.8. New: Inlet
strainer and output pipe connector are
factory-fitted and the seals tested to ensure
proper running of the pump.9. Guaranteed for 2
years.10. Electricity consumption 800 watts at
220-240 Volts AC 50 Hz (requires 10 or 13 amp fuse
and RCD mains socket). Connection cable 10m
H07RN-F.11. Inlet port to the non-removable filter
1 inch (25mm) female BSP. Output port 1 inch
(25mm) female BSP provided with push-fit connector
for 1 inch (25mm) MDPE pipe (1 ¼ inch (32mm)
connector option by special order).12. Dimensions
L 565 W 185 H 260 mm, weight 13.1 kgs * please
note does not include the inline filter

Slash your water bill with this 3P Technik Garden
Steelpump which is a heavy duty and industrial
standard water pump designed for domestic
applications. You'll be able to enjoy the pressure
and convenience of mains water while using free
rainwater with this reliable pump, which comes
with a two-year guarantee and an NRV (non-return
valve) as standard. Simply connect a hose or tap
to the pump and it will run when you open the tap
and automatically shut off when you close it, so
there is no need to run and switch the pump off.
The pump can supply water at 4 bar of pressure
allowing it to push water uphill as high as 40
metres. Using the pump, the flow rate through a
1/2 inch hosepipe is similar to mains water.
Please note: This pump is only suitable for
filtered water so only use with good quality
rainwater tanks which have had the water
pre-filtered on entry, for example by using a
filter-collector such as the one sold with our
rank tank systems. Pump technical details: Power
rating: 600W Weight: 15kg Maximum flow rate: 3,
000 litres/ hour Supply voltage: 230/240V Water
resistance: IP68 (it is submersible) Power cable:
10 metres in length Inlet: 1" Female BSP Outlet:
1.25" Female BSP Dimensions: Length: 477mm Width:
200mm Height: 226mm
